MSI 648 Max Bedienungsanleitung

Version 1.1

G52-M6585X6

MS-6585 (v1.X) ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL 648 Max

Manual Rev: 1.1

Release Date: January 2003

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-Star International MS-6585

Tested to comply

with FCC Standard

For Home or Office Use

iii

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

AMD, Athlon™, Athlon™ XP, Thoroughbred™, and Duron™ are registered

trademarks of AMD Corporation.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Microsoft is a registered trademark of Microsoft Corporation. Windows®98/

2000/NT/XP are registered trademarks of Microsoft Corporation.

NVIDIA, the NVIDIA logo, DualNet, and nForce are registered trademarks or

trademarks of NVIDIA Corporation in the United States and/or other countries.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Kensington and MicroSaver are registered trademarks of the Kensington Tech-

nology Group.

PCMCIA and CardBus are registered trademarks of the Personal Computer

Memory Card International Association.

Revision History

Revision Revision History Date

V1.0 First Release August 2002

V1.1 Add HP Threading Function January 2003

in BIOS

Safety Instructions

1. Read the safety instructions carefully.

2. Save this User’s Guide for possible use later.

3. Keep this equipment away from humidity.

4. Lay this equipment on a stable and flat surface before setting it up.

5. The openings on the enclosure are used for air convection and to prevent

the equipment from overheating. Note: Do not cover the openings.

6. Make sure that the power voltage is within its safety range and has been

adjusted properly to the value of 110/220V before connecting the equip-

ment to the power inlet.

7. Place the power cord in a way that people are unlikely to step on it. Do not

place anything on the power cord.

8. Always unplug the power cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage the equipment

or cause an electrical shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zthe power cord or plug is damaged

zliquid has penetrated into the equipment

zthe equipment has been exposed to moisture

zthe equipment has not work well or you can not get it work according

to User’s Guide

zthe equipment was dropped and damaged

zthe equipment has obvious signs of breakage

12. Do not leave the equipment in an unconditioned environment with a stor-

age temperature of 600 C (1400F) or above, which may damage the

equipment.

CAUTION: To prevent explosion caused by improper battery

replacement, use the same or equivalent type of battery recommended

by the manufacturer only.

Contents

Safety Instructions ....................................................................... v

Chapter 1. Getting Started ........................................................... 1-1

Mainboard Specification ............................................................ 1-2

Mainboard Layout ..................................................................... 1-5

Quick Components Guide ......................................................... 1-5

Fuzzy Logic™ 4.................................................................. 1-6

MSI Special Features ................................................................ 1-6

Live BIOS™/Live Driver™ .................................................... 1-7

Live Monitor™ ..................................................................... 1-8

S-Bracket (Optional) ........................................................... 1-9

D-Bracket™ 2 (Optional) ................................................... 1-10

PC Alert™ 4 ..................................................................... 1-12

Chapter 2. Hardware Setup ......................................................... 2-1

CPU Installation Procedures for Socket 478 ........................ 2-2

Installing the CPU Fan ........................................................ 2-3

CPU Core Speed Derivation Procedure ................................ 2-4

Memory .................................................................................... 2-5

Introduction to DDR SDRAM ............................................... 2-5

DDR DIMM Module Combination ......................................... 2-6

Installing DDR DIMM Modules ............................................. 2-6

Power Supply ............................................................................ 2-7

ATX 20-Pin Power Connector: CONN1 ................................. 2-7

ATX 12V Power Connector: JPW1 ....................................... 2-7

Back Panel ............................................................................... 2-9

Mouse Connector: JKBMS1 ................................................ 2-9

Keyboard Connector: JKBMS1 ............................................ 2-9

USB 2.0 Connectors ........................................................... 2-9

Serial Port Connectors: COMA & COMB .......................... 2-10

RJ-45 LAN Jack ................................................................ 2-10

Audio Port Connectors ...................................................... 2-11

Parallel Port Connector: LPT1 ........................................... 2-13

Connectors ............................................................................. 2-13

Floppy Disk Drive Connector: FDD1 .................................. 2-13

Hard Disk Connectors: IDE1 & IDE2 ................................. 2-15

CD-In Connector: JCD1 ..................................................... 2-15

Fan Power Connectors: CPUFA/SYSFA ........................... 2-17

Front Panel Connectors: JFP1 & JFP2.............................. 2-17

IrDA Infrared Module Header: JIR1 ..................................... 2-19

D-Bracket™ 2 Connector: JDB1 (Optional) ........................ 2-20

Bluetooth Connector: JBT1 ............................................... 2-21

S-Bracket Connector: JSP1 .............................................. 2-22

Front USB 2.0 Connector: JUSB2 ..................................... 2-24

Jumpers .................................................................................. 2-25

Clear CMOS Jumper: JBAT1 ............................................. 2-25

AGP (Accelerated Graphics Port) Slot .............................. 2-26

PCI Slots .......................................................................... 2-26

Slots ....................................................................................... 2-27

PCI Interrupt Request Routing ........................................... 2-27

Chapter 3. AMI® BIOS Setup ...................................................... 3-1

Entering Setup .......................................................................... 3-3

Selecting the First Boot Device ................................................. 3-3

Control Keys ............................................................................. 3-3

Getting Help .............................................................................. 3-5

The Main Menu ......................................................................... 3-5

Standard CMOS Setup ............................................................. 3-7

Advanced BIOS Features .......................................................... 3-9

Advanced Chipset Features .................................................... 3-13

Power Management Setup ...................................................... 3-15

vii

PNP/PCI Configuration ............................................................ 3-19

Integrated Peripherals ............................................................. 3-23

PC Health Status .................................................................... 3-25

Frequency/Voltage Control ...................................................... 3-27

Set Supervisor/User Password ................................................ 3-29

Load Optimal/High Performance Defaults ................................ 3-31

Save & Exit Setup ................................................................... 3-31

Exit Without Saving ................................................................. 3-32

Appendix: Using 4- or 6-Channel Audio Function ..................... A-1

Installing the Audio Driver ......................................................... A-2

Installation for Windows 98SE/ME/2000/XP ....................... A-2

Using 4- or 6-Channel Audio Function ...................................... A-4

Use the Optional S-Bracket ............................................... A-4

Use the Back Panel only ................................................. A-10

Testing the Connected Speakers ............................................ A-14

Testing Each Speaker: ..................................................... A-14

Playing KaraOK ..................................................................... A-16

Playing KaraOK: .............................................................. A-16

Glossary ........................................................................................ G-1

Getting Started

1-1

Chapter 1. Getting Started

Thank you for purchasing 648 Max (MS-6585) ATX mainboards. The

648 Max is a superior computer motherboard based on SiS648 and SiS963

chipsets for optimal system efficiency. Designed to fit the advanced Intel®

Pentium®4 processors in the 478 pin package, the 648 Max delivers a high

performance and professional desktop platform solution.

Getting Started

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

MSI Special Features 1-6

Chapter 1

1-2

CPU

Socket 478 for P4 processors (Willimate 478 and Northwood 478) with 400/

533 MHz (100/133MHz QDIR)

Core frequency from 1.3 GHz to 3.06 GHz and up

Chipset

SiS®648/648 B Stepping (839 pin BGA)

- Supports Intel Pentium 4 processors with data transfer rate up to 533 MHz

- Supports 64-bit high performance DDR 333+ / DDR 333 / DDR 266 memory

controller

- Supports AGP 8X/4X interface at 0.8v or 4x at 1.5v with fast write transaction

- Supports bi-directional 16-bit data bus with 1GHz bandwidth MuTIOL

- Supports Intel Hyper-Threading CPU Function (for SiS®648 B Stepping

only)

SiS®963 (371 pin BGA)

- Supports Dual-IDE ATA 66/100/133

- Integrated audio controller with AC97 interface

- Low pin count interface for SIO

- Advanced power management and PC2001 compliance

MainMemory

Supports three memory banks using two 184-pin unbuffered DDR DIMM.

Supports up to 3GB memory size without EEC.

Supports DDR200/266/333 MHz and up.

Slots

One 8x/4x AGP (Accelerated Graphics Port) universal slot.

Six PCI v2.2 32-bit master PCI bus slots.

On-Board IDE

Dual IDE controllers integrated in SiS 963.

Support P/O, Bus Master, Ultra DMA66/100/133 operation.

Can connect up to four IDE devices.

On-Board Peripherals

On-Board Peripherals include:

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

2.88Mbytes.

- 2 serial ports (COM A + COM B).

Mainboard Specification

Getting Started

1-3

- 1 parallel port supports SPP/EPP/ECP mode.

- 6 USB ports (Rear * 4/ Front * 2).

- 1 IrDA connector for SIR.

- 1 RJ-45 LAN jack (optional).

- 1 audio port.

- 1 Bluetooth pin header

- 1 S-Bracket pin header.

- 1 D-BracketTM 2 pin header.

Audio

AC97 link controller integrated in SiS 963.

6 channels software audio codec RealTek ALC650.

- Compliance with AC97 v2.2 Spec.

- Meet PC2001 audio performance requirement.

- Can support SPDIF Out via S-Bracket only.

LAN (Optional)

Broadcom 4401

- Integrated 10/100 Ethernet MAC and PHY in one chip.

- Supports 10Mb/s and 100Mb/s auto-negotiation operation.

- Compliance with PCI v2.2, mini PCI 1.0 and LAN on Motherboard (LOM)

standard.

Broadcom 5702

- Integrated Gigabit Ethernet MAC and PHY transceiver, auto-negotiation

operation..

- Supports single-port 10MB/s, 100MB/s and 1000MB/s BAST-T application.

- Compliance with PCI v2.2, mini PCI 1.0 and LAN on Motherboard (LOM)

standard.

BIOS

2Mb Award BIOS with PnP, ACPI, SMBIOS 2.3, Green and Boot Block.

Provides DMI2.0, WfM2.0, WOL, WOR, chassis intrusion, and SMBus for

system management.

Dimension

ATX Form Factor: 22.0cm x 30.5cm.

Mounting

6 mounting holes.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere MSI Hauptplatine Handbücher

MSI

MSI P7N SLI PLATINUM - Motherboard - ATX Bedienungsanleitung

MSI

MSI A88XM GAMING Bedienungsanleitung

MSI

MSI Z170A PC MATE Bedienungsanleitung

MSI

MSI MPG Z490 GAMING EDGE WIFI Bedienungsanleitung

MSI

MSI MS-6380 Bedienungsanleitung

MSI

MSI MS-98F6 Bedienungsanleitung

MSI

MSI 845PE Neo Bedienungsanleitung

MSI

MSI MS 7030 - K8N Neo Platinum Motherboard Bedienungsanleitung

MSI

MSI MS-98G6 Bedienungsanleitung

MSI

MSI 785GTM-E45 - Motherboard - Micro ATX Bedienungsanleitung

MSI

MSI 945PL Neo5 Series Bedienungsanleitung

MSI

MSI X299 SLI PLUS Bedienungsanleitung

MSI

MSI H61M-E23 (G3) Series Bedienungsanleitung

MSI

MSI KT4 Ultra Bedienungsanleitung

MSI

MSI A75MA-P35 series Bedienungsanleitung

MSI

MSI MS-6528LE Bedienungsanleitung

MSI

MSI H110M PRO-VD Bedienungsanleitung

MSI

MSI MD 5000 Bedienungsanleitung

MSI

MSI MS-5187 Bedienungsanleitung

MSI

MSI G52-75221X5 Bedienungsanleitung

MSI

MSI NF980-G65 series Bedienungsanleitung

MSI

MSI 870-C45 Series Bedienungsanleitung

MSI

MSI MS-7203 Bedienungsanleitung

MSI

MSI 760GMA-P34 FX series Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
