Multitech Conduit AP 300 Series Montageanleitung

Conduit®AP

MTCAP3 Hardware Guide for Australia and New

Zealand

CONDUIT AP MTCAP3 HARDWARE GUIDE FOR AUSTRALIA AND NEW ZEALAND

2 Conduit®AP MTCAP3 Hardware Guide for Australia and New Zealand

Conduit AP MTCAP3 Hardware Guide for Australia and New Zealand

Models: MTCAP3-EN-A23UEA-LWM, MTCAP3-EN-A23UEA-DWM

Part Number: S000802, Version 1.0

This publication may not be reproduced, in whole or in part, without the specific and express prior written permission signed by an executive officer of

Multi-Tech Systems, Inc. makes no representations or warranties, whether express, implied or by estoppels, with respect to the content, information,

material and recommendations herein and specifically disclaims any implied warranties of merchantability, fitness for any particular purpose and non-

infringement.

Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of

Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

Trademarks and Registered Trademarks

MultiTech, the MultiTech logo, DeviceHQ, and MultiConnect and Conduit are registered trademarks and mPower is trademarks of Multi-Tech Systems, Inc.

All other products and technologies are the trademarks or registered trademarks of their respective holders.

Legal Notices

The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with

applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or

death, significant property damage, or serious physical or environmental damage. Examples of such use include life support machines or other life

preserving medical devices or systems, air traffic control or aircraft navigation or communications systems, control equipment for nuclear facilities, or

missile, nuclear, biological or chemical weapons or other military applications (“Restricted Applications”). Use of the products in such Restricted

Applications is at the user’s sole risk and liability.

The MultiTech products and the final application of the MultiTech products should be thoroughly tested to ensure the functionality of the MultiTech

products as used in the final application. The designer, manufacturer and reseller has the sole responsibility of ensuring that any end user product into

which the MultiTech product is integrated operates as intended and meets its requirements or the requirements of its direct or indirect customers.

MultiTech has no responsibility whatsoever for the integration, configuration, testing, validation, verification, installation, upgrade, support or maintenance

of such end user product, or for any liabilities, damages, costs or expenses associated therewith, except to the extent agreed upon in a signed written

document. To the extent MultiTech provides any comments or suggested changes related to the application of its products, such comments or suggested

changes is performed only as a courtesy and without any representation or warranty whatsoever.

Contacting MultiTech

Sales Support

[email protected] [email protected]

+1 (763) 785-3500 +1 (763) 717-5863

Website

https://www.multitech.com

Knowledge Base

For immediate access to support information and resolutions for MultiTech products, visit https://www.multitech.com/kb.go.

Support Portal

To create an account and submit a support case directly to our technical support team, visit: https://support.multitech.com.

Warranty

To read the warranty statement for your product, visit https://www.multitech.com/legal/warranty.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive, Mounds View, MN 55112

USA

CONTENTS

Conduit®AP MTCAP3 Hardware Guide for Australia and New Zealand 3

Contents

Chapter 1 – Product Overview ................................................................................................................................. 5

Overview ....................................................................................................................................................................... 5

Package Contents.......................................................................................................................................................... 5

Product Build Options ................................................................................................................................................... 6

Documentation Overview ............................................................................................................................................. 6

Related Documentation.............................................................................................................................................. 6

Chapter 2 – Specifications and Hardware Information ............................................................................................. 7

Dimensions.................................................................................................................................................................... 7

Specifications for 915 MHz Models ............................................................................................................................. 8

Connectors and LEDs..................................................................................................................................................... 8

AC Power Consumption .............................................................................................................................................. 10

LoRa Power ................................................................................................................................................................. 10

LoRa Maximum Output Power ................................................................................................................................. 10

Resetting the Device ................................................................................................................................................... 11

Antenna....................................................................................................................................................................... 12

LoRa Antenna............................................................................................................................................................ 12

Chapter 3 – Safety Information .............................................................................................................................. 13

Power Supply Caution................................................................................................................................................. 13

Ethernet Ports ............................................................................................................................................................. 13

Ports Ethernet........................................................................................................................................................... 13

General Safety............................................................................................................................................................. 13

Radio Frequency (RF) Safety ....................................................................................................................................... 13

Sécurité relative aux appareils à radiofréquence (RF).............................................................................................. 14

Interference with Pacemakers and Other Medical Devices ...................................................................................... 14

Potential interference............................................................................................................................................... 14

Precautions for pacemaker wearers ........................................................................................................................ 14

Device Maintenance ................................................................................................................................................... 15

UL Notice .................................................................................................................................................................... 15

Spécifications UL ...................................................................................................................................................... 15

User Responsibility...................................................................................................................................................... 15

Chapter 4 – Labels.................................................................................................................................................. 16

Example Device Labels ............................................................................................................................................... 16

MTCAP3-EN Models.................................................................................................................................................. 16

Chapter 5 – Setting Up Hardware........................................................................................................................... 17

Attaching the Antenna ............................................................................................................................................... 17

Cabling the Device....................................................................................................................................................... 17

CONTENTS

4 Conduit®AP MTCAP3 Hardware Guide for Australia and New Zealand

Chapter 6 – Getting Started ................................................................................................................................... 18

Setting Up Your Credentials (Commissioning) for mPower........................................................................................ 18

mPower Models First-Time Setup .............................................................................................................................. 18

Connecting with LoRaWAN End Devices..................................................................................................................... 18

Chapter 7 – Mounting the Device........................................................................................................................... 19

Mounting the Device................................................................................................................................................... 19

You will need............................................................................................................................................................. 19

Determining Location................................................................................................................................................ 19

Mounting the Device ................................................................................................................................................ 19

Chapter 8 – Regulatory Information....................................................................................................................... 22

Waste Electrical and Electronic Equipment Statement .............................................................................................. 22

WEEE Directive.......................................................................................................................................................... 22

Instructions for Disposal of WEEE by Users in the European Union ........................................................................ 22

REACH-SVHC Statement ............................................................................................................................................. 22

Registration of Substances........................................................................................................................................ 22

Restriction of the Use of Hazardous Substances (RoHS) ............................................................................................ 23

Index...................................................................................................................................................................... 24

PRODUCT OVERVIEW

Conduit®AP MTCAP3 Hardware Guide for Australia and New Zealand 5

Chapter 1 – Product Overview

Overview

Conduit AP (MTCAP3) connects thousands of IoT assets to the cloud using the LoRaWAN®protocol. It expands LoRa

network coverage to difficult to reach areas and is capable of packet forwarding user data between LoRa end

devices and a centrally located network server on the cloud, in a data center, or a public network.

Note: Check for an updated version of this document at https://www.multitech.com/brands/multiconnect-

conduit-ap.

Package Contents

For models with all internal antennas For models with an external LoRa antenna.

Your device ships with the following:

# Description Quantity

1 Conduit AP Access Point 1

2 RJ45 Ethernet cable 1

3 5 Volt, 2.5 Amp power supply 1

4 Mounting bracket 1

5 LoRa antenna (models with external antenna only) 1

Not pictured Mounting feet set 1

Quick start 1

Important: Contact MultiTech Systems if a replacement power supply is needed. Using a different power

supply may damage the device and voids the warranty.

PRODUCT OVERVIEW

6 Conduit®AP MTCAP3 Hardware Guide for Australia and New Zealand

Product Build Options

Product Description

MTCAP3-EN-A23UEA-LWM Ethernet-only mPower programmable access point with LoRa 915 MHz

and external LoRa antenna

MTCAP3-EN-A23UEA-DWM Ethernet-only mPower programmable access point with LoRa 915 MHz

Documentation Overview

The following documents are available at http://www.multitech.com/brands/multiconnect-conduit-ap. Select your

model to find the documents specific for that device.

Document Description (Part Number)

Conduit AP MTCAP3 Hardware Guide for

Australia and New Zealand

This document. Hardware, regulatory, and getting started information.

(S000802)

mPower Software Guide For mPower models only.Includes steps for configuring and using

devices using the mPower platform. (S000727)

Conduit AP MTCAP, MTCAP2, and

MTCAP3 Quick Start

Steps for getting started with hardware. Ships with the device and is

available online.

Application Notes Application Notes include steps for connecting end points to the

device.

Note: Quick Start Guide numbers increase by one when the printed version is updated.
