ICRUZE LCD DISPLAY
MPC FX LCD-UM
INSTALLATION & USER GUIDE
IMPORTANT NOTE:
The installation of iCruze will disconnect
and cease the normal operation and function
of the factory installed remote mounted CD
changer. And, on select vehicles, may disconnect
and cease the normal operation and function
of the factory installed satellite radio and/or
factory rear seat entertainment systems.
A NOTE FROM THE HEAD MONSTER
Thank you for purchasing the Monster iCruze®
LCD Display—the ultimate iCruze accessory.
The iCruze LCD display is essential to maximizing
the ease of use and playlist navigation for your
i od/iCruze set-up. Your LCD Display highlights
title and artist information on a large, easy-
to-read screen so you’ll never have to guess
which disc and track numbers correspond
to your favorite songs or artists again. It’s
small and compact enough to be mounted
anywhere on your dash and it plugs right
into your main iCruze unit without any tools.
You’ll soon be wondering how you
ever got along without it.
With the Monster iCruze LCD Display, your
iCruze experience will truly be complete...
enjoy the ride!
Monsterously,
Noel Lee,
The Head Monster
Noel Lee,
The Head Monster
LOSS OF CERTAIN EXISTING FUNCTIONS
Use and installation of iCruze requires disconnection and loss
of use of any existing factory installed non-integrated CD-changer
(i.e. trunk, center console, under seat).
iCruze is not compatible with some vehicles that have existing,
factory installed integrated CD changers. Typically this is an in-dash
CD changer. Call your dealer and ask if your factory stereo has a CD
or CD changer port/option on the rear of the stereo. If yes, then
it is iCruze compatible.
Existing factory installed vehicle features, such as Satellite Radio,
DVD entertainment systems, navigation systems and video cameras
may be impacted by or cease to function with use and installation
of iCruze, if these components were connected to the CD
changer port. Check the iCruze in-store selection guide, visit
i odiCruze.com, or call customer service at 1-877-800-8989
(9am–5pm Monday through Friday T) for more details.
INSTALLATION SAFETY PRECAUTIONS & WARNINGS
The iCruze LCD Display is designed to show song title and artist info
at a glance without posing driver distraction. To ensure safe driving
conditions, be sure the time you observe the Display does not
interfere with watching the road.
Monster is not responsible for any damage to your vehicle while
installing iCruze. The wiring and installation of the iCruze requires
technical skill. Monster recommends iCruze installation by a MEC
certifi ed professional car audio technician. If you choose to install
yourself, be aware that specialized car stereo removal tools may
be needed and can be found available for purchase on our
website i odiCruze.com.
Make sure you have purchased the correct Monster Factory•Linx
Interface Cable and/or Module. See the iCruze Factory•Linx in-
store selection guide or visit i odiCruze.com to ensure you have
everything you need to install iCruze in your car. Double check
the iCruze in-store selection guide, visit i odiCruze.com, or call
customer service at 1-877-800-8989 (9am–5pm Monday through
Friday T) for more details.
If your factory stereo is protected by an anti-theft code, have
the code available so you can use your stereo once re-connected.
Consult your car owner’s manual or contact your local car dealer
for more information.
Before installing iCruze, remove the cable from the negative
battery terminal. Failure to do so may cause electrical shock
and/or injury.
iCruze is designed to be installed in the dash near the car stereo.
Installation elsewhere or in a dusty or moist area may cause
problems or product failure.
Many connectors in your car may look the same. Do not force
or alter the cable connectors to fi t. Failure to do so may damage
your vehicle’s electronics, cause shock or fi re.
While installing iCruze, make sure to avoid sharp edges which
can damage wiring. Failure in doing so may cause iCruze to not
work or result in a fi re.
Do not attempt to take iCruze apart. The internal circuits are static
sensitive and contain no user serviceable parts.
IMPORTANT iPOD® FUNCTION NOTES & SAFETY
Monster is not responsible for any lost data on your i od,
even during normal use of this product.
Monster is not responsible for damage caused to your i od
from misuse.
iCruze is compatible with i od models with dock connector.
You should never leave or store your i od in your vehicle
for an extended amount of time. Failure to do so may damage
your i od from heat, cold and moisture extremes. See your i od
manual for acceptable temperature ranges.
For added safety and security while driving, Monster recommends
placing the i od in your glove box or other stow-away location such
as a center console.
Your i od must have certain fi rmware for proper iCruze
compatibility. Minimum: version 1.2 for i od mini, version 1.0
for i od hoto and version 2.2 for i od. Visit apple.com/support
for more information.
When you unplug the i od from the iCruze, you will notice that
the i od will display the iCruze logo for a short time which is normal.
It will revert back to the usual screen shortly after this time period.
The functions and control of your i od may diff er depending
on your radio. iCruze is limited by the available functions of your
radio. I.E.- If your radio does not have a shuffl e/random this feature
will not be available.
iCruze utilizes playlists on your i od to access music. Be sure
to refer to your installation and user guide that came with iCruze
for more details on how to optimize your playlist for use with
the main iCruze unit.
INCLUDED ITEMS
(1) iCruze LCD Display
art #153386
BEFORE YOU BEGIN
IMPORTANT: Please completely read and review the installation
guide that came with iCruze BEFORE you begin this installation
for steps required prior to LCD Display installation.
Because iCruze emulates a CD changer, if your vehicle currently
has a CD changer installed, it will need to be unplugged for
the iCruze to operate. Should you experience a problem, please
call Customer Service at 1-877-800-8989 (9am–5pm Monday
through Friday T) to report it.
T
T
j
Installation Diagram/ Location Overview
J1PE
J1PE$BCMF
J$SV[F-$%%JTQMBZ J$SV[F
J$SV[F*OUFSGBDF$BCMF
'BDUPSZ
4UFSFP
*OUFSGBDF
.PEVMF
* Example hook-up shown illustrates
how the iCruze LCD Display confi gures
within iCruze installation. Hook-up in
your particular vehicle may vary slightly.
NOTE:
If you had a professional installer install your iCruze, it is highly
recommended you have the iCruze LCD Display professionally
installed. The iCruze LCD Display installation can be very simple,
however, your iCruze may be in a location that’s diffi cult to access.
Unless you can easily access your iCruze and you feel you are
experienced enough to complete the task, professional installation
is recommended.
Step 1
Find a suitable location for your iCruze LCD Display. lease make sure
to clean area on your dash with a clean cloth. The Display can mount
to most any fl at surface with its strong automotive tape.
WARNING:
When mounting the iCruze Display be sure not to mount the display
in such a way that it obstructs your clear view of the road, interferes
with the normal operation of your vehicle’s airbag system, or blocks
your view of the instrument cluster.
Step 2
The iCruze LCD Display
is mounted with the
attached pivoting platform.
The pivoting platform
is designed for use on
horizontal surfaces plus
it tilts and swivels easily for
just the right viewing angle.
iCruze
®
by
Step 2
Step 3
Once you have decided
on your mounting location,
the iCruze LCD Display needs
to be connected to the main
iCruze unit. The connector that
looks like a phone jack simply
plugs into iCruze in the port
labeled DIS LAY OUT. ush
it in until it clicks. ull back
gently on the cable to make
sure the connection is secure.
Step 4
Turn on your car stereo
and select the iCruze.
Test the display connection
and function by verifying
the song title and artist
information on the iCruze LCD
Display. If there is no song title
and artist displayed, recheck
the connection at the iCruze
module. Turn off the key,
unplug and replug the iCruze
LCD Display connector and test again.
Step 3
Step 4
