MINIMALIST MK2 OVERHEAD SHOWER

Installation Guide

Technical Speciﬁcations:

Operating Pressure:

Min: 150kPa/1.5bar - 500kPa/5bar

Max: 1000kPa/10bar*

Optimum: 150kPa/1.5bar - 500kPa/5bar

Operating Temperature:

Hot: Max 60°C*

Cold: Min 5°C

Inlet Connections:

All ½" BSP

* Regional speciﬁc regulations apply.

Please refer to your warranty statement at

www.methven.com

•

IMPORTANT: Please read all of the instructions before installation.

GENERAL:

•

This product must be installed in

compliance with all relevant regional

regulations.

It is the responsibility of the installer to

ensure a watertight seal is achieved.

All outlets used primarily for personal

hygiene shall deliver water at a safe

temperature as per regional regulations.

Where a Hand Shower and/or Overhead Shower is ﬁtted with a ﬂow regulator the lower ﬂow rate

may not be suitable for the connection to some gravity fed Water Heaters, low pressure supply

networks, Instantaneous Water Heaters, Tempering Valves, Solar Water Heaters & Thermostatic

Mixing Valves. Check with the manufacturers of these products.

Where showers incorporate ﬂow controllers, care must be exercised during installation to ensure

that the male connecting threads do not damage the ﬂow controllers.

NOTE: Use plumbers tape or similar on ¹⁄₂"

male threaded connection to ensure a

reliable seal.

CARE AND CLEANING:

• Never use abrasives or abrasive cleaning agents to clean this product. To clean the chrome-plated

surface use contamination free warm soapy water and a damp soft cloth.

• Lime deposits can be prevented from forming on the faceplate by wiping immediately after use. If

shower performance is compromised by the build-up of lime-scale, soak in limescale remover for up

to 10 minutes. Do not attempt to remove limescale with sharp objects or abrasives. Do not use

products containing chlorine bleach or hydrochloric acid as these can damage the shower. Always

rinse the shower thoroughly after cleaning to remove cleaning products that can damage the shower.

• Clean face plate using a brush with soft bristles.

• Do not use any sharp objects to clean nozzles.

• Clean ﬁlter washer located in the ball joint periodically.

Overhead Shower

Filter Washer

Arm

(If Supplied)

Trim Ring

Min 10mm

Max Ø 25mm

Methven warrants this product against manufacturing defects and that it is suitable for use

under the general operating conditions speciﬁed in this instruction sheet. However, regional

regulations apply and may aﬀect your warranty. Please refer to www.methven.com or call

customer service for full details.

New Zealand

0800 804 222

Australia

13 14 16

0800 195 1602

IS  ISSUE A
