Motorola MG7540 Bedienungsanleitung

User Manual

16x4 Cable Modem

plus

AC1600 Wireless

Router

MG7540

NOTICE

This document contains proprietary information protected by copyright, and this Manual and all

the accompanying hardware, software, and documentation are copyrighted. No part of this

document may be photocopied or reproduced by mechanical, electronic, or other means in any

form.

The manufacturer does not warrant that the hardware will work properly in all environments and

applications, and makes no warranty or representation, either expressed or implied, with respect

to the quality, performance, merchantability, or fitness for a particular purpose of the software or

documentation. The manufacturer reserves the right to make changes to the hardware, software,

and documentation without obligation to notify any person or organization of the revision or

change.

All brand and product names are the trademarks of their respective owners.

SAFETY

This equipment is designed with the utmost care for the safety of those who install and use it.

However, special attention must be paid to the dangers of electric shock and static electricity when

working with electrical equipment. All guidelines of this and of the computer manufacture must

therefore be allowed at all times to ensure the safe use of the equipment.

CAUTION:

 Do not put the cable modem in water.

 Do not use the cable modem outdoors.

 Keep the cable modem in an environment that is between 0°C and 40°C (between 32°F

and 104°F).

 Do not place any object on top of the cable modem since this may cause overheating.

 Do not place the cable modem in a confined space that may cause overheating.

 Do not restrict the flow of air around the cable modem.

 MOTOROLA and MTRLC assume no liability for damage caused by any improper use of the

cable modem.

Table of Contents

Introduction 4

Quick Start 4

Alternate Ways to Connect Your Coax Cable 13

Connecting Devices to Your Cable Modem/Router 14

CONNECTING A DEVICE VIA ETHERNET ................................................................................. 14

CONNECTING A SMARTPHONE, TABLET OR OTHER WIRELESS DEVICE VIA WIRELESS ........................... 14

Setting up an HDTV, Streaming Media Device, or Other Device 16

Accessing the Configuration Manager by Using a Browser 17

Configuring Your MG7540 to Support Devices and Applications with Special

Requirements 23

FOR GAMES PLAYED ON GAME CONSOLES AND PCS, AND SECURITY CAMERAS .................................. 23

TO CREATE A PORT FORWARDING RULE ................................................................................ 26

Changing Wireless Settings 30

TO CHANGE THE NETWORK NAME AND PASSWORD ................................................................... 32

WIRELESS GUEST NETWORKS ............................................................................................ 32

Changing Firewall Settings 35

Tuning Wireless Performance 37

WI-FI MULTIMEDIA (WMM) ............................................................................................. 42

Parental Control 43

SETTING UP A BLACKLIST ................................................................................................. 45

SETTING UP A WHITELIST ................................................................................................. 47

SETTING UP TIMES WHEN INTERNET ACCESS IS ALLOWED AND NOT ALLOWED .................................. 49

Changing Your MG7540’s Username and Password, and Resetting to Factory

Defaults 56

CHANGING YOUR MG7540’S USERNAME AND PASSWORD .......................................................... 56

RESETTING TO FACTORY DEFAULTS ...................................................................................... 57

Configuring Alternate Wi-Fi Security Settings 58

ALTERNATIVES TO WPA2--WPA, WEP, AND RADIUS .............................................................. 58

Troubleshooting Tips 61

WHAT IF I CAN’T MAKE AN INTERNET CONNECTION RIGHT AFTER INSTALLATION? ............................... 61

WHAT IF MY MG7540 HAS BEEN WORKING THEN STOPS WORKING? .............................................. 61

WHAT IF I’M GETTING INTERNET SERVICE BUT MY SPEED IS DISAPPOINTING? ................................... 62

WHAT IF I'M TOLD THAT MY MG7540 ISN'T APPROVED BY MY CABLE SERVICE PROVIDER? .................... 62

WHAT IF I AM CONNECTED WIRELESSLY BUT MY CONNECTION SEEMS SLOW OR KEEPS DROPPING? ........... 62

WHAT IF I DON’T KNOW MY MG7540’S WIRELESS NETWORK NAMES/SSIDS OR SECURITY KEY/PASSWORD?

................................................................................................................................ 63

WHAT IF I THINK THAT WIRELESS DEVICES ARE INTERFERING WITH MY MG7540 WIRELESS ROUTER? ...... 63

Support 64

WE LIKE TO HELP. .......................................................................................................... 64

LIMITED WARRANTY ....................................................................................................... 64

Compliance 65

Introduction

The Motorola Model MG7540 is a 16x4 DOCSIS 3.0 cable modem with a built-in

AC1600 Wi-Fi router that has 4 Gigabit Ethernet ports. This model connects to

standard cable company Internet service. Model MG7540 can provide shared

Internet access to Ethernet-capable and Wi-Fi devices including computers,

smartphones, tablets, HDTVs, game consoles, security cameras, and streaming

media devices. The MG7540 is a dual-band Wi-Fi router, and supports clients that

operate on both the 2.4 and 5 GHz bands.

Basic Installation instructions for Model MG7540 are in the Quick Start that comes

with Model MG7540 and that is duplicated in Chapter 2 of this User Guide.

Model MG7540 has a Configuration Manager that provides a lot of technical

information about Model MG7540 and that tells you how to do some useful things

as summarized below. Please note that some users will never need to use the

Configuration Manager.

Chapter 3: Alternate Ways to Connect Your Coax Cable

Chapter 4: Connecting Devices to Your Cable Modem/Router

Chapter 5: Setting up an HDTV, Streaming Media Device, or Other Device

Chapter 6: Accessing the Configuration Manager by Using a Browser

Chapter 7: Configuring Your MG7540 to Support Devices and Applications with

Special Requirements, like Games Played on Game Consoles and PCs, and

Security Cameras

Chapter 8: Changing Wireless Settings

Chapter 9: Changing Firewall Settings

Chapter 10: Tuning Wireless Performance

Chapter 11: Parental Control

Chapter 12: Troubleshooting Tips

Quick Start

Packaged with your MG7540 modem/router

Power Cube Coax Wrench

Ethernet Cable Velcro

Cable Tie

Let’s get started

If you don’t have cable Internet service, please order that from your cable service

provider.

Now connect your MG7540 as shown on the next panel.

Connecting to a Coax Cable

Soon you’ll need to connect your MG7540 to a

“live” coax cable. Sometimes a cable will already

be available. Sometimes there’s a coax wall jack

available, and you connect to the jack with a coax

cable. Your MG7540 can also share a coax cable

attached to a TV by using a coax splitter.

ETHERNET (LAN 1-4)

You can connect a computer, HDTV,

game station, or other

Ethernet-capable device to any of

these 4 LAN ports.

WLAN button

Wi-Fi on/off button

WPS button

RESET

COAX

Connect a “live” coax cable to the

modem’s COAX connector as

discussed above.

(Tighten the nut

so it’s finger tight. You may want to

use the supplied wrench. Make the

connection snug but not

over-tight.)

ON/OFF button

POWER

Connect the supplied power cube

between the power jack and an

electrical outlet.

Prepare to activate

By now you should have:

 Subscribed to cable Internet service.

 Connected your MG7540.

 Powered up your MG7540. To do this, the On/Off button needs to be On. Wait for

the green online connection light to stop flashing and remain solidly lit.

This

may take up to 15 minutes.

You should have a recent cable bill handy because it has your account number and

you’ll probably need that.

If you’re asked for information about the MG7540, you can find this on the label on

the bottom of the MG7540.

Activate

For some service providers, you activate by calling them. Many service providers

including Comcast and Cox prefer that you activate by opening the Web browser

of a computer that’s plugged into one of the MG7540’s Ethernet ports.

If you don’t have a computer, you can use the Web browser of a Wi-Fi device such

as a smartphone or tablet. In that case you’ll need the unique Wireless Network

Names (SSIDs) and Password printed on the bottom of your MG7540. Note that

your MG7540 supports two Wi-Fi bands, and there are separate SSIDs for these

bands. The bands are 2.4 and 5 GHz. Both bands use the same Password by

default. You’ll use these in setting up your wireless device to connect to the

MG7540. Once you’ve connected, you can open the browser of that wireless

device.

For Comcast XFINITY Users Only

If the activation page does not appear, please go to

www.xfinity.com/internetsetup for more information and to activate your

modem.

Here is a list of phone numbers for some major cable service

providers

. (Note that this list is subject to change.)

Comcast 1 (855) 652-3446

Time Warner

1 (855) 704 4503

Bright House 1 (888) 289-8988

Suddenlink 1 (877) 794-2724

Cable One 1 (877) 692 2253

Cox 1 (888) 556-1193

RCN 1 (866) 832-4726

Once your MG7540 is activated either online or by phone, your

service provider will provision your MG7540 service. Typically this

takes less than 5 minutes, but in some cases this may take 30

minutes or longer to complete.

Try to browse the Web using a device connected via Ethernet or Wi-Fi to the

MG7540. If browsing works, Congratulations! Your MG7540 is working.

If your MG7540 is NOT working, see Troubleshooting Tips below.

Configuration Manager

Most MG7540 users never use the Configuration Manager. Here are some reasons

for using the Configuration Manager:

 You want to change the wireless router setup. For instance, maybe you’re

replacing a router and want to use your existing Wireless Network Name(s) and/or

Password(s) instead of the unique ones that come with the MG7540.

 You want to set up special Internet gaming settings.

 You want to set up parental controls including white lists and/or black lists for

certain users and times.

 You want to get performance information about the MG7540 modem and/or

built-in router. This can be helpful in optimizing wireless performance.

If you need to access the MG7540 Configuration Manager, open your Web

browser. Type http://192.168.0.1 in the address bar and press the Enter key.

In the login dialog box, type the following User Name and Password in lower case,

then click OK.

User Name: admin

Password: motorola

The status page will appear. If the Status page doesn’t appear, please see the

Troubleshooting Tips below.

For details about the Configuration Manager, please see Chapter 6 in this

manual.
