Q Corresponding Ethernet Interface Module

User's Manual (Basic)

-QJ71E71-100

-QJ71E71-B5

-QJ71E71-B2

SAFETY PRECAUTIONS

(Read these precautions before using this product.)

Before using this product, please read this manual and the relevant manuals carefully and pay full attention

to safety to handle the product correctly.

In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".

Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to

serious consequences.

Observe the precautions of both levels because they are important for personal and system safety.

Make sure that the end users read this manual and then keep the manual in a safe place for future

reference.

WARNING

CAUTION

Indicates that incorrect handling may cause hazardous conditions,

resulting in death or severe injury.

Indicates that incorrect handling may cause hazardous conditions,

resulting in minor or moderate injury or property damage.

[Design Precautions]

WARNING

●For the operating status of each station after a communication failure, refer to manuals relevant to the

network. Incorrect output or malfunction due to a communication failure may result in an accident.

●To prevent the malfunction of the programmable controller system due to harmful e-mails, take

preventive measures (such as antivirus measures) so that the mail server for this module does not

receive harmful e-mails.

●To maintain the safety of the programmable controller system against unauthorized access from

external devices via the network, take appropriate measures. To maintain the safety against

unauthorized access via the Internet, take measures such as installing a firewall.

●When connecting a peripheral with the CPU module or connecting an external device, such as a

personal computer, with an intelligent function module to modify data of a running programmable

controller, configure an interlock circuit in the program to ensure that the entire system will always

operate safely. For other forms of control (such as program modification or operating status change)

of a running programmable controller, read the relevant manuals carefully and ensure that the

operation is safe before proceeding. Especially, when a remote programmable controller is controlled

by an external device, immediate action cannot be taken if a problem occurs in the programmable

controller due to a communication failure. To prevent this, configure an interlock circuit in the program,

and determine corrective actions to be taken between the external device and CPU module in case of

a communication failure.

●Do not write any data in the system area of the buffer memory in the intelligent function module. Also,

do not use any use prohibited signals as an output signal from the programmable controller CPU to

the intelligent function module. Doing so may cause malfunction of the programmable controller

system.

CAUTION

●Do not bundle the control wires and the communication cables with the main circuit and the power

wires, and do not install them close to each other. They should be installed at least 100 mm (3.94 in.)

away from each other. Failure to do so may generate noise that may cause malfunctions.

●When changing the operating status of the CPU module (such as remote RUN/STOP) from the

external device, select "Always wait for OPEN (Communication possible at STOP time)" for the "Initial

timing" setting in the network parameter. The communication line will be closed when "Do not wait for

OPEN (Communications impossible at STOP time)" is selected and the remote STOP is executed

from the external device. Consequently, the CPU module cannot reopen the communication line, and

the external device cannot execute the remote RUN.

[Installation Precautions]

[Wiring Instructions]

CAUTION

●Use the programmable controller in an environment that meets the general specifications in the user's

manual for the CPU module used. Using the programmable controller in any other operating

environments may cause electric shocks, fires or malfunctions, or may damage or degrade the

module.

●While pressing the installation lever located at the bottom of module, insert the module fixing tab into

the fixing hole in the base unit until it stops. Then, securely mount the module with the fixing hole as a

supporting point. If the module is not installed properly, it may cause the module to malfunction, fail or

fall off. Secure the module with screws especially when it is used in an environment where constant

vibrations may occur.

●Be sure to tighten the screws using the specified torque. If the screws loose, it may cause the module

to short-circuit, malfunction or fall off. If the screws are tightened excessively, it may damage the

screws and cause the module to short-circuit, malfunction or fall off.

●Shut off the external power supply (all phases) used in the system before mounting or removing the

module. Failure to do so may cause product damage.

●Do not directly touch any conductive part or electronic component of the module. This may cause the

module to malfunction or fail.

CAUTION

●Connectors for external devices and coaxial cables must be crimped or pressed with the tool specified

by the manufacturer, or must be correctly soldered. Incomplete connections may cause short circuit,

fire, or malfunction.

●Shut off the external power supply (all phases) used in the system before connecting the AUI cable.

●Securely connect the connector to the module. Poor contact may cause malfunction.

●Place the cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be pulled,

resulting in damage to the module or cables or malfunction due to poor contact.

●Tighten the terminal screws using the specified torque. If the terminal screws are loose, it may cause

the module to short-circuit, malfunction or fall off. If the terminal screws are tightened excessively, it

may damage the screws and cause the module to short-circuit, malfunction or fall off.

●When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable

with connector, hold the connector part of the cable. For the cable connected to the terminal block,

loosen the terminal screw. Pulling the cable connected to the module may result in malfunction or

damage to the module or cable.

●Be careful not to let any foreign matter such as wire chips get inside the module. They may cause fire,

as well as breakdowns and malfunctions of the module.

●A protective film is attached to the top of the module to prevent foreign matter, such as wire chips,

from entering the module during wiring. A protective film is attached to the top of the module to

prevent foreign matter, such as wire chips, from entering the module during wiring. Remove it for heat

dissipation before system operation.

[Setup and Maintenance Precautions]

[Precautions When Disposing of This Product]

WARNING

●Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction.

●Shut off the external power supply (all phases) used in the system before cleaning the module or

retightening the terminal screws, connector screws, or module fixing screws. Failure to do so may

result in electric shock or cause the module to fail or malfunction.

CAUTION

●Do not disassemble or modify the modules. Doing so may cause failure, malfunction, injury, or a fire.

●Shut off the external power supply (all phases) used in the system before mounting or removing the

module.

●After the first use of the product, do not mount/remove the module to/from the base unit more than 50

times (IEC 61131-2 compliant). Exceeding the limit of 50 times may cause malfunction.

●Always make sure to touch the grounded metal to discharge the electricity charged in the body, etc.,

before touching the module. Failure to do so may cause a failure or malfunctions of the module.

CAUTION

●Dispose of this product as an industrial waste.

CONDITIONS OF USE FOR THE PRODUCT

(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;

i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;

and

ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the

case of any problem, fault or failure occurring in the PRODUCT.

(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.

MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL

RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY

INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE

OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR

WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL

BULLETINS AND GUIDELINES FOR the PRODUCT.

("Prohibited Application")

Prohibited Applications include, but not limited to, the use of the PRODUCT in;

• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the

public could be affected if any problem or fault occurs in the PRODUCT.

• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality

assurance system is required by the Purchaser or End User.

• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,

Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and

Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other

applications where there is a significant risk of injury to the public or property.

Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or

more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific

applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or

other safety features which exceed the general specifications of the PRODUCTs are required. For details, please

contact the Mitsubishi representative in your region.

INTRODUCTION

Thank you for purchasing the Mitsubishi MELSEC-Q series programmable controllers. This manual describes the

operating procedure, system configuration, parameter settings, functions, programming, and troubleshooting of the

Ethernet interface modules: QJ71E71-100, QJ71E71-B5, and QJ71E71-B2 (hereafter referred to as E71).

Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the

functions and performance of the MELSEC-Q series programmable controller to handle the product correctly.

When applying the program examples introduced in this manual to the actual system, ensure the applicability and

confirm that it will not cause system control problems.

Please make sure that the end users read this manual.

COMPLIANCE WITH THE EMC AND LOW VOLTAGE

DIRECTIVES

(1) For programmable controller system

To ensure that Mitsubishi programmable controllers maintain EMC and Low Voltage Directives when incorporated

into other machinery or equipment, certain measures may be necessary. Please refer to one of the following

manuals.

• QCPU User's Manual (Hardware Design, Maintenance and Inspection)

• Safety Guidelines (This manual is included with the CPU module or base unit.)

The CE mark on the side of the programmable controller indicates compliance with EMC and Low Voltage

Directives.

(2) For the product

To ensure that this product maintains EMC and Low Voltage Directives, please refer to one of the manuals listed

under (1).

RELEVANT MANUALS

This manual describes the basic specifications, functions, and usage of the E71.

(1) E71 relevant manual

(2) Operating manual

Manual name

<manual number, model code> Description

MELSEC-Q/L Ethernet Interface Module User's

Manual (Application)

<SH-080010, 13JL89>

E-mail function, communication function (communications via CC-Link IE

Controller Network, CC-Link IE Field Network, MELSECNET/H, or

MELSECNET/10, and communications by using the data link instructions), and file

transfer (FTP server) function of the E71

MELSEC-Q/L Ethernet Interface Module User's

Manual (Web function)

<SH-080180, 13JR40>

Web function of the E71

MELSEC Communication Protocol Reference Manual

<SH-080008, 13JF89>

Details of MELSEC communication protocol (MC protocol) that is used for data

communication between a target device and a CPU module

Manual name

<manual number, model code> Description

GX Works2 Version1 Operating Manual (Common)

<SH-080779, 13JU63>

System configuration, parameter settings, and online operations (common to

Simple project and Structured project) of GX Works2

GX Works2 Version 1 Operating Manual (Intelligent

Function Module)

<SH-080921, 13JU69>

Parameter settings for intelligent function modules, monitoring operations, and the

predefined protocol support function of GX Works2

GX Developer Version 8 Operating Manual

<SH-080373, 13JU41>

Operating methods of GX Developer, such as programming, printing, monitoring,

and debugging

CONTENTS

SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

COMPLIANCE WITH THE EMC AND LOW VOLTAGE DIRECTIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

RELEVANT MANUALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

MANUAL PAGE ORGANIZATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

TERM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

PACKING LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

CHAPTER 1 FEATURES 19

CHAPTER 2 PART NAMES 25

CHAPTER 3 SPECIFICATIONS 27

3.1 General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

3.2 Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

3.3 Function List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.3.1 Function list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.3.2 Use with other functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

3.4 List of I/O Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

3.5 Buffer Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

3.5.1 Configuration of the buffer memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

3.5.2 List of buffer memory addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

CHAPTER 4 PROCEDURES BEFORE OPERATION 60

CHAPTER 5 SYSTEM CONFIGURATION 62

5.1 Configuration of an E71-mounted System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

5.1.1 Applicable modules and base units, and the number of connectable modules . . . . . . . . . . . 62

5.1.2 For use with a Basic model QCPU or safety CPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

5.1.3 For use in a multiple CPU system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

5.1.4 For use in a redundant system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

5.1.5 For use in a MELSECNET/H remote I/O station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

5.2 Network Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

5.2.1 Configuration devices used for 100BASE-TX/10BASE-T connection . . . . . . . . . . . . . . . . . . 71

5.2.2 Configuration devices used for 10BASE5 connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

5.2.3 Configuration devices used for 10BASE2 connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

CHAPTER 6 INSTALLATION AND WIRING 75

6.1 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

6.2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

6.2.1 Wiring with the QJ71E71-100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

6.2.2 Wiring with the QJ71E71-B5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

6.2.3 Wiring with the QJ71E71-B2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mitsubishi Electric Controller Handbücher

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC System Q Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX3S-10M series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric PAC-SC30GRA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric AJ61BT11 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric AnyWire NZ2AW1C2AL Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSERVO-JET Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric QJ71C24N Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC FX2N-16SW Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX2N-16 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC-A/QnA Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Installationsanleitung

Mitsubishi Electric

Mitsubishi Electric FX2N-8EYR-S-ES/UL Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R C Series Betriebsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC Q Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC-F FX3U-232ADP-MB Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric A1SJ71PB96F Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC FX-2DA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC-QS Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX2N-1PG-E Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric SIMPLE MA PAC-YT51CRB Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q172CPU Betriebsanleitung

Mitsubishi Electric

Mitsubishi Electric MR-J5 Series Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
