TABLE OF CONTENTS

Thank you for purchasing a MINUTEMAN UPS Product. To enjoy all the features and

benefits of this Uninterruptible Power Supply (UPS), please read and follow all

installation and operation instructions completely. This UPS is designed to provide

power protection for connected electronic equipment. The accompanying MINUTEMAN

PowerCenter software saves data, closes open applications and automatically shuts

down your computer system in an intelligent and orderly manner.

FCC Notice

This equipment has been tested and found to comply with the limits for a Class B Digital

Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation

between the equipment and receiver. (3) Connect the equipment into an outlet on a

circuit different from that to which the receiver is connected. (4) Consult the dealer or an

experienced radio/TV technician for help. Any special accessories needed for

compliance must be specified in the instruction.

CAUTION: A shielded-type power cord is required in order to meet FCC emission limits

and to prevent interference to the nearby radio and television reception. It is essential

that only the supplied power cord be used. Use only shielded cables to connect I/O

devices to this equipment.

CAUTION: Any changes or modifications not expressly approved by the guarantee of

this device could void the user’s authority to operate the equipment.

Safety Instructions....... ... .. ... ... ... ...1

Description……………………………..1

Determining Power Requirements…..2

Hardware Installation Guide………….2

Software Installation Guide…………..3

Software User Manual………………..4

Battery Replacement Instructions..... 8

LED Indicators………………………..10

Trouble Shooting Guide…………… .11

Specifications………………………. 12

Declaration of Conformity ………… .13

Warranty... ... ... ... ... ... ... ... ... ... . 14

MN 325/MN 525 User’s Manual

Uninterruptible Power Supply (UPS)

IMPORTANT SAFETY INSTRUCTIONS (SAVE THESE INSTRUCTIONS)

This manual contains important safety instruc-

tions. Please read and follow all instructions

carefully during installation and operation of UPS.

Read this manual thoroughly before attempting to

unpack, install, or operate.

CAUTION! To prevent the risk of fire or electric

shock, install in a temperature and humidity con-

trolled indoor area, free of conductive contami-

nants. (Please see specifications for acceptable

temperature and humidity range).

CAUTION! To reduce the risk of electric shock,

do not remove the cover. Authorized Service

Personnel must perform repairs and mainte-

nance. No user serviceable parts inside.

CAUTION! Hazardous live parts inside can be

energized by the battery even when the AC input

power is disconnected.

CAUTION! UPS must be connected to an AC

power outlet with fuse or circuit breaker protec-

tion. Do not plug into an AC wall outlet that is not

grounded. If you need to de-energize this equip-

ment, turn off and unplug the UPS.

CAUTION! To avoid electrical shock, turn off the

UPS and unplug it from the AC power source

before servicing the battery or installing a com-

puter component.

DO NOT USE FOR MEDICAL OR LIFE SUP-

PORT EQUIPMENT! MINUTEMAN UPS does

not sell products for life support or medical appli-

cations. DO NOT use in any circumstance that

would affect operation or safety of any life sup-

port equipment or with any medical applications

or patient care.

DO NOT USE WITH OR NEAR AQUARIUMS!

To reduce the risk of fire or electric shock, do not

use with or near an aquarium. Condensation

from the aquarium can cause the UPS to short

out.

DESCRIPTION

Battery/Surge Outlets

Provides battery-powered/surge outlets for the

connected equipment and insures uninterrupted

operation of your equipment during a power

failure.

Surge Only Outlets

Provides surge protection for non-critical equip-

ment.

Power Switch

Can be used as a master on/off switch for equip-

ment connected to the battery-powered outlets.

Power On Indicator

This LED is illuminated when the utility condition

is normal and the UPS outlets are providing

power, free of surges and spikes.

SWF Indicator (MN 525 Only)

The Site Wiring Fault (SWF) LED will illuminate to

warn the user that a wiring problem exists, such

as bad ground, missing ground or reversed wir-

ing. If the SWF LED is illuminated, disconnect all

of the equipment from the UPS and have an

electrician check to ensure the AC wall outlet is

wired correctly.

Circuit Breaker

The circuit breaker provides overload and fault

protection. Under normal operating conditions,

the circuit breaker is depressed.

Serial Port to PC

This port allows connection and communication

from the DB-9 serial port on the computer to the

UPS. The UPS communicates its status to the

MINUTEMAN PowerCenter software. This inter-

face is also compatible with the UPS service

provided by Windows NT and Windows 2000.

RJ 11 Phone Jacks

Protects any standard modem, fax or single line

telephone.

INSPECTION

The package contents:

(1) MINUTEMAN PowerCenter software (floppy disk); (1) Serial interface cable (DB-9); (1) Telephone

cable; (1) User’s Manual; (1) Warranty registration card; (1) Platinum Protection Policy; (1) UPS.

HOW TO DETERMINE THE POWER REQUIREMENTS OF YOUR EQUIPMENT

1. Make sure that the total Volt-Amp (VA) requirements of your computer, monitor and peripheral

equipment does not exceed 1200VA for the MN 325 or 1440VA for the MN 525.

2. Ensure that the equipment plugged into the battery-powered outlets does not exceed the UPS’s

rated capacity. If UPS’s rated capacities are exceeded, an overload condition may occur and

cause the UPS to shut down and trip the circuit breaker.

3. If the power requirements of your equipment are listed in values other than Volt-Amps (VA),

convert Watts (W) or Amps (A) into VA by doing the calculations below. Note: The equation be-

low only calculates the maximum amount of VA that the equipment can use, not what is typically

used by the equipment at any given time. Users should expect usage requirements to be ap-

proximately 60% of below value to estimate power requirements:

Watts (W) x 1.82 = VA or Amps (A) x 120 = VA

Add the totals for all of the equipment and multiply this total by 0.6 to calculate actual require-

ments.

Note: Many factors can affect the amount of power that your computer system will require. The

total load that you will be placing on the battery-powered outlets should not exceed 80% of the

UPS’s capacity.

Hardware Installation Guide

1. Your new UPS may be used immediately upon

receipt. However, charging the battery for at

least 4-hours is recommended to ensure that

the battery’s maximum charge capacity is

achieved. Charge loss may occur during ship-

ping and storage. To recharge the battery, plug

the power cord into the AC wall outlet and turn

the power switch on. Note: The MN 525 will

charge the battery with the power switch on or off.

2. If you wish to use the software, connect the en-

closed serial interface cable to the serial port on the

UPS and an open serial port on the computer. If

you are not going to use the software, you do not

need to connect the cable.

3. With the UPS unit off and unplugged, connect your

computer, monitor, and any externally powered data storage device

(Zip drive, Jazz drive, Tape drive, etc…) into the battery power sup-

plied outlets. Plug your peripheral equipment (printer, scanner,

speakers) into the full-time surge protection outlets. DO NOT plug a

laser printer, copier, space heater, vacuum or other large elec-

trical device into the UPS. The power demands of these de-

vices will overload and possibly damage the UPS.

4. To protect a fax, phone or modem, connect a telephone cable from

the wall jack outlet to the IN jack of the UPS. Connect a telephone

cable from the OUT jack to the modem port on your computer. The

OUT jack can be used to protect a telephone or fax machine.

MN 325/MN 525 User’s Manual

Uninterruptible Power Supply (UPS)

5. Plug the UPS into a 2 pole, 3 wire grounding receptacle (AC wall outlet). Make sure the wall

branch outlet is protected by a fuse or circuit breaker and does not service equipment with large

electrical demands (e.g. refrigerator, copier, etc…). Note: DO NOT use extension cords, power

or surge strips on the input or the output of the UPS.

6. Depress the power switch to turn the UPS on. The power on indicator light will illuminate and the

UPS will “beep” once.

7. If an overload is detected, an audible alarm will sound and the UPS will emit one long beep. To

correct this, turn the UPS off and unplug at least one piece of equipment from the battery-

powered outlets. Wait 10-seconds. Make sure the circuit breaker is depressed and then turn the

UPS on.

8. Your UPS is equipped with an auto-charge feature (MN 525 only). When the UPS is plugged into

an AC wall outlet, the battery will automatically recharge.

9. To maintain optimal battery charge, leave the UPS plugged into an AC wall outlet with the power

switch turned on at all times.

10. To store your UPS for an extended period, cover and store it with the battery fully charged. Re-

charge the battery every three months to ensure battery life.

MINUTEMAN POWERCENTER SOFTWARE INSTALLATION GUIDE

Note: Use of the software is optional. The UPS will provide surge protection and battery backup

without the software. You must use the software if you wish to have the automatic shutdown feature.

FOR WINDOWS 95/98/Me

1. Turn the UPS off and unplug it.

2. Connect the serial interface cable to the UPS and an open serial port on the back of the com-

puter. Note: You must use the serial cable that was provided with the UPS.

3. Plug the UPS into an AC wall outlet, turn the UPS on and then start your computer.

4. Click on Start, point to Settings, and then click Control Panel.

5. Double-click Add/Remove Programs.

6. Insert the software disk into the floppy drive.

7. Click Install.

8. Follow the on-screen instructions.

9. Once the software is installed, remove the floppy disk and restart your computer.

When your computer restarts, the MINUTE-

MAN PowerCenter software will appear on

your screen for a few seconds, and then mini-

mize. It will appear as a blue and white battery

icon located in the system tray, near the clock.

FOR WINDOWS NT

1. Click on Start, point to Settings, and then click Control Panel.

2. Double-click the UPS Icon.

3. Remove the check mark from the box labeled UPS is installed on.

4. Click OK.

5. Acknowledge the message that the UPS is in an unknown state.

6. Exit to the desktop.

7. Shutdown your computer.

8. Turn the UPS off and unplug it.

9. Connect the serial interface cable to the UPS and an open serial port on the back of your com-

puter. Note: You must use the cable that was provided with the UPS.

10. Plug the UPS into an AC wall outlet, turn the UPS on and then start your computer.

11. Click on Start, point to Settings, and then click Control Panel.

12. Double-click Add/Remove Programs.

13. Insert the software disk into the floppy drive.

14. Click Install.

15. Follow the on-screen instructions.

16. Once the software is installed, remove the floppy disk and restart your computer.

Software Icon

When your computer restarts, the MINUTE-

MAN PowerCenter software will appear on

your screen for a few seconds, and then mini-

mize. It will appear as a blue and white battery

icon located in the system tray, near the clock.

FOR WINDOWS 2000

1. Click on Start, point to Settings, and then click Control Panel.

2. Double-click on Power Options.

3. On the UPS Tab, click Select.

4. In the UPS Selection Dialog Box, under Manufacturers, click None.

5. Exit to the desktop.

6. Shutdown the computer.

7. Turn the UPS off and unplug it.

8. Connect the serial interface cable to the UPS and an open serial port on the back of your com-

puter. Note: You must use the cable that was provided with the UPS.

9. Plug the UPS into an AC wall outlet, turn the UPS on and then start your computer.

10. Click on Start, point to Settings, and then click Control Panel.

11. Double-click Add/Remove Programs.

12. Insert the software disk into the floppy drive.

13. Click Install.

14. Follow the on-screen instructions.

15. Once the software is installed, remove the floppy disk and restart your computer.

When your computer restarts, the MINUTEMAN

PowerCenter software will appear on your

screen for a few seconds, and then minimize. It

will appear as a blue and white battery icon

located in the system tray, near the clock.

MINUTEMAN POWERCENTER SOFTWARE USER MANUAL

OVERVIEW

MINUTEMAN PowerCenter version 1.0 or greater is designed for use with Windows 95, Windows 98,

Windows Me, Windows NT and Windows 2000. The latest version will be available from

www.minutemanups.com. It works in conjunction with the UPS to provide full protection of valuable

computer systems, applications and data. In the event of a power failure, MINUTEMAN PowerCenter

automatically saves and closes open files under auto-assigned file names or existing files names

after a software controlled delay. The computer and UPS are automatically shutdown to conserve

battery power. Files with auto-assigned names will be saved under C:\PCTemp, where Cis the

name of your main hard drive. Files that have previously been saved will be saved in their original

location.

MINUTEMAN PowerCenter is equipped with a Scheduled Shutdown feature which can automati-

cally save and close open files and then shutdown the computer and UPS at a user specified date

and time. Use of this feature is optional and is not required for the power failure shutdown to occur.

The use of the MINUTEMAN PowerCenter software is optional. The UPS unit will provide full surge

protection and battery backup without the software. You must use the software if you wish to have

the automatic shutdown feature.

MINUTEMAN POWERCENTER MAIN WINDOW DESCRIPTION

1. Minimize Button: This button is

used to minimize the software.

2. Power Button: Clicking on the

power button will stop the software.

3. Setup Button: Click the setup but-

ton to open the Setup Window.

4. Log Button: Click on the log button

to open the Log Window.

Software Icon

MN 325/MN 525 User’s Manual

Uninterruptible Power Supply (UPS)

5. Shutdown Button: Click the shutdown button to open the Scheduled Shutdown Window.

6. Battery OK Indicator: This indicator appears in a green color when AC power is normal and the

UPS and software are communicating.

7. AC Power Indicator: This indicator appears in a green color when AC power in normal. When

the power fails, the indicator will change to a red color with an “X” through it.

8. Scheduled Shutdown: If there is a shutdown scheduled within seven days, the information will

be displayed here. The user can schedule a shutdown in the Scheduled Shutdown Window.

9. Final Countdown: When the final countdown timer reaches zero, the software will begin shut-

ting down the system. This can be adjusted in the Setup Window.

MINUTEMAN POWERCENTER SETUP WINDOW

1. Delay Between Warning Mes-

sages: This setting determines the

delay between the audible alarms.

2. Time Between Power Failure and

Initial Warning: This setting de-

termines the delay between when

the power fails and the first audible

alarm.

3. Time Between Power Failure and

Shutdown Process: This user adjustable setting determines how long the UPS will run on bat-

tery before starting to shut down the system. If this is not checked, the UPS will run on battery

until the low battery condition occurs (approximately 2-minutes of backup time remaining), and

then, start the shutdown process. If the low battery condition occurs before this timer reaches

zero, the software will start the shutdown process.

4. UPS is Installed On: This shows the current COM port that the UPS is using. The port assigned

to the UPS needs to be used exclusively for the MINUTEMAN PowerCenter software.

5. OK Button: This button is used to exit the setup window and save any changes.

6. Cancel Button: This button is used to exit the setup window without saving any changes.

7. About Button: This button will display information about the software as well as contact informa-

tion.

MINUTEMAN POWERCENTER LOG WINDOW

1. Display Window: This area displays

either the Event Log or the Closed Appli-

cation Information.

2. Event Log: Select this option to view

MINUTEMAN PowerCenter events such as

program start, program end, power failure

and low battery.

3. Closed Application Information: Select

this option to view the file names of appli-

cations that were saved by the MINUTEMAN PowerCenter software. Note: If an application has

an existing file name, it will be saved under that file name and not appear in this window.

4. OK Button: This button is used to exit the window.

5. Clear Button: This button is used to clear the information in the selected log.

MINUTEMAN POWERCENTER SHUTDOWN WINDOW

1. Display Window: Any schedule information will be displayed here.

2. Special Setting: This option is used to

schedule a shutdown at a specific date

and time.

3. Weekly Setting: This option is used to

schedule a shutdown for a specific time

and day of the week.

4. OK Button: This button is used to exit

the window.

5. Add Button: This button is used to add

an item to the schedule.

6. Clear Button: This button is used to delete the selected item.

7. Cancel Shutdown: This button is used to cancel the current shutdown.

8. Day, Date and Time: This is the area where you select the day, date and time that you want the

shutdown to occur. Once you have selected it, click the Add Button to add the item to the

schedule.

Note: The use of the schedule is optional and will have no effect on the shutdown of your system

during a power failure. This feature is simply used if you want to have your computer automati-

cally shut down at a scheduled time.

USING THE WINDOWS NT UPS SERVICE

If you are running Windows NT, you may choose to use the Windows NT service instead of the

MINUTEMAN PowerCenter. You can run either MINUTEMAN PowerCenter or the NT service, but

not both.

To Configure the Windows NT UPS Service:

1. Click on Start, point to Settings, then Control Panel.

2. Double-click the UPS Icon.

3. Select the COM port that the UPS is connected to.

4. Set the Power Failure Signal to Negative.

5. Set the Low Battery Signal to Negative.

6. Set the Remote UPS Shutdown Signal to Positive.

7. Click OK.

Note: This service must be stopped in order to use the MINUTEMAN PowerCenter software. To

stop the service, remove the checkmark from Uninterruptible Power Supply is installed on. Click

OK. Acknowledge the message that the UPS is in an unknown state and exit to the desktop.

USING THE WINDOWS 2000 UPS SERVICE

If you are running Windows 2000, you may choose to run the Windows 2000 UPS service instead of

the MINUTEMAN PowerCenter. You can run either MINUTEMAN PowerCenter or the Windows

2000 UPS service, but not both.

To Configure the Windows 2000 UPS Service:

1. Click on Start, point to Settings, then Control Panel.

2. Double-click on Power Options.

3. On the UPS Tab, click Select.

4. In the UPS Selection Dialog Box, under Select Manufacturer, select Generic.

5. Under Select Model, select Custom.

6. On the UPS Tab, click Configure.

7. Set Power Fail/On Battery to Negative.

8. Set Low Battery to Negative.

9. Set UPS Shutdown to Positive.

10. Click OK.

Note: This service must be stopped in order to run the MINUTEMAN PowerCenter. To disable the

service, set the Manufacturer to None.

MN 325/MN 525 User’s Manual

Uninterruptible Power Supply (UPS)

Note: You must be logged on as an administrator or a member of the administrator’s group to make

these changes. Network policies may also prevent you from making these changes. Please contact

your network administrator for further assistance.

TESTING YOUR UPS SYSTEM

Once you have set up your UPS system, you may wish to test it. Make sure that the UPS has been

charged for at least 4-hours before performing this test.

If you are using the MINUTEMAN PowerCenter:

1. With your UPS and computer on, open an application such as notepad.

2. Enter some data into the application.

3. Unplug the UPS from the AC wall outlet.

When a power failure occurs, the MINUTEMAN PowerCenter will appear on the screen. The outlet

and battery symbols will change to indicate a power failure. The countdown timer will move towards

zero. When the timer reaches zero, the software will begin to save and close any open applications.

The software will auto-assign names to any files that have not been previously saved, and then save

the file to the PCTemp folder which is located in the root directory of your C drive (where Cis the

name of your main hard drive). Once, all open files have been saved and closed the MINUTEMAN

PowerCenter will shutdown the operating system. Once the operating system is shutdown, the UPS

will turn off within 90-seconds. Wait until the UPS has turned off before plugging the UPS back into

the AC wall outlet.

Once, the test has been completed, plug the UPS back into the AC wall outlet and turn it back on.

You may then restart your computer. Please allow 4-hours for the UPS to recharge before attempting

another self-test.

If you are NOT using the MINUTEMAN PowerCenter:

1. Have your computer and UPS turned on.

2. Unplug the UPS from the AC wall outlet to simulate a power failure.

3. The UPS will begin beeping, indicating a power failure.

4. Save and close any open files.

5. Shut down the operating system.

6. Once the computer system is shutdown, turn the UPS off.

As the battery discharges, the unit will beep more rapidly, indicating that the battery is nearing dis-

charge. Once the test is complete, plug the UPS back in and start your computer. Please allow 4-

hours for the UPS to recharge before attempting another self-test.

REPLACING THE BATTERY (Authorized Service Personnel)

CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the bat-

tery. Service the battery under the supervision of Authorized Service Personnel knowledgeable of

batteries and their precautions.

CAUTION! Use only the specified type of battery. See your dealer for replacement batteries.

CAUTION! The battery may present risk of electrical shock. Do not dispose of battery in a fire, as it

may explode. Follow all local ordinances regarding proper disposal of batteries.

CAUTION! Do not open or mutilate the batteries. Released electrolyte is harmful to skin and eyes

and may be toxic.

CAUTION! Although the battery system voltage is only 12VDC, the battery can present a high risk of

short circuit current and electrical shock. The short circuit current capability of the battery is sufficient

to burn wire or tools very rapidly producing molten metal. Observe these precautions when replacing

the battery:

1. Remove all watches, rings or other metal objects.

2. Only use tools with insulated handles.

3. Do not lay tools or metal parts on top of battery or any terminals.

4. Wear protective eye gear (goggles), rubber gloves and boots.

5. Disconnect the charging source before connecting or disconnecting the battery terminals.

6. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove the source

of ground. Contact with a grounded battery can result in electrical shock! The likelihood of such

shock will be reduced if; such grounds are removed during installation and maintenance (applica-

ble to a UPS and a remote battery supply not having a grounded circuit).

BATTERY REPLACEMENT PROCEDURE

1. Turn off and unplug all connected equipment.

2. Turn the UPS off and unplug the UPS’s power cord from the AC wall outlet.

3. Turn the UPS upside down.

4. Remove the retaining screws from the battery compartment door.

5. Remove the battery compartment door.

MN 325

Retaining Screws

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Minuteman UPS Handbücher

Minuteman

Minuteman Smart Up Series Bedienungsanleitung

Minuteman

Minuteman Encompass Series Bedienungsanleitung

Minuteman

Minuteman EN750LCD Bedienungsanleitung

Minuteman

Minuteman Entrepid Series Bedienungsanleitung

Minuteman

Minuteman PRO1100E Bedienungsanleitung

Minuteman

Minuteman MM-AVR Bedienungsanleitung

Minuteman

Minuteman Enterprise Plus Series Bedienungsanleitung

Minuteman

Minuteman PRO-E Bedienungsanleitung

Minuteman

Minuteman CPE 1000 On-Line Series Bedienungsanleitung

Minuteman

Minuteman SentryII UPS Bedienungsanleitung

Minuteman

Minuteman MN 325 Bedienungsanleitung

Minuteman

Minuteman Continuous Power Series Bedienungsanleitung

Minuteman

Minuteman Enterprise Plus LCD RTXL UPS Series Bedienungsanleitung

Minuteman

Minuteman Entrust-LG Series Bedienungsanleitung

Minuteman

Minuteman 1000 VA Bedienungsanleitung

Minuteman

Minuteman AT300 Bedienungsanleitung

Minuteman

Minuteman Enspire Series Bedienungsanleitung

Minuteman

Minuteman MBK Series Bedienungsanleitung

Minuteman

Minuteman Pro 2200r Bedienungsanleitung

Minuteman

Minuteman MCP 1000 Bedienungsanleitung

Minuteman

Minuteman Pro Series Bedienungsanleitung

Minuteman

Minuteman Pro Series Bedienungsanleitung

Minuteman

Minuteman MBK-E SERIES Bedienungsanleitung

Minuteman

Minuteman ERS1500RTNC Bedienungsanleitung

Beliebte UPS Handbücher anderer Marken

Pylontech

Pylontech Victron & Pylontech US5000 Bedienungsanleitung

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Bedienungsanleitung

Mecer

Mecer ME-1000-WTU Bedienungsanleitung

Mustek

Mustek PowerMust 530(B) Plus Installations- und Betriebshandbuch

Emerson

Emerson Liebert NXL series Bedienungsanleitung

MAKELSAN

MAKELSAN BOXER SERIES Bedienungsanleitung

Block

Block PC-0524-400-0 Bedienungsanleitung

CyberPower

CyberPower CP585LCD Bedienungsanleitung

Eaton

Eaton 3S Montageanleitung

CyberPower

CyberPower Office Tower Series UPS 1000 Bedienungsanleitung

CyberPower

CyberPower BM100 Bedienungsanleitung

Best Power

Best Power 610 Bedienungsanleitung

Best Power

Best Power Unity/I UT3K Bedienungsanleitung

Mustek

Mustek PowerMust 400 Offline Bedienungsanleitung

Xantrex

Xantrex Trace 512 UR-UPS Bedienungsanleitung

Forza

Forza SL-1501UL Bedienungsanleitung

LEGRAND

LEGRAND keor 310081 Bedienungsanleitung

ABB

ABB Conceptpower DPA 500 Bedienungsanleitung
