Montpellier CT200 Bedienungsanleitung

Installation

and

Operating

Instructions

MODEL: CT200/CT250

Built-In 2 Zone Ceramic Hob

Please

read

these

instructions

carefully

before

attempting

install

use

this

appliance.

It is

advisable

keep

these

instructions

safe

place

for

future

reference.

(Picture shown for indicative purposes only

)

roduc

ion

Thank you for choosing this

montpellier branded appliance. It

has been designed to give years of trouble-free use provided

it is installed and maintained correctly.

Please read these instructions carefully before installing or

using your appliance. It is advisable to keep your purchase

and

installation receipts with these instructions in a safe place for

future reference. Included is some important safety information

in addition to guidelines and recommendations that will enab

you to take full advantage of all the functions available.

his

quali

applian

has

been

and

ied

all

applicable UK electrical and safety standards.

This appliance must be installed and connected in

accordance with current regulations.

After unpacking the appliance ensure that there is no visib

damage. If the appliance has been damaged during transit,

do not use it, contact your retailer immediately.

Your 2 year Manufacturer's guarantee

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.

Your new montpellier appliance carries a free guarantee which protects you against the cost of

repairs during the first 24 months from date of purchase provided that:

Any claim is accompanied by evidence of the model reference, model serial number and proof of

purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24

months prior to the date of claim.

What is not covered under the Guarantee:

·Any appliance not correctly installed and operated in accordance with the

manufacturer's instructions.

·Any appliance that is used for anything other than domestic purposes.

·Any defect caused by accident, misuse, unauthorized modification or inexpert repair.

·Cost of Call-out where a fault cannot be found with the appliance.

·Cost of Call-out for work covering routine maintenance, such as, but not exclusively,

cleaning of filters or defrosting.

·Cost of Call-out for work required to correct the alignment of doors following door

reversal procedures carried out by you.

·Use of the appliance by anyone other than the Householder.

·Use in any commercial environment.

·Consumable items, such as, but not exclusively, fuses in plugs, bulbs and breakable

items which require routine replacement.

·Repair costs incurred that have not been authorised by Repairtech and/or carried

out by a non-approved Repairtech engineer.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack and return it with a

stamp affixed or Alternatively you can Register online at www.repairtechuk.com

SERVICE HELP-LINE

Should your appliance develop a fault, please call the

Repairtech Service Helpline on:

01527-888133

Please remember to have all your product details available, including the model number, serial

number, date of purchase and your retailers’details before registering a fault.

Your service call cannot progress without this information.

Description

the

Appliance

1. Dual Cook Zone

2. Large Cook Zone

3. Touch Controls

(Picture shown is for indicative purposes only)

CONTENTS:

Section 1. Installation

Section 2. Safety Advice

Section 3. Operating the Appliance

Section 4. Maintenance

Section

Installation

-Remove all packaging, protective film and securing tape from the appliance.

-Position the appliance in a dry atmosphere.

- The following dimensions are provided as a guide for installation –your installer will

carry out the installation in accordance with the current regulations.

- Your installer will connect the power cable in accordance with the current regulations.

To install this appliance, please proceed as follows:

1.1. Work-Surface Cut-Out & Position Near Walls

1.2. Securing the Hob

Apply the one sided self-adhesive sealing tape supplied all the way around the lower

edge of the cooking surface along the outer edge of the glass ceramic panel.

Now position the hob into the work surface cut-out to secure it into place.

Adjoining Walls

A(mm)

B(mm)

Combustible 60 150

Non-combustible 40 50

1.3. Electrical Connection

This appliance can be fitted with a 13 amp plug and plugged into a standard 13 amp

socket.

We recommend that this appliance is ‘hard wired’to a suitable fused point adjacent to

the appliance housing and protected with a 20 amp fuse. Please note that a

switchable spur should be accessible above the work surface to allow the power to

be turned off by the consumer.

Your installer will connect this appliance in accordance with current regulations.

The wires in the mains lead are coloured in accordance with the following code:

Brown = L (Live), Blue = N (Neutral), Green/Yellow = Earth

If not supplied with a fitted cable, you should connect the power supply to the

appliance as follows:

Section 2. Safety Advice

-Please read this booklet thoroughly before installing and switching on the

appliance. The manufacturer accepts no responsibility for incorrect

installation and usage.

-This appliance is guaranteed for Domestic Use Only.

-The appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning the use of the appliance by a person responsible for their

safety. Children should be supervised to ensure that they do not play with

the appliance.

-This appliance must only be used for cooking/heating foods and liquids.

Do not use it for any other purpose.

-If using an adaptor, this must be used in accordance with the

manufacturers instructions and ensure that the electrical circuit is not

overloaded as this could cause overheating.

-Do not twist or bend the cables, and keep them away from hot surfaces.

-Following installation make sure that the power cable is not trapped

underneath the appliance.

-Keep the appliance surfaces clean. Failure to do this could lead to the

appliance malfunctioning.

-The surface of this appliance will get hot during use. The surface of this

appliance will remain hot after it has been turned off. Do not touch or

clean the heating zone until it has completely cooled down.

-If the power supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order to

avoid a hazard.

Section 3. Operating the Appliance

3.1. Control Panel

3.2. Timer, Power and Cooking Functions

Switching the appliance on:

Switch the hob on by touching the ON/OFF key . All heater displays show a static

“0”and the bottom right dot will blink. If no cooking zone is selected within 10

seconds, the hob will automatically turn off.

Switching the appliance off:

Switch the appliance off at any time by touching .

Switching the cooking zones on:

Touch the heater selection key corresponding to the zone you wish to cook on. There

is a static dot indication of the selected heater display and a blinking dot on all other

displays.

Select the temperature by using the increase setting key or decrease setting

key . The heat selection buttons must be pressed within 3 seconds, or the heater

selection will be cancelled. The element is now ready to cook.

Dual-Oven

Zone Heater

Rear Heat

zone Heat Setting Child Lock

Front Heat Zone Heat Setting Timer On-Off

Switching the cooking zones off:

A cooking zone can be turned off in 3 different ways:

·Simultaneous operation of the and keys.

·Reducing the heat setting to “0”by operating key.

·Use of the timer turn off function.

If the cooking zone is hot, “H”will be displayed instead of “0”.

Dual Zone Function:

The dual zone function can be activated by selecting the Dual Zone Selector key. The

extension zone can only be activated after a heat level of 1-9 is selected.

Heat Boost Function:

All heat zones are equipped with a heat boost function.

If the heat boost function is active then the heat zone will operate with maximum

power for the period of the heat boost time. This is indicated through a flashing “A”,

alternating with the heat setting value on the heater display. Once the heat boost time

has ended only the heat setting will be shown.

If the heat boost is to be used for a heat zone, heat level 9 must be selected by

pressing starting from level 0. After this “A”should alternately be displayed. The

heat boost can be turned off by pressing until heat setting “0”appears. The heat

boost can be activated again by pressing if the heat setting is set to 9. The display

will flash “A/9”.

Operating Time Limitation:

Every cooking zone will be switched off after a defined maximum operation time if the

heat setting is not modified. Every change in the cooking zone resets the timer of the

safety switch off function. The maximum operation time depends on the selected

temperature level.

Sensor Safety Cut Off:

To prevent the appliance from unwanted, random sensor operation, a sensor monitor

is included. In case one or more buttons are held for longer than 12 seconds, the

appliance will make a sound and switch off. The safety turn off causes the display to

flash “F”on all heaters displays.

Over Temperature Switch Off:

As the control panel is located fairly near a heat zone it is possible for an incorrectly

placed pan to heat up the glass of the control panel and cause damage. If this area

gets too hot it will switch off automatically and be indicated on the heater display with

the letter “t”until the temperature decreases.
