Monoprice 34898 Bedienungsanleitung

HDMI® and USB KVM Extender

P/N 34898

User's Manual

SAFETY WARNINGS AND GUIDELINES

Please read this entire manual before using this device, paying extra attention to these

safety warnings and guidelines. Please keep this manual in a safe place for future reference.

This device is intended for indoor use only.

Do not expose this device to water or moisture of any kind. Do not place drinks or

other containers with moisture on or near the device. If moisture does get in or on

the device, immediately unplug it from the power outlet and allow it to fully dry

before reapplying power.

Do not touch the device, the power cord, or any other connected cables with wet

hands.

Do not expose this device to excessively high temperatures. Do not place it in, on,

or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it in direct

sunlight.

Do not subject the product to extreme force, shock, or fluctuations in temperature

or humidity.

Prior to operation, check the unit and power cord for physical damage. Do not use if

physical damage has occurred.

Before plugging the unit into a power outlet, ensure that the outlet provides the

same type and level of power required by the device.

Unplug this device from the power source when not in use.

Take care to prevent damage to the power cord. Do not allow it to become

crimped, pinched, walked on, or become tangled with other cords. Ensure that the

power cord does not present a tripping hazard.

Never unplug the unit by pulling on the power cord. Always grasp the connector

head or adapter body.

Ensure that power is turned off and disconnected before making any electrical

connections.

Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or

detergents. For stubborn deposits, moisten the cloth with warm water.

This device has no user serviceable parts. Do not attempt to open, service, or

modify this device.

INTRODUCTION

Thank you for purchasing this HDMI® and USB KVM Extender! This Keyboard-Video-Mouse

extender can extend high resolution HDMI video and USB 2.0 signals to distances up to 164

feet (50 meters) over a single Cat6 Ethernet cable with zero latency. It supports video

resolutions up to 1080p@60Hz and is compliant with the HDMI 1.4b, HDCP 1.4, and USB 2.0

specifications. It also supports the Power over Cable (PoC) feature, which allows either unit

to draw power over the Ethernet cable, so you only need a single AC power adapter.

FEATURES

Supports video resolutions up to 1080p@60Hz

Compliant with the HDMI 1.4b and HDCP 1.4 specifications

Includes an HDMI loop-out on the transmitter for use with a local display

Compliant with the DVI standard

Supports USB 2.0

Zero latency and uncompressed transmission technology

Supports up to 7.1 channels of high-definition compressed and uncompressed audio,

including LPCM, DTS-HD Master Audio™, and Dolby TrueHD™

CUSTOMER SERVICE

The Monoprice Customer Service department is dedicated to ensuring that your ordering,

purchasing, and delivery experience is second to none. If you have any problem with your

order, please give us an opportunity to make it right. You can contact a Monoprice

Customer Service representative through the Live Chat link on our website

www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun: 9am-

6pm PT) or via email at [email protected]

PACKAGE CONTENTS

Please take an inventory of the package contents to ensure you have all the items listed

below. If anything is missing or damaged, please contact Monoprice Customer Service for a

replacement.

1x KVM Transmitter

1x KVM Receiver

1x AC Power Adapter (12 VDC, 1A)

1x User's Manual

PRODUCTION OVERVIEW

Transmitter

1. POWER: The POWER LED illuminates when power is applied.

2. HDMI: The HDMI® LED illuminates when there is an active HDMI input signal.

3. USB: The USB LED flashes slowly there is no USB signal being transmitted and

flashes rapidly when USB data is being transmitted.

4. DC 12V: DC barrel connector for connecting the included AC power adapter.

5. HDMI IN: HDMI® connector for connecting the HDMI video source.

6. HDMI OUT: HDMI loop output connector for connecting a local display.

7. CAT5e/6 (POC): RJ45 jack for connecting an Ethernet cable (not included) to the

receiver.

8. USB: USB Type-B port for connecting the host PC.

Receiver

1. POWER: The POWER LED illuminates when power is applied.

2. HDMI: The HDMI® LED illuminates when there is an active HDMI input signal.

3. USB: The USB LED flashes slowly there is no USB signal being transmitted and

flashes rapidly when USB data is being transmitted.

4. DC 12V: DC barrel connector for connecting the included AC power adapter.

5. HDMI OUT: HDMI connector for connecting the remote display.

6. CAT5e/6 (POC): RJ45 jack for connecting an Ethernet cable (not included) from the

transmitter.

7. USB KEYBOARD: USB port for connecting the remote keyboard.

8. USB MOUSE: USB port for connecting the remote mouse.

SAMPLE CONNECTION DIAGRAM

SPECIFICATIONS

Model

34898

Transmitter Inputs

1x HDMI®, 1x USB Type-B

Transmitter Outputs

1x HDMI, 1x RJ45

Receiver Inputs

1x RJ45

Receiver Outputs

1x HDMI, 2x USB Type-A

Maximum Video Resolution

1080p@60Hz

HDMI Version

1.4b

HDCP Version

1.4

USB Version

2.0

Maximum Transmission Distance

Up to 146 feet (50m)

Color Depth

8 bits/channel (24 bits total)

Audio Support

Up to 7.1 channels high definition

compressed or uncompressed

Input Power

12 VDC, 1A

AC Adapter Input Power

100 ~ 240 VAC, 50/60Hz

Maximum Transmitter Power Consumption

1.92 watts

Maximum Receiver Power Consumption

1.68 watts

Operating Temperature

+32 ~ +104°F (0 ~ +40°C)

Storage Temperature

-4 ~ +140°F (-20 ~ +60°C)

Operating Humidity

20 ~ 90% RH, non-condensing

Dimensions (each)

4.3" x 3.0" x 1.0" (109 x 77 x 25 mm)

Transmitter Weight

7.5 oz. (213g)

Receiver Weight

7.5 oz. (212g)

REGULATORY COMPLIANCE

Notice for FCC

Modifying the equipment without Monoprice's authorization may result in the equipment

no longer complying with FCC requirements for Class B digital devices. In that event, your

right to use the equipment may be limited by FCC regulations, and you may be required to

correct any interference to radio or television communications at your own expense.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Notice for Industry Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

HDMI®, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or

registered trademarks of HDMI Licensing LLC in the United States and other countries.

DTS®, the Symbol, and DTS and the Symbol together are registered trademarks of DTS, Inc.

DTS-HD™ and DTS-HD Master Audio™ are trademarks of DTS, Inc.

Dolby®, Dolby® TrueHD™, Dolby Audio™, and the double-D symbol are trademarks of Dolby

Laboratories.
