QUICK USER GUIDE
Please read the main content in the instruction manual for detailed operating
method.
Connected to power supplies
or
Connect the drain pipe with the back pipe of the machine.The
interface is fitted with clamps and tightened with a screwdriver.
Fix the drain pipe with
suction cups
The connection of the drain pipe: Put end of the drain hose into a sink or bucket.
Add water into the dishwasher’s tank
There are two ways of checking the tank is full of water
1. Before starting:
When the water tank is full, the machine will beep
for 3 seconds.
2. After starting:
If water is not enough, light is on;
When the water tank is full the machine will beep for 3 seconds.
Remove the larger residue
Scrape off excess food before placing the dishes in the dishwasher.
The power supply is 220-240VAC 50 Hz
the specification of the socket is 10 A 250 VAC
There are two ways to add water into the tank:
or
1
2
1
2
Connect inlet hose to the tap or,
Open the cap and add water into the dishwasher’s
tank manually
Note: Before adding water, you need to press power
button to turn on the diswasher
Close the door, select the program and start the dishwasher
Open the door, placing the dishes and adding detergent
Place large items on the sides and small items in the middle for optimal
cleaning performance. All cutlery should be placed in cutlery basket.
Left Right
Pull open
The place to add the detergent
NB: Do not add detergent when selecting Fruit Program!
CONTENTS
Please carefully read this manual before using the dishwasher, it will help you
use and maintain the dishwasher properly .
IMPORTANT SAFETY INSTRUCTIONS
5
INSTALLATION INSTRUCTION
25
Installation preparation
Power connection
Water connection
Connection of drain hoses
26
27
26
25
28
31
TROUBLESHOOTING TIPS
Before calling for service
Error codes
Technical information
32
GETTING TO KNOW YOUR APPLIANCE
Dishwasher features
Control panel
10
10
11
USING YOUR DISHWASHER
Loading the dishwasher baskets
Filling the dispenser
15
12
12
17
18
18
PROGRAMMING THE DISHWASHER
Wash cycle table
Turning on the appliance
Change the programme
Forget to add a dish?
At the end of the wash cycle
Forced drainage operation
20
19
MAINTENANCE AND CLEANING
Filter system
Caring for the dishwasher
How to keep your dishwasher in shape
21
21
22
17
28
20
24
IMPORTANT SAFETY INSTRUCTIONS
WARNING
When using your dishwasher, follow the
precautions listed below:
This appliance is intended to be used in households
and similar applications such as:
-staff kitchen areas in shops, offices and other
working environments;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
Caravans and RV Recreational vehicles and Motor
Homes.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.(For AS/NZS 2007.1)
This appliance is not intended for use by
persons (including children) with reduced physical,
sensory or mental capabilities, or lack of
5
Earthing instructions
experienceand knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
(For IEC60335-1)
This appliance is for indoor use only, household and
mobile home use only.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other
liquid.
Please unplug before cleaning and maintaining the
appliance.
Use a soft cloth moisten with mild soap, and then use
a dry cloth to wipe it again.
This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will
an
equipment-
earthing conductor and a earthing plug.
The plug must be plugged into an appropriate
earth
with all local codes and ordinances.
reduce the
risk of electric shock by providing a path of least
resistance of electric current. This appliance is
equipped with a cord having an
outlet that is installed and ed in accordance
6
General use
Do not modify the plug provided with the
appliance, if it does not fit the outlet. Have a proper
outlet installed by a qualified electrician.
Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly earthed.
Do not abuse, sit on, or stand on the door or dish rack
of the dishwasher.
Do not operate your dishwasher unless all enclosure
panels are properly in place.
Open the door very carefully if the dishwasher is
running, there is a risk of water splashing out.
Do not place any heavy objects on or stand on the
door when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2) Knives and other utensils with sharp
points must be loaded in the basket with their
points down or placed in a horizontal position.
Check that the detergent powder is empty after
completion of the wash cycle.
Warning:
7
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
without mark, check the manufacturer's
recommendations.
Use only detergent additives designed for an
automatic dishwasher.
Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
Children should be supervised to ensure that they do
not play with the appliance.
The door should not be left open.
If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
During installation, the power supply must not be
excessively or dangerously bent or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should
not be reused.
The maximum number of place settings to be
washed is 3.
The maximum permissible inlet water pressure is
1MPa.
The minimum permissible inlet water pressure is
0.04MPa.
8
Disposal
For disposal of package and the
appliance, please go to a recycling
centre. Therefore cut off the power
cord and close the door.
Cardboard packaging is manufactured from
recycled paper and should be disposed in the waste
paper collection for recycling.
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product.
For more detailed information about recycling of
this product, please contact your local city office
and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted
municipal waste. Collection of such waste
separately for special treatment is necessary.
9
GETTING TO KNOW YOUR APPLIANCE
IMPORTANT:
Before using this dishwasher for the first time and to get the best performance,
read these instructions.
Dishwasher features
Handle
Control panel
Kick board
Water jug
Cap of water tank
Upper spray arm
Filter
Basket
Tableware basket
The place to
add detergent
Lower spray arm
10
