Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 2

AT Commands Reference Guide

The Following Products Use This Command Set:

External Modems:

MultiModem®ZBA (MT5634ZBA Series, MT5634ZBA-USB, MT5634IND, MT5634ZBA-DID)

Internal Modems:

MultiModem®ZPX (MT5634ZPX-PCI Series, MT5634ZPX-ISA)

Server Cards:

MultiModem®ISI (SI5634UPCI Series)

Legacy Modems:

MultiModem®(MT5634ZLX Series)

PN S000272J, Version J

This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi-

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and specifically

disclaims any implied warranties of merchantability or fitness for any particular purpose. Furthermore, Multi-Tech

Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

Revisions

Revision Level Date Description

A 10/30/02 Initial release.

B 02/24/03 Change +PIG=0 to enable PCM upstream with default 1.

Add #CBS4. Add +VRID.

C10/01/03 The guide is now applicable to the ISI5634PCI.

D 11/17/03 This guide is now applicable to the MT5634ZPX-ISA. Explained the default for

the S-Register S0: the default for internal modems is 0 while the default external

modems is 1.

E 01/04/05 Removed \X command. Added &L for the MT5634IND. Added Index cross-

references. Changed font.

F 12/30/05 Changed the description of \N1. Added a chapter on setting country codes.

G 04/11/07 Updated the Technical Support contact list.

H 12/28/07 Changed Technical Support contact list.

I02/05/10 Updated the $FC command.

J09/02/10 Updated Chapter 4, Setting Your Country/Regional Code.

Added the default (0) to &L, Leased-Line Operation.

Added a note and example to S-Registers regarding Range and Default as

dependent upon country code.

Added examples of S-Register ranges and defaults as determined by country

codes.

10/07/10 Updated the Multi-Tech web link to the global configuration page.

Trademarks

MultiModem and the Multi-Tech logo are Registered Trademarks of Multi-Tech Systems, Inc.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

Phone: 763-785-3500 or 800-328-9717

Fax: 763-785-9874

Internet Address: http://www.multitech.com

Technical Support

Please the Copyright/Technical Support page of the product User Guide or Developer Guide.

Downloaded from Arrow.com.Downloaded from Arrow.com.

Contents

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 3

Contents

Chapter 1 - AT Commands............................................................................................................................................4

Introduction..............................................................................................................................................................4

List of General Commands .....................................................................................................................................5

List of V.92 Commands ...........................................................................................................................................6

List of Caller ID Commands ....................................................................................................................................6

List of Callback Commands....................................................................................................................................6

List of Escape Commands ......................................................................................................................................7

List of DID Commands.............................................................................................................................................7

AT Commands Detail...............................................................................................................................................8

V.92 Commands.....................................................................................................................................................17

Caller ID Commands..............................................................................................................................................21

Callback Security Commands...............................................................................................................................22

Escape Sequence Commands..............................................................................................................................23

DID Commands ......................................................................................................................................................24

Chapter 2 - S-Registers...............................................................................................................................................26

Examples of Ranges and Defaults Determined by Country Codes......................................................................28

Chapter 3 - Result Codes............................................................................................................................................29

Chapter 4 – Setting Your Country or Regional Code................................................................................................30

Index .............................................................................................................................................................................31

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 4

Chapter 1 - AT Commands

Introduction

The AT commands are used to control the operation of your modem. They are called AT commands because the

characters AT must precede each command to get the ATtention of the modem.

AT commands can be issued only when the modem is in command mode or online command mode. The modem

is in command mode whenever it is not connected to another modem. The modem is in data mode whenever it is

connected to another modem and ready to exchange data. Online command mode is a temporary state in which

you can issue commands to the modem while connected to another modem. To put the modem into online

command mode from data mode, you must issue an escape sequence (+++) followed immediately by the AT

characters and the command, e.g., +++ to hang up the modem. To return to data mode from online command

mode, you must issue the command ATO.

To send AT commands to the modem you must use a communications program, such as the HyperTerminal

applet in Windows 98/95 and NT 4.0, or some other available terminal program. You can issue commands to the

modem either directly, by typing them in the terminal window of the communications program, or indirectly, by

configuring the operating system or communications program to send the commands automatically. Fortunately,

communications programs make daily operation of modems effortless by hiding the commands from the user.

Most users, therefore, need to use AT commands only when reconfiguring the modem; e.g., to turn autoanswer

on or off.

The format for entering an AT command is ATXn, where Xis the command and nis the specific value for the

command, sometimes called the command parameter. The value is always a number. If the value is zero, you

can omit it from the command; thus, AT&W is equivalent to AT&W0. Most commands have a default value,

which is the value that is set at the factory.

You must press ENTER (depending on the terminal program it could be some other key) to send the command

to the modem. Any time the modem receives a command, it sends a response known as a result code. The

most common result codes are OK, ERROR, and the CONNECT messages that the modem sends to the

computer when it is connecting to another modem.

You can issue several commands in one line, in what is called a command string. The command string begins

with AT and ends when you press ENTER. Spaces to separate the commands are optional; the command

interpreter ignores them. The most familiar command string is the initialization string, which is used to

configure the modem when it is turned on or reset, or when your communications software calls another modem.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 5

List of General Commands

Command Description

AT Attention Code

A Answer

A/ Repeat Last Command

B Communication Standard Setting – Bell or CCITT

D Dial

%M Enable Dialing Message

DS=nDial Stored Telephone Number

E Echo Command

F Echo Online Data Characters

H Disconnect (Hang Up)

I Information Request

L Not Applicable

M Monitor Speaker Mode

N Modulation Handshake

O Return to Online Data Mode

P Set Pulse Dial Default

Q Result Codes Enable/Disable

Sr=n Set Register Value

Sr? Read Register Value

T Set Tone Dial Default

V Result Code Format

W Result Code Options

X Result Code Selection

Z Modem Reset

&C Data Carrier Detect (DCD) Control

&D Data Terminal Ready (DTR) Control

&E XON/OFF Pacing Control

&F Restore Factory Settings (Configuration)

&G Select Guard Tone Control

&K Flow Control Selection

&L Leased-Line Operation

&Q Asynchronous Communication Mode (same as \N Error Correction Mode)

&S Data Set Ready (DSR) Control

&T Loopback Tests

&V Display Current Settings (Configuration and Stored Profiles)

&W Store Current Settings (Configuration and Stored Profiles)

&Zn=x Store Dialing Command

\A Select Maximum MNP Block Size

\B Transmit Break to Remote

\K Break Control

\N Error Correction Mode Selection

\Q Flow Control Selection

\T Inactivity Timer

\V Protocol Result Code

-C Data Calling Tone

%A Adaptive Answer Result Code Enable

%B View Numbers in Blacklist

%C Data Compression Enable/Disable

%DC AT Command Control

%DT “AT” Command Timer

%E Fallback and Fall Forward Control

%H Direct Connect Enable

%R Cisco Configuration

%S Response Speed

$D DTR Dialing

$EB Asynchronous Word Length

$LB Long Break

$RP Response Priority

$SB Serial Port Baud Rate

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 6

List of V.92 Commands

Command Description

+PCW=nCall Waiting Enable

+PIG=nPCM Upstream Enable

+PMH=nModem-on-Hold Enable

+PMHF V.92 Modem Hook Flash

+PMHR=nModem-on-Hold Initiate

+PMHTR=nModem-on-Hold Timer

+PQC=nQuick Connect Control

+DCS=x,y Select V.44 Data Compression

+DR=nV.44 Data Compression Reporting

+DS44=nV.44 Data Compression

+MS Modulation Selection

$FC Quick Connect

List of Caller ID Commands

Command Description

+VCID Caller ID Enable/Disable

+VDR=x,y Distinctive Ring Report “ERROR”

+VRID Allows query of modem’s last call received

List of Callback Commands

These commands are used with modems that support Callback Security

Command Description

#CBA Callback Attempts

#CBD Callback Delay

#CBF? Callback Failed Attempts Display

#CBFR Callback Failed Attempts Reset

#CBI Local Callback Inactivity Timer

#CBNy=x Store Callback Password

#CBP Callback Parity

#CBR Callback Security Reset

#CBS Callback Enable/Disable

#P Set 11-bit Parity

#SxEnter Setup Password

#S=xStore Setup Password

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 7

List of Escape Commands

Command Description

+++AT Escape Sequence

%%%ATMTSMODEM Remote Configuration Escape Sequence

List of DID Commands

Command Description

*DD Digit Format

*DF Format for Reporting Incoming DID Number

*DS Start Protocol

*DT Wait for Digit Time-Out Time

*DW Busy Out After Call Completion

*DN Number of DID Digits

*DW Busy Out After Call Completion

*DN Number of DID Digits

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 8

AT Commands Detail

Command: AT Attention Code

Values: n/a

Description: The attention code precedes all command lines except A/ and escape sequences.

Command: A Answer

Values: n/a

Description: Answer an incoming call before the final ring.

Command: A/ Repeat Last Command

Values: n/a

Description: Repeat the last command string. Do not precede this command with AT. Do not press ENTER

to execute.

Command: Bn Communication Standard Setting

Values: n= 0-3, 15, 16

Default: 1 and 16

Description: B0 Select ITU-T V.22 mode when modem is at 1200 bps

B1 Select Bell 212A when modem is 1200 bps.

B2 Deselect V.23 reverse channel (same as B3).

B3 Deselect V.23 reverse channel (same as B2).

B15 Select V.21 when modem is at 300 bps.

B16 Select Bell 103 when modem is at 300 bps.

Command: DsDial

Values: s= dial string (phone number and dial modifiers)

Default: none

Description: Dial telephone number s, where smay be up to 40 characters long and include these

characters: 0-9, *, #, A, B, C, D

Can also include these Dial String Modifiers: L, P, T, W, S, comma (,), semicolon (;), !, @, ^,

and $.

Dial String Characters and Modifiers

0-9 DTMF digits 0 to 9.

*The 'star' digit (tone dialing only).

#The 'gate' digit (tone dialing only).

A-D Some countries may prohibit sending of these digits during dialing (tone dialing

only)

LRedial last number. (Must be placed immediately after ATD.)

PSelects pulse dialing until a Tis encountered. Affects current and subsequent

dialing. Some countries prevent changing dialing modes after the first digit is

dialed.

TSelects tone dialing until a Pis encountered. Affects current and subsequent

dialing. Some countries prevent changing dialing modes after the first digit is

dialed.

WWait for a new dial tone before continuing to dial. (X2, X4, X5, X6, or X7 must be

selected).

S=n Dial the number stored in the directory (n = 0 to 3). (See &Z.)

,Pause during dialing for set set in in register S8.

;Return to command mode after dialing. Place at the end of dial string.

!Hook Flash. Causes the modem to go on-hook for a time defined by the value of

S29, then off-hook again. Country requirements may limit the time imposed.

@Wait for quiet answer (silence). Causes the modem to wait for a ring back, then 5

seconds of silence before processing the next part of the command. If silence is

not detected, the modem returns a NO ANSWER code.

^Toggles the calling tone between enable/disable. Applicable to current dial

attempt only.

$ Detect AT&T call card “bong” tone. The character should follow the phone

number and precede the user’s call card number:

ATDT1028806127853500$123456789

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 9

Ignored Characters

( ) Ignored: may be used to format the dial string.

-Ignored: may be used to format the dial string.

<space> Ignored: may be used to format the dial string.

<i> Invalid character: will be ignored.

Command: %M Enable Dialing Message

Values: 0, 1

Default: 0

Description: Enables dialing message. It will display when the ATDL=n command is used and dialing

from memory or DTR dialing.

0 = Disabled - turns dialing message off

1 = Enabled - turns dialing message on

Command: DS=n Dial Stored Telephone Number

Values: n= 0, 1, 2

Default: none

Description: Dials a number previously stored in the directory by the &Zn=x command. Ex: ATDS=2.

Command: En Echo Command

Values: n= 0 or 1

Default: 1

Description: E0 Disables echo command.

E1 Enables echo command.

Command: FnEcho Online Data Characters

Values: n = 0, 1

Default: 1

Description: F0 Enables online data character echo. (Not supported.)

F1 Disables online data character echo (included for backward compatibility).

Command: HnDisconnect (Hang Up)

Values: n= 0 or 1

Default: 0

Description: H0 The modem goes on-hook (hangs up).

H1 The modem goes off-hook (makes the phone line busy).

Command: InInformation Request

Values: n= 0–5, 9, 11

Default: None

Description: I0 Displays default speed and controller firmware version.

I1 Calculates and displays ROM checksum (e.g., B399).

I2 Checks ROM and verifies the checksum, displaying OK or ERROR.

I3 Displays default speed and controller firmware version.

I4 Displays firmware version for data pump (e.g., 17)..

I5 Displays the board ID: software version, hardware version, and the country ID in

hexidecimal format (e.g., s0503a01V, 0,34).

I7 Displays release information and V.92 capabilities.

I9 Displays the country code in decimal format (e.g., 52).

I11 Displays diagnostic information for the last modem connection, such as DSP and

firmware version, link type, line speed, serial speed, type of error correction/data

compression, number of past retrains, etc.

Command: LnNot Applicable

Command: MnMonitor Speaker Mode

Values: n = 0, 1, 2, or 3

Default: 1

Description: M0 Speaker always off.

M1 Speaker on until carrier signal detected.

M2 Speaker always on when modem is off-hook.

M3 Speaker on until carrier is detected, except while dialing.

Chapter 1 – AT Commands

Multi-Tech Systems, Inc. AT Commands for the MT5634 Family of Products (S000272J) 10

Command: NnModulation Handshake

Values: n = 0 or 1

Default: 1

Description: N0 Modem performs handshake only at communication standard specified by S37 and the

Bcommand.

N1 Modem begins handshake at communication standard specified by S37 and the B

command. During handshake, fallback to a lower speed can occur.

Command: OnReturn to Online Data Mode

Values: 0, 1, 3

Default: None

Description: O0 Exits online command and returns to data mode (see +++AT escape sequence).

O1 Issues a retrain and returns to online data mode.

O3 Issues a rate renegotiation and returns to data mode.

Command: P Set Pulse Dial Default

Values: P, T

Default: T

Description: Configures the modem for pulse (non-touch-tone) dialing. Dialed digits are pulsed until a T

command or dial modifier is received.

Command: QnResult Codes Enable/Disable

Values: n= 0 or 1

Default: 0

Description: Q0 Enables result codes.

Q1 Disables result codes.

Q2 Dumb Answer Mode (also known as No Response Answer). Q2 sets the answer

mode to be handled without responses and echo turned off; however, the originate

mode remains intelligent.

Command: Sr=n Set Register Value

Values: r= S-Register number; n varies

Default: None

Description: Sets the value of the register Srto the value of n, where nis entered in decimal format:

Example: S0=1.

Command: Sr? Read Register Value

Values: r= S-Register number

Default: None

Description: Reads the value of the register Srand displays it in 3-digit decimal form. Example: S2?

gives the response 043.

Command: T Set Tone Dial Default

Values: P, T

Default: T

Description: Configures the modem DTMF (touch-tone) dialing. Dialed digits are tone dialed until a P

command or dial modifier is received.

Command: VnResult Code Format

Values: n= 0 or 1

Default: 1

Description: V0 Displays result codes as digits (short form or terse).

V1 Displays result codes as words (long-form or verbose).

Command: WnResult Code Options

Values: n = 0, 1, 2

Default: 2

Description: W0 CONNECT result code reports serial port speed, disables protocol result codes.

W1 CONNECT result code reports serial port speed, enables protocol result codes.

W2 CONNECT result code reports line speed, enables protocol result codes.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Multitech Modem Handbücher

Multitech

Multitech SocketModem EDGE Bedienungsanleitung

Multitech

Multitech MultiModemUSB MT5634ZBA-USB Bedienungsanleitung

Multitech

Multitech MultiConnect microCell MTCM2-L4G1 Bedienungsanleitung

Multitech

Multitech MultMobile MT9234MU Bedienungsanleitung

Multitech

Multitech Dragonfly MTQ-LNA7 Bedienungsanleitung

Multitech

Multitech MultiModem iCell Bedienungsanleitung

Multitech

Multitech MultiConnect rCell 100 Series Bedienungsanleitung

Multitech

Multitech MMH2834 Technisches Handbuch

Multitech

Multitech MT5656ZDX Series Bedienungsanleitung

Multitech

Multitech MT5600BA Bedienungsanleitung

Multitech

Multitech MT1932ZDX Bedienungsanleitung

Multitech

Multitech etherFAX A2E Bedienungsanleitung

Multitech

Multitech MultiConnect MTPCIE-H5 Bedienungsanleitung

Multitech

Multitech Multimobile MT10100ZL-X/E Bedienungsanleitung

Multitech

Multitech Multimodem MTCBA-G-F1 Bedienungsanleitung

Multitech

Multitech MultiConnect microCell Bedienungsanleitung

Multitech

Multitech MultiModem ZBA USB MT5634ZBA-USB Bedienungsanleitung

Multitech

Multitech MTCBA-C-U-N1 Bedienungsanleitung

Multitech

Multitech MultiModem ISIHI-2S Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZBA-V.92 Bedienungsanleitung

Multitech

Multitech BL-Series Bedienungsanleitung

Multitech

Multitech Multimodem RJ-45 Bedienungsanleitung

Multitech

Multitech SocketModem MT5600SMI-32 Bedienungsanleitung

Multitech

Multitech MTD-H5 Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
