INSTALLATION & OPERATION MANUAL 10130 REV 4 (10/22)
PAGE 6 OF 24
UNPACKING
IMMEDIATELY INSPECT FOR SHIPPING DAMAGE
Immediately after unpacking, check for possible shipping damage. If the tilting braising pan is found to be damaged,
save the packaging material and contact the carrier within 15 days of delivery.
side panel as you face the front of the braising pan. If the supply and equipment requirements do not agree, contact
The installation location must allow adequate clearances for servicing and proper operation.
A minimum front clearance of 36” and rear clearance of 4” is required.
I C
Your Crown Tilting Braising Pan must be installed in accordance with:
edition).
Electrical grounding must be provided in accordance with local codes, or in the absence of local codes, with the National
for Ventilation and Fire Protection of Commercial Cooking Operations.
1. Place tilting braising pan in the installation position.
2. Place a carpenter’s level on top of the braising pan and turn the adjustable feet to level braising pan side-to-side and
front-to-back.
Diagram on page 4.) Insert proper anchoring devices (not supplied).
5. Place tilting braising pan back in the installation position.
6. Place carpenter’s level on top of braising pan and re-level side-to-side and front-to-back.
