Movincool Office Pro 60 Bedienungsanleitung

Technical Services Department

DSCA P/N: LA990009-1219 Third Issue: March 2003

GAC P/N: LA484007-1441 Printed in the U.S.A.

DENSO SALES CALIFORNIA, INC.

3900 Via Oro Avenue

Long Beach CA 90810-1868

800-264-9573 / 310-834-6352

www.movincool.com

OPERATION MANUAL

OFFICE PRO 60

READ THIS MANUAL CAREFULLY FOR INSTRUCTIONS ON CORRECT

INSTALLATION AND USAGE, AND READ ALL SAFEGUARDS.

POSTAGE WILL BE PAID BY ADRESSEE

FIRST-CLASS MAIL PERMIT NO. 8390 LONG BEACH, CA

BUSINESS REPLY MAIL

DENSO SALES CALIFORNIA, INC.INC.

3900 VIA ORO AVENUE

LONG BEACH, CA 90810-9969

NO POSTAGE

NECESSARY

IF MAILED

IN THE

UNITED STATES

SECCIÓN EN ESPAÑOL

SECTION EN FRANÇAIS

LIMITED WARRANTY

DENSO SALES CALIFORNIA, INC. ("DENSO") warrants its MOVINCOOL

Products only to the extent stated in its official written warranties. Unless

otherwise specifically provided in writing by DENSO, DENSO warrants to end-

user that the Products shall be free of defects in materials or workmanship and will

function in accordance with DENSO's published specifications under ordinary in-

tended use and service for a period of twelve (12) months after delivery to the end-

user; provided, however, in the case of the compressor element of the Products

such warranty shall be for a period of thirty six (36) months after delivery to the

end-user. DENSO shall, at its sole option, repair or replace any defective Product

covered by this warranty. Such remedy shall be end-user's sole remedy with

respect to any particular defect in the Products.

This warranty does not cover defects or malfunctions which result from causes

beyond DENSO's control, including, without limitation, (i) unusual physical or

electrical stress; (ii) accident, neglect, abuse, misuse or other abnormal use; (iii)

failuretoperform routinemaintenanceinaccordancewithDENSO'Srecommended

procedures; (iv) normal wear and tear; (v) repairs or attempted repairs by an

unauthorized person; (vi) modifications or alterations to the Products; (vii) use with

supplies or devices not supplied or approved by DENSO; or (viii) improper

servicing. This warranty shall extend only to the original end-user and shall be void

if any labels or other identifying marks permanently affixed to Products when

shipped by DENSO are removed, altered, defaced or obliterated.

The aforesaid warranty is the only warranty made by DENSO with respect to the

Products and is in lieu of all obligations or liabilities on the part of DENSO for

damages arising out of or in connection with the sale, use or performance of the

Products, including, without limitation, any lost profits or any other consequential,

incidental, special or exemplary damages of any kind. DENSO DISCLAIMS ALL

OTHER WARRANTIES WITH REGARD TO THE PRODUCTS, INCLUDING ALL

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE. THERE

ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION CON-

TAINED HEREIN.

PURCHASE DATE: _____________________________________________________

SERIAL NUMBER: _____________________________________________________



DETACH HERE



wholeorinpart, withoutthewrittenpermission ofthepublisher.DENSO

SALES CALIFORNIA, INC. reserves the right to make changes

without prior notice. MovinCool is a registerd trademark of

DENSO Corporation.

OPERATION MANUAL

OFFICE PRO 60

TABLE OF CONTENTS

FOREWORD ............................................................................................ 1

Definition of Terms .......................................................................... 1

GENERAL WARNINGS & CAUTIONS.................................................... 2

INVENTORY ............................................................................................ 3

INSTALLATION ....................................................................................... 4

Choosing an Installation Site.......................................................... 4

Moving the Unit................................................................................ 5

Plugging in the Unit ......................................................................... 6

FEATURES .............................................................................................. 7

OPERATION ............................................................................................ 8

Control Panel ................................................................................... 8

Operating in COOL Mode ............................................................. 10

Operating in Fan Only Mode ......................................................... 10

Changing from Fan Only Mode to COOL Mode .......................... 10

How to Set a Program ................................................................... 11

Operating Modes ........................................................................... 13

Emptying the Drain Tank (If equipped) ........................................ 14

Drain Pump .................................................................................... 15

HOSE INSTALLATION .......................................................................... 16

DAILY INSPECTION & MAINTENANCE .............................................. 17

Emptying the Drain Tank ............................................................... 17

Cleaning the Air Filters.................................................................. 17

FIlter Removal Method ..................................................................17

Cleaning Method ........................................................................... 18

In-Season/Off-Season Inspection & Maintenance ..................... 18

TROUBLESHOOTING ........................................................................... 19

Office Pro 60 Self-Diagnostic Codes ........................................... 19

TECHNICAL SPECIFICATIONS ........................................................... 20

SECCIÓN EN ESPAÑOL ....................................................................... 21

SECTION EN FRANÇAIS ...................................................................... 45

iii

FOREWORD

Congratulations on purchasing the MovinCool portable air conditioner.

This manual explains how to assemble, install and operate the

MovinCool Office Pro 60 portable air conditioning unit. Please read this

operation manual thoroughly to familiarize yourself with the features of

the unit and to ensure years of reliable operation. You may also find it

useful to keep this operation manual on hand for reference.

Components and/or procedures are subject to change without prior

notice.

Definition of Terms

WARNING: Describes precautions that should be observed in

order to prevent injury to the user during installation or unit opera-

tion.

CAUTION: Describes precautions that should be observed in

order to prevent damage to the unit or its components, which may

occur during installation or unit operation if sufficient care is not

taken.

NOTE: Provides additional information that facilitates installation or

unit operation.

GENERAL WARNINGS & CAUTIONS

•All electrical work, if necessary, should only be performed by

qualified electrical personnel. Repair to electrical components by

non-certified technicians may result in personal injury and/or dam-

age to the unit. All electrical components replaced must be genuine

MovinCool parts, purchased from an authorized reseller.

•The proper electrical outlet for MovinCool units must be equipped

with a UL approved ground-fault breaker to prevent electrical shock

from the unit.

•The Office Pro 60 is equipped with a six (6) foot (1.8 meter) power

cord. If replacement, fixed location (hard wired) or power cord

lengthening (extension cord) cords are required, contact your

reseller or a qualified electrician for approved replacement methods.

•Never fold, or place heavy objects on the power cord. This could

result in damage to the power cord causing electrical shock or fire.

•Do not place water or any other liquid on the unit. This can cause

damage to the unit and increase the risk of electrical shock.

•Do not sit or stand on the unit.

INVENTORY

After unpacking your MovinCool unit, please check to make sure you

have the following items:

•Office Pro 60 MovinCool Unit (1)

•Operation Manual/Warranty Card (1)

NOTE: If any of these items were not included in the box or appear

damaged, please contact your MovinCool reseller for replacement.

OPERATION MANUAL/

WARRANTY CARD

INSTALLATION

Choosing an Installation Site

CAUTION: Following are some precautions to consider before

choosing your installation site. Please review carefully as improper

installation may result in personal injury or damage to the unit.

•Do not use the unit in areas where leakage of flammable gas may

occur.

• Do not use the unit in areas where it will be exposed to rain or water.

• Do not use the unit in an atmosphere of excessively corrosive gas or

vapor.

•Do not use in areas where the temperature is outside the allowable

operating range.

• Do not install the unit in sloping areas. The unit may move or topple

over even if the casters are set to the LOCKED position.

• Install the unit in areas that can withstand the weight of the unit. The

Office Pro 60 weighs approximately 625 lbs (281 kg).

•Allow 24 inches (610 mm) of unobstructed airflow for both air inlets

and outlets.

•Do not use the unit above the following conditions:

106˚ F (41 ˚C)
