9
Operation
Please confirm that all wires are properly
connected and that there are no mis-connections
or short circuits prior to operating the fan.
This fan is designed to be operated with a remote
control.
Operate the remote control while directly below the
fan to avoid interfering the operation of other fans.
How to use the remote control:
a.Press the "On/Off" button to start the fan.
b.Press the "On/Off" button to stop the fan.
c.Press the "Fan Speed" button to adjust fan speed. The fan speed
will cycle through low, medium, high, low, medium, high selections
with each press of the button.
Low speed: Blue LED light is on.
Medium speed: Green LED light is on.
High speed: Red LED light is on.
d.Press the "Rotate" button to adjust the wind direction and angle.
e.Press the "Timer" button to set time. The timer will cycle through
1, 4, and 8 hour selections with each press of the button.
Notes
The air circulating fan is not suitable for use in places near or around an open flame, or
where the surrounding temperature exceeds 40 degrees Celsius. Do not use this product in
places where there are large volumes of waste paper, and/or scrape metal, or where there is
flammable gas, high humidity, heavily oiled surface, and/or constant water washing.
Do not insert fingers or objects into the louver grill or touch the fan blades when the fan is in
operation.
Do not block the fan blade and/or the louver grill when the fan is in operation.
Please perform regular cleaning and maintenance. If any abnormality arises while the fan is
in operation, please shut off the power before performing an inspection.
Cleaning and Maintenance
Shut off the power during cleaning and maintenance operations to avoid the risk of electric
shock.
Rotate the center plate that secures the front cover to the unit counter-clockwise to remove it.
Then, the louver grill may be removed for cleaning.
Only the front cover of the fan may be washed in water, the rest of the fan should be wiped
with a damp rag. After the cleaning, place the front cover back in its original location, and
secure it by attaching the center plate with clockwise rotation.
Please use a mild detergent. Do not use corrosive cleaning agents.
Technical Specifications
Input Voltage: 127 V~
Frequency: 60 Hz
Power Consumption: 65 W
On/Off
Fan Speed
Timer
Rotate
