montpellier MCH59CK Bedienungsanleitung
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
59cm Ceramic Hob - Side Control
MCH59CK
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
We recommend that you keep this manual in a safe place for future
reference.
Your appliance is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your
appliance, you can rest assured that you are fully protected against the cost of
repairs for the first 24 months . Please note that any claim must be accompanied
by the model reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can
be found inside your appliance.
NB: Please make sure that you keep a copy of your original sales invoice as this
will be needed if any service call is required.
There are three ways to register your Guarantee:
•
•
Online: Visit the Support page on our website and complete the online
Product Registration form. www.montpellier-appliances.com
By Post: Simply detach and fill in the form provided, attach a stamp and send
it in the post. Don't forget to include your e-mail address so that we can send
confirmation through to you.
By Phone: Contact our warranty registration department on 0808 1961388
Welcome
Thank you for choosing this Montpellier appliance.
Our appliances have been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing or
using your appliance to ensure you get the most from your purchase.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
•
Thank you for choosing this product.
This User Manual contains important safety information and instructions on the operation and
maintenance of your appliance.
Please take the time to read this User Manual before using your appliance and keep this book for
future reference.
The design and specifications are subject to change without prior notice for product improvement.
THANK YOU LETTER
Thank you for choosing Montpellier! Before using your new Montpellier product, please
read this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance offers in a safe way.
1
CONTENTS
THANK YOU LETTER
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT INSTALLATION
PRODUCT OVERVIEW
QUICK START GUIDE
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
DISPOSAL AND RECYCLING
HERE FOR YOU
1
2
5
6
10
12
14
16
17
18
19
Intended Use
The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe
or incorrect operation of the appliance. Please check the packaging and appliance on arrival to
make sure everything is intact to ensure safe operation. If you find any damage, please contact
the retailer or dealer. Please note modifications or alterations to the appliance are not allowed
for your safety concern. Unintended use may cause hazards and loss of warranty claims.
SAFETY INSTRUCTIONS
2
SAFETY WARNINGS
Electrical Shock Hazard
Your safety is important to us. Please read this information before using your cooktop.
INSTALLATION
•Disconnect the appliance from the mains electricity supply before carrying out any work or
maintenance on it.
•Connection to a good earth wiring system is essential and mandatory.
•Alterations to the domestic wiring system must only be made by a qualified electrician.
•Failure to follow this advice may result in electrical shock or death.
Cut Hazard
•Take care - panel edges are sharp.
•Failure to use caution could result in injury or cuts.
Important Safety Instructions
•Read these instructions carefully before installing or using this appliance.
•No combustible material or products should be placed on this appliance at any time.
•Please make this information available to the person responsible for installing the appliance as
it could reduce your installation costs.
•In order to avoid a hazard, this appliance must be installed according to these instructions for
installation.
•This appliance is to be properly installed and earthed only by a suitably qualified person.
•This appliance should be connected to a circuit which incorporates an isolating switch providing
full disconnection from the power supply.
•Failure to install the appliance correctly could invalidate any warranty or liability claims.
•This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
OPERATION AND MAINTENANCE
Electrical Shock Hazard
•Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack,
switch the appliance off immediately at the mains power supply (wall switch) and contact a
qualified technician.
•Switch the cooktop off at the wall before cleaning or maintenance.
•Failure to follow this advice may result in electrical shock or death.
•Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
•WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric
shock, for hob surfaces of glass-ceramic or similar material which protect live parts.
•Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface
since they can get hot.
•A steam cleaner is not to be used.
•Do not use a steam cleaner to clean your cooktop.
•The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
•WARNING: Danger of fire: do not store items on the cooking surfaces.
•The cooking process has to be supervised. A short term cooking process has to be supervised
continuously.
•WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame
e.g. with a lid or a fire blanket.
3
•During use, accessible parts of this appliance will become hot enough to cause burns.
•Do not let your body, clothing or any item other than suitable cookware contact the glass
until the surface is cool.
•Keep children away.
•Handles of saucepans may be hot to touch. Check saucepan handles do not overhang other
cooking zones that are on. Keep handles out of reach of children.
•Failure to follow this advice could result in burns and scalds.
Hot Surface Hazard
Cut Hazard
•The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted. Use
with extreme care and always store safely and out of reach of children.
•Failure to use caution could result in injury or cuts.
Important safety instructions
•Never leave the appliance unattended when in use. Boil over causes smoking and greasy spill
overs that may ignite.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Never use your appliance for warming or heating the room.
•After use, always turn off the cooking zones and the cooktop as described in this manual.
•Do not allow children to play with the appliance or sit, stand, or climb on it.
•Do not store items of interest to children in cabinets above the appliance. Children climbing on
the cooktop could be seriously injured.
•Do not leave children alone or unattended in the area where the appliance is in use.
•Children or persons with a disability which limits their ability to use the appliance should have a
responsible and competent person to instruct them in its use. The instructor should be satisfied
that they can use the appliance without danger to themselves or their surroundings.
•Do not repair or replace any part of the appliance unless specifically recommended in the
manual. All other servicing should be done by a qualified technician.
•Do not place or drop heavy objects on your cooktop.
•Do not stand on your cooktop.
•Do not use pans with jagged edges or drag pans across the Induction glass surface as this can
scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as
these can scratch the ceramic glass.
•This appliance is intended to be used in household and domestic applications only.
•WARNING: The appliance and its accessible parts become hot during use.
•Care should be taken to avoid touching heating elements.
•Children less than 8 years of age shall be kept away unless continuously supervised.
4
SPECIFICATIONS
MCH59CK
Cooking Hob
Cooking Zones
Supply Voltage
Installed Electric Power
Product Size L×W×H(mm)
Building-in Dimensions A°B (mm)
4 Zones
220-240V~ 50Hz or 60Hz
5500-6600W
590X520X55
Weight and Dimensions are approximate. Because we continually strive to improve our
products we may change specifications and designs without prior notice.
560X490
5
6
PRODUCT INSTALLATION
Selection of Installation Equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5cm space shall be preserved around
the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-
resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material
shall not be used as work surface material unless impregnated) to avoid the electrical shock
and larger deformation caused by the heat radiation from the hotplate. As shown below:
Note: The safety distance between the sides of the hob and the inner surfaces of the
worktop should be at least 3mm.
590
L(mm)
520
W(mm)
55
H(mm)
51
D(mm)
560±4
A(mm)
490±4
B(mm)
50 min
X(mm)
3 min
F(mm)
LW
x
x
x
B
Min. 3mm
F
SEAL
DH
A
7
There are ventilation holes around outside of the hob. YOU MUST ensure these holes
are not blocked by the worktop when you put the hob into position.
•Be aware that the glue that joins the plastic or wooden material to the furniture, has
to be resist to a temperature not below 150°C, to avoid unstucking of the paneling.
•The rear wall, adjacent and surrounding surfaces must therefore be able to
withstand a temperature of 90°C.
WARNING: Ensuring Adequate Ventilation
Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. In
order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable
electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a
minimum distance of 50mm from the bottom of the hob. Follow the requirements below.
Min. 50mm
Max. 5mm Max. 5mm
Note: The safety distance between the hotplate and the hood/cupboard above the hotplate
should be at least 650mm (refer to the installation instructions for hoods as the measurements
may vary).
650
A(mm)
50 min
B(mm)
20 min
C(mm)
Air intake
D
Air exit 5mm
E
A
BEE
C
D
wall
Min.30mm
650mm
Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air
inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As
shown below.
Inhaltsverzeichnis
Andere montpellier Kochfeld Handbücher
montpellier
montpellier SP601W Bedienungsanleitung
montpellier
montpellier MCH29 Bedienungsanleitung
montpellier
montpellier INT750 Bedienungsanleitung
montpellier
montpellier CT251 Bedienungsanleitung
montpellier
montpellier MON-INT251 Bedienungsanleitung
montpellier
montpellier INT400 Bedienungsanleitung
montpellier
montpellier MON-CER60T15 Bedienungsanleitung
montpellier
montpellier GH60BG Bedienungsanleitung
montpellier
montpellier GH91X Bedienungsanleitung
montpellier
montpellier MON-CT251 Bedienungsanleitung
montpellier
montpellier CS440 Bedienungsanleitung
montpellier
montpellier INT61T15 Bedienungsanleitung
montpellier
montpellier SP200X Bedienungsanleitung
montpellier
montpellier MINH59 Bedienungsanleitung
montpellier
montpellier INT780 Bedienungsanleitung
montpellier
montpellier INT900 Bedienungsanleitung
montpellier
montpellier INT61NT Bedienungsanleitung
montpellier
montpellier MON-CDH2 Bedienungsanleitung
montpellier
montpellier GH71X Bedienungsanleitung
montpellier
montpellier CT750 Bedienungsanleitung
