Mitsubishi QJ72LP25-25 Gebrauchsanweisung

MELSECNET/H

Network Module

User’s Manual

(Hardware)

QJ72LP25-25, QJ72LP25G

QJ72BR15

Thank you for purchasing the Mitsubishi programmable controller

MELSEC-Q Series.

Prior to use, please read both this manual and detailed manual

thoroughly and familiarize yourself with the product.

MODEL NET/H-R-U-H

MODEL

CODE 13JT17

IB(NA)-0800145-I(0809)MEE

2000 MITSUBISHI ELECTRIC CORPORATION

-1

zSAFETY PRECAUTIONS z

(Always read these instructions before using this equipment.)

Before using this product, please read this manual and the relevant manuals

introduced in this manual carefully and pay full attention to safety to handle the

product correctly.

Precautionary notes in this manual cover only the installation of this product. For

precautions on designing and discarding this product, refer to "Safety

Precautions" in the MELSECNET/H Reference Manual.

For safety precautions on the programmable controller system, refer to the CPU

User's Manual.

In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".

Indicates that incorrect handling may cause hazardous

conditions, resulting in death or severe injury.

Indicates that incorrect handling may cause hazardous

conditions, resulting in medium or slight personal injury or

physical damage.

Note that the CAUTION level may lead to a serious consequence

according to the circumstances.

Always follow the instructions of both levels because they are important to

personal safety.

Please save this manual to make it accessible when required and always forward

it to the end user.

CAUTION

DANGER

-2

[Installation Precautions]

CAUTION

zUse the programmable controller in the operating environment that meets

the general specifications given in the CPU module used.

Using this programmable controller in an environment outside the range of

the general specifications could result in electric shock, fire, erroneous

operation, and damage to or deterioration of the product.

zWhile pressing the installation lever located at the bottom of module, insert

the module fixing tab into the fixing hole in the base unit until it stops. Then,

securely mount the module with the fixing hole as a supporting point.

Incorrect loading of the module can cause a malfunction, failure or drop.

When using the programmable controller in the environment of much

vibration, tighten the module with a screw.

Tighten the screw in the specified torque range.

Undertightening can cause a drop, short circuit or malfunction.

Overtightening can cause a drop, short circuit or malfunction due to damage

to the screw or module.

zCompletely turn off the externally supplied power used in the system before

mounting or removing the module.

Not doing so could result in damage to the product.

zFor remote I/O stations of function version D or later, online module change

can be performed. However, the modules which can be replaced online are

limited, and replacement procedures are determined for each module.

For details, refer to the Q Corresponding MELSECNET/H Network System

Reference Manual (Remote I/O network).

zDo not directly touch the module's conductive parts or electronic

components.

Touching the conductive parts could cause an operation failure or give

damage to the module.

zBefore touching the module, always touch grounded metal, etc. to discharge

static electricity from human body, etc. Not doing so can cause the module

to fail or malfunction.

-3

[Wiring Precautions]

DANGER

zCompletely turn off the externally supplied power used in the system when

placing wiring.

Not completely turning off all power could result in electric shock or damage

to the product.

CAUTION

zSolder coaxial cable connectors properly. Incomplete soldering may result in

malfunction.

zBe sure there are no foreign substances such as sawdust or wiring debris

inside the module. Such debris could cause fires, damage, or erroneous

operation.

zThe module has an ingress prevention label on its top to prevent foreign

matter, such as wire offcuts, from entering the module during wiring. Do not

peel this label during wiring. Before starting system operation, be sure to

peel this label because of heat dissipation.

zMake sure to place the communication and power cables to be connected to

the module in a duct or fasten them using a clamp. If the cables are not

placed in a duct or not fastened with a clamp, their positions may become

unstable and may move, or they may be pulled inadvertently. This may

damage the module and the cables or cause the module to malfunction

because of faulty cable connections.

zWhen disconnecting a communication cable, do not pull it by holding the

cable part.

To disconnect the cable, hold its connector that is plugged into the module.

Pulling the cable part with the cable still connected to the module may

damage the module and/or cable, or cause malfunctions due to poor cable

contact.

zInstall our programmable controller in a control panel for use. Wire the main

power supply to the power supply module installed in a control panel through

a distribution terminal block. Furthermore, the wiring and replacement of a

power supply module have to be performed by a maintenance worker who

acquainted with shock protection. (For the wiring methods, refer to QCPU

User's Manual (Hardware Design, Maintenance and Inspection).)

-4

Revisions

*The manual number is noted at the lower right of the top cover.

Print Date *Manual Number Revision

Sep., 2000 IB(NA)-0800145-A First edition

Mar., 2001 IB(NA)-0800145-B

Model addition

QJ72LP25G

May, 2004 IB(NA)-0800145-C

Partial correction

SAFETY PRECAUTIONS, Compliance

with the EMC Directive and the Low

Voltage Directive, Chapter 2, Section 3.1,

Chapter 4 (a), (b), (1), Chapter 5, 6

Aug., 2004 IB(NA)-0800145-D

Partial correction

SAFETY PRECAUTIONS,

Chapter 1, 2, 3, 4, 5, 6

Jan., 2005 IB(NA)-0800145-E

Partial correction

Compliance with the EMC Directive and

the Low Voltage Directive,

Chapter 1, 2, 3, 6

Nov., 2005 IB(NA)-0800145-F

Partial correction

Compliance with the EMC Directive and

the Low Voltage Directive, Chapter 4

Mar., 2006 IB(NA)-0800145-G

Partial correction

Chapter 2, 4

Mar., 2007 IB(NA)-0800145-H

Change of a term

“PLC” was changed to “Programmable

controller”

Partial correction

SAFETY PRECAUTIONS, Chapter 3, 4, 5

Sep., 2008 IB(NA)-0800145-I

Partial correction

SAFETY PRECAUTIONS, Compliance

with the EMC Directive and the Low

Voltage Directive, Chapter 2, 4, 5, 6

This manual confers no industrial property rights or any rights of any other kind,

nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot

be held responsible for any problems involving industrial property rights which

may occur as a result of using the contents noted in this manual.

2000 MITSUBISHI ELECTRIC CORPORATION

-5

CONTENTS

1. Overview........................................................................................................ 1

2. Performance Specifications ........................................................................... 2

3. Handling ........................................................................................................ 6

3.1 Module Handling Precautions................................................................... 6

4. Part Identification Names............................................................................... 7

5. Wiring .......................................................................................................... 10

6. External Dimensions .................................................................................... 11

-6

About Manuals

The following manuals are also related to this product.

In necessary, order them by quoting the details in the tables below.

Related Manuals

Manual name Manual No.

(Model code)

Q corresponding MELSECNET/H Network System

Reference Manual (Remote I/O network)

SH-080124

(13JF96)

Q corresponding MELSECNET/H Network System

Reference Manual (PLC to PLC network)

SH-080049

(13JF92)

Compliance with the EMC and Low Voltage Directives

(1) For programmable controller system

To configure a system meeting the requirements of the EMC and Low

Voltage Directives when incorporating the Mitsubishi programmable

controller (EMC and Low Voltage Directives compliant) into other

machinery or equipment, refer to Chapter 9 "EMC AND LOW VOLTAGE

DIRECTIVES" of the QCPU User's Manual (Hardware Design,

Maintenance and Inspection).

The CE mark, indicating compliance with the EMC and Low Voltage

Directives, is printed on the rating plate of the programmable controller.

(2) For the product

For the compliance of this product with the EMC and Low Voltage

Directives, refer to Section 9.1.3 "Cables" in Chapter 9 "EMC AND LOW

VOLTAGE DIRECTIVES" of the QCPU User's Manual (Hardware Design,

Maintenance and Inspection).

1. Overview

This manual explains how to handle the MELSECNET/H network module, model

numbers QJ72LP25-25, QJ72LP25G and QJ72BR15 (hereinafter referred to as

the network module).

This network module is used as a remote I/O station of a remote I/O network in

the MELSECNET/H network system, not in a PLC to PLC network.

After unpacking the network module, confirm that any of the following products is

enclosed.

Model name Part name Quantity

QJ72LP25-25 QJ72LP25-25 MELSECNET/H Network Module

(optical loop type) 1

QJ72LP25G QJ72LP25G MELSECNET/H Network Module

(optical loop type) 1

QJ72BR15 MELSECNET/H Network Module

(coaxial cable bus type) 1

QJ72BR15

F-type connector (A6RCON-F) 1

Important

The coaxial bus-type network system requires terminal resistors at both terminal

stations of the network. Terminal resistors are not included with the QJ72BR15;

they must be purchased separately.

* Terminal resistor (75 )

yA6RCON-R75

2. Performance Specifications

If the X/Y numbers are duplicate, only one side is taken into consideration.The

following table shows the performance specifications for the network module:

Specifications

Item QJ72LP25-25 QJ72LP25G

LX/LY 8192 points

LB 16384

points

Remote master station remote sub-master,

remote I/O station: 8192 points

Remote sub-master, remote I/O station

remote master station: 8192 points

Maximum number

of links per network

LW 16384

points

Remote master station remote sub-master,

remote I/O station: 8192 points

Remote sub-master, remote I/O station

remote master station: 8192 points

Maximum number of links per

station

• Remote master station Remote I/O station *1

{(LY + LB) /8 + (2 × LW)} 1600 bytes

• Remote I/O station Remote master station *1

{(LX + LB) /8 + (2 × LW)} 1600 bytes

• Multiplexed remote master station

Multiplexed remote sub-master station

{(LY + LB) /8 + (2 × LW)} 2000 bytes

Maximum I/O points per

remote I/O station

X + Y 4096 points

If the X/Y numbers are duplicate, only one side is taken into

consideration.

Communication speed 25Mbps/10Mbps

(selected with MODE switch) 10Mbps

Communication method Token ring

Synchronization method Frame synchronization

Transmission path format Duplex loop

Maximum number of networks 239

Number of stations per network 65 stations

(Remote master stations: 1, Remote I/O stations: 64) *2

Overall distance 30 km

10Mbps

Sl optical cable: 500 m

H-PCF optical cable: 1 km

Broad-band H-PCF optical cable:

1 km

QSl optical cable: 1 km

GI-50/125optical

cable: 2 km

Distance between

stations *3

25Mbps

Sl optical cable: 200 m

H-PCF optical cable: 400m

Broad-band H-PCF optical cable:

1 km

QSl optical cable: 1 km

Network cable Optical fiber cable (procured by user *4)

Applicable connector 2-core optical connector plug (procured by user *4)

Base unit installation position CPU slot

5 VDC internal current

consumption 0.89A

External dimensions 98 (3.86) (H) 27.4 (1.08) (W) 90 (3.54) (D) [mm(inch)]

Weight 0.15kg

*1: The remote master station includes the multiplexed remote master station and multiplexed

remote sub-master station.

*2: On a multiplexed remote I/O network, one of 64 remote I/O stations works as a multiplexed

remote sub-master station.

*3: There are restrictions on the distance between stations, being determined according to the

type of cable. Refer to the Q Corresponding MELSECNET/H Network System Reference

Manual (Remote I/O network) for details.

*4: Specialized skill and specific tools are required to connect the connector to the optical-fiber

cable; the connector itself is a custom product. Please contact your nearest Mitsubishi

Electric System Service Corporation when purchasing these items.

For general specifications of the network module, refer to the user's manual for the CPU that is

to be used.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mitsubishi Steuereinheit Handbücher

Mitsubishi

Mitsubishi A8GT-50KBF Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-L Series Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC QJ71C24N Bedienungsanleitung

Mitsubishi

Mitsubishi AJ71PB92D Bedienungsanleitung

Mitsubishi

Mitsubishi Wi-Fi Control Bedienungsanleitung

Mitsubishi

Mitsubishi A1SD75M3 Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-A AJ71DN91 Bedienungsanleitung

Mitsubishi

Mitsubishi FR-A5ND Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC L Series Bedienungsanleitung

Mitsubishi

Mitsubishi Q62HLC Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-F FX-1GM Montageanleitung

Mitsubishi

Mitsubishi AL-ASI-BD Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC L Series Bedienungsanleitung

Mitsubishi

Mitsubishi AJ65SBT2B-64AD Bedienungsanleitung

Mitsubishi

Mitsubishi MAC-588IF-E Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC System Q Bedienungsanleitung

Mitsubishi

Mitsubishi MELSECNET/10 A1SJ72QLP25 Bedienungsanleitung

Mitsubishi

Mitsubishi M80 series Einrichtungshandbuch

Mitsubishi

Mitsubishi A1S62TCRTBW-S2 Bedienungsanleitung

Mitsubishi

Mitsubishi L Series Bedienungsanleitung

Mitsubishi

Mitsubishi MELDAS MDS-C1 Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC A1S64AD Bedienungsanleitung

Mitsubishi

Mitsubishi MELSEC-A A1S68AD Bedienungsanleitung

Mitsubishi

Mitsubishi Melsec-A AJ65SBT Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
