montpellier MW8014 Bedienungsanleitung
Freestanding Washing Machine
MW8014 - All Colours - 1400RPM - 8kg Load
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
Thank you for choosing this Montpellier Washing Machine.
Our Washershave been designed to provide you with the best combination of style, reliability and performance to
give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing or
using your Washing Machine to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Washing Machine is covered by a comprehensive two year Parts & Labour
Guarantee. In the unlikely event that you experience a problem with your Washer,
you can rest assured that you are fully protected against the cost of repairs for
the first 24 months . Please note that any claim must be accompanied by the
model reference number, serial number and proof of purchase.
To activate your guarantee, you will need your product serial number. This can be
found on the rear of the machine.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS ALL OUR MODELS
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
1
CONTENTS:
Section 1: Safety Instructions 3
4
5/6
Section 2: Installation
7
8
9
10
-Correct Usage
-General Warnings
-Safety Warnings
-Removing Transit Bolts
-Adjusting the Feet
-Electrical Connection
-Water Inlet Hose Connection
-Water Discharge Connection 11
12
Section 3: Technical Specifications
Section 4: Control Panel
-Control Panel
-Detergent Drawer
-Program Knob
13/15
13
14
Section 5: Washing your Laundry
-Preliminary Preparation of Laundry
-Putting Laundry in the Machine
-Adding Detergent to the Machine
-Operating your Machine
-Auxiliary Functions
-Child Lock
-Cancelling a Program
-Finishing a Program
16/17
18
19
19/20
21/22/23
24
24
24
Section 6: Maintenance and Cleaning
25
26
-Water Inlet Filters
-Pump Filters
-Detergent Draw 27
28/29/30
31
32/33
34
Section 7: Troubleshooting
Section 8: Fault Codes
Section 9: Program Table
Here To Help: Service Contact Details:
Description
of
the
Appliance
Transit
Bolt
Water
Inlet
Valve
DischargingHose
Power Cable
Transit Bolt
Transit
Bolt
Transit
Bolt
BEFORE
OPERATING
YOUR
WASHING
MACHINE
YOU MUST
REMOVE THE TRANSIT BOLTS. FAILURE TO DO SO MAY DAMAGE
THE MACHINE AND WILL INVALIDATE YOUR GUARANTEE.
2
Section 1. Safety
Advice
1.1 Correct Usage
Read the user instruction manual.
Your
machine is designed to be used
domestical
ly.
Commercial
use will cause your warranty to be invalid.
Keep pets away from your machine.
Please check the packaging of your machine is in good order before installation, and the
outer surface of
the machine after the package is opened. Do not operate damaged
machines.
Have your machine installed only by a qualified person.
Any interference to your machine
by anyone other than a qualified person will invalidate your
warranty.
The appliance in
not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
Use your machine only for laundry that has been specified as suitable for washing by the
manufacturer.
Before operating the washing machine, remove the 4 transit
bolts and rubber spacers from the back of the machine. If the bolts
are not removed, it will cause heavy vibration, noise and product
malfunction (invalidating the guarantee).
-
Your
machine is not covered under warranty for faults caused by any kind of external
factors (pesticides, fire, etc.).
-
Please do not throw away this user manual: keep it for future reference as it
contains full operating instructions as well as the serial number of your machine.
You will need this should you wish to book a service call.
Note: Specifications may vary depending on the product purchased.
3
1.2 General
Warnings
-
The ambient temperature for your
machine’s
ideal operation is 15
-
25ºC.
-
Frozen hoses can tear and explode. In regions where temperature is below zero, ambient
temperature might
endanger the safe operation of the electronic circuit board.
-
Please ensure that the clothes put into your machine do not contain any foreign objects
(nails, needles, coins, lighters, matches, clips, etc.) in pockets.
These objects can
damage your machine.
It is recommended that the first washing operation is carried out on a
90º Cotton program but without laundry and using ½ the dose of
detergent in the 2nd compartment of the detergent drawer.
- If a detergent or softener is exposed to air for any time, residue may be caused, be sure
to
only put your detergent or softener
in the detergent drawer at the beginning of every wash.
-
It is advised that you unplug your machine and clos
e the water inlet tap if you do not intend
to use the machine for a prolonged period of time.
Also, leaving the door of your appliance
open will prevent the formation of bad odours due to humidity.
-
Some water might be left in your machine after factory trials and tests conducted due to
Quality Control procedures.
This is normal and will not damage your machine.
-
Remember the packaging materials of your machine may be dangerous for children. Keep
the packagi
ng materials in a place where children cannot reach them and dispose of them
appropriately.
-
Keep any small parts away from the reach of
children and babies.
-
Use Pre
-
wash programs only for very dirty
laundry.
-
Never open the detergent compartment when the appliance is running.
- In case of any breakdown, unplug the appliance first and then turn the
water inlet
off.
Do not attempt repair by yourself, always contact the
authorised service agent help line.
-
The amount of laundry you put in your washing machine should not
exceed the maximum amount indicated.
-
Never
force the door to open when the machine is running.
-
Do not wash clothes covered in flour or other powders in your machine as
it will cause damage.
-
Please adhere to detergent/fabric conditioner manufacturer’s advice
regarding the use of fabric conditioner or similar products.
-
Set up your machine in a place where its door can be completely opened.
-
Set up your machine in a position where it can be fully ventilated and
has constant air circulation.
4
1.3 Safety Warnings
You must take note of these warnings, as this can protect you, your
family and the product.
DANGER OF GETTING BURNT!
Do not touch the discharge hose or water during the discharge process
as the appliance can reach high temperatures during operation.
RISK DUE TO ELECTRICAL CURRENT!
lDo not use multi-sockets on an extension lead.
lDo not plug in damaged plugs.
lNever pull the cable when unplugging - always grip the plug itself.
lDo not plug-in or remove the plug with wet hands.
lNever touch the machine with wet hands or feet.
If the mains cable becomes damaged it must be replaced by an
authorised electrician or service agent.
DANGER OF FIRE!
lDo not keep flammable liquids near your machine.
lThe sulphur content of paint removers might cause corrosion. For this
reason, never use paint-removing materials in your machine.
lNever use products that contain solvent material in your machine.
lRemove all objects from the pockets of your laundry (needles,
paperclips, lighters, matches, etc.) before placing it in your machine.
5
1.3 Safety Warnings (continued)
FALL AND INJURY HAZARD!
Do not climb on your machine. The top lid of your machine may
break and you might get injured.
Tidy the hose, cable and packaging of your machine during
installation, to avoid tripping or falling over.
Do not turn your machine upside down or on its side.
Do not lift your machine by holding it from extruding parts
(detergent drawer, door). These parts might break and cause
you to get injured.
There’s the risk of tripping and injury if the materials like hoses
and cables are not properly stored after your machine is installed.
Machine must be carried by 2 people.
CHILD SAFETY!
Do not leave children unattended near the machine. Children
might lock themselves inside.
Door glass and surface may get hot while your machine operates.
And as a result of this, touching the machine might damage the
skin, especially that of children.
Keep packaging material away from children.
Danger may occur if detergent or cleaning materials are
consumed, and eyes or the skin might be irritated if contact is
made. Keep the cleaning materials away from the reach of
children.
6
Section 2. Installation
2.1 Removing transit bolts
4
X
4
X
4
X4
Before operating the washing machine,
remove the 4 transit bolts and rubber
spacers from the back of the machine.
If the bolts are not removed, it will
cause heavy vibration, noise and product
malfunction, (invalidating the guarantee).
Loosen the transit bolts by rotating
counter-clockwise using an appropriate
wrench.
The transit bolts are removed by
pulling out.
Fit the plastic transit bolt caps (in the
accessories bag) into the holes left by the
removal of the transit bolts.
The transit bolts should be stored to be
used in case of future transportation.
NOTE: You must remove the
transit bolts of your machine
before first use. Faults occurring
to the machine if operated with
transit bolts fitted will be out of
scope of warranty.
7
2.2 Adjusting the feet
Do not install your machine on a carpet or
anything that will prevent ventilation under
the base.
To ensure silent and vibration-free
operating of your machine, it should be
sited on a non-slippy firm floor.
You can adjust the level of your machine by
the adjustable feet.
Loosen the plastic adjustment nut.
X4
Adjust the feet upwards or downward by
rotating them.
After maintaining the level, compress the
plastic adjustment nut upwards again.
Note: The machine must be level.
Never put cardboard, wood or other
materials under your machine if you
are trying to level any distortion in the
floor.
When cleaning the floor, on which
your machine stands, be careful not
to disturb the balance of the machine.
8
Inhaltsverzeichnis
Andere montpellier Waschmaschine Handbücher
montpellier
montpellier MW9140P Bedienungsanleitung
montpellier
montpellier MW8140P Bedienungsanleitung
montpellier
montpellier MWM610W Bedienungsanleitung
montpellier
montpellier MWBI8014 Bedienungsanleitung
montpellier
montpellier MTL6120W Bedienungsanleitung
montpellier
montpellier MON-MW7012P Bedienungsanleitung
montpellier
montpellier MW5101W Bedienungsanleitung
montpellier
montpellier MWM71400W Bedienungsanleitung
montpellier
montpellier MWM61200W Bedienungsanleitung
montpellier
montpellier MWM6120W Bedienungsanleitung
montpellier
montpellier MW1045W Bedienungsanleitung
montpellier
montpellier MIWM84-1 Bedienungsanleitung
montpellier
montpellier MWM1214W Bedienungsanleitung
montpellier
montpellier MWM814BLK Bedienungsanleitung
montpellier
montpellier MW6101W Bedienungsanleitung
montpellier
montpellier MWM1014BLW Bedienungsanleitung
montpellier
montpellier MW1012P Bedienungsanleitung
montpellier
montpellier MWD8514W Bedienungsanleitung
montpellier
montpellier MIWM65 Bedienungsanleitung
montpellier
montpellier MW7120P Bedienungsanleitung
