Instruction manual

MULTIPICK ARTEMIS

Valid as of: 03/2022

Original operating instructions in

English language. Save for future

use!

Distributed by: Multipick

Godesberger Str. 51

D-53175 Bonn

[email protected]

multipick.com

1.0.0 Introduction

• These operating instructions should be available to the user at all times.

• These operating instructions are meant to help you

- to familiarise yourself with the MULTIPICK ARTEMIS,

- to use the MULTIPICK ARTEMIS for its intended purpose,

- to use the MULTIPICK ARTEMIS in an optimal way.

• Please read these operating instructions carefully!

It contains important information on how to use the MULTIPICK ARTEMIS:

- safely and

- properly.

• Observing them is the assurance of:

- the safety of the user

- the prevention of harmful situations.

 -awlessoperationoftheMULTIPICKARTEMIS.

• We take no responsibility for damage and malfunctions resulting from non-

observance of these operating instructions.

1.1.0 Warranty

The warranty applies in accordance with our General Terms and Conditions

(GTC) in the version valid at the time of delivery.

1.2.0 Disclaimer

• Multipick is not liable for any damage and costs incurred

due to improper use.

• The use of MULTIPICK ARTEMIS is permitted exclusively

for commercial and legal use.

2.0.0 Safety - Accident Prevention

2.1.0 Warnings and special indications

In the operating instructions, the following symbols are used for safety instructions

and information:

Situation. Failure to observe this warning may result in minor inju-

ries. Special warnings and precautions to prevent damage.

Special warnings and precautions to prevent

damage.

Specialinformationregardingefcientuseaswell

as important additional information.

Indicates an imminent danger. Failure to adhere to

the warning may result in death or serious injury.

Indicates a potentially hazardous situation. Failure to

follow the warning may result in serious injury.

2.2.0 Intended use

• The MULTIPICK ARTEMIS may only be deployed to open a cylinder lock.

Any other use or use beyond this is considered unintended use! The

manufacturer/supplier is not liable for any damage resulting from this. The risk

is borne solely by the user.

• Before operating the MULTIPICK ARTEMIS beyond the intended purpose

described above, the customer service of Multipick must be consulted, to avoid

the loss of warranty.

• Observing the operating instructions is also part of the intended use.

• The MULTIPICK ARTEMIS may only be serviced and repaired by

 qualiedpersonnel.

• The MULTIPICK ARTEMIS may only be used with original

accessories from Multipick.

In the event of incorrect operation or misuse, there is a risk of

dangerto:-materialassets-theefcientfunctioningofthe

MULTIPICK ARTEMIS

2.4.1 How to react in emergency situations

By releasing the control button, any movement will be stopped immediately.

stopped.

2.5.0 Noise emission

The equivalent A-weighted continuous sound level is less than 70 dB(A).

3.0.0 Technical data

3.1.0 Dimensions, weights etc.

Length: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181 mm

Diameter: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 mm

Weight incl. battery: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0,190 kg

Idling speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 9.500 U/min

Needledeectionattheendoftheneedlechuck:............1-4mm

3.2.0 Battery

Lithium-ionrechargeablebattery.....................3,7V,1400mA

• NEVER leave the device unattended and within reach

of children.

• NEVER remove safety ttings or put them out of

operation by alteration.

• It is not permitted to operate the MULTIPICK ARTEMIS

with technical defects.

• Always use original Multipick spare parts. Only they

meet the specied technical requirements.

• Only use protected Li-Ion rechargeable batteries.

2.3.0 Improper handling

• Using the device without instructions

• Using the device beyond the intended purpose (legal use, etc.)

• Opening the MUTLIPCIK ARTEMIS

• Deliberately negligent or careless handling of the device

• injuring a third party

2.4.0 Potential hazards - Accident prevention

Do not touch the moving parts when the device is switched on. There is a risk of

injury here! The MULTIPICK ARTEMIS is constructed according to state-of-the-

art technology and conforms to the approved safety regulations. Compliance with

the relevant work safety and accident prevention regulations are assumed. It is

recommended to wear protective eyewear when working with the Artemis. Remo-

ve the batteries prior to changing a pick needle.

(There is a possibility that the device may accidentally switch on when changing

the batteries).

4.0.0 CE-mark

The MULTIPICK ARTEMIS is built in accordance with the currently valid

EC directives and bears the CE-mark.The enclosed declaration of

conformitylosesitsvalidityiftheMULTIPICKARTEMISismodiedor

altered without our consent.

5.0.0 Scope of delivery of the MULTIPICK ARTEMIS

• 1 Multipick Artemis electric pick gun

• 1 Charging cradle for 2 batteries incl. USB charging cable and charger

•2Li-Ionhigh-performancebattery3.7V/1400mAh

• 3 Elite pick needles 0.5 mm (item no. 11500P)

• 3 Elite pick needles 0.6 mm (item no. 11500P-6)

• 1 Elite pick needle EPN02 (item no. 11501)

• 1 Elite pick needle EPN15 ( item no. 11515)

• 1 Elite tensioner - 03 ( item no. MP3SP03)

• 1 Elite tensioner - 06 ( item no. MP3SP06)

• 1 Elite tensioner - 23 (Article no. MP3SP23)

• 1 Hex key T10 Torx for needle change

• 1 Spare needle clamp with Torx screw

• 1 Online manual (download)

• 1 Secure carrying case with foam insert

5.1.0 Advantages of the Multipick Artemis

•Lightweightconstructionmadeofthenestaluminium

• Smooth and quiet running

•Verynelyadjustableamplitudedeection

• Li-Ion battery technology

• Can be used with all Multipick ELITE pick needles

• Ergonomic handgrip

• Made in Germany

• Soft-touch coating in colours of red, black and green-grey

• Non-slip surface due to Sotf-Touch

• Powerful quality motor

• Two years warranty

The MULTIPICK ARTEMIS is shipped with protected

lithium-ion batteries.

• As soon as the motor rpm drops, replace the batteries

immediately with fully charged fresh ones.

• Never drain the battery completely. This could

destroy the battery.

3.2.1 Charging the battery

The scope of delivery includes an appropriate charger for charging both batteries

at the same time. If you use your own charger, make sure to use it accordingly.

Only use protected lithium-ion batteries.

5.2.0 Warranty

The MULTIPICK ARTEMIS is covered by a two-year warranty from the date of

purchase.

6.0.0 Operating the MULTIPICK ARTEMIS

6.1.0 Inserting the batteries

To insert the batteries, unscrew the battery cover. Now you can insert the batte-

ries. Pay attention to the + and - poles. The positive pole must face towards the

front. The cover is the negative pole.

To insert the batteries (2), proceed as follows:

1. Unscrew the battery cover (1).

2. Insert the Li-Ion batteries (2).

3. Screw the battery cover (1) back on, done.

• Only use protected Li-Ion batteries.

• Do not use batteries that are faulty (deformed).

Make sure that you insert the battery with the correct polarity.

+++ Attention +++

+ Pol - Pol

6.2.0 Inserting the pick needle

Unscrew the clamping screw (7) with the supplied Allen key.

Insertthepickneedle(4)intothegap(5)betweenholder(8)andclamp(6)and

push the pick needle as far as it goes.

Tightentheclampingscrew(7)withthehexkeyTorxT10untiltheneedleisrmly

seated.

Now the MULTIPICK ARTEMIS is ready for use.

6.3.0 Working with the MULTIPICK ARTEMIS

6.3.1 Switching the MULTIPICK ARTEMIS on and off

9 10

To switch on the Multipick ARTEMIS, press the button on top of the device.

As soon as you release the button (10), the ARTEMIS is switched off.

6.3.2 Adjusting the amplitude

With the adjustment screw (9) on the top of the device you can adjust the amplitu-

dedeectionwithinarangeof1-4mmduringoperation.Thepressurespringon

the adjustment screw holds the adjusted position.

Turn the adjusting screw (9) to the left (counterclockwise):

- Amplitude is increased

Turn the adjusting screw (9) to the right (clockwise):

-Amplitude is decreased

6.3.3 Operation

The continuous operating time should not exceed 10 minutes.

A strong heating of the motor and the housing is possible. In case the pick need-

le jams inside the cylinder or if the pressure is too high, the operation has to be

brieystopped.Thereisadangerthatthemotorcouldgetoverloadedandthat

electronic components might suffer damage. Furthermore, it can happen that

the batteries may also suffer strain. However, this is protected by the protective

mechanism. As a result, the motor will stop and the device cannot be operated for

aperiodofapprox.2to4seconds.Onlyprotectedrechargeablebatteriesmustbe

used to operate the E-Pick.

To ensure safe operation, only E-Pick needles from our company should be used.

The E-Pick needles should only be changed when the device is switched off. Re-

move the battery to prevent it from being switched on accidentally.

6.4.0 Maintaining your device

Your device has been designed and manufactured with utmost care and should

also be treated with care. The following recommendations should help you to

maintain your warranty rights.

• Store the unit in a dry place. Precipitation, humidity and all

types of liquids and moisture may contain minerals that cause

electronic circuitry to corrode.

• If the unit gets wet, remove the batteries and allow the device

to dry completely before reinserting the batteries.

• Do not use or store the device in environments that are dusty

or dirty. Doing so, moving parts and electronic components

may be damaged.

6.5.0 Storage and careful handling

• Never expose the MULTIPICK ARTEMIS to extremely high or

low temperatures.

• Large temperature uctuations can cause condensation to form

inside the device. This can lead to corrosion and damage to the

circuitry.

• Avoid dropping the unit. Shocks, blows and other impacts can

cause damage to the circuitry or mechanical parts.

• Clean the MULTIPICK ARTEMIS only with a clean, dry and soft

cloth.

• The use of cleaning agents can damage the surface of the MUL

TIPICK ARTEMIS.

• High temperatures, such as those caused by strong sunlight

or storage near hot surfaces, can damage the circuitry and

even lead to the risk of explosion.

7.0.0 Disposal

This product must not be disposed of with normal household trash

at the end of its operating lifetime.

Make sure that accumulators, batteries, consumables and spare

parts are disposed of in an environmentally friendly manner.

By bringing it to the appropriate recycling and disposal centre,

you are making an important contribution to the protection of our

environment.

Thecopyrighttothismanualremainswithus.Thespecicationsand

technical drawings in this manual may not be reproduced in whole or

in part, neither may their contents be passed on to other parties.

7.1.0 Copyright

Andere Multipick Werkzeuge Handbücher

Multipick

Multipick KRONOS Bedienungsanleitung

Beliebte Werkzeuge Handbücher anderer Marken

Martor

Martor SECUNORM 175 Bedienungsanleitung

ERKCO

ERKCO 1000 Bedienungsanleitung

jbc

jbc N4473 Bedienungsanleitung

FEINMETALL

FEINMETALL FZWZ-SET-001 Bedienungsanleitung

Worx Professional

Worx Professional Sonicrafter WU676 Bedienungsanleitung

Gage Bilt

Gage Bilt GB713SH Bedienungsanleitung

Hilti

Hilti DX 9-ENP Bedienungsanleitung

norbar

norbar NORTRONIC 34399 Bedienungsanleitung

BGS technic

BGS technic 8578 Bedienungsanleitung

Makita

Makita DHR241 Bedienungsanleitung

Motor Guard

Motor Guard JMB-1250 Bedienungsanleitung

Power Adhesives

Power Adhesives 805-12 Bedienungsanleitung

Clemco

Clemco 24189 Bedienungsanleitung

VVG

VVG VNG 903 Series Bedienungsanleitung

Hilti

Hilti FX 3-A Bedienungsanleitung

Grizzly

Grizzly H6472 Bedienungsanleitung

axing

axing BWZ 5-02 Bedienungsanleitung

Dh-Robotics

Dh-Robotics RGI-100 Anleitung zur Verwendung
