MJ LED LIGHTNING MJ-3372 Bedienungsanleitung

LED Studio Light-723

MJ-3372

User Manual

======PROFESSIONAL LED LIGHTING ========

Thank you for choosing our LED studio light. For the sake of your safety, Please

read and follow these instructions carefully and keep this manual in a safe place for

future reference.

Important notice:

Before open the LED studio light and if you want to do the repair

work, please make sure the power source is at the separation

condition.

Unceasingly carries on the product improvement about our company

the policy, in this instruction booklet carries the data will have the

possibility to be able to change in the future, when no longer separate

notice change matters concerned. Our company retains when the

product improvement changes the related specification the authority.

This instruction booklet publisher cannot be responsible regarding

this instruction booklet in information accuracy, also cannot the

related consequence which causes regarding these information be

responsible.

IV. Technical Parameters

Voltage: AC100-240V, 50Hz/60Hz

Power Consumption: 216Watts

LED: 3W*72pcs white LED

LED Current: 700mA / 1 pc

LED Beam Angle: 45°

LED Lifetime: 80,000-100,000 hours

Color: white color

Dimming: 0-100% smooth dimmer

Strobe: 10 Flashes per second

Operation Modes: DMX512, Master-slave, Internal Program

DMX Control: 2 Channels

Control Panel: Digital 4 Character Alphanumeric

Maximum Ambient Temperature: 40° C

Net Weight: 7.5 Kg

Gross Weight:8.8Kg

Package Size: 49×40×23.5CM

V. DMX function

2CH mode

Channel Value Function

CH1 0-255 Main dimming from dark to bright

CH2 0-255 Control strobe from slowly to quickly

Warning:

Please do NOT connect the power cable hand by hand over 4pcs.

I. Installation

1. In order to secure the safe installation of the light, always use it in the

well-ventilated environment.

2. Always keep this light with a safe distance from any flammable

materials.

3. Never install, dismantle and maintain this light when it is powered; and

all work aforesaid must be conducted by professionals.

4. The packing list of this light is as follows:

1) LED studio light --------------------------------------1pcs

2) Power cable---------------------------------------------1pcs

2) User manual------------------------------------------1pcs

II. Effect

1. This light operation is very simple, Attractive appearance, Humanized

design, Dim without flicker and shake, Energy-efficient, Durable. It is

suitable for photography, television stations, stage, dance hall, KTV, bar,

evening show.

2. The program of this light can automatically operate, sound, accept

DMX512 signal control and be connected for use.

III. Menu display function table

Please press “Menu” button to choose function , and press

“Enter” button to confirm.

No. Display Function

1 A001 A001—A512 (2 channel) press “UP” and “Down”

button change the DMX address

2 DE00 DE01—DE99 (Color change by Pulse), press

“UP” and “Down” button change the Pulse speed

3 U000 U000—U255 (white dimming by hand)
