Multitech MultiMobile MT5634ZLX Bedienungsanleitung

MultiMobile Modem Family

PC Card Modem

MT5634ZLX

MT5634ZLXI

MT5634ZLX/FE

Quick Start Guide

MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE

P/N 82001650 Revision A

expressed written permission from Multi-Tech Systems, Inc.

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents

hereof and specifically disclaims any implied warranties of merchantability or fitness for any

particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this

publication and to make changes in the content hereof without obligation of Multi-Tech

Systems, Inc. to notify any person or organization of such revisions or changes.

Revision Date Description

A 07/30/02 MT5634ZLX MultiMobile Family Quick Start initial release.

08/04/03 Changed the paper size setting to make it consistent with other guides.

Send out for printing without changing the Revision number.

Patents

4,453,450; 4,603,320; 4,686,506; 4,972,470

Trademarks

MultiMobile and the Multi-Tech logo are trademarks of Multi-Tech Systems, Inc.

Adobe and Acrobat are trademarks of Adobe Systems Incorporated. Microsoft, Windows is

either a registered trademark of Microsoft Corporation in the United States and/or other

countries. All other brands and product names mentioned in this publication are registered

trademarks of their respective companies.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, MN 55112

U.S.A

Telephone (763) 785-3500 or (800) 328-9717

Fax (763) 785-9874

Internet http://www.multitech.com

Technical Support

Country By Email By Phone

France support@multitech.fr +(33) 1-64 61 09 81

India support@multitechindia.com +91 (124) 6340778

U.K. support@multitech.co.uk +(44) 118 959 7774

U.S. and Canada support@multitech.com (800) 972 -2439

Rest of the World support@multitech.com +(763) 717-5863

Note the status of the modem before contacting Technical Support. The status can include

information about LED indicators, screen messages, diagnostics test results, problems with an

application, etc.

Recording Your Modem Information

Record the following information about your Multi-Tech modem before calling Technical

Support.

Modem Model Number:

Modem Serial Number:

These numbers are printed on the bottom of the modem.

MultiMobile Modem Family Quick Start Guide

MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE 1

Getting Started

This Quick Start Guide will help you install and set up your MultiMobile

PC Card modem. A User Guide containing detailed configuration

information, a command reference, a troubleshooting chapter, and an

index can be found on the MT5634ZLX CD. The User Guide, which is in

Adobe Acrobat 4.0 format, can be viewed on your monitor or printed for

easy reference.

The MT5634ZLX is designed for use in the United States and Canada.

The MT5634ZLXI is designed for use world-wide.

The MT5634ZLX/FE is designed for use in the United States, Canada,

and Europe.

The MT5634ZLX/FE can connect to an enterprise LAN as well as the

Internet.

Safety Warnings

·Use this product only with UL- and CUL-listed computers.

·To reduce the risk of fire, use only 26 AWG (.41mm) or larger telephone

wiring.

·Never install telephone wiring during a lightning storm.

·Never install a telephone jack in a wet location unless the jack is

specifically designed for wet locations.

·Never touch uninsulated telephone wires or terminals unless the

telephone line has been disconnected at the network interface.

·Use caution when installing or modifying telephone lines.

·Avoid using a telephone during an electrical storm; there is a risk of

electrical shock from lightning.

·Do not use a telephone in the vicinity of a gas leak.

MultiMobile Modem Family Quick Start Guide

2 MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE

We Supply

Your modem package has several components. Please make sure you

have all parts before trying to operate your modem. The MT5634ZLX,

MT5634ZLXI, and MT5634ZLX/FE packages contain the following:

MT5634ZLX and MT5634ZLXI MT5634ZLX/FE

MT5634ZLX, MT5634ZLXI

MultiMobile PC Card modem

MT5634ZLX/FE

MultiMobile PC Card modem

This Quick Start Guide is included with each modem.

An MultiMobile Modem CD containing modem drivers, the User Guide, a

data communications software program, and Acrobat Reader is inlcuded

with each modem.

MT5634ZLX MT5634ZLXI MT5634ZLX/FE

RJ-11 adapter cable RJ-11 telephone cord RJ-11 telephone cord

One Modem-LAM (Line

Adapter Modules)

Two LAMs (Line

Adapter Modules)

·One Modem-LAM

·One Ethernet-LAM

MultiMobile Modem Family Quick Start Guide

MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE 3

Installing the MT5634ZLX Card

1. Insert the MT5634ZLX Card into the laptop’s PCMCIA slot. Be sure

that the label is facing up.

2. Plug 15-pin adapter end of the telephone cord into the MT5634ZLX

Card.

3. Plug the other end of the RJ-11 into an available telephone wall jack.

This connects you to the PSTN (Public Switched Telephone Network).

MT5634ZLX Connections

MultiMobile Modem Family Quick Start Guide

4 MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE

Installing the MT5634ZLXI Card

1. Insert the MT5634ZLXI Card into the laptop’s PCMCIA slot. Be sure

that the label is facing up.

2. Plug the Modem-LAM (Line Adapter Module) into the modem port of

the PC Card.

3. Plug one end of the RJ-11 telephone line cord into the open end of the

Modem-LAM (this is the LAM’s RJ-11 receptacle side).

4. Plug the other end of the RJ-11 into an available telephone wall jack.

This connects you to the PSTN (Public Switched Telephone Network).

5. With your PC turned on, verify the operation of the LEDs.

OH (Off-Hook) light on means that the MT5634ZLXI is dialing, is

online, or answering a call.

CD (Carrier Detect) light on means that a valid carrier signal from

another modem is detected.

RD (Receive Data) light flashes when data is being received.

TD (Transmit Data) light flashes when data is being transmitted.

MT5634ZLXI Connections

MultiMobile Modem Family Quick Start Guide

MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE 5

Installing the MT5634ZLX/FE Card

1. Insert the MT5634ZLX/FE Card into the computer’s PCMCIA slot. Be

sure that the label is facing up.

2. Plug the Modem-LAM (Line Adapter Module) into the modem port of

the PC Card.

3. Plug one end of the RJ-11 telephone line cord into the open end of the

Modem-LAM (this is the LAM’s RJ-11 receptacle side).

4. Plug the other end of the RJ-11 into an available telephone wall jack.

This connects you to the PSTN (Public Switched Telephone Network).

5. Plug the Ethernet-LAM into the Ethernet port of the PC Card.

6. Plug one end of either a UTP or an STP cable into the Ethernet-LAM.

7. Plug the other end of the UTP/STP cable into the Ethernet LAN.

8. Installation of the driver for the MT5634ZLX/FE: When prompted for

drivers, choose the Advanced path and browse to the Drivers_FE folder

and then to the appropriate subfolder for your Windows version.

MT5634ZLX/FE Connections

MultiMobile Modem Family Quick Start Guide

6 MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE

Installing the Modem Driver

You must install the modem’s driver onto the hard drive of your laptop PC.

If you are using Windows 95/98/Me/2000/XP, the driver is installed with

Windows’ Plug and Play feature. For Windows NT, which does not support

Plug and Play, see the Modem Driver Installation for Windows NT below.

Modem Driver Installation for Windows 95/98/Me/2000/XP

1. Make sure your modem PC card is connected properly, and then turn

on your laptop PC. Windows should detect your new modem and

open the install New Modem wizard.

2. Insert the MT5634ZLX Modem Family CD into your laptop PC’s CD-

ROM drive, and then click OK.

3. Windows installs the modem driver.

4. Installing the ZLX/FE drivers requires you to select the Advanced

option. Then browse the Drivers_FE folder and select the appropriate

subfolder.

5. Click Finish to exit.

Modem Driver Installation for Windows NT

1. Make sure your modem PC card is connected properly, and then turn

on your laptop PC. Windows should detect your new modem and

open the install New Modem wizard.

Note: If Windows cannot find a modem, your modem may not be

connected properly. Check your connections.

2. In the Install New Modem wizard, select Don’t detect my modem; I will

select it from a list, and then click Next.

3. Insert the MT5634ZLX CD into your laptop PC’s CD-ROM drive, and

then click Have Disk.

4. In the Install from Disk dialog box, select the drive that the CD is in,

and then click OK.

5. A list of modems appears. Select your modem and click Next.

6. Select the port that the modem is connected to, and then click Next.

7. Windows installs and configures the modem driver.

8. Click Finish to exit.

MultiMobile Modem Family Quick Start Guide

MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE 7

Loading Data Communication Software

Data communications software is designed to enable your modem to send

and receive data. Multi-Tech has included a communications software

program, Phone Tools, with your modem.

To install Phone Tools:

·Insert the MultiMobile CD into your laptop’s CD-ROM drive

·Click on the Phone Tools icon.

·You will be asked to choose your language.

·The software automatically loads onto your laptop.

Important: How to Eject the PC Card

The PC Card is a hot-swappable card. However, when the

MT5634ZLX/FE is connected to a LAN and transferring data, it is

recommended that you use the following steps to eject the PC Card if you

choose to do so during this process. Removing the PC Card during this

process without following these steps could cause Windows to lock up.

1. On the task bar, click the PCMCIA icon.

2. Select Stop MultiMobile Mt5634ZLX PCMCIA.

3. The Safe to Remove Hardware dialog box displays. Click OK.

4. Eject the PCMCIA adapter.

MultiMobile Modem Family Quick Start Guide

8 MT5634ZLX, MT5634ZLXI, MT5634ZLX/FE

Configure the Modem for Your Country

Note: Country configuration applies to:

·The MT5634ZLXI is designed for use world-wide.

·The MT5634ZLX/FE is designed for use in Europe, Canada, and the

United States.

Different countries have different requirements for how modems must

function. Therefore, before you use your modem, you must configure it to

match the defaults of the country in which you are using it. You can use

one of two configuration methods:

·Using the Global Wizard to Configure Your Modem

·Using AT Commands to Configure Your Modem

Using the Global Wizard to Configure Your Modem

The Global Wizard configuration utility is recommended for computers

running in Windows.

1. Insert the MT5634ZLX CD into the CD-ROM drive. The Autorun

dialog box appears.

2. Click Initial Setup and Country Selection.

3. Choose either:

·Run Global Wizard from CD.This option will not load the wizard

onto your hard drive, or

·Install Global Wizard on the HD. This option installs the wizard

onto your hard drive for future use.

4. The Global Wizard dialog box appears. Click Next.

5. The Global Wizard searches for your modem and identifies it. Click

Next.

6. Select the country in which the modem will be used, and then click

Next.

7. Review your choice of country. If it is correct, click Next to configure

the modem.

8. When Global Wizard announces that the parameters have been set,

click Finish to exit.

Andere Handbücher für MultiMobile MT5634ZLX

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Multitech Modem Handbücher

Multitech

Multitech MultiModem MT5600ZDX Bedienungsanleitung

Multitech

Multitech IWay MTA128ST Bedienungsanleitung

Multitech

Multitech MultiConnect rCell 100 Series Bedienungsanleitung

Multitech

Multitech MTCBA-C-U Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZPX Bedienungsanleitung

Multitech

Multitech MultiConnect microCell MTCM2-L4G1 Bedienungsanleitung

Multitech

Multitech MT2834MR Technisches Handbuch

Multitech

Multitech MultiModem Cell MTCBA-E1 Bedienungsanleitung

Multitech

Multitech MultiModem ISI ISI3334/4 Bedienungsanleitung

Multitech

Multitech MultiConnect microCell Bedienungsanleitung

Multitech

Multitech MultiModem Cell MTCBA-E1-U Bedienungsanleitung

Multitech

Multitech MultiModemISDN MTA128ST-USB Bedienungsanleitung

Multitech

Multitech MT9234MU-CDC-XR Bedienungsanleitung

Multitech

Multitech MultiModem MT9234ZPX-UPCI Bedienungsanleitung

Multitech

Multitech V.92 Desktop Modems MultiModem ZDX Bedienungsanleitung

Multitech

Multitech MultiModem IND MT5634IND Bedienungsanleitung

Multitech

Multitech SocketModem Series Anwendungshandbuch

Multitech

Multitech MultiModem MT5600DSDV2 Bedienungsanleitung

Multitech

Multitech MTCBA-E Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZPX Bedienungsanleitung

Multitech

Multitech SocketModem Cell Cat M1 Anwendungshandbuch

Multitech

Multitech MultiConnect Cell 100 series Bedienungsanleitung

Multitech

Multitech Multimodem RJ-45 Bedienungsanleitung

Multitech

Multitech 5634 Series Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
