Montpellier MR90CEMK Bedienungsanleitung

Installation

and

Operating

Instructions

MODELS: MR90CEMK, MR90CEMX,

MR90CMC & MR90CMK

90cm Range Cooker - Electric

Please read these instructions carefully before attempting to install or use this appliance.

It is advisable to keep these instructions in a safe place for future reference.

N.B. Should your appliance require attention, our service agents will not be able to book

a service call without your unique serial number which can be found on the last page of

this manual.

montpellier

(Picture indicative of model supplied)

roduc

ion

Thank you for choosing this montpellier branded appliance.

It has been designed to give years of trouble-free use provided

it is installed and maintained correctly.

Please read these instructions carefully before installing or

using your appliance. It is advisable to keep your purchase

and

installation receipts with these instructions in a safe place for

future reference. Included is some important safety informat

ion

in addition to guidelines and recommendations that will enab

you to take full advantage of all the functions available.

This quality appliance has been tested and certified to meet all

applicable UK electrical and safety standards.

This appliance must be installed and connected in

accordance with current regulations.

After unpacking the appliance ensure that there is no visible

damage. If the appliance has been damaged during transit, do

not use it, contact your retailer immediately.

Your 2 year Manufacturer's guarantee

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.

Your new montpellier appliance carries a free guarantee which protects

you against the cost of repairs during the first 24 months from date of

purchase provided that:

Any claim is accompanied by evidence of the model reference, model serial

number and proof of purchase, such as a Sales Receipt, showing that the

appliance was purchased within the 24 months prior to the date of claim.

What is not covered under the Guarantee:

Any appliance not correctly installed and operated in accordance with the

manufacturer's instructions.

Any appliance that is used for anything other than domestic purposes.

Any defect caused by accident, misuse, unauthorized modification or

inexpert repair.

Cost of Call-out where a fault cannot be found with the appliance.

Cost of Call-out for work covering routine maintenance, such as, but not

exclusively, cleaning of filters or defrosting.

Cost of Call-out for work required to correct the alignment of doors

following door reversal procedures carried out by you.

Use of the appliance by anyone other than the Householder.

Use in any commercial environment.

Consumable items, such as, but not exclusively, fuses in plugs, bulbs and

breakable items which require routine replacement.

Repair costs incurred that have not been authorised by Repairtech and/or

carried out by a non-approved Repairtech engineer.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack and

return it with a stamp affixed or Alternatively you can Register online at

www.repairtechuk.com

SERVICE HELP-LINE

Should your appliance develop a fault, please call the

Repairtech Service Helpline on:

01527-888133

Please remember to have all your product details available, including the model

number, serial number, date of purchase and your retailer’s details before

registering a fault.

Your service call cannot progress without this information.

Description

The

Appliance

CONTENTS:

Section 1. Installation

Sect

n 2.

Safety

Section 3. Operating the Appliance

Section 4. Maintenance

Section

Installation

Remove all packaging, protective film and securing tape from

the appliance.

Position the appliance in a dry atmosphere.

The following dimensions are provided as a guide for

installation – your installer will carry out the installation in

accordance with the current regulations.

Your installer will connect the power cable in accordance with

the current regulations.

1.1. Positioning the Appliance

Position the appliance as shown in the diagram below.

Ensure an air gap of at least 2cm on all sides of the appliance.

You must ensure a minimum gap of 65cm between the top of

the appliance and a cooker hood. The gap must be 70cm if

there is no cooker hood installed above the appliance.

1.2. Electrical Connection

This appliance must be ‘hard wired’ into a suitable

fused spur adjacent to the appliance housing, by a Qualified

Electrician.Please note that a switchable spur should be accessible

above the work surface in order that the power can be turned

off by the consumer.

Your installer will supply and use the appropriate diameter of

electrical cable based on the Power Rating of the appliance as

shown on the Rating Label affixed to the appliance.

Electrical Connection Diagram:

1.3. Level the Appliance

Finally, ensure that the appliance is level by adjusting the 4

feet as shown below.

Section 2. Safety Advice

-Please read this booklet thoroughly before installing and

switching on the appliance. The manufacturer accepts no

responsibility for incorrect installation and usage.

-This appliance is guaranteed for Domestic Use Only.

-The appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning the use of the

appliance by a person responsible for their safety. Children

should be supervised to ensure that they do not play with the

appliance.

-This appliance must only be used for cooking/heating food

items. Do not use it for any other purpose.

-If using an adaptor, this must be used in accordance with the

manufacturers instructions and ensure that the electrical

circuit is not overloaded as this could cause overheating.

-Do not twist or bend the cables, and keep them away from hot

surfaces.

-Following installation make sure that the power cable is not

trapped underneath the appliance.

-Keep the appliance surfaces clean. Failure to do this could

lead to the appliance malfunctioning.

-The surface of this appliance will get extremely hot during use.

Take care when using the appliance and keep children well

away.

-The interior and surface of this appliance will remain hot after

it has been turned off. Do not touch or clean the appliance

until it has completely cooled down.

-Never lift this appliance using the door handle or ‘open’ door.

-If the power supply cord is damaged, it must be replaced by

the manufacturer, it’s service agent or similarly qualified

persons in order to avoid a hazard.

Section 3. Operating the Appliance

3.1. Oven Control Panel

1. Oven Function Control Knob

2. Oven Thermostat Operation Light

3. Oven Thermostat Control Knob

4. Digital Timer

5. Rear Left Heat Zone Control Knob

6. Front Left Heat Zone Control Knob

7. Centre Heat Zone Control Knob

8. Front Right Heat Zone Control Knob

9. Rear Right Heat Zone Control Knob

3.2. Cooking & Functions

3.2.1. Operating the Hotplate

Turn the appropriate Heat Zone control knob to the required

heat setting (Position 1 is low and position 6 is high – see

diagram below).

Use only flat bottomed pans.

Never use a pan with a smaller diameter than that of the heat

zone.
