Motorola K16A Bedienungsanleitung

read me

XT2075-1

10 AUG 2020

CE/FCCCert.

10 AUG 2020

CE/FCCCert.

Let’s get started

Before using your phone, please read the legal,

safety, and regulatory information provided with

your product.

USB-C/Charger

Volume

Buttons

Power Butt

on &

Fingerprint

Sensor

Microphone

SIM &

microSD

Card Tray

Speaker

Earpiece

Ultra-wide

Camera

Quad Pixel Camera

Headset

Jack

Google

Assistant

Button*

Press: Open the Google Assistant.

Press & hold: Say a command or question.

Note: This feature may not be available in all languages.

Proximity Sensor

English

10 AUG 2020

CE/FCCCert.

Your phone has two front and four back

cameras, which means you can take amazing

photos in any situation.

Press & hold: Phone on/o.

Press: Display on/o.

Tap: Unlock with ﬁngerprint sensor.

Flash

Depth

Camera

Quad Pixel

Camera

Ultra-wide

Camera

Macro Camera

Power Button &

Fingerprint

Sensor*

10 AUG 2020

CE/FCCCert.

Put in the cards & power on

Nano SIM

1 Insert the SIM tool

into the tray hole to

pop out the tray.

Make sure you use

the correct size SIM

card and don’t cut

the SIM card.

One SIM model

SIM

2 Insert the SIM

card with the

gold contacts

down, then gently

push the tray into

the slot.

Add a microSD

card for additional

storage.*

3 Press and hold the

Power button, then

follow the prompts

to get started.

*microSD card is optional, sold separately.

10 AUG 2020

CE/FCCCert.

Help & more

Get answers, updates, and info:

•Help is here: From the home screen, swipe up and tap Settings

>Help to learn how to use your phone and get support.

•Get more: Get software, user guides, and more at

www.motorola.com/ xxxxxxx.

•Get apps: Tap Play Store to browse and download apps.

Legal information. This guide provides important legal, safety, and

regulatory information that you should read before using your

product. For the complete legal information, from the home screen

swipe up and tap Settings > , then type Legal information, or visit

www.motorola.com/device-legal.

Water repellent. Your phone is not waterproof. For more about your

phone’s water-repellent design and care, see the user guide.

Battery safety. To prevent possible burning and injury, the battery in

your phone should only be removed by a Motorola-approved service

center or similar skilled personnel.

If your phone becomes unresponsive, press and hold the Power

button until the screen goes dark and your phone restarts.

Charge your phone using a compatible Motorola charger. Use of

other chargers is not recommended. Don’t charge your phone in

temperatures below -20°C (-4°F) or above 45°C (113°F). For more,

see the “Legal information” section of this guide, or visit

www.motorola.com/device-legal.

Warning about high volume usage. To prevent possible

hearing damage, do not listen at high volume levels for long

periods.

Disposal & recycling. For help recycling products and

packaging responsibly, visit www.motorola.com/recycling.

Class 1 Laser. This device is classiﬁed as a

Class 1 Laser product, which is safe in normal use

per IEC60825-1:2007 and IEC60825-1:2014. This

device complies with 21 CFR 1040.10 and 1040.11, except for

deviations pursuant to Laser Notice 50, dated June 24, 2007.Do not

attempt to modify or disassemble.

Extreme heat or cold. Don’t use your phone in temperatures below

-20°C (-4°F) or above 45°C (113°F). Don’t store/transport your

phone in temperatures below -20°C (-4°F) or above 60°C (140°F).

SAR information (on e-label). To view speciﬁc absorption rate

(SAR) values for this phone, from the home screen swipe up and tap

Settings > , then type Regulatory, or visit www.motorola.com/sar.

Legal disclaimers. Features, services and applications are network

dependent and may not be available in all areas; additional terms/

charges may apply. Features, functionality, and other product

speciﬁcations, as well as the information contained in this guide,

are based upon the latest available information and believed to

be accurate at the time of printing. Motorola reserves the right to

CLASS 1 LASER PRODUCT

10 AUG 2020

CE/FCCCert.

correct or change any information without notice.

Arbitration. Your purchase is governed by a binding arbitration

clause. For more information and how to opt-out, see the legal guide

that came with your phone.

Supported frequencies and power. This phone is capable of

operation on the following frequencies, subject to location and

network availability.

Model: XT2075-1

Operating mode Frequency range

MHz / Band

Maximum nominal

transmit power

(conducted) dBm

Bluetooth 2400 – 2483.5 20

WLAN 2400 – 2483.5 20

WLAN 5150 - 5250 23

WLAN 5250 - 5350 20

NFC 13.56 -14.5dBuA/m @10m

GPS 1559 - 1610 N/A

GSM 2/3/5/8 33

UMTS 1/2/5/8 24

LTE 1/2/3/4/5/7/8/12/1 3/

17/20/ 66

NR (when

supported) n2/5/66 /260/261 23

and the MOTO family of marks are trademarks or registered

trademarks of Motorola Trademark Holdings, LLC. Google, Android,

Google Play and other related marks and logos are trademarks

of Google LLC. microSD Logo is a trademark of SD-3C, LLC. All

other product or service names are the property of their respective

owners.

WLAN 5470 - 5725 20

WLAN 5725 - 5850 14

10 AUG 2020

CE/FCCCert.

Note: 5G service plan and 5G network coverage available in certain

areas in 2020, expanding after that. See your service provider for

details.

Product ID: Model XT2075-1

Manual Number: TBD-A

10 AUG 2020

CE/FCCCert.

motorola.com

10 AUG 2020

CE/FCCCert.
