MSI Digital@nywhere-ATSC Bedienungsanleitung
1
Digital@nywhere-ATSC Installation Manual
Contents
V1.10
Chapter 1: Digital@nywhere-ATSC Hardware Installation ..............................................................................2
1.1 Package Contents.................................................................................................................................2
1.2 System Requirements...........................................................................................................................2
1.3 Hardware Installation...........................................................................................................................2
Chapter 2 : Digital@nywhere-ATSC Drivers And Utilities Setup.....................................................................3
Chapter 3: Power Cinema Software Installation................................................................................................5
Chapter 4: Remote Control Layout....................................................................................................................8
-2-
Chapter 1: Digital@nywhere-ATSC Hardware Installation
1.1 Package Contents
Unpack your Digital@nywhere-ATSC HDTV package and make sure that all items are included. The
following items should be included in your package:
Digital@nywhere-ATSC PCI Card
Remote control and remote sensor
Audio cable
Converter plug x 2
User Manual
Quick Guide
Installation CD
1.2 System Requirements
Pentium-IV 1.6GHz or above
256MB RAM of system memory or above
One available PCI slot
Graphics card (Must support DirectX 9.0)
Sound card (AC97 Compatible Sound Card)
1GB free HD space
CD-ROM drive (For software installation)
Microsoft Windows® XP/ MCE
(when using MCE OS an extra 3rd party DVD decoder must be installed)
1.3 Hardware Installation
Follow the steps shown below for installation of your TV card and use the pictorial guide below for
peripheral connections.
1. Turn off all power to the computer and any
attached peripherals.
2. Select an available PCI slot and remove the slot
cover, screw, etc.
3. Push the TV card firmly into the slot until it
snaps in place and secure the card by replacing
the screw you removed in step 2.
4. Replace the PC lid cover back and turn on the
power..
-3-
Chapter 2 : Digital@nywhere-ATSC Drivers And Utilities Setup
The Digital@nywhere-ATSC package comes with complete Windows software utilities. These utilities can
be found on the installation CD included in the package. Before installation, we recommend that you exit all
background programs. These include applications such as anti-virus software and system monitoring
applications.
1. Once you finish the hardware installation, restart your
system. A window labeled: “Windows Found New
Hardware Wizard” will pop up. Click “Cancel” and run
the utilities setup included in the CD.
2. Put the installation CD into the CD-ROM drive. Check
Driver Install to install drivers and utilities, the autorun
function will help you setup step by step.
3. The setup utilities will guide you install
Digital@nywhere-ATSC PCI TV card drivers and
utilities on your PC. Check “Next” to continue.
-4-
4. Check “Next” to install the BDA drivers.
5. Click “Start” to begin installing MSI
Digital@nywhere-ATSC BDA driver, please wait
for a minute.
6. Choose “Yes, I want to restart my computer now” and
click “Finish” to restart your computer and
activate the drivers.
Note:
You can restart your computer anytime after installing “Power Cinema” software application
-5-
Chapter 3: Power Cinema Software Installation
After the drivers are installed, install “Power Cinema” software by following the steps below.
1. Click “Power Cinema” from autorun then the installation
wizard of Power Cinema will guide you through
installation.
2. Select the language you want to install.
3. Check “Next” to install Power Cinema on your computer.
-6-
4. Read the license agreement and click “Yes” to install
Power Cinema.
5. Enter the User Name, Company Name and CD-Key, then
click “Next” to install.
6. Click “Next” to install or click “Browse” to select the
folder you want to install.
-7-
7. Select the folder and click “Next” to continue.
8. Click “Next” to install CyberLink Power Cinema on your
computer.
9. Click “Finish”.
Note: For user manual of Power Cinema, click “Browse” and choose Power Cinema folder.
-8-
Chapter 4: Remote Control Layout
：Powerkey ：Time Shifting
：Standby ：Stop
：NumberKeys(0~9) ：Record
：Back ：Fast Rewind & Forward
：Enter
：Previous&NextChapter
：ChannelUp/Down ：Pause & Play
：VolumeUp/Down ：Stop
：Mute ：Back to previous
：Stereo ：Enter TV Manual
：Source ：View the TV recorded list
：ZoomIn/Out ：View the captured Picture
：ShutDown ：Enter Video Manual
＆＆& ：：Enter the recorded Music list
Mouse Control Pad or Arrow Keys ：Guide
：Enter ：Help
-9-
Key Definitions
Key Description MCE 2005 PowerCinema
Put the system in standby/ wake
the system N/A N/A
Number Keys (0~9) Y Y
Back previous step N/A Y
Enter Y Y
Stereo N/A N/A
Switch Video Source N/A N/A
Zoon In / Out Y N/A
Shut Down Y Y
Mouse Control Pad or Arrow
keys Y Y
Enter Y Y
Time Shifting N/A N/A
Stop Y Y
Record Y Y
Fast Rewind & Forward Y Y
Previous & Next Chapter N/A Y
Pause & Play Y Y
Stop Y Y
-10-
Hot Key MCE 2005 PowerCinema
Back to previous page Escape current screen
Enter TV Manual Capture photo
Record TV list Enter TV Manual
View captured photo Information of Electronic Program Guide
Enter Video Manual View Captured photo
View recorded Music Enter Video Manual
Guide TELTXT/ClosedCaption
Help Help
