OWNER’S MANUAL

Washing Machine

Read This Manual

the installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

product is sold or passed on, ensure

that the new owner always receives this

manual.

This manual is for reference only, the

factory specifications shall prevail.

Use all instructions and explanations for

MJ70N68P

CONTENTS

SAFETY INSTRUCTIONS

Safety instructions ................................................. ....

INSTALLATION

Product description .............................................. .....

Unpacking the washing machine ..............................

Levelling the washing machine ..................................

Selection of tap .................................................... ......

Connection of inlet hose, tap and washing machine...

Preparation before washing.......................................

Washing .......................................................... ...........

After washing................................................. .............

Washing matters needing attention ...........................

The usage of detergent and washing powder.............

Control panel .............................................................

Option............................................................ .............

Personalized setting of washing program...................

Operations of washing process....................................

Washing program table .............................. ................

MAINTENANCE

Cleaning and care .............................................. ........

Cleaning the cabinet............................................ ........

Trouble shooting..................................................... .....

Technical ...................................... ........specifications .

OPERATIONS

Accessories..................................................................

....................... ... ..Installation of drain hose ...... ......... 9

Cleaning the inlet filter..................................... 17

Installation area ................................................. .......

Packing of the washing machine........................

Installation of the cabinet base cover..................

SAFETY INSTRUCTIONS

For your safety, the information in this manual must be followed

to minimize the risk of fire, explosion, electric shock and to

prevent property damage, personal injury or loss of life. Failing to

Safety instructions

follow these instructions shall void any warranty.

SAFETY INSTRUCTIONS

•

• The openings must not be obstructed by a carpet.

• This appliance is intended to be used in household and similar

applications such as:

− staff kitchen areas in shops, offices and other working environments;

− farm houses;

− by clients in hotels, motels and other residential type environments;

− areas for communal use in blocks of flats.

Children should be supervised that they do not play with the

appliance.

The new hose-sets supplied with the appliance are to be

used and that old hose-sets should not be reused.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons

in order to avoid a hazard.

•

This appliance is not intended for use by persons(including

aged from 8 years old or above)with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

• The appliance can be used by children aged

and persons with reduced physical,

mental capabilities or lack of experience and

if they have been given supervision or instruction

use of the appliance in a safe way and understand

involved. Children shall not play with the appliance.

and user maintenance shall not be made by children

supervision.

• Animals and children may climb into the machine. Check the

machine before every operation.

from 8 years

and above sensory or

knowledge

concerning

the hazards

Cleaning

without

SAFETY INSTRUCTIONS

Risk to children!

Warning!

The electric shock!

•

• Do not put washing machine at humid place.

• Hands shall not be inserted into running drum .

• If the drum does not stop within 15 seconds after opening

the cover , please stop using the machine and have it repaired.

• Before any maintenance, unplug the appliance from the

mains.

• Always unplug the machine and turn off the water supply

after use.

• To ensure your safety, power plug must be inserted into

an earthed three-pole socket. Check carefully and make sure

that your socket is properly and reliably earthed.

• Make sure that the water and electrical devices must be

connected by a qualified technician in accordance with the

manufacturer's instructions and HongKong safety regulations.

This appliance is for indoor use only.

• The openings must not be obstructed by a carpet.

• Washing machine shall not be installed in bathroom or very wet

rooms, as well as in the rooms with explosive or caustic gases.

• Remove all packages before using the appliance. Otherwise,

serious damage may be resulted.

• The washing machine can be

• Plug must be accessible after installation.

• The machine isn't intended to be built-in installation.

connected to the cold water

supply only.

Risk of damaging appliance!

SAFETY INSTRUCTIONS

Caution

Installing the product!

• Your product is only for home use and is only designed

for the textiles suitable for machine washing.

• Do not climb up and sit on top cover of the machine.

• Do not lean against machine door.

Risk of explosion!

•

in, soaked in, or dabbed with combustible or explosive substances

( such as wax, oil, paint, gasoline, degreasers, dry-cleaning

solvents, kerosene, etc.) This may result in fire or explosion.

• Articles stained with combustible or explosive substances

should be washed thoroughly by hand before placing into the

washing machine.

Do not wash articles that have been cleaned in, washed

Operating the appliance!

• Before washing the clothes at the first time, the product

operated once throughout all the procedures without any

clothes inside.

• Flammable and explosive or toxic solvents are forbidden.

Gasoline and alcohol etc. shall not be used as detergents.

Please only select detergents which suitable for machine washing,

especially for drum.

• Make sure that all clothing pockets are emptied. Sharp and

rigid items such as coin, brooch, nail, screw or stone etc.

may cause

• Please check whether the water inside the drum has been

drained before opening its door. Please do not open the door

if there is any water remained.

• Never refill water by hand during washing.

• After the program is completed, please wait for two minutes to

open the door.

shall

serious damages to this machine.

1.The remained water shall be drained out of the machine.

2.Handle the machine carefully. Never hold each protruded

part on the machine while lifting. Machine door cannot

be used as the handle during the conveyance.

3.This appliance is heavy. Transport with care.

• Please do not close the door with excessive forces.

SAFETY INSTRUCTIONS

Cautions during Handling the machine

Packaging/Old appliance

INSTALLATION

Product description

• The product line chart is for reference only, please refer to real product as

standard.

Note!

Accessories

Drain loose accessories

Inlet hose accessories Manual Screw

Cabinet baseboard

• If the drain hose is already installed on the machine, then there is no

spring clamp and drain hose in the accessories.

Note!

Frame

Top cover

Drain hose

Handle

Power cord and plug

Control panel

Cabinet

Adjustable foot knob

Water inlet valve

Installation area

Before installing the machine, the location characterized

follows shall be selected:

1.Rigid, dry, and level surface

2.Avoid direct sunlight

3.Sufficient ventilation

4.Room temperature is above 0 C

5.Keep far away from the heat resources.

Unpacking the washing machine

1. Remove the cardboard box and styrofoam packing.

2. Lift the washing machine and remove the base packing.

3. Remove the tape securing the power supply cord and drain hose.

4. Remove the inlet hose from the drum.

•

Stability is important to prevent the product from

wandering!

Make sure that the product should not stand on

the power cord.

Warning!

• dangerous for children.

• well away from children.

Packaging materials (e.g. Films, Styrofoam) can be

There is a risk of suffocation ! Keep all packaging

Warning!

INSTALLATION

W> 20mm L> 45mm

Packing of the washing machine

•

• Position drain hose properly ,otherwise damage might be resulted due to

water leakage.

Do not kink or protract the drain hose.

• If drain hose is too long, do not force it into washing machine as it will cause

abnormal noises.

Trough

Hose

Retainer

Bind

Min.86cm

Max.100cm

Warning!Warning!

Min.86cm

100cm

Max.

1.Check if the legs are tightly attached

the cabinet. If not, please turn them to

their original positions tighten the nuts.

2.Check alignment of the product with a

spirit level and correct the level if

3.Loosen the lock nut and turn the feet

until it contacts with

required

tightly the floor.

4.After being locked properly, press four

corners again to make sure that they have

been adjusted properly.

• The lock nuts on all four feet must be screwed tightly against the housing.

Levelling the washing machine

Warning!

INSTALLATION

Lock nut Foot

Right

Wrong

Raise Lower

Lock

Loosen

Installation of drain hose

Installation of the cabinet base cover

Lean the washing machine backward at a specific angle,

then insert the cabinet base cover into washing machine

base trough, push it to the end.

Fix the cabinet base cover and cabinet base with all screws

coming with the machine.

Soft fabric

Cabinet

base cover

Running the machine or washing while placing on

the base styrofoam packing is strictly forbidden

Inhaltsverzeichnis

Andere Midea Waschmaschine Handbücher

Midea

Midea MFL80-DU1403B/C14E-EU Bedienungsanleitung

Midea

Midea MF200W80WB Series Bedienungsanleitung

Midea

Midea X8 Bedienungsanleitung

Midea

Midea RW145 Bedienungsanleitung

Midea

Midea MFW-701S Bedienungsanleitung

Midea

Midea MA100W70/G-MV Bedienungsanleitung

Midea

Midea MF200W85B Series Bedienungsanleitung

Midea

Midea FP-90LTL060GETL-N Bedienungsanleitung

Midea

Midea MF700S Bedienungsanleitung

Midea

Midea MF20EW70WB Bedienungsanleitung

Midea

Midea MLH27N5AWWC Handbuch

Midea

Midea MFL80-ES1200 Bedienungsanleitung

Midea

Midea MFW-752S Bedienungsanleitung

Midea

Midea MFL80S14 Bedienungsanleitung

Midea

Midea MF200W90WB Series Bedienungsanleitung

Midea

Midea MAC160-S2802TPS/FM Bedienungsanleitung

Midea

Midea MFN75-S1403/C31E-AU(25) Bedienungsanleitung

Midea

Midea FP-90LTT060GMTM-B Bedienungsanleitung

Midea

Midea MT700W Bedienungsanleitung

Midea

Midea LUNAR 01 Bedienungsanleitung

Midea

Midea MAV10-A2804PS/01FM-US Bedienungsanleitung

Midea

Midea MFW-1255CV Bedienungsanleitung

Midea

Midea Sicily Glory G01 Bedienungsanleitung

Midea

Midea MTWR45 Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Electrolux

Electrolux EWF1284EDW Bedienungsanleitung

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung
