My Weigh IBalance 601 Bedienungsanleitung

High Precision Balances

iBalance 601

iBalance M01

(LED Display)

Operation Manual

KD-TBED-en,V1.2-2005

Table of Contents

I. Attention Notes ------------------------------------------(1)

II. Transport Protection ----------------------------------- (1)

III. Precautions Before Using The Balance -------------(1)

IV. Specification ----------------------------------------------------(2)

V. Explanation Of Display Symbols -------------------(2)

VI. Keypad Functions -------------------------------------(3)

VII. Counting Function-----------------------------------------(4)

VIII.Operations --- --------------------------------------------(4)

IX. Error message -----------------------------------------------(5)

X. Datatransmission–SerialRS-232interface------(6)

XI. Power Supply ------------------------------------------------(7)

XII. Options --------------------------------------------------------(8)

XIII.Calibration----------------------------------------------------(8)

XIV.

XV.Select range of zero track and zero display -----(9)

XV. Select the range of zero track and zero display

Press the key until the display shows “0.5d. 1.0d. 1.5d.

2.0d. 3.0d” to power on, press the key to select the

range of zero tracking, press to confirm. Then it will

display “ZEr-S” or“ ZEr-L” , press to select the zero

display range (ZEr-S mean 0d, ZEr-L mean ±3.0 d),

press to confirm, then choose the Communication

method by pressing the Key to rotate/revolve (Con:

send in succession; stable: send steadily) and key for

confirmation, then start to select the baud. Press key to

change/revolve and choose “1200” or “2400” or “9600”,

then press the key for confirmation. The scale will return

to the normal weighing state.

Weight response speed ---------------------------------(8)

XII. Options

RS-232 interface

XIII. Calibration

Pressandhold topoweron, releasethekeyatthe

end of the self-test, the display will show “CAL 0” . Then it will

display the calibration weight needed (e.g. CAL 600g), when

“chirp” is heard, place the weight on the pan. The calibration is

finished after “chirp” is heard again.

Note: The weight placed on the pan is not correct if the

display shows “err1”.

XIV. Weight response speed

Press the key until the display shows “nb0” or “nb1” or

“nb2” or “nb3”, then press the key to select (nb0: the

slowest , nb3: the fastest), press the key to confirm, and

the scale will return to the normal weighing state.

I. Attention Notes

To enable you to use this scale precisely, we suggest you

to read these instructions carefully before operation.

1. Do not get the scale wet. If it gets wet, please wipe it

with a dry cloth. If damage occurs due to water it will

void your warranty.

2. Do not drop or shock the scale and do not drop any

item onto the scale or tray. It may cause permanent

damage. Only operate the scale gently and place

items on the tray gently. Overloading the balance will

damage the weighing sensor.

3. Extreme temperature/humidity fluctuations, shocks

and vibrations should be avoided at all times.

4. If the scale will not be used for a long time, please

remove or unplug the battery, clean the scale and

store in a non-static polybag. A desiccant is suggested

to be included.

5. Matter charged with static electricity can affect

accuracy. Discharge all static electricity. For example,

one method is to use Static-Guard spray, and spray it

on both sides of the weighing platform.

II. Transport Protection

Before the initial use, please refer to the included drawings

to remove the protection screw. Please re-install the

protection screw before transport to help avoid possible

damage.

III. Precautions Before Using the Balance

1. The balance must be in an exactly horizontal position

in order to achieve accurate measurement results.

2. Please use an independent power outlet to avoid

interference by other electrical appliances.

3. In order to bring the balance into a horizontal position, the

adjustable feet are turned either clockwise or

counter-clockwise until the air bubble is in the center of the

marked circle.

4. Don’t put any object on scale before powering on.

5. When possible please allow the scale to warm up for

several minutes before operation.

6. Items should always be placed on the center of the

platform when being weighed.

7. Whenthe“ ” LEDlightsislightingmeans，the rechargeable

sealed lead-acid battery need to be recharged.

8. Operating temperature range ：0℃~ 40℃.

9. For optimum accuracy, recalibrate before each use.

IV. Specification

model iBalance601 iBalanceM01

Maximum capacity 600g 1000g

Display scale interval (d) 0.01g 0.01g

Pan size Ø116mm Ø116mm

Power source Rechargeable battery 6v/1.3Ah

or 8.5v 0.2A AC/DC adaptor

V. Explanation of display symbols

2D (HEX) = “- ”(negative sign) 20 (HEX) =“ ”(blank)

2E (HEX) =“. ”(decimal point)

UNIT (4 byte)

g= 20 (HEX)

；20 (HEX) ；20 (HEX) ；67 (HEX)

kg= 20 (HEX) ；20 (HEX) ；6B (HEX) ；67 (HEX)

ct= 20 (HEX) ；20 (HEX) ；63 (HEX) ；74 (HEX)

ozt= 20 (HEX) ；6F (HEX) ；7A (HEX) ；74 (HEX)

CR= OA (HEX) ；OD (HEX)

Transmission example

1. Ex. : stable net + 0.168 g

HEAD，HEAD，DATA UNIT CR

ST ，NT ，+ 0.168 g OA, OD

XI. Power Supply and Recharging the battery

Alternative Power Supplies

1. DC 6V/1.3Ah rechargeable sealed lead-acid battery.

2. 8.5V / 0.2A AC/DC power adaptor.

Low voltage indication

When the “ ” LED is lighting ，the battery needs to be

recharged. The balance will automatically shut off when power

voltage goes down to 5.2V ± 0.15V. Low voltage may also

cause inaccuracy or instability.

**SPECIAL WARNING**

Cell-Phones, Cordless-Phones, and any radio-frequency device

can cause temporary interference and cause the scale to

temporarily not work properly. Please do not use any

electronic device near the i101. Just like in an Airplane, do not

use your cell-phone near the scale when it is in use. While

there is NO risk of permanent damage to the scale, interference

can cause an incorrect calibration or incorrect weight readings.

X. Data transmission – series RS-232 interface

(only for communication )

1. iBalance 0232C’s UART signal

2. Format

(1) Baud rate : 1200 bps 2400 bps 9600 bps

(2) Data bits : 8 bits

(3) Parity bit : none

(4) Stop bit : 1 bit

(5) Code ASCII

DATA FORMAT：

HEAD1，HEAD2，DATA UNIT CR

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

HEAD1 (2BYTES) HEAD2 (2BYTES)

OL - overload NT – net weight mode

ST –stable US -unstable

DATA(8BYTE)

Explanation Of Display Symbols

● : Scale is in ZERO mode.

● : Scale is in TARE mode.

● : Scale needs recharging once this battery appear

● : The display reading is in STABLE condition.

● Pcs : Scale is in COUNT mode .

● Ct : The unit is ct .

● ozt : The unit is ozt .

● g : The unit is g .

● In charge : Scale is in the process of recharge .

VI. Keypad functions

: ON/OFF power switch.

: For weight unit (g , ozt & ct ) selection.

: This key is used for sampling & counting.

: This key is used to deduct the weight of an Item or

container. Press tare again to exit the tare mode (when

empty), then the tare indication will disappear.

: Zero key, press this key to return the display to

zero if a small weight reading is left while

unloaded/empty.

VII. Counting function

Sampling

1.Press key, the display will show “Cnr10pcs”

(means sample size is 10 pcs)

2.Press the key again and again, 10、20、50、100 pcs will

appear in succession. Stop at the one you want to use.

3. Put the exact quantity of samples as desired on the pan

and press ,the determined sample size will be shown.

4.Keep adding objects to be counted on the pan, the total

number of the objects will be displayed.

※If the unit weight is too small for the counting resolution,

“ ”will be shown.

VIII. Operations

● Weight units

Press key to choose the preset weight units g, ct & ozt.

● Tare function

Put a container on the pan and press when the display

reading is stable. The tare weight will be stored into memory

and display will be brought to zero. “ ” indication in the

display will appear. The weight will be displayed as net

weight. To cancel the tare mode, press when no load

on the weighing pan.

※Tare range : Up to balance’s maximum capacity.

● Zero function

Press key to return the display to the center of zero if the

zero Shifts during operation.

※Zero range : ± 2% of max. capacity

Ⅸ. Error messages

When the display shows “ ”it means that the

balance is overloaded. Please remove the object from the pan immediately so

as to avoid damage to the load sensor inside the balance.
