Owner’s

Manual

Bar Refrigerator

with Icemaker

ZIBI240

ZIBS240

Consumer Information

Bar Refrigerator with Icemaker

Introduction

Your new Monogram bar refrigerator with icemaker makes an eloquent statement of

style, convenience and kitchen planning flexibility. Whether you chose it for its purity

of design or the assiduous attention to detail, you will find that your Monogram

bar refrigerator with icemaker’s superior blend of form and function will delight you

for years to come.

The information on the following pages will help you operate and maintain your

bar refrigerator with icemaker properly.

If you have any other questions, visit our Website at: www.monogram.com

Contents

Built-In Dimensions . . . . . . . . . . . . .13, 14

Care and Cleaning . . . . . . . . . . . . . .11, 12

Consumer Services . . . . . . . . . . . . . . . .19

Controls and Features . . . . . . . . . . . .8–10

Installation Instructions . . . . . . . . . .14, 15

Model and Serial Numbers . . . . . . . . . . .2

Problem Solver . . . . . . . . . . . . . . . . .16–18

Product Registration . . . . . . . . . . . . . . . .2

Repair Service . . . . . . . . . . . . . . . . . .3, 19

Safety Instructions . . . . . . . . . . . . . . . .4–7

Warranty . . . . . . . . . . . . . . . . .Back Cover

Before

using your

bar

refrigerator

with

icemaker

Read this manual carefully. It is intended

to help you operate and maintain your

new bar refrigerator with icemaker

properly.

Keep it handy for answers to your

questions.

If you don’t understand something or

need more help, there is a list of toll-free

consumer service numbers included in

the back section of this manual.

Visit our Website at: www.monogram.com

Write

down the

model &

serial

numbers

You will find them on a label on the

ceiling inside the bar refrigerator with

icemaker.

Please write these numbers here:

Model Number

Serial Number

Use these numbers in any correspondence

or service calls concerning your bar

refrigerator with icemaker.

If you received

a damaged

appliance

The warranty does not cover damage

caused after delivery. Immediately contact the dealer (or

builder) that sold you the bar refrigerator

with icemaker.

If you

need

service

To obtain service, see the Consumer

Services page in the back of this manual.

We are proud of our service and want you

to be pleased. If for some reason you are

not happy with the service you receive,

here are steps to follow for further help.

For customers in the USA:

FIRST, contact the people who serviced

your appliance. Explain why you are not

pleased. In most cases, this will solve the

problem.

NEXT, if you are still not pleased, write

all the details—including your phone

number—to:

Manager, Customer Relations

GE Appliances

Appliance Park

Louisville, KY 40225

For customers in Canada:

FIRST, contact the people who serviced

your appliance. Explain why you are not

pleased. In most cases, this will solve the

problem.

NEXT, if you are still not pleased, write

all the details—including your phone

number to:

Manager, Consumer Relations

Camco Inc.

1 Factory Lane, Suite 310

Moncton, N.B. E1C 9M3

Consumer Information

Bar Refrigerator with Icemaker

After

installation

is completed

• Promptly inspect your new Monogram

bar refrigerator with icemaker. If it has

been damaged, contact the Installer or

Dealer immediately.

• This bar refrigerator with icemaker must

be properly leveled to ensure correct

door alignment, door closure and ice

production. Contact the Installer if

the unit is not level.

• The unit should be centered in the

opening. In a standard 24″opening, the

front face of the Stainless Steel door will

be flush with adjacent cabinetry. The

front face of the Custom Panel door

should be 13⁄4″forward of adjacent

cabinetry. Contact the installer if

clearance is not correct.

• Test the door swing. Carefully open and

close the door. The door should not rub

or catch on adjacent cabinetry. Notify the

installer if the door makes contact with

cabinetry.

Please Contact the Installer or Dealer if

you experience any of these problems.

Your custom panel (ZIBI240 model only)

bar refrigerator with icemaker is shipped

with two toekicks, a stainless steel and a

black toekick. For shipping purposes, one

of the toekicks will be secured to the back

of the unit and the second will be installed

on the unit. Keep the unused toekick and

other unused or removed parts for

possible future use.

Remove

packaging

Before using, be sure all packing materials

and tape have been removed.

To assure no damage is done to the finish

of the product, the safest way to remove

the adhesive left from packaging tape on

new appliances is an application of

household liquid detergent. Apply with

a soft cloth and allow to soak. Wipe dry

and then apply an appliance polish to

thoroughly clean and protect the surface.

Save time

& money

Before you request service, check the

Problem Solver in the back of this manual. It lists causes of minor operating problems

that you can correct yourself.

REFRIGERANTS

All refrigeration products contain

refrigerants, which under federal law must

be removed prior to product disposal.

If you are getting rid of an old refrigeration

product, check with the company handling

the disposal about what to do.

wWARNING—When using

this appliance, always exercise basic safety

precautions, including the following:

•Use this appliance only for its intended

purpose as described in this Owner’s

Manual.

•This bar refrigerator with icemaker must

be properly installed in accordance with

the Installation Instructions before it is

used.

•Do not allow children to climb, stand

or hang on the shelves in the bar

refrigerator with icemaker. They

could damage the bar refrigerator with

icemaker and seriously injure themselves.

•Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

•Keep fingers out of the “pinch point”

areas: clearances between the door and

between the door and cabinet are

necessarily small. Be careful closing the

door when children are in the area.

•Unplug your bar refrigerator with

icemaker before cleaning or making

repairs. NOTE: We strongly recommend

that any servicing be performed by a

qualified individual.

•Before replacing a burned-out light bulb,

the bar refrigerator with icemaker should

be turned OFF or unplugged in order to

avoid contact with a live wire filament.

(A burned-out light bulb may break

when being replaced.)

•In bar refrigerators with automatic

icemakers, avoid contact with the moving

parts of the ejector mechanism, or with

the heating element located on the

bottom of the icemaker.

Do not place fingers or hands on the

automatic icemaking mechanism while

the unit is plugged in.

wDANGER: RISK OF CHILD ENTRAPMENT

Child entrapment and suffocation

are not problems of the past. Junked or

abandoned refrigeration products are

still dangerous…even if they will sit for

“just a few days.” If you are getting rid of

your old appliance, please follow these

instructions to help prevent accidents.

Before You Throw Away Your Old

Refrigeration Product:

•Take off the doors.

•Leave the shelves in place so that

children may not easily climb inside.

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

wDANGER! RISQUES POUR LES ENFANTS

Les enfants pris au piège ou morts

d’asphyxie sont toujours d’actualité.

Les appareils de réfrigération abandonés

sont toujours aussi dangereux, même si

on n’attend que “quelque jours” pour

s’en débarasser. Si vous ne gardez pas

votre ancien appareil, veuillez suivre

les directives ci-dessous afin de prévenir

les accidents.

Avant de vous débarasser de votre vieux

appareil de réfrigération :

•Démontez les portes.

•Laissez les clayettes en place afin

d’empêcher les enfants de grimper

à l’intérieur.

RÉFRIGÉRANTS

Tous les appareils de réfrigération

contiennent des refrigerants qui,

conformément aux lois fédérales, doivent

être enlevés avant toute élimination de

l’appareil.

Si vous vous débarrassez de vieux appareils

de réfrigération, vérifiez, auprès de la

société qui s’occupe de leur élimination,

ce que vous devez faire.

IMPORTANTES INSTRUCTIONS DE SÉCURITÉ

LIRE ET CONSERVER CES INSTRUCTIONS

wAVERTISSEMENT—

Lorsque vous utilisez l’appareil,

observez toujours certaines précautions

de base, notamment :

• N’utilisez l’appareil que pour son usage

prévu, comme décrit dans le présent

manuel.

• Installez le réfrigérateur de bar avec

machine à glaçons conformément aux

directives d’installation avant de l’utiliser.

• Ne laissez pas les enfants grimper,

s’asseoir, se tenir debout ni se pendre

aux clayettes du réfrigérateur de bar

avec machine à glaçons. Ils pourraient

endommager le réfrigérateur de bar avec

machine à glaçons et se blesser

gravement.

• N’entreposez et n’utilisez pas d’essence

ou autres vapeurs et liquides inflammables

à proximité de cet appareil ou de tout

autre appareil électroménager.

• Éloignez les doigts des parties du

réfrigérateur où l’on peut facilement se

pincer : les espaces entre les portes et

entre les portes et les placards sont

toujours étroits. Soyez prudent lorsque

vous fermez les portes de l’appareil en

présence des enfants.

• Débranchez votre réfrigérateur de bar

avec machine à glaçons avant de le

nettoyer et de le réparer. REMARQUE :

Nous vous recommandons vivement de

confier toute réparation à un technicien

qualifié.

• Avant de remplacer une ampoule grillée,

le réfrigérateur de bar avec machine à

glaçons doit être débranché afin d’éviter

tout contact avec un fil sous tension.

(Une ampoule grillée peut se briser

pendant l’opération).

•Dans les réfrigérateurs de bar qui ont

une machine à glaçons automatique,

évitez de toucher les pièces mobiles

du mécanisme d’éjection ou l’élément

chauffant situé en bas de la machine

à glaçons.

Ne mettez jamais vos doigts ou vos mains

sur le mécanisme de machine à glaçons

automatique quand votre réfrigérateur

est branché.

HOW TO CONNECT ELECTRICITY

Do not, under any circumstances, cut or

remove the third (ground) prong from the

power cord. For personal safety, this

appliance must be properly grounded.

The power cord of this appliance is equipped

with a 3-prong (grounding) plug which mates

with a standard 3-prong (grounding) wall

outlet to minimize the possibility of electric

shock hazard from this appliance.

Have the wall outlet and circuit checked

by a qualified electrician to make sure

the outlet is properly grounded.

Where a standard 2-prong wall outlet

is encountered, it is your personal

responsibility and obligation to have

it replaced with a properly grounded

3-prong wall outlet.

Use of a GFI (Ground Fault Interrupter)

is not recommended for the bar

refrigerator with icemaker.

The appliance should always be plugged

into its own individual electrical outlet

which has a voltage rating that matches

the rating plate. This provides the best

performance and also prevents overloading

house wiring circuits which could cause a

fire hazard from overheated wires.

DO NOT USE AN

ADAPTER PLUG

TO CONNECT THE BAR

REFRIGERATOR WITH

ICEMAKER TO A 2-PRONG

OUTLET.

DO NOT USE AN

EXTENSION CORD WITH

THIS APPLIANCE.

Never unplug an appliance by pulling on

the power cord. Always grip the plug firmly

and pull straight out from the outlet.

Repair or replace immediately all power

cords that have become frayed or otherwise

damaged. Do not use a cord that shows

cracks or abrasion damage along its length

or at either end.

When moving the appliance, be careful

not to roll over or damage the power cord.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

RACCORDEMENT ÉLECTRIQUE

Ne coupez ni retirez en aucun cas la troisième

broche (mise à la terre) de la fiche du cordon

d’alimentation. Pour votre sécurité, cet

appareil doit être correctement mis à la terre.

Le cordon d’alimentation de cet appareil est

muni d’une fiche à 3 broches (mise à la terre)

qui se branche dans une prise mural ordinaire

à 3 alvéoles (mise à la terre) pour réduire au

minimum les risques du chocs électriques.

Faites examiner la prise de courant et le circuit

par un électricien qualifié pour vous assurer

que la prise est correctement mise à la terre.

Si la prise murale est du type standard à 2

alvéoles, il vous incombe de la faire remplacer

par une prise à 3 alvéoles correctement mise

à la terre.

L’appareil doit toujours être branché dans

sa propre prise de courant, dont la tension

nominale est identique à celle indiquée sur

la plaque signalétique.

L’utilisation d’un disjoncteur de fuite à la

terre est recommandée pour le réfrigérateur

de bar avec machine à glaçons.

Cette précaution est recommandée pour

garantir un rendement optimum et éviter

une surcharge des circuits électriques de la

résidence, ce qui pourrait créer un risque

d’incendie par surschauffe des fils.

N’UTILISEZ JAMAIS

UNE PRISE À

ADAPTATEUR POUR LE

RÉFRIGÉRATEUR DE BAR

AVEC MACHINE À

GLAÇONS À UNE PRISE

BIPOLAIRE.

N’UTILISEZ JAMAIS DE

RALLONGE AVEC CET

APPAREIL.

Ne débranchez jamais l’appareil en tirant le cordon

d’alimentation. Saisissez fermement la fiche du

cordon et tirez droit pour la retirer de la prise.

Réparez ou remplacez immédiatement tout

cordon effiloché ou endommagé. N’utilisez

pas un cordon fendillé ou présentant des

signes d’usure.

Lorsque vous déplacez l’appareil, faites

attention de ne pas la faire rouler sur le cordon

d’alimentation afin de ne pas l’endommager.

IMPORTANTES INSTRUCTIONS DE SÉCURITÉ

CONSERVEZ CES DIRECTIVES

Controls and Features

Bar Refrigerator with Icemaker

Unit

ON/OFF

This pad stops cooling in the bar refrigerator

with icemaker, turns off the temperature

controls and removes power to the light circuit.

NOTE: The icemaker is on a separate

on/off switch. To remove power from the

icemaker See Automatic Icemaker section.

Press this pad for a minimum of 3 seconds

to turn the bar refrigerator with icemaker

on or off, or unplug the unit for long

vacations or absences, or when cleaning

the unit or changing the light bulb.

Temperature

control

The temperature display shows the actual

temperature of the bar refrigerator with

icemaker. The actual temperature may

vary slightly from the set temperature

based on factors such as door openings,

amount of food and room temperature.

To change the temperature setting, press

the WARMER or COLDER pads until you

reach the desired set temperature. After

5 seconds, the display will return to the

actual temperature.

After making adjustments, allow 12 to 24

hours for the bar refrigerator with icemaker

to reach the temperature you have set and

before making any further adjustments.

Temperature Settings

Minimum: 34°F (1.1°C)

Maximum: 45°F (7.2°C)

Glass shelves

Tempered glass shelves in the bar

refrigerator with icemaker are removable

for easy cleaning or for storing larger items.

To remove a shelf, open the door

completely to avoid potential damage to

the gasket. Lift up on the back of the shelf

slightly. Tilt the shelf to one side at an

angle while pulling forward.

To replace a shelf, open the door

completely to avoid potential damage to

the gasket. Tilt the shelf to one side at an

angle and slide toward the back wall,

placing one side onto the shelf support.

Place the other side onto the opposite shelf

support. Ensure rear locking tabs are

engaged. When installed properly, the shelf

will not slide forward when gently pulled.

To remove, lift up on the back of the shelf Tilt the shelf at an angle while removing

or replacing

Place in slots when replacing the shelf

Appearance may vary

NOTE: The icemaker temperature is not displayed.

Child control

lockout

This child control lockout feature

prevents unwanted changes to your

temperature settings.

After the desired temperature is set, the

temperature can be locked. To lock, press

both the +and –pads at the same time for

five seconds. To unlock, press both +and

–pads for five seconds.

Controls and Features

Bar Refrigerator with Icemaker

Automatic

icemaker

The icemaker will produce seven cubes

per cycle—approximately 100–130 cubes

in a 24-hour period, depending on freezer

compartment temperature, room

temperature, number of door openings

and other use conditions.

If the bar refrigerator with icemaker is

operated before the water connection is

made to the water valve, set the icemaker

power switch to O (off).

When the unit has been connected to

the water supply, set the icemaker power

switch to I (on). The green light will

come on.

The icemaker will fill with water when it

cools to 15°F (–10°C). A newly installed

bar refrigerator with icemaker may take

12 to 24 hours to begin making ice cubes.

You will hear a buzzing sound each time

the icemaker fills with water.

Throw away the first few batches of ice to

allow the water line to clear.

Be sure nothing interferes with the sweep

of the feeler arm.

When the bin fills to the level of the feeler

arm, the icemaker will stop producing ice.

It is normal for several cubes to be joined

together.

If ice is not used frequently, old ice cubes

will become cloudy, taste stale and shrink.

If ice cubes get stuck in the icemaker,

the green power light will blink. To

correct this, set the icemaker power switch

to O (off) and remove the cubes. Set the

icemaker power switch to I (on) to restart

the icemaker.

After the icemaker has been turned on

again, there will be a delay of about 45

minutes before the icemaker resumes

operations.

NOTE: In homes with lower-than-average

water pressure, you may hear the icemaker

cycle multiple times when making one

batch of ice.

Icemaker

Feeler Arm

Power Switch

Green

Power Light

Ice storage

bin

To remove, pull the icemaker drawer fully

open and remove the transportable ice

storage bin by lifting up and out.

NOTE: Ice can fall behind the ice storage

bin. Prior to replacing the bin, check for

any fallen ice.

If the ice storage bin is removed from

the refrigerator for an extended period of

time, we recommend setting the icemaker

power switch to O (off).

To replace, grasp the side of the right side

of the bin with the higher edge so that the

angled side is against the drawer front.

Lower the bin into place and close the

drawer.

CAUTION: Failure to install properly

could cause potential damage to the

icemaker.

The ice storage bin is dishwasher safe, top

rack only.

The interior fan is located in the rear

wall of the bar refrigerator with icemaker

and is designed to run continuously to help

maintain the proper cooling temperature.

In most instances, the interior fan will run

when the door is open. However, it will not

operate when the door is opened during a

defrost cycle.

Controls and Features

Bar Refrigerator with Icemaker

tips and

suggestions

The bottom full extension drawer holds

five bottles and is loaded with necks facing

the rear. Tall bottles should not be loaded

on the bottom drawer because they may

prevent the door from closing.

• Do not block the thermistor, located on

the right hand side, just above the top

shelf of the bar refrigerator with icemaker.

Blocking the thermistor could impair the

air circulation and temperature control.

Bottom drawer arrangement

Removing

full

extension

drawer

To remove:

1. Pull the full extension drawer out to the

STOP position.

2. Push the tab on right drawer guide

down while pulling the tab on left guide

up, and pull the drawer out.

To replace:

1. Push the drawer slide arm back into

the unit.

2. Pull the small slide sub assembly

completely forward.

3. Insert the sides of the drawer back

into the guides.

4. Push until the tabs lock into place.

Tab (push tab down on right

drawer guide, pull tab up on

left drawer guide)

NOTE: Make sure the tabs on the full

extension drawer guides are fully engaged

before loading any bottles. Pull the drawers

out all the way to the STOP position and

push back in several times to make sure

locking tabs are properly engaged.

To replace, push drawer slide

arm back into unit

Pull small slide sub assembly

completely forward

Appearance may vary

Interior fan

Ice scoop

The bar refrigerator with icemaker

includes an ice scoop in the ice storage

bin. To maximize ice bin capacity, store the

ice scoop as shown. Do NOT wash the ice

scoop in the dishwasher. For cleaning,

handwash in mild soapy water or use the

baking soda solution noted in Cleaning the

inside section.

Andere Handbücher für ZIBI240

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Monogram Kühlschrank Handbücher

Monogram

Monogram ZDOD240 Bedienungsanleitung

Monogram

Monogram ZDOD240 Bedienungsanleitung

Monogram

Monogram Side-by-Side Stainless Steel Free-Standing Bedienungsanleitung

Monogram

Monogram ZDOD240 Bedienungsanleitung

Monogram

Monogram ZISS480DXASS Bedienungsanleitung

Monogram

Monogram ZIDI240 Bedienungsanleitung

Monogram

Monogram ZIC360 Bedienungsanleitung

Monogram

Monogram Side-by-side stainless Steell Free-Standing... Bedienungsanleitung

Monogram

Monogram ZIDS240HSS Bedienungsanleitung

Monogram

Monogram ZDOG240 Bedienungsanleitung

Monogram

Monogram Monogram ZIS360NRJ Bedienungsanleitung

Monogram

Monogram ZISB360DPII Bedienungsanleitung

Monogram

Monogram ZIPP360NHSS Bedienungsanleitung

Monogram

Monogram Built-in refrigerators Bedienungsanleitung

Monogram

Monogram ZIDI240HII Bedienungsanleitung

Monogram

Monogram Side-by-Side36" Bedienungsanleitung

Monogram

Monogram Bottom-Freezer Built-In Refrigerators Bedienungsanleitung

Monogram

Monogram zis420nh Bedienungsanleitung

Monogram

Monogram ZIK30GNHAII Bedienungsanleitung

Monogram

Monogram ZIS480NRF Bedienungsanleitung

Monogram

Monogram ZISS420DHSS Gebrauchsanweisung

Monogram

Monogram WX08X10002 Bedienungsanleitung

Monogram

Monogram ZIR36N LH Bedienungsanleitung

Monogram

Monogram ZISB360DRF Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
