MSI Aegis B939 Bedienungsanleitung

Aegis Series

Personal Computer

Aegis B939

User Guide

2Contents

Contents

Getting Started.............................................................................................................. 3

Package Contents................................................................................................... 3

Safety & Comfort Tips ............................................................................................ 3

System Overview..................................................................................................... 4

Hardware Setup...................................................................................................... 8

Windows 10 System Operations................................................................................ 10

Power Management ............................................................................................. 10

Network Connection............................................................................................. 12

System Recovery .................................................................................................. 15

Windows 11 System Operations................................................................................ 19

Power Management ............................................................................................. 19

Network Connections........................................................................................... 23

System Recovery .................................................................................................. 31

F3 Hotkey Recovery (Optional) .................................................................................. 33

Safety Instructions...................................................................................................... 34

Regulatory Notices..................................................................................................... 36

Revision

V1.0, 2021/11

Getting Started

This chapter provides you with the information on hardware setup procedures. While

connecting devices, be careful in holding the devices and use a grounded wrist strap

to avoid static electricity.

Package Contents

Personal Computer Aegis B939

Documentation

User Guide (Optional)

Quick Guide (Optional)

Warranty Book (Optional)

Accessories

Power Cord

Mouse (Optional)

Keyboard (Optional)

2.5”/3.5” SATA Cable (Optional)

3.5” HDD Bracket (Optional)

2.5” Screws (Optional)

⚠

Important

∙

Contact your place of purchase or local distributor if any of the items is damaged or

missing.

∙

Package contents may vary by country.

∙

The included power cord is exclusively for this personal computer and should not be

used with other products.

Safety & Comfort Tips

∙Choosing a good workspace is important if you have to work with your PC for a long

period of time.

∙Your work area should have enough illumination.

∙Choose the proper desk and chair and adjust their height to fit your posture when

operating.

∙When sitting on the chair, sit straight and keep a good posture. Adjust the chair’s

back (if available) to support your back comfortably.

∙Place you feet flat and naturally on the floor, so that your knees and elbows have the

proper position (about 90-degree) when operating.

∙Put your hands on the desk naturally to support your wrists.

∙Avoid using your PC in a place where discomfort may occur (such as on the bed).

∙The PC is an electrical device. Please treat it with great care to avoid personal

injury.

4Getting Started

System Overview

1 1

1211

1010101015

22 23

4 5 6 7 4 8

Getting Started

1Headset Holder

Pull out the hanger, then a headset can be hung on the holder.

2Gaming Dial

Gaming Dial displays system information and supports quick switch

between functions like Mystic Light/ audio volume or game launch.

3Power Button / Power LED

The power LED glows when the system is turned on and goes off when

the system is shut down. In terms of power saving, the LED blinks in S3

(Suspend to RAM) mode and goes off in S4 (Suspend to Disk) mode.

4USB 3.2 Gen 1 Port

This connector is provided for USB peripheral devices. (Speed up to 5 Gbps)

5Microphone Jack

6Headphone Jack

7USB 3.2 Gen 2 Port (Type-C)

This connector is provided for USB peripheral devices. (Speed up to 10

Gbps)

8Hard Disk Drive LED

This indicator shows the activity status of the HDD. It flashes when the

system is accessing data on the HDD and remains off when no disk activity

is detected.

9Ventilator

10 Line-In Jack

11 Line-Out Jack

12 Mic-In Jack

13 CS-Out Jack

Center/ subwoofer line out in 5.1/ 7.1 channel mode.

14 RS-Out Jack

Rear surround sound line out in 4/ 5.1/ 7.1 channel mode.

6Getting Started

15 S/PDIF-Out

This S/PDIF (Sony & Philips Digital Interconnect Format) connector is

provided for digital audio transmission to external speakers through an

optical fiber cable.

16 2.5 Gbps LAN Jack

The standard RJ-45 LAN jack is provided for connection to the Local Area

Network (LAN). You can connect a network cable to it.

LINK/ACT

LED

SPEED

LED

LED Status Description

Link/ Activity

LED

Off No link

Yellow Linked

Blinking Data activity

Speed LED

Off 10 Mbps

Green 100/1000 Mbps

Orange 2.5 Gbps

17 USB 3.2 Gen 2 Port

This connector is provided for USB peripheral devices. (Speed up to 10

Gbps)

18 USB 3.2 Gen 2x2 Port (Type-C)

This connector is provided for USB peripheral devices. This connector can

provide up to 5V/3A of power. (Speed up to 20 Gbps)

19 LAN Jack

The standard RJ-45 LAN jack is provided for connection to the Local Area

Network (LAN). You can connect a network cable to it.

LINK/ACT

LED

SPEED

LED

LED Status Description

Link/ Activity

LED

Off No link

Yellow Linked

Blinking Data activity

Speed LED

Off 10 Mbps

Green 100 Mbps

Orange 1 Gbps

Getting Started

20 Thunderbolt™ 4 Port (USB Type-C) (Optional)

∙Support up to 40Gbps transfer rate with Thunderbolt devices.

∙Support up to 20Gbps transfer rate with USB 3.2 Gen 2x2 devices.

∙Support up to 10Gbps transfer rate with USB 3.2 devices.

∙Support up to 5V/3A, 9V/3A, 15V/3A, and 20V/3A power charging

∙Each port can daisy-chain up to three Thunderbolt 4 devices or five

Thunderbolt 3 devices.

∙Support up to 8K display.

21 HDMI 1.4b Port

Supports a maximum resolution of 4K 30Hz.

⚠

Important

∙

Graphics specifications may vary depending on the installed CPU.

∙

For processors without integrated graphics, connect your monitor to the

discrete graphics card.

22 PS/2® Keyboard/ Mouse Port

23 USB 2.0 Port

This connector is provided for USB peripheral devices. (Speed up to 480

Mbps)

⚠

Important

High-speed devices are recommended for USB 3.2 ports whereas low-

speed devices, such as mouse or keyboard, are suggested to be plugged

into the USB 2.0 ports.

24 Kensington Lock Port

This PC provides a Kensington lock port, which allows users to secure the

PC in place with a key or some mechanical PIN device and attached through

a rubberised metal cable. The end of the cable has a small loop which

allows the whole cable to be looped around a permanent object, such as a

heavy table or other similar equipment, thus securing the PC in place.

25 Power Jack

8Getting Started

Hardware Setup

Connect your peripheral devices to suitable ports.

⚠

Important

∙

For detailed instructions on how to connect, please refer to the manuals of your

peripheral devices.

∙

Reference image only. Appearance will vary.

Connecting Thunderbolt Devices via Daisy-chain (Optional)

Daisy-chain is a method of connecting multiple devices to a PC with only one output

terminal. Daisy-chain allows you to connect multiple Thunderbolt devices to a single

Thunderbolt port on the rear I/O panel.

You can also daisy-chain monitors on the rear I/O panel. Please note that monitors

should be the last devices on the chain.

If you want to connect USB devices, please place them at the end of the chain.

Getting Started

Connect the power cord to the system and electrical outlet.

Power Rating

•850W: 100-240V~, 50-60Hz, 12V-6A

Press the power button to power on the system.

⚠

Important

When unplugging the AC power cord,

always hold the connector part of the

cord. Never pull the cord directly.

10 Windows 10 System Operations

Windows 10 System Operations

This chapter provides you with essential information on system operations.

⚠

Important

All information is subject to change without prior notice.

Power Management

Power management of personal computers (PCs) and monitors has the potential to

save significant amounts of electricity as well as deliver environmental benefits.

To be energy efficient, turn off your display or set your PC to sleep mode after a period

of user inactivity.

Power Management in Windows 10

∙[Power Options] in Windows OS allow you to control the power management

features of your display, hard drive, and battery. Right-click [Start] , select

[Control Panel] from the list and then click [System and Security].

∙Select [Power Options] and choose a power plan that suits your personal needs. You

may also fine-tune the settings by clicking [Change plan settings].

∙The Shut Down Computer menu presents the options of Sleep (S3/S4) & Shut Down

(S5) for rapid and easy management of your system power.

Power Management

The power management feature allows the computer to initiate a low-power or

“Sleep” mode after a period of user inactivity. To take advantage of these potential

energy savings, the power management feature has been preset to behave in the

following ways when the system is operating on AC power:

∙Turn off the display after 10 minutes

∙Initiate Sleep after 30 minutes
