Using Your

XP-600

Security System

ARMED

READY

SYSTEMü

FIRE

ZONE 1

ZONE 2

ZONE 3

ZONE 4

ZONE 5

ZONE 6

NAPCO

Oi218a.pub

page 1 Thursday, December 18, 1997 18:29

Introduction

Congratulations on your purchase of an advanced NAPCO EXPRESS XP-600 Security System. Meticulously developed

by a leading manufacturer of state-of-the-art security products, this system will provide you with unprecedented peace-of-mind

& incorporates some of the most sophisticated features available today. Above all, it has been designed an extra step, to

provide all those operating it with very easy, intuitive use. Please carefully review the information contained in this manual, so

that you and all potential users of the system familiarize yourselves with its operation, and can therefore take full advantage of

EXPRESS’ many convenience features and amenities.

Your system consists of a control panel (a computer housed within a white metal panel enclosure), one or more EXPRESS

Decorator Keypads for controlling the system, and various security detection devices. These detection devices are divided

among separate areas known as “zones”, set up throughout your premises. Each zone number corresponds to a Zone light on

your Keypad’s gray display area.

When a zone’s red light is ON (or lit), it indicates that one or more detection device(s) assigned to that area are active or open.

For example, if Zone 1 is the front door, and it is open, the Zone 1 light will be on. If zone 2 is a motion detector, and there is

movement in that area, Zone light 2 will turn ON. Depending upon the actual layout your security professional has chosen

to properly protect your premises, each zone may function a little differently: The zone protecting your front door may be

programmed as an Exit/Entry zone to allow you time to enter the premises disarm the system , without inadvertently sounding

the alarm. Alternatively, a zone protecting a window could be designated as an “instant” zone, so that if it is entered or

opened while the system is on/armed, there will be an immediate alarm.

Your easy NAPCO EXPRESS Keypad puts super-simple system control at your fingertips. Most keypad commands

involve entering your four digit User Code. This includes Arming (or activating) and Disarming (or deactivating) the system.

Simply put, ARMED means the system is ON; DISARMED means the system is OFF. If the system is OFF and you want to

turn it ON, just enter your Code. To turn the system back OFF, enter your code again. It’s easy, just always remember, in

the event of an alarm, entering your User Code will silence all Sirens. Your keypad is your command and status center,

it keeps you informed visibly, using its zone and status lights (in the gray display area) and audibly, using its built-in keypad

sounder. For more information, please see Keypad Controls and Indicators on page 4.

Oi218a.pub

page 2 Thursday, December 18, 1997 18:29

1Bell / Battery Test

Test your bell or siren by pressing Afollowed by 1.This

will cause the bell, or siren to sound for 2 seconds and also

initiate a test of the battery .

2Central Station Communication Test

(This test should only be performed on weekends or at a

time designated by your alarm company)

1. Notify Central Station of the impending test.

2. Secure all zones to light Ready Light on your keypad.

3. Enter your user code to Arm the system.

4. Violate your alarm by opening a window / door etc.

5. The siren or bell should sound and the system will send

the alarm signals to the Central Station

6.Enter you user code to silence the bell or sounder.

7. Call Central Station to insure that the alarm signals were

received properly.

Introduction

System Information

Central Station Phone Number: ____________________

Central Station Account Number: ____________________

For Service Call: ____________________

Entry Delay: ____________________

Exit Delay: ____________________

Alarm Time-out: ____________________

Important - Test Your System Weekly !

Table of Contents

Keypad Controls and Indicators ................................ 4

Arming your System (When Leaving) ....................... 5

Protecting Yourself While Home ............................... 6

Emergency Keys ....................................................... 7

Disarming the System ............................................... 8

Silencing an Alarm..................................................... 8

Resetting a Fire Alarm............................................... 8

Fire Protection .......................................................... 9

Special Functions ....................................................

System Troubles .......................................................

Oi218a.pub

page 3 Thursday, December 18, 1997 18:29

ARMED

READY

SYSTEM

FIRE

ZONE 1

ZONE 2

ZONE 3

ZONE 4

ZONE 5

ZONE 6

Keypad Controls and Indicators

Ready Light will light when all zones are secure

and system is ready to be Armed.

AC Light will light to indicate that AC Power

is present.

Fire Alarm Light will flash and the Keypad

sounder will beep when system is in a Fire Alarm

Condition (See Silencing a fire Alarm, Page 8)

Zone Lights (1 through 6) will light to indicate

that the corresponding Zone is open, and will

flash to indicate a zone in alarm.

Armed Light will light when system is Armed,

and will flash when system is in Alarm

#Key - used to reset Fire Zone, clear miss-

entered codes, reset Alarm Memory, etc..

üü System Light will light and the Keypad

sounder will pulse to indicate that a system trou-

ble is present.(See System Troubles, Page12)

üü Key Press to display any present

System troubles. Only available when

üü System Light is lit.

(See System troubles, Page 12)

Emergency Keys Press

simultaneously to signal

an emergency condition.

Press F+Ffor Fire,

A+Afor Auxiliary or

P+Pfor Police Emer-

gency. (Programmable)

Bypass Key Used to

bypass zones. Press

Bypass and the corre-

sponding zone number,

and then Arm system.

*Key Used to enable

special functions and op-

tions. Press *and then

the corresponding Spe-

cial Function number

Option (See Special

Functions, Page 11)

Numerical Keys 1-9, 0. Used to enter

User Codes, Zone numbers, etc.

NAPCO

Oi218a.pub

page 4 Thursday, December 18, 1997 18:29

Arming Your System When Leaving

1Before arming your system, make sure the Green Ready light is ON. This indicates that all of your prot-

ective zones are secure. If any zones are open, the corresponding Zone light will be ON. Secure these

zones before proceeding. If any zones cannot be secured, see Bypassing Zones below.

2 Enter your user code. The Green Ready light will go out, the Red Armed light will light.

• If you make a mistake entering your code, press Band re-enter the code.

• If the FIRE light is on, the Fire zone has not been properly reset. Press B and enter the code.

(See Silencing a Fire Alarm, page 8)

3 Leave the premises through the Exit/Entry door. If the keypad gives a steady tone you have taken

too long. Enter your code again to disarm system and then re-enter code and leave.

Easy Arm

The Easy Arm feature allows the system to be armed by simply pressing A followed by 0.

This will allow the easy arming of the system by someone who is not a regular system user.

Bypassing Zones

If an open zone cannot be immediately fixed it can be left unprotected, or Bypassed, while the rest of the

system is Armed. To Bypass a zone:

1Press Cfollowed by the zone number to be Bypassed. The Bypassed Zone’s light will flash slowly.

2 Enter your user code. The Green Ready light will go out and the Red Armed light will light.

3 Leave the premises through the Exit/Entry door.

When the system is subsequently disarmed, all bypassed zones will be reset, ready to be armed again.

If it is necessary to bypass any inoperative zone(s), it is important to have the zone(s) repaired as soon as

possible. A bypassed zone does not provide any protection, compromising system security.

Arming Your System

FIRE

SYSTEM

READY

ZONE 3

ZONE 1

ZONE 2

ZONE 5

ZONE 6

ZONE 4

ARMED

Oi218a.pub

page 5 Thursday, December 18, 1997 18:29

Protecting Yourself While at Home

1 Before arming your system, make sure the Green Ready light is ON. This indicates that all of your

protective zones are secure. If any zones are open, the corresponding Zone light will be ON. Secure

those zones before proceeding.

2 Enter your user code. The Green Ready light will go out, and the Red Armed light will light.

3Before your exit delay expires, press Cto bypass any interior zones, deactivating devices such

as motion sensors, and allowing free movement throughout the premises. The Zone light of any

bypassed zones will flash slowly.

• Your system may have been programmed for Automatic Interior Bypass , in which case it will recognize

that you have not left the premises and will automatically bypass any interior zones.

Instant Mode

Pressing Afollowed by 4will cancel the Entry delay , activating the “Instant” mode. This is typically

done in the evening when all family members are home for the night. Instant Mode can be activated at

any time after the system has been armed. The Red Armed light will flash rapidly while in the Instant Mode.

Easy Exit (optional)

Your System may have been programmed to allow Easy Exit, which allows a user to exit the premises

with the system armed. By pressing Bfollowed by 0, the protection is removed from the Exit/ Entry

zone for 3 minutes. This will allow, for example, an early morning commuter to exit the house in the

morning, without having to disarm and rearm the system, waking the family.

Arming With a System Trouble Present (the üü System Light is Lit)

If the XP600 has a system trouble present, the üüSYSTEM light will be lit and the keypad sounder

pulsing. If you cannot immediately clear the system trouble, the system can still be armed. Simply

press Cto view the trouble, press Cagain to reset the trouble and then arm the system.

Arming Your System

FIRE

SYSTEM

READY

ZONE 3

ZONE 1

ZONE 2

ZONE 5

ZONE 6

ZONE 4

ARMED

Oi218a.pub

page 6 Thursday, December 18, 1997 18:29

Emergency Buttons

The three sets of emergency buttons, if programmed, are always active whether the system is armed

or disarmed. Discuss these Buttons with your installer. The emergency signal will only be activated

when the two respective buttons are pressed at the same time.

Fire Alarm: Simultaneously press E+Eto sound a fire alarm, and to alert the central

station of a fire emergency, if so programmed.

Auxiliary Alarm: Simultaneously press F+Fto alert the central station of an auxiliary

emergency, if so programmed.

(The nature of this emergency alarm is to be determined by the installer)

Police Emergency: Simultaneously press G+Gto sound a police emergency alarm, and to alert

the central station of a fire emergency, if so programmed.

Emergency Conditions

E F GG

EFire

eEmergency

Enabled?

Yes No

FAuxiliary

FEmergency

Enabled?

Yes No

Ambush Alarm

In the event that you are forced by an intruder to disarm your system, the ambush alarm can be

activated. Disarming the system with the Ambush Code will cause the system to disarm and

simultaneously send a silent ambush alarm signal to Central Station. If your system has the Ambush

feature enabled, the code assigned as the User 6 code will function as your Ambush Code.

GPolice

GEmergency

Enabled?

Yes No

Ambush

Alarm

Enabled?

Yes No

Oi218a.pub

page 7 Thursday, December 18, 1997 18:29

Disarming Your System when Returning

1Enter your premises through the Entry/Exit door. The keypad will sound a steady tone to remind you to

disarm the system before your Entry Delay time expires.

2 Enter your user code. The Red Armed light will go out, indicating that the system has been disarmed.

Note: If you make a mistake entering your code, press the Bkey and re-enter the code.

Alarm Indication

If the Red Armed light is flashing rapidly, an alarm occurred while you were away. Proceed with caution!

For your own protection, leave immediately and call authorities from a neighbor’s phone .

Silencing an Alarm

In the event that the system goes into alarm due to a violated burglary zone, the bell or siren will sound and

the keypad sounder will also activate. To silence the system, enter your User code. The zone light of the

zone which went into alarm will continue to flash until Bis pressed to reset the alarm memory.

Silencing a Fire Alarm

In the event that the Fire alarm activates due to an violated smoke or fire detector, the bell or siren will

sound a distinct pulsating tone. The Red FIRE light on the keypad will be flashing, and the keypad sounder

will emit a pulsing tone. If a Fire Alarm does occur:

1If a fire is in progress, evacuate the premises immediately!Call the Fire Department from an outside

phone.

2If there is no evidence of a fire, enter your User Code. The bell or siren will silence, and the FIRE light on

the keypad will stop flashing but will still be lit.

3Determine which device went into alarm. If you are protected by smoke detectors, the light on the active

detector will be lit. Once it is determined which smoke detector is in alarm, press Bto reset the fire

zone.

4 If the Fire zone has reset properly, the FIRE light on the keypad should go out in approx. 30 seconds

Disarming Your System / Silencing an Alarm

FIRE

SYSTEM

READY

ZONE 3

ZONE 1

ZONE 2

ZONE 5

ZONE 6

ZONE 4

ARMED

Oi218a.pub

page 8 Thursday, December 18, 1997 18:29

Preparing a Fire Escape Plan

Even with the most advanced fire alarm system, adequate protection requires an escape plan.

To prepare your plan, draw floor plans of your building. (space is provided on the next page) Show two exits - a front or

back door and a window from each room. (Make sure each window works. You may need a special fire-escape ladder if

the window is high up.) Write down your outside meeting place.

Family Rehearsal

Rehearse each of the following activities:

1Everyone in his room with the doors closed.

2One person sounds the alarm.

3Each person tests his door.

4Pretend that the door is hot and use the alternate escape exit.

5Everyone meets outdoors at the assigned spot.

Important! - Read Carefully

Discuss each of these escape procedures with all those who

use the building.

1In a residence, sleep with the bedroom door closed.

2When the fire alarm signals, escape quickly. Do not stop to pack.

3Test the door. If it is hot, use your alternate route through the window.

If the door is cool, brace your shoulder against it and open it cautiously.

Be ready to slam the door if smoke or heat rushes in. Crawl through the

smoke, holding your breath. Close the doors again on leaving to help

prevent the fire from spreading.

4Go to your specific outdoor meeting place so you can see that everyone is safe.

5Call the Fire Department from a neighbor’s telephone.

Fire Protection

Would You Like More Safety Informa-

tion?

For more information on home fire detection,

burn safety, and home fire safety, write to:

National Fire Protection Association,

Public Affairs Dept. 05A,

Batterymarch Plaza,

Quincy, MA 02269

Oi218a.pub

page 9 Thursday, December 18, 1997 18:29

Fire Protection

Floorplan

Draw a plan of your premises below.

Oi218a.pub

page 10 Thursday, December 18, 1997 18:29

Andere Handbücher für EXPRESS XP-600

Inhaltsverzeichnis

Andere NAPCO Sicherheitssystem Handbücher

NAPCO

NAPCO XP-400 Datenblatt

NAPCO

NAPCO FREEDOM F-64TP Bedienungsanleitung

NAPCO

NAPCO Magnum Alert-825HS Produkthandbuch

NAPCO

NAPCO MAGNUM ALERT-725 Bedienungsanleitung

NAPCO

NAPCO XP-400 Express Series Bedienungsanleitung

NAPCO

NAPCO FREEDOM F-64TPBR Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT 825 SYSTEM Bedienungsanleitung

NAPCO

NAPCO Magnum Alert-900 Produkthandbuch

NAPCO

NAPCO F64 CODED Bedienungsanleitung

NAPCO

NAPCO Magnum Alert 1016e Bedienungsanleitung

NAPCO

NAPCO iSecure Installationshandbuch

NAPCO

NAPCO MAGNUM ALERT 1008e Bedienungsanleitung

NAPCO

NAPCO NETLINK Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT 854 SYSTEM Bedienungsanleitung

NAPCO

NAPCO Magnum Alert-800 Bedienungsanleitung

NAPCO

NAPCO XP-400 Datenblatt

NAPCO

NAPCO StarLink Connect Series Bedienungsanleitung

NAPCO

NAPCO SECURITY COMMAND CENTER Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT-850 Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT 854 SYSTEM Produkthandbuch

NAPCO

NAPCO XP-600 - 9-16-1997 Bedienungsanleitung

NAPCO

NAPCO MAGNUM ALERT-850 Bedienungsanleitung

NAPCO

NAPCO EXPRESS XP-600 Bedienungsanleitung

NAPCO

NAPCO EXPRESS XP-600 Bedienungsanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
