Midea FlashChef G1 Bedienungsanleitung

Commercial

High Speed Oven

QUICK START GUIDE

208/240V~ 60Hz, 6000W

HIGH SPEED

OVEN “QUICK-START” GUIDE

Start up screen will appear

(Swirl and Midea Logo with Music)

Place desired Accessory(ies)

in the cavity.

To turn on the oven,

Press and Hold the Start button

on the front panel (2 Sec)

PreHeat screen will appear – tap

desired pre-heat temp（Example: 500F）

When 100% is reached, this screen will appear. Oven is now preheated. Press "Start"

Screen will show PreHeat progress

by % completed. Times: (300F – 6:00,

400F – 9:45, 500F – 15:00)

The “Recents” home screen will display.

Time - 00:50

MW Power - 60%

Fan Speed - 90%

EXAMPLE: To Cook/Programme the HSO

oven to heat an 8” Sub Sandwich with

Meat & Cheese: Temperature: 495F

Press the “Chef Cook” icon in the middle

of the left of the screen.

In the Top Right corner, press the TEMP

down Caret ( )

a.Press “Input the PWD” (Password)

on the screen

b.Keyboard will appear to enter PWD

(ﬂashtune or Password depending on

version)

c.Press “Check” icon on the keyboard

(to “enter”)

i.(PWD was set when the oven was

1st plugged in (new))

Cooking/Programming Function

Screen will appear.

13 "Now Press "time" for the 1st stage"

Time - 00:50

MW Power - 60%

Fan Speed - 90%

3 Control Slides will appear – Set to:

Tap or Slide TEMP Control bar to

desired Temperature. "Use the +1

or -1 for small adjustments"

In the Top Right corner, press the

TEMP UP Caret (▲) 495 is nowset

Press “Input Recipe Name”, Keyboard

will appear

Type “Sandwiches” and press “Check”

(Enter)

Enter the name of the Recipe and

press “check” to enter.

Add Category

Follow Steps 1 - 7 to simply cook the sandwich you just entered.

Temperature: 495F

Time - 00:50

MW Power - 60%

Fan Speed - 90%

Note: the “Space Bar” is along the bottom of the keyboard – it says

“English” on it.

Edit recipes and categories with the

FlashTune program on your PC.

When ﬁnished, "Drag and Drop" the

saved ﬁle on to the USB drive you

are using. Using "Save As" on the

program will work to save it on the

PC but not to the USB - must be

copied to the USB from the folder.

Save the recipes on to the pc

To Upload the recipes:

1. Drag and Drop the saved recipe ﬁle (.db) to the USB Memory Device

2. Press the "Setting" icon ( )

3. Press "User Settings"

4. Input the password by pressing that area of the screen - the keyboard

will appear and type "ﬂashtune" - then press the small "check" mark on

the keyboard to enter.

5. Press the USB window on the screen

6. Insert the USB into the port on the front right side of the oven.

(contact on the USB drive should be oriented towards the operator)

7. Wait for the area next to "Recipes Upload" "Recipes Download" and

"Firmware Update" to populate with "DISK_IMG".

7. Press "Recipes Upload"

8. Select the folder

9. If successful, folder will now show a circled "check mark" in the center.

10. Press the recipes icon and uploaded recipes will appear.

Don’t "Save As" the recipe directly into USB, simply save it on to the PC

and drag it into your USB to upload
