MSI 845E Max2 Series Bedienungsanleitung

Version 1.0

G52-MA00566

MS-6398E (v1.X) ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL 845E Max2 Series

Manual Rev: 1.0

Release Date: March 2002

FCC-BRadioFrequencyInterferenceStatement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6398E

Testedtocomply

withFCCStandard

ForHome orOffice Use

iii

Edition

March 2002

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

V1.0 First release March 2002

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipmentfrom overheating. DONOT COVERTHEOPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. AlwaysUnplug thePower Cordbefore insertinganyadd-on cardor module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged.

zLiquid has penetrated into the equipment.

zThe equipment has been exposed to moisture.

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged.

zThe equipment has obvious sign of breakage.

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT

MAYDAMAGETHEEQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specification ......................................................................1-2

Mainboard Layout ...............................................................................1-4

Quick Components Guide ....................................................................1-5

MSI Special Features ...........................................................................1-6

FuzzyLogic™4 .............................................................................1-6

PCAlert™ III .................................................................................1-7

LiveBIOS™/LiveDriver™ ............................................................1-8

Live Monitor™ .............................................................................. 1-9

D-Bracket™2(Optional) ............................................................. 1-10

S-Bracket(Optional) .................................................................... 1-12

Chapter2.HardwareSetup ....................................................................... 2-1

Central Processing Unit: CPU .............................................................. 2-2

CPU Installation Procedures ......................................................... 2-2

Installing the CPU Fan ..................................................................2-3

CPU Core Speed Derivation Procedure .........................................2-4

Memory................................................................................................2-5

Introduction to DDR SDRAM....................................................... 2-5

DDR Module Combination ............................................................ 2-6

Installing DDR Modules ............................................................... 2-6

Power Supply .......................................................................................2-7

ATX 20-Pin Power Connector: JWR1 ............................................2-7

ATX 12V Power Connector: JPW1 ................................................2-7

BackPanel ............................................................................................2-8

Mouse Connector: JKBMS1 ......................................................... 2-8

Keyboard Connector: JKBMS1 ..................................................... 2-9

USB Connectors ............................................................................2-9

Serial Port Connector: COM A & COM B ................................... 2-10

RJ-45LAN Jack(Optional) .......................................................... 2-10

Parallel Port Connector: LPT1...................................................... 2-11

Joystick/Midi Connectors ........................................................... 2-12

Audio Port Connectors ............................................................... 2-12

Connectors......................................................................................... 2-13

Floppy Disk Drive Connector: FDD1........................................... 2-13

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-14

ATA133 RAID Connectors: IDE3 & IDE4 (Optional) .................. 2-15

CD-InConnector:JCD1 ............................................................... 2-16

IrDA Infrared Module Header: JIR1 ............................................ 2-16

Fan Power Connectors: CFAN1/SFAN1/PFAN1 ......................... 2-17

Power Saving Switch Connector: JGS1........................................ 2-18

Chassis Intrusion Switch Connector: JCI1 .................................. 2-18

Bluetooth Connector: JBT1 (Optional) ........................................ 2-19

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-20

Front Panel Audio Connector: JAUD1 ........................................ 2-21

FrontUSBConnector: USB1/USB3 ............................................. 2-22

SPDIF Connector: JSP1 or JSP3 ................................................... 2-24

D-Bracket™2 Connector:JDB1 .................................................. 2-26

Jumpers .............................................................................................. 2-27

Clear CMOS Jumper:JBAT1 ........................................................ 2-27

Slots ................................................................................................... 2-28

AGP (Accelerated Graphics Port) Slot......................................... 2-28

PCI Slots ...................................................................................... 2-28

CNR(Communication NetworkRiser) ......................................... 2-29

PCI Interrupt Request Routing .................................................... 2-29

Chapter3. BIOSSetup.............................................................................. 3-1

Entering Setup......................................................................................3-2

Selecting the First Boot Device .....................................................3-2

Control Keys ................................................................................. 3-3

Getting Help .................................................................................. 3-3

vii

The Main Menu ................................................................................... 3-4

Standard CMOS Features .................................................................... 3-6

Advanced BIOS Features .................................................................... 3-8

Advanced Chipset Features............................................................... 3-12

Power Management Features............................................................. 3-14

PNP/PCI Configurations..................................................................... 3-18

Integrated Peripherals ........................................................................ 3-21

PC Health Status ................................................................................ 3-24

Frequency/Voltage Control ................................................................ 3-25

Set Supervisor/User Password........................................................... 3-27

Load High Performance/BIOS Setup Defaults.................................... 3-28

Appendix:Using4-or6-ChannelAudioFunction ....................................A-1

Installing the Audio Driver .................................................................A-2

Installation for Windows 98SE/ME/2000/XP ................................A-2

Using 4- or 6-Channel Audio Function ...............................................A-4

Attaching Speakers ......................................................................A-4

Selecting 4- or 6-Channel Setting .................................................A-9

Testing the Connected Speakers.......................................................A-11

Testing Each Speaker ................................................................. A-11

PlayingKaraOK ................................................................................A-12

PlayingKaraOK ..........................................................................A-12

Glossary ....................................................................................................G-1

Getting Started

1-1

Chapter 1. Getting Started

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

MSI Special Features 1-6

Getting Started

Thank you for purchasing the MS-6398E v1.X ATX mainboard. The MS-

6398E v1.X is based on Intel®Brookdale-E & ICH4 chipsets for optimal system

efficiency. Designed to fit the advanced Intel®Pentium®4 processors in the

478 pin package, the MS-6398E delivers a high performance and professional

desktop platform solution.

Chapter 1

1-2

CPU

Supports Intel®Pentium®4 processor in 478 pin package.

Supports1.5GHz,1.6GHz,1.7GHz,1.8GHz,1.9GHz,2GHz,2.1GHz,2.2GHz

and up.

Chipset

Intel®Brookdale-E chipset

- Support 100MHz/133MHz system clock.

- Intel NetBurst micro-architecture supports 400MHz/533MHz system bus.

- 1.5V AGP interface with 4x data transfer and 4x fast write capability.

Intel®ICH4 chipset

- Hi-Speed USB (USB2.0) controller, 480Mb/sec.

- 2 channel Ultra ATA 100 bus Master IDE controller.

- PCI Master 2.2.

- I/O APIC.

- AC’97 2.2 interface.

- 3 UHCI Host controllers and 1 EHCI Host controller.

MainMemory

Supports four memory banks using three 184-pin DDR DIMM.

Supports up to 2GB PC2100/PC1600 DDR SDRAMs.

Supports 2.5v DDR SDRAM.

Slots

One AGP (Accelerated Graphics Port) 4x slot (1.5V only).

Six PCI 2.2 32-bit Master PCI bus slots (support 3.3V/5V PCI bus interface).

One CNR (Communication Network Riser) slot.

On-BoardIDE

An IDE controller on the ICH4 chipset provides IDE HDD/CD-ROM with

PIO, Bus Master and Ultra DMA66/100 operation modes.

Can connect up to four IDE devices.

ATA133 RAID supported by Promise PDC20276.

On-BoardPeripherals

On-Board Peripherals include:

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

Mainboard Specification

Getting Started

1-3

2.88Mbytes.

- 2 serial ports (COM A + COM B).

- 1 parallel port supports SPP/EPP/ECP mode.

- 1 IrDA connector for SIR/ASKIR/HPSIR.

- 1 D-Bracket™ pin header.

- 1 S-Bracket pin header.

- 1 audio/game port.

Audio

Realtek ALC650 6-channel audio

- SPDIF out (through S-Bracket only).

BIOS

The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

The mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications.

Dimension

ATXForm Factor30.5cmx23cm.

Mounting

6 mounting holes.

Others

Modem (External/Internal) Ring Wake Up Function.

LAN Wake Up Function.

Suspend to RAM/Disk.

PC2001Compliant.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere MSI Hauptplatine Handbücher

MSI

MSI MEG Z390 ACE Bedienungsanleitung

MSI

MSI ms 7529 Kurzanleitung

MSI

MSI PRO Z790-P WIFI DDR4 Bedienungsanleitung

MSI

MSI PRO H610M-C EX Bedienungsanleitung

MSI

MSI MPG Z390M GAMING EDGE AC Bedienungsanleitung

MSI

MSI RS480M Bedienungsanleitung

MSI

MSI P4M900M Bedienungsanleitung

MSI

MSI B350 GAMING PRO CARBON Bedienungsanleitung

MSI

MSI B650M GAMING PLUS WIFI Bedienungsanleitung

MSI

MSI H8M-P32 Bedienungsanleitung

MSI

MSI XPOWER GAMING TITANIUM X99A Bedienungsanleitung

MSI

MSI WS WRX80 Bedienungsanleitung

MSI

MSI Z170A SLI PLUS Bedienungsanleitung

MSI

MSI 785G-E65 Series Bedienungsanleitung

MSI

MSI X58A-GD65 series Bedienungsanleitung

MSI

MSI 890FXA-GD65 series Bedienungsanleitung

MSI

MSI 915GVM-V Bedienungsanleitung

MSI

MSI B560-A PRO Bedienungsanleitung

MSI

MSI MS-6528 LE Bedienungsanleitung

MSI

MSI MS-7304 Bedienungsanleitung

MSI

MSI MICRO ATX AL12 Bedienungsanleitung

MSI

MSI 990FXA-GD65 Series Bedienungsanleitung

MSI

MSI A55M-E45 V2 Bedienungsanleitung

MSI

MSI K8MM-V Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
