MoxPower Power-resq Bedienungsanleitung

Trademarks

All brand and product names are trademarks or registered trademarks of Maka GPS Technologies Group. In association

with Maka GPS Technologies Private Limited (Singapore), Maka GPS Technologies Sdn. Bhd. (Malaysia), Maka

Technologies Group (H.K.) Limited & Maka Corporation (USA) Inc.

The information in this manual is subject to change without notice.

www

makagps

2015

1.1

USER MANUAL

Ensure battery is fully discharge prior to the first charging to maximise your battery life.

MULTI-FUNCTION JUMP STARTER

Safety information

To prevent injury to yourself and others or damage to your device, read the safety information about your device before

using the device.

Warning

Failure to comply with safety warnings and regulations can cause serious injury or death.

Do not use damaged power cords or plugs, or loose electrical sockets

Unsecured connections can cause electric shock or fire.

Do not touch the car charger with wet hands or disconnect the charger by pulling the cord

Doing so may result in electrocution.

Do not bend or damage the car charger

Doing so may cause electric shock or fire.

Do not use your device while it is charging or touch your device with wet hands

Doing so may cause electric shock.

Do not short-circuit the charger or the device

Doing so may cause electric shock or fire, or the battery may malfunction or explode.

Use manufacturer-approved batteries, chargers, accessories, and supplies

Using generic batteries or chargers may shorten the life of your device or cause the device to malfunction. They may

also cause a fire or cause the battery to explode.

Use only Maka GPS Technologies Group-approved battery and charger specifically designed for your device.

Incompatible battery and charger can cause serious injuries or damage to your device.

Maka GPS Technologies Group cannot be responsible for the user’s safety when using accessories or supplies that are

not approved by Maka GPS Technologies Group.

Do not drop or cause an impact to the charger or the device.

Handle and dispose of the device and charger with care

Never dispose of the battery or device in a fire. Never place the battery or device on or in heating devices, such as

microwave ovens, stoves, or radiators. The device may explode when overheated. Follow all local regulations when

disposing of used battery or device.

Never crush or puncture the device.

Avoid exposing the device to high external pressure, which can lead to an internal short circuit and overheating.

Protect the device, battery and charger from damage

Avoid exposing your device and battery to very cold or very hot temperatures.

Extreme temperatures can damage the device and reduce the charging capacity and life of your device and battery.

Prevent the battery from coming into contact with metal objects, as this can create a connection between the + and –

terminals of your battery and lead to temporary or permanent battery damage.

Never use a damaged charger or battery.

Do not bite or suck the device or the battery

Doing so may damage the device or result in an explosion or fire. • Children or animals can choke on small parts.

If children use the device, make sure that they use the device properly.

Do not handle a damaged or leaking Lithium Ion (Li-Ion) battery

For safe disposal of your Li-Ion battery, contact your nearest authorised service centre

Caution

Failure to comply with safety cautions and regulations can cause injury or property damage

Do not expose the device to heavy smoke or fumes

Doing so may damage the outside of the device or cause it to malfunction.

If you notice strange smells or sounds coming from your device or the battery, or if you see smoke or liquids

leaking from the device or battery, stop using the device immediately and take it to a Maka Service Centre

Failure to do so may result in fire or explosion.

Do not store your device in very hot or very cold areas. It is recommended to use your device at temperatures from

0 °C to60 °C and humidity from 10% to 80%

Doing so may cause the screen to malfunction, result in damage to the device, or cause the battery to explode.

Do not use your device or applications for a while if the device is overheated

Prolonged exposure of your skin to an overheated device may cause low temperature burn symptoms, such as red spots

and pigmentation.

Do not drop your device or cause impacts to your device

Your device may be damaged or may malfunction.

If bent or deformed, your device may be damaged or parts may malfunction.

Ensure maximum battery and charger life

Avoid charging your device for more than a week, as overcharging may shorten battery life.

Over time, unused device will discharge and must be recharged before use.

Disconnect the charger from power sources when not in use.

Leaving batteries unused over time may reduce their lifespan and performance. It may also cause the batteries to

malfunction or explode, or cause a fire.

Your device may wear out over time. Some parts and repairs are covered by the warranty within the validity period, but

damages or deterioration caused by using unapproved accessories are not.

Do not disassemble, modify, or repair your device

Any changes or modifications to your device can void your manufacturer’s warranty. If your device needs servicing, take

your device to a Maka Service Centre.

Do not disassemble or puncture the battery, as this can cause explosion or fire.

Turn off the device before removing the battery. If you remove the battery with the device turned on, it may cause the

device to malfunction.

When cleaning your device, mind the following

Wipe your device or charger with a towel or an eraser.

Do not use chemicals or detergents. Doing so may discolour or corrode the outside the device or may result in electric

shock or fire.

Do not distribute copyright-protected material

Do not distribute copyright-protected material without the permission of the content owners. Doing this may violate copyright

laws. The manufacturer is not liable for any legal issues caused by the user’s illegal use of copyrighted material.

Correct disposal of this product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger,

headset, USB cable) should not be disposed of with other household waste.

To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these

items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government office, for

details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and

its electronic accessories should not be mixed with other commercial wastes for disposal.

Disclaimer

Some content and services accessible through this device belong to third parties and are protected by copyright, patent

trademark and/or other intellectual property laws. Such content and services are provided solely for your personal non-

commercial use.

You may not use any content or services in a manner that has not been authorised by the content owner or service provider.

Without limiting the foregoing, unless expressly authorised by the applicable content owner or service provider, you may not

modify, copy, republish, upload, post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or

medium any content or services displayed through this device.

“THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS.” MAKA GPS TECHNOLOGIES GROUP DOES NOT WARRANT

CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. MAKA EXPRESSLY

DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE. MAKA GPS TECHNOLOGIES GROUP DOES NOT GUARANTEE THE ACCURACY, VALIDITY,

TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND

UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL MAKA GPS TECHNOLOGIES GROUP BE LIABLE, WHETHER IN

CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY FEES,

EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR

AS A RESULT OF THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.”

Third party services may be terminated or interrupted at any time, and Maka GPS Technologies Group makes no

representation or warranty that any content or service will remain available for any period of time. Content and services are

transmitted by third parties by means of networks and transmission facilities over which Maka GPS Technologies Group has

no control. Without limiting the generality of this disclaimer, Maka GPS Technologies Group expressly disclaims any

responsibility or liability for any interruption or suspension of any content or service made available through

this device.

Maka GPS Technologies Group is neither responsible nor liable for customer service related to the content and services.

Any question or request for service relating to the content or services should be made directly to the respective

content and service providers.

About this manual

This device provides high quality digital recording device using Maka’s high standards and technological expertise. This

user manual is specially designed to detail the device’s functions and features.

Please read this manual before using the device to ensure safe and proper use. Descriptions are based on the

device’s default settings.

Images and screenshots may differ in appearance from the actual product.

Content may differ from the final product, or from software provided by service providers and is subject to change

without prior notice.

For the latest version of the manual, refer to the Maka website at www.makagps.com.

Available features and additional services may vary by device, software.

Applications and their functions may vary by country, region, or hardware specifications.

Maka is not liable for performance issues caused by applications from any provider other than Maka.

Maka is not liable for performance issues or incompatibilities caused by not installing the device as stated in this

manual. Attempting to customise the installation may cause the device or applications to work improperly. This may

result in device malfunctions and data corruption or loss. These actions are violations of your Maka agreement and will

void your warranty.

Default applications that come with the device are subject to updates and may no longer be supported without prior

notice. If you have questions about an application provided with the device, contact Maka Service Centre.

Table of Contents

Product Specifications 9

Getting Started

Overview of your MaxPower 9900mAh Power ResQ

MaxPower 9900mAh Power ResQ Layout 10

Car Jump Terminal Layout 11

Standard Packaging of your MaxPower 9900mAh Power ResQ

Package Contents 12

Jump Start 12V Car Installation of your MaxPower 9900mAh Power ResQ

Jump Start 12V Car Installation 13

Acting as a Backup Battery in your Car 17

Charging your MaxPower 9900mAh Power ResQ

Charging your Battery 18

Charging the your smartphones/ laptops 19

Operating the LED Touch Light

Turning on your Touch Light 20

FAQ on MaxPower 9900mAh Power ResQ 38

Product Specifications

Smart-Charge Technology

Restore and Recharge MaxPower 9900mAh Power ResQ at the same time by diverting overloaded electricity back to

the device.

Intelligent Reverse Polarity Protection

Prevents damage to the jump starter if the battery is connected in reverse.

Alert user with an alarm and an error message on the car jump terminal display.

Multiple Intelligent Protections

Protect and limit damage to your car engine and battery from short-circuit, over-voltage, and over-current.

Extensively Charging Cycles

Delivering up to 3,000 times charging cycle that is 3 times more than the normal jump starter batteries

Dimension

(L)150mm x (W)73mm x (H)28mm

Weight

328grams

Capacity

9900mAh

Stating Current

>250A

Peak Current

450A<3S

Charging Cycles

Up to 3,000 times*

Input

14V/1A

Output

USB Port: 5V/2A

Laptop Port: 19V/3.5A

Jump Starter Output

12V

Full Charge Time

3 Hours

Operating Temperature

20°C ~ 60°C

Battery Type

Lithium Polymer

*One full charge and discharge of MaxPower 9900mAh Power ResQ Multi-function Jumpstarter.

Getting Started

Overview of your MaxPower 9900mAh Power ResQ

Figure 1: MaxPower 9900mAh Power ResQ Multi-Function Jump Starter

Table 1: Keys of MaxPower 9900mAh Power ResQ

Key

Function

Power Button

Press and hold to turn the device on or off.

Output Port 1

Power supply can provide up to 5 Volts @ 1.0 Amps (maximum).

Output Port 2

Power supply can provide up to 19 Volts @ 3.5 Amps (maximum).

Jump Starter Port

Connect the Smart Terminal during a jump start operation. This power system is used

ONLY on vehicles with 12 volt DC battery systems.

Input Port

Connect the wall socket charger to the charging port.

LED Indicator Lights

LED indicator lights for battery level or charging status.

LED Torch Light

Emergency LED Torch Light. 3 modes: Torchlight, Burst Flashing, SOS

REAR VIEW

FRONT VIEW

Andere Handbücher für power-resq

Inhaltsverzeichnis

Andere MoxPower Fernstartsystem Handbücher

MoxPower

MoxPower power-resq Bedienungsanleitung

Beliebte Fernstartsystem Handbücher anderer Marken

AstroStart

AstroStart 803U Bedienungsanleitung

Durite

Durite 0-649-20 Handbuch

EINHELL

EINHELL BT-PS 1000 Handbuch

Linear

Linear ACCESS AK-21 Technische Daten

Soundstream

Soundstream TARANTULA RS.2 Bedienungsanleitung

Jaycar Electronics

Jaycar Electronics MB3752 Bedienungsanleitung

Ultra Start

Ultra Start 72 Series Bedienungsanleitung

ADS

ADS FLASHLOGIC FLRSVW1 Bedienungsanleitung

Selecta

Selecta JS012 Bedienungsanleitung

Black Widow Security

Black Widow Security BW RAS 400 Bedienungsanleitung

Vector

Vector Power City DK080706 Beilage

Code Alarm

Code Alarm CA-535 Bedienungsanleitung

Ozito

Ozito OJS-800 Bedienungsanleitung

Profi-Partner

Profi-Partner 46387 Bedienungsanleitung

EZ STARTER

EZ STARTER EZ-45 Bedienungsanleitung

Viper

Viper 4204 Bedienungsanleitung

Essex Electronics

Essex Electronics KE-1701 Bedienungsanleitung

EINHELL

EINHELL EGS 3600 Handbuch
