MSI MS-6575 Bedienungsanleitung

Version 1.0

G52-MA00542

MS-6575 (v1.X) M-ATX Mainboard

MSI

MICRO-STAR INTERNATIONAL

Manual Rev: 1.0

Release Date: March 2002

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party responsible

for compliance could void the users authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIRLANOTICEDINSTALLATIONAVANTDERACCORDERAURESEAU.

Micro-Star International MS-6575

Tested to comply

with FCC Standard

For Home or Office Use

iii

Edition

March 2002

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

V1.0 First release March 2002

Safety Instructions

1. Read the safety instructions carefully.

2. Save this Users Guide for possible use later.

3. Keep this equipment away from humidity.

4. Lay this equipment on a stable and flat surface before setting it up.

5. The openings on the enclosure are used for air convection and to prevent

the equipment from overheating. Note: Do not cover the openings.

6. Make sure that the power voltage is within its safety range and has been

adjusted properly to the value of 110/220V before connecting the equip-

ment to the power inlet.

7. Place the power cord in a way that people are unlikely to step on it. Do not

place anything on the power cord.

8. Always unplug the power cord before inserting any add-on card or module.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage the equipment

or cause an electrical shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

lthe power cord or plug is damaged

lliquid has penetrated into the equipment

lthe equipment has been exposed to moisture

lthe equipment has not work well or you can not get it work according

to Users Guide

lthe equipment was dropped and damaged

lthe equipment has obvious signs of breakage

12. Do not leave the equipment in an unconditioned environment with a stor-

age temperature of 600 C (1400F) or above, which may damage the

equipment.

CAUTION: To prevent explosion caused by improper battery

replacement, use the same or equivalent type of battery recommended

by the manufacturer only.

CONTENTS

Chapter 1. Getting Started ........................................................................ 1-1

Mainboard Specification ...................................................................... 1-2

Mainboard Layout ............................................................................... 1-4

Quick Components Guide .................................................................... 1-5

Chapter 2. Hardware Setup ....................................................................... 2-1

Central Processing Unit: CPU .............................................................. 2-2

CPU Installation Procedures ......................................................... 2-2

Installing the CPU Fan .................................................................. 2-3

CPU Core Speed Derivation Procedure ......................................... 2-4

Memory ................................................................................................ 2-5

Introduction to DDR SDRAM ....................................................... 2-5

DDR Module Combination ............................................................ 2-6

Installing DDR Modules ............................................................... 2-6

Power Supply ....................................................................................... 2-7

ATX 20-Pin Power Connector: CONN1 ......................................... 2-7

ATX 12V Power Connector: JPW1 ................................................ 2-7

Back Panel ............................................................................................ 2-8

Mouse Connector: JKBMS1 ......................................................... 2-9

Keyboard Connector: JKBMS1 ..................................................... 2-9

Joystick/Midi Connectors ........................................................... 2-10

Audio Ports ................................................................................. 2-10

Serial Port Connectors: COM A & COM B (for SiS 645) ............. 2-11

VGA Connector (for SiS 650) ....................................................... 2-11

Parallel Port Connector: LPT1 ...................................................... 2-12

RJ-45 LAN Jack ........................................................................... 2-13

USB Connectors .......................................................................... 2-13

Connectors ......................................................................................... 2-14

Floppy Disk Drive Connector: FDD1........................................... 2-14

IrDA Infrared Module Header: IR1 .............................................. 2-14

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-15

CD-In Connector: CD_IN1 .......................................................... 2-16

CPUFAN1/CHSFAN1/PWRFAN1 ............................................... 2-17

Wake On Ring Connector: JWR1 ................................................ 2-18

Wake On LAN Connector: JWL1 ................................................ 2-18

Power Saving Switch Connector: JSMI1 ..................................... 2-19

Chassis Intrusion Switch Connector: JCI1 .................................. 2-19

Front Panel Connector: JFP1 ....................................................... 2-20

Front Panel Audio Connector: JAUD1 ........................................ 2-21

Front USB Connectors: JUSB1 & JUSB4 ..................................... 2-22

Jumpers .............................................................................................. 2-23

Clear CMOS Jumper: JBAT1 ........................................................ 2-23

BIOS Flash Jumper: JP1 ............................................................... 2-24

Slots ................................................................................................... 2-25

AGP (Accelerated Graphics Port) Slot ......................................... 2-25

PCI Slots ...................................................................................... 2-25

CNR (Communication Network Riser) ......................................... 2-26

PCI Interrupt Request Routing .................................................... 2-26

Chapter 3. AWARD BIOS Setup ............................................................... 3-1

Entering Setup...................................................................................... 3-2

Control Keys ................................................................................. 3-2

Getting Help .................................................................................. 3-3

The Main Menu ................................................................................... 3-4

Standard CMOS Features .................................................................... 3-6

Advanced BIOS Features .................................................................... 3-8

vii

Advanced Chipset Features............................................................... 3-12

Integrated Peripherals ........................................................................ 3-14

Power Management Setup ................................................................. 3-20

PNP/PCI Configurations..................................................................... 3-24

PC Health Status ................................................................................ 3-26

Frequency/Voltage Control ................................................................ 3-27

Load Fail-Safe/Optimized Defaults ..................................................... 3-29

Set Supervisor/User Password ........................................................... 3-30

Getting Started

1-1

Chapter 1. Getting Started 1

Getting Started

Thank you for purchasing the MS-6575 v1.X M-ATX mainboard. The

MS-6575 v1.X is based on SiS 645/650 & SiS 961 chipsets for optimal system

efficiency. Designed to fit the advanced Intel®Pentium®4 processors in the

478 pin package, the MS-6575 delivers a high performance and professional

desktop platform solution.

TOPICS

Mainboard Specification 1-2

Mainboard Layout 1-4

Quick Components Guide 1-5

Chapter 1

1-2

CPU

Support Socket 478 for Intel®Pentium 4 Williamette & Northwood processors

Core Frequency from 1.7 GHz to 2.2 GHz

Chipset

SiS 645/650 HMAL/IGUI HMAL (702-pin BGA)

- High performance host interface (400MHz)

- 64-bit performance DDR333/DDR266/DDR200 memory controller

- Integrated A.G.P. compliant target/66 MHz Host-to-PCI bridge

- High throughput SiS HyperZip connect to SiS961 HyperZip Media I/O

- Dedicated isochronous response queue

SiS 961 HyperZip Media I/O (371-pin BGA)

- High performance HyperZip connect to SiS series NB

- Integrated multi-threaded I/O link ensures concurrency of up/down data

transfer

- Integrated HyperZip connect to PCI bridge

- Dual IDE Master/Slave controller

- Integrated USB host controller Fast Ethernet MAC controller

- Integrated audio controller with AC97 interface

- Advanced power management and PC2001 compliance

- Integrated RTC and DMA Interrupt and Keyboard controller

- Integrated PCI to LPC bridge

MainMemory

Support two 184-pin unbuffered double-sided DDR DIMM

Support up to 2 GB memory size

Slots

One AGP (Accelerated Graphics Port) 1x/2x/4x slot

- support 1.5V/3.3V

Three PCI slots

One CNR (Communication Network Riser) slot

Mainboard Specification

Getting Started

1-3

On-Board IDE

Dual IDE controllers integrated in SiS 961

Support P/O, Bus Master, Ultra DMA 66/100 operation

Can connect up to four IDE devices.

On-Board Peripherals

On-board Peripherals include:

- 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes

- 2 serial ports COM A + COM B (for SiS645, optional)

- 1 VGA port (for SiS 650, optional)

- 1 parallel port

- 1 RJ-45 LAN jack (optional)

- 6 USB ports (Rear x 2/ Front x 4)

- 1 Line-In/Line-Out/Mic-In/Game port

Audio

2 channels S/W audio codec RealTek ALC201A

- Compliance with AC97 v2.1 spec.

- Meet PC2001 audio performance requirement

AC97 link controller integrated in SiS 961

BIOS

The mainboard BIOS provides Plug & Play function which detects the

peripherals devices and expansion cards of the board automatically

The mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications

Dimension

M-ATX Form Factor: 24.4cm x 23.4cm

Mounting

6 mounting holes

Others

Support STR/STD (S3/S4)

Support WOR/WOL (optional)

Andere MSI Hauptplatine Handbücher

MSI

MSI A68HM Bedienungsanleitung

MSI

MSI IA-Q45 Bedienungsanleitung

MSI

MSI Z77A-GD55 series Bedienungsanleitung

MSI

MSI MAG B550 TOMAHAWK Bedienungsanleitung

MSI

MSI MAG B550 TOMAHAWK Bedienungsanleitung

MSI

MSI B350 TOMAHAWK Bedienungsanleitung

MSI

MSI A68H PC Mate Bedienungsanleitung

MSI

MSI MPG B550I GAMING EDGE WIFI Bedienungsanleitung

MSI

MSI MS-6791 Bedienungsanleitung

MSI

MSI Z77A-G45 GAMING series Bedienungsanleitung

MSI

MSI MPG X570S Carbon EK X Bedienungsanleitung

MSI

MSI MS-CF02 Bedienungsanleitung

MSI

MSI B75A-E33 Series Bedienungsanleitung

MSI

MSI P4M900M3-L Bedienungsanleitung

MSI

MSI PRO B660M-A WIFI DDR4 Bedienungsanleitung

MSI

MSI K9N2 SLI PLATINUM - Motherboard - ATX Bedienungsanleitung

MSI

MSI X299 RAIDER Bedienungsanleitung

MSI

MSI MS7797 Bedienungsanleitung

MSI

MSI B450 GAMING PRO CARBON AC Bedienungsanleitung

MSI

MSI 845 Pro2-C Bedienungsanleitung

MSI

MSI Z270I GAMING PRO CARBON AC Bedienungsanleitung

MSI

MSI 845E Max2 Series Bedienungsanleitung

MSI

MSI G52-74111X2 Bedienungsanleitung

MSI

MSI Z390-A PRO Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
