INSTALLATION & MAINTENANCE MANUAL

POTHB1 / POTHB2

These instructions should be read carefully and retained after installation by the end user for

future reference and maintenance.

These instructions should be used to aid installation of the following products:

POTHB1 / POTHB2

GENERAL INSTRUCTIONS

• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)

and current Building Regulations. If in any doubt, consult a qualified electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the

circuit cable, fuse, or circuit breaker

• Please note the IP (Ingress Protection) rating of this product when deciding the location for installation

• Do not overload this accessory or subject it to conditions outside its rating

• This product is for indoor use only

• This product is Class I and must be earthed

• This product is IP65 rated

SAFETY

INSTALLATION

Note – Microwave sensors may not be suitable for all installations, for example enclosed spaces, as they are

able to detect movement through non-metallic surfaces like plasterboard and thin doors.

Suspension mounting

• To suspend the fitting, screw the mounting hoop into the top of the luminaire (see Fig. 1) then secure using

suitable fixing accessories.

INSTALLATION & MAINTENANCE MANUAL

These instructions should be read carefully and retained after installation by the end user for future reference and

maintenance.

These instructions should be used to aid installation of the following products:

PROHB1 / PROHB2

SAFETY

•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations

(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician

•Please isolate mains prior to installation or maintenance

•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of

the circuit cable, fuse, or circuit breaker

•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation

•Do not overload this accessory or subject it to conditions outside its rating

•This product is for indoor use only

•This product is Class I and must be earthed

•This product is IP65 rated

INSTALLATION

Note – Microwave sensors may not be suitable for all installations, for example enclosed spaces, as they are able

to detect movement through non-metallic surfaces like plasterboard and thin doors.

Suspension mounting

•To suspend the fitting, screw the mounting hoop into the top of the luminaire (see Fig. 1) then secure

using suitable fixing accessories.

Screw down mounting hoop

Fig. 1

Bracket mounting

•Using the PROHB1BRAC or PROHB2BRAC mounting bracket as a template (sold separately), mark

the location of the fixing holes, drill 2 x 10mm holes ensuring not to infringe with any joists, gas or water

pipes or electrical cables

•Using a hammer, tap the expansion bolts provided into the 10mm fixing holes (see Fig 2)

•Align the mounting bracket with the with the expansion bolts, attach the nuts and washers to the bolts

and tighten securely to the surface

Fig. 1

Fig. 2

Bracket mounting

• Using the POTHB1BRAC or POTHB2BRAC mounting bracket as a template (sold separately), mark the

location of the fixing holes, drill 2 x 10mm holes ensuring not to infringe with any gas / water pipes or

electrical cables

• Using a hammer, tap the expansion bolts provided into the 10mm fixing holes (see Fig. 2)

• Align the mounting bracket with the with the expansion bolts, attach the nuts and washers to the bolts and

tighten securely to the surface

Fig. 2

•Align the luminaire with the holes on the sides of the bracket then adjust to the desired angle using the

screws and nuts attaching the main body to the bracket (see Fig. 3)

Fig. 3

WIRING

•Provide power to the required point of installation

•Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown), Earth

(green/yellow), Neutral (blue)

•Select the desired power output and colour temperature via the switches on the rear of the luminaire

(see Fig. 4)

Fig. 4

•Switch on and check for correct operation.

PROBHBDALI DALI control module

•The luminaire can be connected to a 0-10V dimmer or controlled via DALI (PROHBDALI is required,

control gear and software not supplied)

•Connect the luminaire to the Dali module ensuring the correct polarity is observed: GND (pink), +12V

(black and white), 0-10V (purple) (see Fig. 5)

Fig. 2

•Align the luminaire with the holes on the sides of the bracket then adjust to the desired angle using the

screws and nuts attaching the main body to the bracket (see Fig. 3)

Fig. 3

WIRING

•Provide power to the required point of installation

•Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown), Earth

(green/yellow), Neutral (blue)

•Select the desired power output and colour temperature via the switches on the rear of the luminaire

(see Fig. 4)

Fig. 4

•Switch on and check for correct operation.

PROBHBDALI DALI control module

•The luminaire can be connected to a 0-10V dimmer or controlled via DALI (PROHBDALI is required,

control gear and software not supplied)

•Connect the luminaire to the Dali module ensuring the correct polarity is observed: GND (pink), +12V

(black and white), 0-10V (purple) (see Fig. 5)

• Align the luminaire with the holes on the sides of the bracket then adjust to the desired angle using the

screws and nuts attaching the main body to the bracket (see Fig. 3)

• Provide power to the required point of installation

• Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown), Earth

(green/yellow), Neutral (blue)

• Select the desired power output and colour temperature via the switches on the rear of the luminaire

(see Fig. 4)

Fig. 3

Fig. 2

•Align the luminaire with the holes on the sides of the bracket then adjust to the desired angle using the

screws and nuts attaching the main body to the bracket (see Fig. 3)

Fig. 3

WIRING

•Provide power to the required point of installation

•Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown), Earth

(green/yellow), Neutral (blue)

•Select the desired power output and colour temperature via the switches on the rear of the luminaire

(see Fig. 4)

Fig. 4

•Switch on and check for correct operation.

PROBHBDALI DALI control module

•The luminaire can be connected to a 0-10V dimmer or controlled via DALI (PROHBDALI is required,

control gear and software not supplied)

•Connect the luminaire to the Dali module ensuring the correct polarity is observed: GND (pink), +12V

(black and white), 0-10V (purple) (see Fig. 5)

Fig. 2

•Align the luminaire with the holes on the sides of the bracket then adjust to the desired angle using the

screws and nuts attaching the main body to the bracket (see Fig. 3)

Fig. 3

WIRING

•Provide power to the required point of installation

•Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown), Earth

(green/yellow), Neutral (blue)

•Select the desired power output and colour temperature via the switches on the rear of the luminaire

(see Fig. 4)

Fig. 4

•Switch on and check for correct operation.

PROBHBDALI DALI control module

•The luminaire can be connected to a 0-10V dimmer or controlled via DALI (PROHBDALI is required,

control gear and software not supplied)

•Connect the luminaire to the Dali module ensuring the correct polarity is observed: GND (pink), +12V

(black and white), 0-10V (purple) (see Fig. 5)

WIRING

Fig. 4

• Switch on and check for correct operation.

POTHBDALI DALI control module

• The luminaire can be connected to a 0-10V dimmer or controlled via DALI (POTHBDALI is required, control

gear and software not supplied)

• Connect the luminaire to the DALI module ensuring the correct polarity is observed: GND (pink), +12V (black

and white), 0-10V (purple) (see Fig. 5)

POTHBMS Microwave sensor

•POTHBRC (sold separately) is required to operate the sensor

• Using a screwdriver remove the blanking piece from the centre of the lens

• Insert the sensor into the hole and screw clockwise ensuring a tight seal is made to maintain the IP rating

(see Fig. 6)

Fig. 5

PROHBMS Microwave sensor PROHBMS (sold separately) is required to operate the sensor

•Using a screwdriver remove the blanking piece from the centre of the lens

•Insert the sensor into the hole and screw clockwise ensuring a tight seal is made to maintain the IP

rating (see Fig.6)

Fig. 6

PROHBMS Remote control

•Insert 2 x AAA batteries (not included)

•Adjust sensor settings as required (see table below)

Fig. 5

PROHBMS Microwave sensor PROHBMS (sold separately) is required to operate the sensor

•Using a screwdriver remove the blanking piece from the centre of the lens

•Insert the sensor into the hole and screw clockwise ensuring a tight seal is made to maintain the IP

rating (see Fig.6)

Fig. 6

PROHBMS Remote control

•Insert 2 x AAA batteries (not included)

•Adjust sensor settings as required (see table below)

Fig. 5

Fig. 6

POTHBxL60 60° Lens

•To replace the lens supplied with the luminaire for the optional 60° lens, remove all the screws that attach

the lens to the luminaire and remove the existing lens. Align the replacement lens with the ﬁtting ensuring all

screw holes align including the centre ones, and replace the screws, ensuring a good seal is made. The three

O-rings supplied must be ﬁtted under the screw heads nearest to the centre of the lens. If not using a sensor

attachment, the threaded blanking piece must be transferred from the old lens to the new one.

POTHBRC Remote control

• Insert 2 x AAA batteries (not included)

• Adjust sensor settings as required (see table below)

Settings indicators show which functions have been selected

Function settings

Settings indicator light area shows which functions have been

set

Function settings

WARNING

This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance

testing. Irreparable damage will occur if this instruction is not followed.

GENERAL

This product contains a light source of energy efficiency class E to Regulation (EU) No. 2019/2015 and (UK)

2021 No. 1095.

ON/OFF

Press ON/OFF button until Brightness indicator light is on

or off to turn on the remote or press once to turn the

sensor on/off. When using ON/OFF button all functions

except BRIGHTNESS and SEND are disabled (the remote

control needs to be turned on to change any settings)

BRIGHTNESS

Press to adjust dimming level 70% / 80% / 90% / 100%

SEND

Press to save setting after each change. The indicator light

will illuminate to confirm the setting. After each setting

change SEND must be pressed to save the setting

HOLD TIME

Press to adjust the hold time 10s / 1min / 10min / 30min

STANDBY DIM

Press to adjust the standby dimming level 10% / 20% /

30% / 50%

STANDBY TIME

Press to adjust standby time +∞ / 1min / 30min / 60min

SENSITIVITY

Press to adjust sensitivity 20% / 50% / 75% / 100%

DAYLIGHT

Press until daylight indicator light is on then press to cycle

through daylight threshold settings 10lx / 30lx / 50lx / 100lx

RESET

Press for factory settings: Brightness 70% / Hold time 10s /

Sensitivity 20% / Daylight level disabled / Standby dimming

level 10% / standby time +∞

Press to increase brightness (0-100%)

Press to reduce brightness (100%-0)

TEST

Press to test the sensor, hold time is 3s all functions

except SENSITIVITY and SEND will be disabled

ON/OFF To turn on the remote control, hold ON/OFF button until brightness

indicator light is on.

Press once to turn the sensor on/off. When the sensor is off, all

functions except BRIGHTNESS and SEND are disabled. The remote

control needs to be turned on to change any settings.

BRIGHTNESS Press to adjust dimming level 70% / 80% / 90% / 100%

SEND Press to save setting after each change. The indicator light will

illuminate to conﬁrm the setting. After each setting change SEND

must be pressed to save the setting

HOLD TIME Press to adjust the hold time 10s / 1min / 10min / 30min

STANDBY DIM Press to adjust the standby dimming level 10% / 20% / 30% / 50%

STANDBY TIME Press to adjust standby time +∞ / 1min / 30min / 60min

SENSITIVITY Press to adjust sensitivity 20% / 50% / 75% / 100%

DAYLIGHT Press until daylight indicator light is on then press to cycle through

daylight threshold settings 10lx / 30lx / 50lx / 100lx

RESET Press for factory settings: Brightness 70% / Hold time 10s /

Sensitivity 20% / Daylight level disabled / Standby dimming level

10% / Standby time +∞

+ Press to increase brightness (0-100%)

- Press to reduce brightness (100%-0)

TEST Press to test the sensor. In test mode, hold time is 3s and all

functions except SENSITIVITY and SEND are disabled

This product contains contains a non-replaceable light source and non-replaceable control gear

Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the

product.

Do not use any source of high-pressure washers to maintain or clean this luminaire.

This product is non-dimmable.

This product should be dismantled for disposal when it reaches the end of its life. Please see website for

dismantling instructions.

This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities

for where facilities exist.

WARRANTY

This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with

the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will

invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place of

purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve the

right to alter product specification without prior notice.

230V 50Hz, IP65, Class 1, 10V Dim, Ta -20~40

AKJAN23_V1

WARRANTY

This product has a warranty of 5 years from date of purchase. Failure to install this product in accordance with

the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will

invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place

of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve

the right to alter product speciﬁcation without prior notice.

WARNING

GENERAL

This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance

testing. Irreparable damage will occur if this instruction is not followed.

This product contains a light source of energy efﬁciency class D to Regulation (EU) No. 2019/2015 and (UK)

2021 No. 1095.

This product contains a non-replaceable light source and non-replaceable control gear

Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the

product.

Do not use any source of high-pressure washers to maintain or clean this luminaire.

This product should be dismantled for disposal when it reaches the end of its life. Please see website for

dismantling instructions.

This product should be recycled in the correct manner when it reaches the end of its life. Check local

authorities for where facilities exist.

Manufacturers Declaration of Conformity

For ML Accessories (Knightsbridge)

Electrical products in accordance with UKCA marking

ML Accessories Ltd. declare that all products have been designed, manufactured, and tested in

accordance with the requirements of the relevant legislation

UKCA marking legislation

UK SI 2016 No. 1091 Electro Magnetic Compatibility Regulations 2016

UK SI 2016 No. 1101 The Electrical Equipment (Safety) Regulations 2016

UK SI 2012 No. 3032 Restriction of the use of Certain Hazardous Substances in Electrical and

Electronic Equipment Regulations 2012

UK SI 2017 No. 1206 Radio Equipment regulations 2017

UK SI 2021 No. 1095 The Ecodesign for Energy-Related Products and Energy

Information (Lighting Products) Regulations 2021

Included Legislation

UK SI 2008 No. 2852 UK REACH

UK SI 2013 No. 3113 WEEE

Safety Standards

Full individual declarations and speciﬁc safety standards applicable to relevant product series can be found on

our website www.mlaccessories.co.uk

We hereby declare that the equipment named above has been designed to comply with the relevant

sections of the above referenced speciﬁcations. The products comply with all essential requirements of

the directives.

Scott Brewer Catherine Connolly

Head of Technical CEO

ML Accessories Ltd. Unit E Chiltern Park, Boscombe Road, Dunstable. Bedfordshire, LU5 4LT

This declaration becomes invalid if technical or operational modiﬁcations are introduced without ML Accessories Ltd. written consent.

Manufacturers Declaration of Conformity

For ML Accessories (Knightsbridge)

Electrical products in accordance with CE marking

ML Accessories Ltd. Declare that all products have been designed, manufactured, and tested in

accordance with the requirements of the relevant legislation

CE marking legislation

In Accordance with the following Directives:

2014/35/EU Low Voltage Directive

2014/30/EU EMC Directive

2014/53/EU Radio Equipment Directive

Including Legislation

1907/2006 REACH

2015/863 RoHS

2021/341 ERP

Safety Standards

Full individual declarations and speciﬁc safety standards applicable to relevant product series can be found on

our website www.mlaccessories.co.uk

We hereby declare that the equipment named above has been designed to comply with the relevant

sections of the above referenced speciﬁcations. The product complies with all essential requirements of

the directives.

Scott Brewer Catherine Connolly

Technical Manager CEO

ML Accessories Ltd. Unit E Chiltern Park, Boscombe Road, Dunstable. Bedfordshire, LU5 4LT

This declaration becomes invalid if technical or operational modiﬁcations are introduced without ML Accessories Ltd. written consent.

AKFEB23_V1

122

SUPPLIED BY:

(UK) MANUFACTURER

ML ACCESSORIES LTD, UNIT E CHILTERN PARK,

BOSCOMBE ROAD, DUNSTABLE LU5 4LT,

WWW.MLACCESSORIES.CO.UK

(EU) AUTHORISED REPRESENTATIVE

SLV LIGHTING GROUP,

DAIMLERSTRASSE 21-23,

52531 ÜBACH-PALENBERG, GERMANY

EMAIL: EPREL@GROUP.SLV.COM

MADE IN CHINA

>80

CRI

-40~

50°C

230V

50Hz IP65

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ML Accessories Beleuchtungsausrüstung Handbücher

ML Accessories

ML Accessories UNDKIT3WWW Bedienungsanleitung

ML Accessories

ML Accessories Knightsbridge EMTWINPC Bedienungsanleitung

ML Accessories

ML Accessories CABBCCW Bedienungsanleitung

ML Accessories

ML Accessories ENM5C Bedienungsanleitung

ML Accessories

ML Accessories WALL1 Bedienungsanleitung

ML Accessories

ML Accessories 12DCIP40 Bedienungsanleitung

ML Accessories

ML Accessories LSPIKEA Bedienungsanleitung

ML Accessories

ML Accessories T8BLED12 Bedienungsanleitung

ML Accessories

ML Accessories SPIKE4BL Bedienungsanleitung

ML Accessories

ML Accessories BA01 Series Bedienungsanleitung

ML Accessories

ML Accessories Knightsbridge SFPL Series Bedienungsanleitung

ML Accessories

ML Accessories SHE1BEM Bedienungsanleitung

ML Accessories

ML Accessories OSPCKIT Bedienungsanleitung

ML Accessories

ML Accessories Knightsbridge SPIKEW Handbuch

ML Accessories

ML Accessories NH023AW Bedienungsanleitung

ML Accessories

ML Accessories LFC24B M Series Bedienungsanleitung

ML Accessories

ML Accessories E27PR Bedienungsanleitung

ML Accessories

ML Accessories RD1 Series Bedienungsanleitung

ML Accessories

ML Accessories SURF236EMHF Bedienungsanleitung

ML Accessories

ML Accessories CFR5CCT Bedienungsanleitung

ML Accessories

ML Accessories Knightsbridge LEDF24RGB Handbuch

ML Accessories

ML Accessories Knightsbridge BT9H4/6K Bedienungsanleitung

ML Accessories

ML Accessories EMLSUS Bedienungsanleitung

ML Accessories

ML Accessories OWALL1 Series Bedienungsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung
