Microtek 515C Bedienungsanleitung

USER'S MANUAL

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that

may cause undesired operation.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to

provide reasonable protection against harmful interference in a residential

installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution:

To comply with the limits for an FCC Class B computing device, always use the

shielded signal cord supplied with this unit.

The Federal Communications Commission warns that changes or modifications of

the unit not expressly approved by the party responsible for compliance could void

the user’s authority to operate the equipment.

CE mark for Class B ITE (Following European standard EN55022/

1998; EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998,

EN60950/1992+A1+A2+A3+A4+A11)

P/N: 219-20-990232

Radio Frequency Interference Statement

Warning:

This is a Class B product. In a domestic environment, this product may cause radio

interference in which case the user may be required to take adequate measures.

Canadian Doc Notice

For Class B Computing Devices

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus as set out in the Radio Interference Regulation of the

Canadian Department of Communications.

“Le présent appareil numérique n’èmet pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la class B prescrites dans le

Règlement sur le brouillage radioélectrique édicté par le ministère des

Communications du Canada.”

Energy Star Notice

As an ENERGY STAR Partner, Microtek International, Inc. has

determined that this monitor meets the ENERGY STAR

guidelines for energy efficiency.

iii

Table of Contents

Introduction 1

Product Features.................................................................... 1

Unpacking .............................................................................. 1

Precautions ............................................................................ 2

Cleaning ................................................................................. 3

Installation 4

Installing the Monitor............................................................ 4

Connecting the Monitor ........................................................ 5

Operating the Monitor 6

How to Use the OSD ............................................................. 6

Operating Procedure ....................................................... 6

Adjusting Monitor Display .................................................... 7

AutoAdjustment ............................................................. 7

ManualAdjustment ......................................................... 7

OSDAdjustment Lock ..................................................... 8

The MenuTable ..................................................................... 9

Appendixes

A: Specifications ................................................................. 10

B: SupportedTiming ........................................................... 11

C:Troubleshooting .............................................................. 12

D: Power Management ........................................................ 14

E: ForYour Safety ................................................................ 15

Introduction

Congratulations on the purchase of your new Microtek LCD

monitor! Providing a maximum resolution of 1024 x 768 pixels

with a flicker-free display at up to 75Hz refresh rate, your LCD

monitor offers sharp and vibrant color display without the

radiation emission and hazards associated with CRT monitors.

Product Features

• 15.0”TFT active matrix color crystal displays

• Supports XGA resolution of 1024 x 768 pixels

• Wide viewing angle

• Wide tilting angle

• VESA PMS-compliant power saving:Automatically powers

down the monitor after a defined period of inactivity

• Digital character smoothing

• Automatic setup

• Ergonomic design:TCO approved

• Compatible withWindows and Macintosh

• Easy-to-use OSD (On-Screen Display)

• Plug & Play: Conforms to VESA standards and supports

DDC1/2B specifications

• Multiscan functions of XGA 1024 x 768, SVGA 800 x 600,VGA

640 x 480, 720 x400, and 640 x 350 for a perfect graphics

performance

• Extra-slim design to maximize your desk space

Unpacking

Before unpacking your LCD monitor, prepare a stable, level, and

clean surface near a wall outlet for your LCD monitor.

1. Set the LCD monitor box in an upright position and open

from the top of the box before removing the right/left

cushions.

2. Check to see that you have the following accessories shown

below:

Note: Remember to save your original box and packaging

material in case you need to transport or ship the monitor.

Precautions

• Read all of these warnings and save the manual for later use.

• Follow all warnings and instructions on the product.

• Do not cover or block the vent holes in the case.

• Do not insert sharp objects or spill liquid into the LCD

monitor through the cabinet slots; this may cause accidental

fire, electric shock or failure.

• Disconnect the power plug from the AC outlet if you are not

going to use the monitor for an extended period of time.

• Do not attempt to service this product yourself, as opening or

removing the cover may expose you to dangerous voltage

points or other risks.

• Do not touch the screen directly with your fingers as you may

damage the screen, and oil from your skin is difficult to

remove.

User's Manual

VGA Cable

(Built-in)

AC/DC Adapter Power Cord User’s Manual

• Do not apply pressure to the screen, as the screen is very

delicate.

• Keep the monitor away from extremely hot, cold or humid

places.

• Do not place the monitor directly under sunlight, in dusty

surroundings, or near equipment which may generate strong

magnetic fields.

Cleaning

Warning:

If you drop any material or liquid such as water onto the

monitor when cleaning, unplug the power cable immediately

and contact your dealer or the nearest service center. Always

make sure your hands are dry when unplugging the power

cable.

Caution:

• For safety reasons, turn off the power switch and unplug the

monitor before cleaning.

• Do not scratch or rub the screen with a hard object.

• Never use any of the following solvents on the LCD monitor:

Thinner; spray-type cleaners; benzene; wax; abrasive

cleaners; and acid or alkaline solvents. Such harsh chemicals

may cause damage to the cabinet and the LCD screen.

• Rubbing the cabinet with products made of rubber or plastic

for prolonged periods may cause degeneration or loss of

paint on the cabinet.

Cabinet

• Remove dirt with a lightly moistened cloth and a mild solvent

detergent.Then wipe the cabinet with a soft dry cloth.

LCD

• Periodic cleaning with a soft dry cloth is recommended.

• Do not use tissue to clean the screen, as this may damage the

LCD screen.

Installation

Installing the Monitor

• DO NOT install the monitor where sudden temperature

changes may occur, or in humid, dusty, or smoky areas as

fire, electric shock or damage may ensue.

• DO NOT place your LCD monitor near a window as it may be

severely damaged if exposed to rain, water, moisture, or

sunlight.

• MAINTAIN good ventilation; covering of ventilation slots or

holes may cause fire.

• PLACE the monitor at least 4 inches (or 10 cm) away from the

walls

• SAFE storage temperature of the LCD monitor is in a range of

–4ºF to +149ºF (-20ºC to +65ºC).

Connecting the Monitor

Warning: Do not operate the LCD monitor with unspecified

power supply. Usage of incorrect voltage will cause

malfunction and may cause fire or electric shock.

1. Turn off your computer and LCD monitor.

2. Use theVGA cable to connect theVGA connector of the LCD

monitor to theVGA port of the computer. Make sure the

cables are securely connected.

3. Plug the DC connector of the adapter to your monitor’s DC

jack.

4. Plug the female end of the power cord into the AC adapter.

5. Connect the male end of the power cord into a wall socket.

6. Turn on your computer, and then turn on your LCD monitor.

VGA Cable:

Connect with VGA

cable.

Power:

Plug into the AC

power adapter.

Note: For added protection, the use of a Surge Protection

device is recommended.The Surge Protection device should be

installed between the AC Adapter and the electrical wall outlet to

prevent the effects of sudden current variations from reaching

and damaging the LCD monitor.

VGA cable

AC/DC Adapter

Power cord
