Multitech RoteFinder RF500S Bedienungsanleitung
Model RF500S
Broadband Router
Quick Start Guide
Quick Start Guide
Broadband Router
PN S000127D Revision D
Copyright © 2000-2002
This publication may not be reproduced, in whole or in part, without prior expressed written
permission from Multi-Tech Systems, Inc. All rights reserved.
Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents
hereof and specifically disclaims any implied warranties of merchantability or fitness for any
particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this
publication and to make changes from time to time in the content hereof without obligation of
Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.
Revision Date Description
A 10/09/00 Updated for release with MTS case. All pages at software
Version 7.12
B 10/26/01 Updated to include a section on “Web Browser Configuration and
Management” and minor edits. Added warranty section. All pages
at software Version 7.26
C01/03/02 All pages at software Version 7.29
D07/16/02 Changed the graphics showing the back of the RF500S.
Trademarks
The Multi-Tech logo is a trademark of Multi-Tech System, Inc. Windows is a trademark of
Microsoft. All other trademarks are owned by their respective companies.
Record Router Information
Model Number: _______________________
Serial Number: _______________________
Technical Support
Country By Email By Phone
India: support@multitechindia.com +91 (124) 6340778
World Headquarters
Multi-Tech Systems, Inc.
2205 Woodale Drive
Mounds View, Minnesota 55112
(763) 785-3500 or (800) 328-9717
Fax (763) 785-9874
Internet Address: http://www.multitech.com
RouteFinder RF500S Quick Start Guide
Contents
Introduction ................................................................................................................... 1
Related Documentation ................................................................................................ 1
Hardware Installation.................................................................................................... 2
Safety Warnings ........................................................................................................... 2
Unpacking Your RouteFinder ....................................................................................... 2
Requirements ............................................................................................................... 2
Cabling Your RouteFinder ............................................................................................ 3
Cabling Directions ........................................................................................................ 4
Application Examples................................................................................................... 5
Example 1 – Connecting a Local LAN to the Internet................................................... 5
Example 2 – Local LAN to the Internet / Remote Site .................................................. 6
Example 3 – LAN to LAN via an Async Port................................................................. 7
Configuration and Management ..................................................................................8
Configure and Manage Using a Web Browser............................................................ 9
Setup Wizard.............................................................................................................. 10
Device Information...................................................................................................... 16
Device Status ............................................................................................................. 17
Advanced Settings...................................................................................................... 18
System Tools.............................................................................................................. 27
Multi-Tech Systems, Inc. Warranty............................................................................ 35
Introduction
1
Introduction
The Multi-Tech Broadband RouteFinder connects a cable modem or DSL
modem to an Ethernet LAN to provide high-speed broadband access to the
Internet for up to 253 users. The Broadband Router features a built-in 4-port
10/100M bps switch, one asynchronous port for backup Internet access or
dial-in remote access, firewall services, and network security. This product
is ideal for any business looking for cost-effective broadband access to the
Internet for every user on the LAN or for the home user looking to share
their DSL cable connection.
The RouteFinder RF500S
Related Documentation
This guide is intended to be used by systems administrators and network
managers. It provides the information for a qualified person to unpack,
cable, install software, and configure the device for proper operation.
User Guide
A detailed User Guide in Adobe Acrobat PDF format is provided on the
System CD included in your RouteFinder package. The User Guide provides
in-depth information on the features and functions available on your router.
It also includes the product warranty statement, software user license
agreement, ordering accessories, regulatory compliance, tools for your
RF500S, cabling diagrams, a glossary, and sections on troubleshooting and
frequently asked questions. The User Guide can be displayed using Adobe
Acrobat Reader. You can save the .pdf file to your PC or print a copy.
Adobe Acrobat Reader
Adobe Acrobat Reader is a free program used to view documents created in
Adobe PDF format. Adobe Acrobat Reader can be installed from the System
CD (click on the Install Manuals option and select Install Adobe Acrobat
Reader) or downloaded from Adobe’s Web site at:
http://www.adobe.com
RouteFinder RF500S Quick Start Guide
2
Hardware Installation
Safety Warnings
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in a wet location unless the jack is
specifically designed for wet locations.
3. This product is to be used with UL and cUL listed computers.
4. Never touch uninsulated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
5. Avoid using a telephone during an electrical storm. There may be a
remote risk of electrical shock from lightening.
7. Do not use the telephone to report a gas leak in the vicinity of the leak.
8. To reduce the risk of fire, use only No. 26 AWG or larger
Telecommunications line cord.
9. Use only the power source supplied with your product or an equivalent
power source supplying the minimum power requirements.
Unpacking Your RouteFinder
The RF500S shipping box contains the following items:
•SystemCD
• Power Supply
• The RouteFinder RF500S
• This Quick Start Guide
• A serial cable
If any item is missing or damaged, please contact Multi-Tech Systems.
Requirements
• Intel 486 or higher processor.
• 10/100 BaseT cable to connect the RF500S to the network.
• One DSL or Cable Modem.
• A networked computer with Windows 95/98/2000, Windows NT 3.5 or
higher and TCP/IP protocol installed, (or a non-Windows system with
TCP/IP properly installed to enable Telnet configuration).
• Any Windows communication application for Dial-Out operation.
• Any PPP supported communication application for Dial-In operation.
• TCP/IP installed and configured on each PC accessing the Internet.
Hardware Installation
3
Cabling Your RouteFinder
Cabling your RouteFinder requires making the appropriate connections to
PCs, Cable or DSL modem, analog modem or ISDN TA (optional), AC power
and the RouteFinder. Then, after your device is properly cabled, you will
have to configure your RouteFinder. Follow the instructions provided in the
Web Browser Configuration and Management section of this Quick Start
Guide.
RouteFinder RF500S Quick Start Guide
4
Cabling Directions
Before beginning, turn the power off on all network devices (PCs, Cable/DSL
modems, analog modems, ISDN TAs, and the router).
1. Connect the Ethernet port of each PC or network device to one of the 4
LAN ports.
Important: If you are using the Uplink option, Port Number 1 cannot
be used as a LAN port).
2. If you are using an analog modem, connect it to the Serial Async port.
3. If you are using the Uplink option to connect to another network
segment, slide the Uplink/Normal switch into the Uplink position.
Connect the LAN cable to LAN Port Number 1. Plug the other end of
the LAN cable into another hub, router, or switch.
Note: If you are not using the Uplink feature, place the switch in the
Normal position.
4. Connect a network cable from the cable or DSL modem to the 10 BT
WAN port.
5. Connect the provided power supply cable to the 5VDC power port on
the back of the router. Plug the power supply into an AC power outlet
as shown above.
Power and Reset Button
1. Power on your cable or DSL modem.
2. If you are using an analog modem or ISDN TA, power on the device.
3. Press and hold the RouteFinder’s Reset button for 3 seconds to restore
the default settings.
Hardware Installation
5
Application Examples
The following examples provide information about RF500S typical
applications. The three examples include:
1. Connecting a local LAN to Internet.
2. Connecting a local LAN to the Internet and setting up a remote site.
3. Setting up a LAN to LAN via the Async Port.
Example 1 – Connecting a Local LAN to the Internet
RouteFinder RF500S Quick Start Guide
6
Example 2 – Local LAN to the Internet / Remote Site
Andere Handbücher für RoteFinder RF500S
