MINUSWIRE MW-1000Pro Bedienungsanleitung
MW-1000Pro
Dongguan Kantsang Electroacoustic Technology Co., Ltd.
Address: No.8, Lu Yi Yi Road, Tangxia, Dongguan, China
MANUFACTURER
Support contact:
E-mail: [email protected]
MADE IN CHINA
www.minuswire.com
MODEL: MW-1000Pro
TRUE WIRELESS STEREO EARBUDS
User Guide
FCC ID: PAZMW-1000PRO
CONTENTS
English
Deutsch
Français
Español
Italiano
日本語
01-11
12-23
24-36
37-49
50-61
62-72
PACKAGE CONTENTS (Fig. 1)
①
②
③
④
⑤
EN
DE
FR
ES
IT
JP
MINUSWIRE True Wireless Stereo Earbuds (MW-1000Pro)
6 x Ear Tips (two are equipped on the earbuds)
1 x USB Charging Cable
1 x User Manual
1 x Quick Start Guide
①
②
③
④
⑤
MINUSWIRE True Wireless Stereo-Kopfhörer (MW-1000Pro)
6 x Ohrstöpsel (zwei sind bereits an den Ohrhörern angebracht)
1 x USB-Ladekabel
1 x Bedienungsanleitung
1 x Schnellstart-Anleitung
①
②
③
④
⑤
MINUSWIRE Écouteurs Bluetooth Sans Fil (MW-1000Pro)
6 x Embouts d’Oreillette (deux sont déjà installés sur les écouteurs)
1 x Câble de Charge USB
1 x Manuel de l'Utilisateur
1 x Guide de Démarrage Rapide
①
②
③
④
⑤
Auriculares Inalámbricos Estéreo MINUSWIRE (MW-1000Pro)
6 x Puntas de Goma para Oídos (dos están equipados en los auriculares)
1 x Cable de Carga USB
1 x Manual de Usuario
1 x Guía de Inicio Rápido
①
②
③
④
⑤
Auricolari Stereo True Wireless Stereo MINUSWIRE (MW-1000Pro)
6 Puntali Auricolari (due già montati sugli auricolari)
1 x Cavo di Ricarica USB
1 x Manuale Utente
1 x Manuale di Avvio Rapido
①
②
③
④
⑤
MINUSWIRE完全ワイヤレスステレオイヤホン(MW-1000Pro)
6xイヤーチップ（2つは設置済み）
1xUSB充電ケーブル
1x取扱説明書
1xクイックスタートガイド
① ② ③
1
④ ⑤
①
②
③
④
⑤
⑥
⑦
⑧
Charging Contacts
USB-C Charging Port
Charging Slot
Charging Indicators
Touch Sensor area
LED Indicator
Charging Case
Microphone
PRODUCT DIAGRAM (Fig. 2)
EN DE
FR ES
IT JP
Product Diagram
①
②
③
④
⑤
⑥
⑦
⑧
Ladekontakte
USB-C-Ladeanschluss
Ladesteckplatz
Ladeanzeigen
Touch-Sensor Bereich
LED-Anzeige
Ladehülle
Mikrofon
Produktdiagramm
①
②
③
④
⑤
⑥
⑦
⑧
Contacts de chargement
Port de chargement USB-C
Emplacement de chargement
Indicateurs de chargement
Zone du capteur tactile
Indicateur LED
Étui de chargement
Micro
Schéma du produit
①
②
③
④
⑤
⑥
⑦
⑧
Contactos de carga
Puerto de carga USB-C
Ranura para cargar
Indicadores de carga
Zona del sensor táctil
Indicador LED
Estuche de carga
Micrófono
Diagrama del producto
①
②
③
④
⑤
⑥
⑦
⑧
Contatti di carica
Porta di carica USB-C
Slot di carica
Indicatori di carica
Zona sensore tattile
LED
Custodia di carica
Microfono
Diagramma del prodotto
①
②
③
④
⑤
⑥
⑦
⑧
充電用接点
USB-C充電ポート
充電スロット
充電インジケータ
タッチセンサ部分
LEDインジケータ
充電ケース
マイク
製品外観
2
⑤
⑧
⑥
①
②
③
④⑦
01 02
EN
IMPORTANT SAFETY INSTRUCTIONS
Hearing Safety
Caution
HOW TO WEAR
Please read the instructions thoroughly before using this product and retain it
for future reference.
• Do not wear earbuds with high volume for a long time to avoid damaging
your hearing.
• Set the earbuds to low volume before you put them on, then increase the
volume gradually as per your preference.
• Do not set volume too high to stay aware of your surroundings.
• Please refer to local laws and regulations if you want to answer phone calls
via this device during driving.
• For your safety, avoid distraction from music or phone calls when you are
driving or doing other activities with potential dangers.
Warning: Please set the volume to proper level to avoid hearing damages.
• Do not expose this product to high temperatures.
• Do not immerse the earbuds into water or expose them to humidity for a
long time.
• Do not clean the product with detergent containing alcohol, ammonia,
benzene or abrasives.
• Avoid dropping.
• Place the earbuds back into the charging case when not in use and keep it
away from children and pets to avoid choking hazard.
• Unauthorized disassembly of any parts of this product is forbidden, which
may cause fire hazard, warranty voidance, and/or property loss.
• Close attention is needed when using near children.
• Keep the charging case away from water, rain or any other liquid.
• Don’t use the product in thunderstorm to avoid malfunction or electric shock.
• Always ask a professional technician or authorized personnel for repair.
Choose the Right Tips (Fig. 3)
Ear tips with different sizes are included in the package, try all sizes and
choose the ones fitting you best.
This product contains lithium battery. Never expose it to excessive heat
such as direct sunlight or fire to avoid explosion.
3
03 04
USING YOUR EARBUDS
7
Wear the Earbuds (Fig. 4)
Please wear the earbuds as shown below.
Pictures only for reference.
Bluetooth Caution
• When the device is connected wirelessly to another device, place the two
devices close to each other to achieve their normal functionalities and avoid
possible signal interference.
• When using a wireless connection, make sure there are no obstacles
between the two devices. Obstacles including walls and fences may shorten
the effective range.
Charging
Charging the Earbuds
1. Put the earbuds into the charging case as per the L (left) and R (right) marks
(Fig. 5).
2. Cover the lid and charging will start automatically (Fig. 6).
Note:
• Please fully charge the earbuds when using them for the first time.
• When battery is low, a “Please Charge” voice prompt will be heard (if you are
wearing the earbuds). Please charge it in time or the earbuds will turn off
automatically around 10 minutes later.
• Charge the earbuds at least once every 3 months when not using for a long time.
Charging the Charging Case
1. Connect the charging port with any USB charging adapter or active
computer USB port (Fig. 7).
2. The four step charging bar will light up progressively.
Note: Unplug the charging cable (timely) when fully charged.
4
① ②
5 6
L R
05 06
Power On (Fig. 8)
Uncover the lid and take out earbuds and they will power on automatically.
Power Off (Fig. 9)
Put the earbuds into the charging case and they will turn off automatically.
Pairing
• You can use one earbud or both earbuds as per your preference. Please
refer to the corresponding pairing instructions.
• Before pairing, please turn off other Bluetooth devices and place the
device to be connected close to the earbuds.
• When the earbuds are disconnected from your device for more than 5 minutes,
they will turn off automatically.
Couple Earbuds Mode
1. Uncover the lid and take out earbuds to turn on the earbuds, they will connect
with each other automatically. Once connected, The LED indicators on both
earbuds will flash white indicating the earbuds are in pairing mode now.
2. Turn on the Bluetooth function on your device and search for nearby devices.
Find “MW-1000Pro” in the searching results, tap on the name to connect.
3. Once connected, the LED indicators on both earbuds be turned off.
Note:
• If the earbuds failed to pair with each other, please disconnect the Bluetooth
connection with your device, put them back into the charging case, close the lid
then open it and take out the earbuds to pair again.
• It is not recommended to wear the two earbuds on different people. If needed,
please keep the 2 earbuds within 3 meters / 9.8 feet in couple earbuds mode.
Single Earbud Mode
1. Take out one earbud from the charging case, and make sure the other one is
placed in the charging case.
2. It will try to pair with the last paired device first then enter pairing mode with its
LED indicator flashing white if pairing failed.
3. Turn on the Bluetooth function on your device and search for nearby devices.
Find “MW-1000Pro” in the searching results, tap on the name to connect.
4. Once connected, the LED indicator will be turned off.
Note:
If you want to change to couple mode, simply take out the other earbud from the
charging case, they will pair with each other automatically.
8
L R
9
L R
07 08
OPERATION AND FUNCTIONS
Note:
If you want to pair the earbuds with another device when you have already
paired them with a device, deactivate the Bluetooth function on the paired
device or clear “MW-1000Pro” from its Bluetooth list. Operation
Press the touch sensor area on either of the
earbuds once
Press the touch sensor area on either of the
earbuds 2 times
Long press the touch sensor area on either
of the earbuds for 2 seconds
Press the touch sensor area on the left
earbud 2 times
Press the touch sensor area on the right
earbud 2 times
Press the touch sensor area on either of the
earbuds once
When the earbuds are paired with your
device successfully, press and hold for 2
seconds the touch sensor area (left / right
earphone)
Function
Answer Phone Call
Hang up Phone Call
Reject Incoming Call
Previous Track
Next Track
Play / Pause
Activate Siri / Google Assistant
09 10
CLEANING AND MAINTENANCE
No. Problem Solution
1
2
3
4
5
6
7
8
9
10
TROUBLESHOOTING
1. Clean the earbuds and the charging case on a regular basis.
2. Use dry and soft cotton cloth to wipe the unit.
Note: Do not insert anything into the product.
3. Keep away from sharp objects to avoid scratches.
4. Put the unit in a dry and shady place if it is to be idle for a long time.
5. Do not clean the product with detergent or chemicals.
Failed to turn on the
earbuds
Failed to charge the
earbuds
Can’t charge the
charging case
Can’t find
“MW-1000Pro”
in the Bluetooth device
list
Earbuds low battery, please charge them
• Place the earbuds into the charging
case properly
• Make sure the charging case is charged fully
Make sure the charging cable is intact
and plugged in properly
The earbuds reconnected with previously
paired device automatically:
• Deactivate the Bluetooth function of
previously paired device or clear
“MW-1000Pro”
from its Bluetooth device list, and then
search again
Failed to pair the
earbuds with your
device
No sound in one of the
earbuds in couple
earbuds mode
Poor sound quality
Unstable connection
Can’t hear the other
party during a phone call
The other party can’t
hear your voice during a
phone call
• Turn on the device and activate its
Bluetooth function before pairing
• Bring the earbuds into pairing mode as
instructed in the “Pairing” section
Place both earbuds back to the charging
case then take them out, they will pair
with each other automatically. If pairing
failed, restore them back to the factory
settings as instructed in the “Clear Pairing
List” section
• Wear the earbuds properly and keep
them close to each other
• Place the connected device close to the
earbuds or remove the obstacles
between them
• Clear the debris on the earbuds
• The effective distance may shorten with
obstacles in the way
• Turn off other Bluetooth devices to
decrease the interference
Set the volume to higher level
Free the built-in microphone of any covers
11 12
WARRANTY AND SERVICE
11 Touch sensor area of the
earbuds is unresponsive
Place the two earbuds into the charging
case and cover the lid, disconnect the
Bluetooth connection. Uncover the lid to
turn on the earbuds and pair again
If any problems occur, please contact the Minuswire Customer Care Centre
in your country via the contact information listed in this User Guide.
DE
WICHTIGE SICHERHEITSHINWEISE
Bitte lesen Sie sich die Anleitung sorgfältig durch, bevor Sie das Produkt
benutzen, und bewahren Sie sie zur künftigen Bezugnahme gut auf.
Gehörschutz
• Um Gehörschäden zu vermeiden, sollte man Kopfhörer nicht über längere
Zeit bei hoher Lautstärke tragen.
• Regeln Sie die Kopfhörer-Lautstärke herunter, bevor Sie sie aufsetzen, und
erhöhen Sie die Lautstärke dann schrittweise nach Bedarf.
• Sie sollten die Lautstärke nicht zu stark erhöhen, damit Sie Ihre Umgebung
weiterhin wahrnehmen.
• Bitte achten Sie auf lokale Gesetze und Richtlinien, wenn Sie während des
Autofahrens Telefonate über dieses Gerät führen wollen.
• Zu Ihrer eigenen Sicherheit sollten Sie Ablenkungen durch Musik oder
Telefonate beim Fahren oder anderen Aktivitäten, die mögliche Gefahren
bergen, meiden.
Warnung: Bitte stellen Sie die Lautstärke richtig ein, um Gehörschäden zu
vermeiden.
Achtung
• Setzen Sie dieses Produkt keinen hohen Temperaturen aus.
• Tauchen Sie die Kopfhörer nicht unter Wasser und setzen Sie sie nicht über
längere Zeit Feuchtigkeit aus.
• Reinigen Sie das Produkt nicht mit Reinigungsmitteln, die Alkohol,
Ammoniak, Benzol oder Schleifkörper enthalten.
• Lassen Sie das Produkt nicht herunterfallen.
• Legen Sie die Kopfhörer wieder in die Ladehülle, wenn Sie sie nicht
benutzen, und halten Sie sie von Kindern und Haustieren fern, damit sie
Inhaltsverzeichnis
Sprachen:
Andere MINUSWIRE Kopfhörer Handbücher
