Muratec F-360 Bedienungsanleitung

For

F-360

Quick Reference

Fax

Sending a fax.....................page

Broadcast........................page

Cancel sending a fax...............page

Copy

Making a copy ....................page

Using the bypass tray ..............page

Just in case

Clearing original document jams .....page

Clearing printout jams.............page

Function table

...........page

Enter the fax number using the numeric keypad

Press the one-touch key*1

Press

SPEED DIAL/GROUP

once and enter

the speed-dial number using the numeric keypad

Press

SPEED DIAL/GROUP

twice and enter

the group number using the numeric keypad

: When you press a one-touch key, you do not need

to press

START

Set the document in the

ADF face up and adjust

the document guides.

Adjust the followings, if necessary:

• Select the resolution by pressing

[Mode]

• Select the contrast by pressing

[Contrast]

Enter the fax number.

Sending a fax

The number of the pages you

can set in the ADF at one time

is as follows:

Letter-sized: 80 sheets

Half letter-sized: 80 sheets

Legal-sized: 50 sheets

Press

START

Fax

Set the document in the

ADF face up.

Adjust the resolution and the

contrast, if necessary.

Broadcast

Enter the fax number using the numeric keypad

Press the one-touch key*1

Press

SPEED DIAL/GROUP

once and enter

the speed-dial number using the numeric keypad

Press

SPEED DIAL/GROUP

twice and enter

the group number using the numeric keypad

: When you press a one-touch key, you do not need

to press

START

Press

START

Enter the fax number.

To add more fax numbers,

repeat steps 2 and 3.

Press

BROADCAST

If you want to review the numbers

you entered, press

[Review]

When you are finished, press

[Return]

to return to the previous display.

Press

STOP

Press

[Location]

to see the individual numbers within

the broadcast.

Press or until you find the number you want to cancel.

Cancel sending a fax

When the command you want to cancel shown,

press

[Erase]

Press or to scroll through

currently stored commands.

Press

COMM.CANCEL/CONFIRM.

Press

[Yes]

If you want to cancel another command,

repeat steps 2–4.

Press

START

Set the document in the

ADF face up.

Adjust the followings,

if necessary.

• Select the resolution by

pressing

[Mode]

• Select the contrast by pressing

[Contrast]

Enter the number of copies

using the numeric keypad.

Making a copy

Press

COPY

to change

to Copy mode.

Copy

If you want to reduce the document, set the reduction rate in advance:

1. Press

, 2, 3, 0, 1,

ENTER

2. Select "Copy Reduction Rate", then press

ENTER

3. Select Auto, 100% or 78%(Legal -> Letter), then press

ENTER

4. Select "Exit", then press

ENTER.

Helpful Tip

Press

COPY

to change

to Copy mode.

Using the bypass tray

Hopper

Flapper release lever

Open the bypass tray on the right

side of your machine.

Pull out the hopper of the bypass tray

and raise the flapper release lever.

Set the document in the ADF face up.

Place the paper on the bypass tray

face down. Insert up to 50 sheets.

Adjust the paper guide to fit the

paper. Then lower the flapper

release lever.

When you use transparency film,

select "OHP".

The LCD will show:

Using the cursor key, select

the paper size you’ve set on

the bypass tray.

Press

ENTER

Enter the number of

copies.

Press

START

Bypass Tray

Letter OHP

Legal

H.LTR

Adjust the following, if necessary.

• Select the resolution by pressing

[Mode]

• Select the contrast by pressing

[Contrast]

8 9

Just in case Clearing original document jams

In this step, if more than 60 seconds passes without

pressing any keys, the machine will erase from memory

all pages stored during this operation and the machine

will return to the standby mode.

In this step, if more than 60 seconds passes without

pressing any keys, the machine will begin to send or

copy the document(s) stored during this operation.

The check message "Repeat transmission."

will be printed out if the document jammed

during transmission.

Reset the document from

the jammed page and

press

START

If the document jammed in the following cases,

perform the job again from the beginning

after removed the jammed paper.

• The first page of the document jammed.

• During the quick memory transmission.

If you see this message on the LCD

and wish to resume scanning from

the jammed page, press

[Yes]



To abort the operation, press

[No]

Continue Storing?

[ Yes ][ No ]

Document Jam

Open the scanner cover and remove

the jammed paper (see next page).

Open & Check

the Blinking Cover

Document Jam

To remove the document...

Gently close the scanner cover.

Make sure both sides are

snapped down securely.

If the document has become wrinkled

or torn, do not re-send it.

Open the scanner cover.

Remove the original document.

If you cannot remove it, go to step 2.

Otherwise, skip to step 3.

Open the inner cover.

Remove the original document.

Clearing printout jams

Be careful not to put your hand between

the top cover and the machine.

Important !

Open the top cover.

Pull up the printer cover release

and open the printer cover.

Shield the drum cartridge from light,

especially strong light.

Important !

Remove the toner and

drum cartridge.
