MSI 645E Max-U Bedienungsanleitung
i
Version 2.2
G52-MA00646
MS-6547 (v2.1) ATX Mainboard
MSI
MICRO-STAR INTERNATIONAL
645E Max-U
ii
Manual Rev: 2.2
Release Date: July 2002
FCC-B Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case the user will be required to correct
the interference at his own expense.
Notice 1
The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Notice 2
Shielded interface cables and A.C. power cord, if any, must be used in order to
comply with the emission limits.
VOIRLANOTICED’INSTALLATIONAVANTDERACCORDERAURESEAU.
Micro-Star International MS-6547
Tested to comply
with FCC Standard
For Home or Office Use
iii
Edition
July 2002
Copyright Notice
The material in this document is the intellectual property of MICRO-STAR
INTERNATIONAL. We take every care in the preparation of this document,
but no guarantee is given as to the correctness of its contents. Our products
are under continual improvement and we reserve the right to make changes
without notice.
Trademarks
All trademarks are the properties of their respective owners.
Intel®and Pentium®are registered trademarks of Intel Corporation.
PS/2 and OS®/2 are registered trademarks of International Business Machines
Corporation.
Windows®98/2000/NT/XP are registered trademarks of Microsoft Corporation.
Netware®is a registered trademark of Novell, Inc.
Award®is a registered trademark of Phoenix Technologies Ltd.
AMI®is a registered trademark of American Megatrends Inc.
Revision History
Revision Revision History Date
V2.2 Use SiS 645DX & 962L Chipsets July 2002
Add JBT1 & JSP1, delete JMDM1,
JAUX1 & JMD1
iv
Safety Instructions
1. Read the safety instructions carefully.
2. Save this User’s Guide for possible use later.
3. Keep this equipment away from humidity.
4. Lay this equipment on a stable and flat surface before setting it up.
5. The openings on the enclosure are used for air convection and to prevent
the equipment from overheating. Note: Do not cover the openings.
6. Make sure that the power voltage is within its safety range and has been
adjusted properly to the value of 110/220V before connecting the equip-
ment to the power inlet.
7. Place the power cord in a way that people are unlikely to step on it. Do not
place anything on the power cord.
8. Always unplug the power cord before inserting any add-on card or module.
9. All cautions and warnings on the equipment should be noted.
10. Never pour any liquid into the opening that could damage the equipment
or cause an electrical shock.
11. If any of the following situations arises, get the equipment checked by a
service personnel:
zthe power cord or plug is damaged
zliquid has penetrated into the equipment
zthe equipment has been exposed to moisture
zthe equipment has not work well or you can not get it work according
to User’s Guide
zthe equipment was dropped and damaged
zthe equipment has obvious signs of breakage
12. Do not leave the equipment in an unconditioned environment with a stor-
age temperature of 600 C (1400F) or above, which may damage the
equipment.
CAUTION: To prevent explosion caused by improper battery
replacement, use the same or equivalent type of battery recommended
by the manufacturer only.
v
CONTENTS
Chapter 1. Getting Started ........................................................................ 1-1
Mainboard Specification ...................................................................... 1-2
Mainboard Layout ............................................................................... 1-4
Quick Components Guide .................................................................... 1-5
MSI Special Features ........................................................................... 1-6
Fuzzy Logic™ 4 ............................................................................. 1-6
Live BIOS™/Live Driver™ ............................................................ 1-7
D-Bracket™ 2 ................................................................................ 1-8
PC Alert™ III ............................................................................... 1-10
Chapter 2. Hardware Setup ....................................................................... 2-1
Central Processing Unit: CPU .............................................................. 2-2
CPU Installation Procedures ......................................................... 2-2
Installing the CPU Fan .................................................................. 2-3
CPU Core Speed Derivation Procedure ......................................... 2-4
Memory ................................................................................................ 2-5
Introduction to DDR SDRAM ....................................................... 2-5
DDR Module Combination ............................................................ 2-6
Installing DDR Modules ............................................................... 2-6
Power Supply ....................................................................................... 2-7
ATX 20-Pin Power Connector: CONN1 ......................................... 2-7
ATX 12V Power Connector: JPW1 ................................................ 2-7
Back Panel ............................................................................................ 2-8
Mouse Connector: JKBMS1 ......................................................... 2-8
Keyboard Connector: JKBMS1 ..................................................... 2-9
USB Connectors ............................................................................ 2-9
Serial Port Connector: COM A & COM B ................................... 2-10
Joystick/Midi Connectors ........................................................... 2-10
Audio Port Connectors ............................................................... 2-10
Parallel Port Connector: LPT1 ...................................................... 2-11
vi
Connectors ......................................................................................... 2-12
Floppy Disk Drive Connector: FDD1 ........................................... 2-12
Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-13
Fan Power Connectors: CPUFA/SYSFA ...................................... 2-14
Front Panel Connector: JFP1 & JFP2 ........................................... 2-15
Front Panel Audio Connector: JAUD1 ........................................ 2-16
D-Bracket™ 2 Connector: JLED1 ................................................. 2-17
Front USB Connectors: JUSB1 & JUSB2 ..................................... 2-18
Bluetooth Connector: JBT1 ......................................................... 2-20
S-Bracket Connector: JSP1 .......................................................... 2-21
CD-In Connector: JCD1 ............................................................... 2-22
IrDA Infrared Module Header: JIR1 ............................................ 2-22
Jumpers .............................................................................................. 2-23
Clear CMOS Jumper: JBAT1 ........................................................ 2-23
Slots ................................................................................................... 2-24
AGP (Accelerated Graphics Port) Slot ......................................... 2-24
PCI Slots ...................................................................................... 2-24
PCI Interrupt Request Routing .................................................... 2-25
Chapter 3. BIOS Setup .............................................................................. 3-1
Entering Setup ...................................................................................... 3-2
Selecting the First Boot Device ..................................................... 3-2
Control Keys ................................................................................. 3-3
Getting Help .................................................................................. 3-3
The Main Menu ................................................................................... 3-4
Standard CMOS Features .................................................................... 3-6
Advanced BIOS Features .................................................................... 3-8
Advanced Chipset Features ............................................................... 3-12
Power Management Setup ................................................................. 3-14
PNP/PCI Configurations ..................................................................... 3-18
vii
Integrated Peripherals ........................................................................ 3-21
PC Health Status ................................................................................ 3-25
Frequency/Voltage Control ................................................................ 3-26
Set Supervisor/User Password ........................................................... 3-28
Load Optimal/High Performance Defaults .......................................... 3-29
Appendix: Using 4- or 6-Channel Audio Function .................................... A-1
Installing the Audio Driver ................................................................. A-2
Installation for Windows 98SE/ME/2000/XP ................................ A-2
Using 4- or 6-Channel Audio Function ............................................... A-4
Attaching Speakers ...................................................................... A-4
Selecting 4- or 6-Channel Setting ................................................. A-9
Testing the Connected Speakers ....................................................... A-11
Testing Each Speaker ................................................................. A-11
Playing KaraOK ................................................................................ A-12
Playing KaraOK .......................................................................... A-12
Glossary .................................................................................................... G-1
Getting Started
1-1
Chapter 1. Getting Started
Thank you for purchasing the 645E Max-U (MS-6547 v2.1) ATX
mainboard. The 645E Max-U is a superior computer mainboard based on
SiS®645DX & SiS®962L chipsets for optimal system efficiency. Designed to fit
the advanced Intel®Pentium®4 processors in the 478 pin package, the 645E
Max-U delivers a high performance and professional desktop platform solution.
1
Getting Started
TOPICS
Mainboard Specification 1-2
Mainboard Layout 1-4
Quick Components Guide 1-5
MSI Special Features 1-6
Chapter 1
1-2
CPU
Support Socket 478 for Intel®Pentium®4 processors (Williamette- and
Northwood-core)
Support FSB at 400/533MHz (100/133MHz QDR)
Core Frequency 533MHz from 1.3GHz to 2.53GHz
Chipset
SiS®645DX Chipset NB
- Support 64 bit P4 processors at 533MHz
- Support 32 bit AGP 4x/2x slot
- Support 64 bit high performance DDR333/DDR266 memory controller
- Support bi-directional 16 bit data bus with 533MHz bandwidth MuTIOL
SiS®962L Chipset SB
- Support Dual-IDE ATA 66/100/133
- AC’97 link controller
- Low pin count interface for SIO
- Integrated high speed USB 2.0 Host Controller
MainMemory
Three 184-pin DDR DIMM socket
Max. memory size at 3GB w/o ECC
Slots
One AGP (Accelerated Graphics Port) 2x/4x slot
Six 32-bit PCI bus slots
On-BoardIDE
Dual IDE controllers integrated in SiS®962L chipset
Support P/O, Bus Master, Ultra DMA 66/100/133 operation
Can connect up to four IDE devices
Mainboard Specification
Getting Started
1-3
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 2 serial ports (COM A + COM B)
- 1 parallel port supports Normal/Bi-Dir/EPP/ECP mode
- 2 USB ports (USB 2.0 Controller by SiS®962L SB)
- 1 IrDA connector for SIR
- 1 audio/game port
Audio
6 channels audio codec Realtek ALC650
BIOS
2MB AMI BIOS w/PnP, ACPI, SMBIOS 2.3, Green and Boot Block
Provide DMI2.0, WfM2.9, WOR, and SMBus for system management
Dimension
ATX Form Factor: 30.5cm(L) x 22.0cm(W)
Mounting
6 mounting holes
Others
Support STR/STD
PC2001 compliant
Support D-Bracket 2 (optional)
Support PC2PC Bluetooth (optional)
Vcore adjustable
Support S-Bracket (optional)
Support USB 2.0 Bracket (optional)
Inhaltsverzeichnis
Andere MSI Hauptplatine Handbücher
MSI
MSI MPG Z390I GAMING EDGE AC Bedienungsanleitung
MSI
MSI MS-7865 Bedienungsanleitung
MSI
MSI PRO B760M-P DDR4 Bedienungsanleitung
MSI
MSI 850 Pro2 Bedienungsanleitung
MSI
MSI LPX SI15 Bedienungsanleitung
MSI
MSI G52-MA00353 Bedienungsanleitung
MSI
MSI 870A Fuzion Power Edition series Bedienungsanleitung
MSI
MSI B450 GAMING PLUS MAX Bedienungsanleitung
MSI
MSI MEG Z390 ACE Bedienungsanleitung
MSI
MSI MS-6380 Bedienungsanleitung
MSI
MSI B450 GAMING PRO CARBON AC Bedienungsanleitung
MSI
MSI A320M PRO-M2 Bedienungsanleitung
MSI
MSI MS-6340M Bedienungsanleitung
MSI
MSI X299 RAIDER Bedienungsanleitung
MSI
MSI MS-7181 Bedienungsanleitung
MSI
MSI PRO X670-P WIFI Bedienungsanleitung
MSI
MSI MAG X570 TOMAHAWK WIFI Bedienungsanleitung
MSI
MSI X470 GAMING PLUS Bedienungsanleitung
MSI
MSI X79A-GD45 Plus seres Bedienungsanleitung
MSI
MSI G52-M7246X1 Bedienungsanleitung
Beliebte Hauptplatine Handbücher anderer Marken
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Bedienungsanleitung
Gigabyte
Gigabyte GA-9IVDT Bedienungsanleitung
Texas Instruments
Texas Instruments ADS8372EVM Bedienungsanleitung
Commell
Commell MS-C73 Bedienungsanleitung
IBT Technologies
IBT Technologies MB860 Bedienungsanleitung
Nvidia
Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung
