My Weigh HD150 Bedienungsanleitung

HD-SERIES

ENGLISH

Thank you for purchasing the MyWeigh HD Series heavy duty shipping scale. This scale is designed to provide years of accurate

weighing. Please read this entire manual before use. If you have any questions about your scale or have troubleshooting con-

cerns, please visit our website at www.MyWeigh.com.

SPECIFICATIONS

Model HD150 HD300

Capacity 68kg/150lb 136kg/300lb

Accuracy 0.02kg/0.05lb 0.05kg/0.1lb

POWER SUPPLY

The HD Series scale is designed to run with 6.0V / 100 mA AC power (ac adapter included) or optional 4x AA batteries.The AC

adapter plugs into the socket on the rear of the scales weighing indicator. If you want to use batteries, please install them in the

battery compartment on the underside of the base of the scale.

Battery Installation

For battery installation, turn over the scale, you’ll see the battery compartment on the underside of the base of the scale , lift

and open (see the enclosed drawing Fig1) the battery cover, remove and/or install the batteries. Be sure that the batteries are

installed correctly following the polarity indicators in the battery compartment. Reinstall the battery cover.

OPERATION INSTRUCTIONS

on the scale. Either place the remote display box together with the scale on its surface or mount the display box on a wall at a

suitable height with the included wall mounting kit.

Weighing Procedures

Press the key to turn on the scale, the display will show“150.00lb”for the HD150 shipping scale or“300.0lb”for the HD300

shipping scale. When the display will shows ”0.00”thhe scale is now ready for use.To begin weighing, follow these steps:

1. Press and release the

2. Press the [M] key to change the weighing unit between“lb”and“kg”.

3. Press the [T] key toTARE or Zero the scale.

4. Press the [D] key to transmit the data through the USB port.

This document hosted by: www.oldwillknottscales.com

Display Messages

150.00: the scales maximum capacity is 150.00lbs, the scale is attempting to locate the proper zero position for accurate

weighing.

300.00: the scales maximum capacity is 300.00lbs, the scale is attempting to locate the proper zero position for accurate

weighing.

Err-Z: zero track range has exceeded

A.0FF.x

CAL-Er: calibration error

CAL-0: the indicator mark of calibration zero

CAL-F: the indicator mark of calibration full capacity

Err-0: overload

Err-S: unstable

1. Press down the [D] key until the indicator displays“A.OFF.X”(X=0.1.2.3.4.5.6.7.8.9 minutes), the display value“X”is the

[M] or [D] key; the X value will increase or decrease by 1, press the [T] key to

key, the display will then reset.

CALIBRATION

Calibration is only for ADVANCED USERS or scale technicians and should only be performed if absolutely necessary.

There are two calibration methods available: one is using standard professional calibration weights, the other is the selection of

1. Press down the [T] key until the indicator displays “GE.Uxx”, “GE.oxx” or “GE. FAC”; a.“GE.Uxx” means: USA geographic

location code “xx” is selected; b. “ GE. FAC”means: Factory geographic location code is selected; c. “ GE.oxx”means:

Other(except for USA and Factory) geographic location code “xx” is selected.

2. Press the [M] or [D] key to change the geographic location code; please refer the geographic location code table and maps at

the end of the manual.

3. After selecting the appropriate geographic location code, press the [T] key, the scale will store your selection and display

“CAL-0” or “Go.on?”

If “CAL-0” is displayed, that means the scale must be calibrated once more by using standard weights and you should proceed

to the next step;

If “Go.on?” is displayed and the key is pressed, the scale will use the selected geographic location code and reset automati-

cally to resume normal weighing mode;

If “Go.on?” is displayed and the [T] key is pressed, the scale will display “CAL-0” and you should proceed to the next calibration

step.

4. Remove all weights from the scale platform, press the [T] key , the “0” in “CAL-0”

5. After the reading (0.00) becomes stable, the scale will display “CAL-F”; place the correct standard weight(s) on the platform

(60kg standard weight for HD150, 120kg standard weight for HD300), press the [T] key, the “F” in “CAL-F”

6. After the readings (60.00 for HD150 or 120.00 for HD300) are stable, the indicator will display“CAL-0”; remove the weight(s)

from the platform, press the [T] key; the “0” in “CAL-0”

Calibration is now complete.

GRAVITY MODE

The Gravity Mode feature provides a means of adjusting the scale’s internal calibration factors to compensate for variations in

ferent weight at an end-users (local) site than it did at the Calibration (CAL) site.

The scale maintains two gravity setting values: one is local site gravity value; the other is calibration site gravity value.The

scale will use the relationship between calibration and local gravity for its weight calculations.

We have compiled a list of local gravity values for some areas of the world.You only need select the index number of them

scale. It is important to select the proper code. If your location is not listed, select closest one. This kind of adjustment needs no

calibration weights.

However, whenever possible, we strongly recommend that you calibrate the scale by using standard professional calibration

weights.

Europe Geographic Location Codes

Portugal

Morocco

Iceland

Ireland

Spain

Albania

Andorra

Austria

Belarous

Belgium

Bosnia and Herzegovina

Bulgaria

Croatia

Czech Republic

Denmark

Estonia

Faroe Islands

Finland

France

Lyon & North

South of Lyon

Germany

Frankfort & North

South of Frankfort

Gibraltar

Algeria

Netherlands

Belgium

France

Norway

Sweden

Denmark

Germany

Switzerland

Czech Rep.

Slovenia

Italy

Finland

11 Estonia

Latvia

Poland

Slovakia

Hungary

Lithuania

Serbia &

Bosnia &

Herezgovinia

Belarus

Romania

Montenegro

Albania

Greece

Holy See (Vatican City)

Hungary

Iceland

Ireland

Italy

Latvia

Liechtenstein

Lithuania

Luxembourg

Macedonia

Malta

Moldova

Monaco

Netherlands

Norway

Poland

Portugal

Romania

Bulgaria

Macedonia

Greece

Ukraine

Moldova

Turkey

Russia

Moscow & North

South of Moscow

Spain

Madrid & North

South of Madrid

Serbia and Montenegro

Slovakia

Slovenia

San Marino

Sweden

North of Stockholm

Stockholm & South

Switzerland

Ukraine

United Kingdom

North of Newcastle

Newcastle & South

Croatia

Austria

Code Code Code

Country Country Country

Canada Geographic Location Codes

Yukon

Territory

British

Columbia

Northwest

Territories

Alberta

State

Alberta

North of Edmonton

Edmonton & South

British Columbia

North of Prince George

Prince George & South

Manitoba

North of Norway House

Norway House & South

New Brunswick

Newfoundland

North of Hopedail

Between Hopedail & Fleur de lys

Fleur de lys & South

Nova Scotia

Ontario

North of Nakina

Nakina & South

Saskatchewan

Nunavut Territory

Manitoba

Ontario

Quebec

Ottawa

Newfoundland

Prince

Edward Island

New Brunswick

Prince Edward Island

Quebec

Sept-Iles & South

Saskatchewan

North of Prince Albert

Prince Albert & South

Northwest Territories

Echo bay & North

South of Echo bay

Nunavut Territory

Victoria Island & North

Between Victoria Island &

Baker Lake

South of Baker Lake

Yukon Territory

North of Dawson

Dawson & South

Nova Scotia

Code Code

State State

Europe Geographic Location Codes

Illinois

Bloomington & North

South of Bloomington

Indiana

North of Indianapolis

Indianapolis & South

Iowa

North of Des Moines

Des Moines &South

Kansas

Kentucky

Louisiana

Maine

Maryland

Massachusetts

Michigan

Northwest of Lake Michigan

Southeast of Lake Michigan

Minnesota

Pennsylvania

Rhode Island

South Carolina

South Dakota

Tennessee

Texas

Northeast of Colorado River

Southwest of Colorado River

Utah

Vermont

Virginia

Washington. DC

Washington State

West Virginia

Wisconsin

Green Bay & North

South of Green Bay

Wyoming

North of Casper

Casper & South

USA Geographic Location Codes

State

Alabama

Birmingham & North

South of Birmingham

Alaska

North of Fairbanks

Between Anchorage & Fair-

banks

South of Anchorage

Arizona

Phoenix & North

South of Phoenix

Arkansas

California

Redding & North

Between Redding & Fresno

Fresno & Los Angeles

Los Angeles & South

Colorado

Denver & North

South of Denver

Connecticut

Delaware

Florida

West Palm Beach & North

South of West Palm Beach

Georgia

Hawaii

Idaho

North of Salmon River Mtns

South of Salmon River Mtns

MT ND

UT CO

17 MN

State

Mississippi

Kosciusko & North

South of Kosciusko

Missouri

Montana

Helena & North

South of Helena

Nebraska

Nevada

New Hampshire

New Jersey

New Mexico

New York

Albany & North

South of Albany

North Carolina

Raliegh & North

South of Raliegh

North Dakota

Ohio

Akron & North

South of Akron

Oklahoma

Oregon

Salem & North

Between Oakridge & Salem

South of Oakridge

Code Code

CONNECTING THE HD-300 SCALE VIA USB

1. Connect the HD-300 scale to an available USB port on your computer.

2. Power on the scale.

SETTING UP THE HD-300 FOR USE WITH THE UPS WORLDSHIP SOFTWARE

- USA/CANADA ONLY

** Please note this function will not work in Europe**

1. Open the UPS Worldship software and click on “tools”.

2. Click on “System Preferences”.

3. Click on “Hardware” in the drop-down menu.

4. Click on “Scale Port” drop-down menu and choose “USB”.

5. Click on “Scale Type” drop-down menu and choose “Toledo PS60-5155 150lb Flat Top”.

6. Click the “Test Scale” button.
