Kit Instructions

Large Basket Corner Module (Corner Bagwell)

7358-K580/K583/K584

Issue B

The product described in this document is a licensed product of NCR Corporation.

NCR is a registered trademark of NCR Corporation. NCR FastLane SelfServ™ Checkout is a trademark of NCR Corporation in

the United States and/or other countries. Other product names mentioned in this publication may be trademarks or registered

trademarks of their respective companies and are hereby acknowledged.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks

of HDMI Licensing LLC in the United States and other countries.

Where creation of derivative works, modifications or copies of this NCR copyrighted documentation is permitted under the terms

and conditions of an agreement you have with NCR, NCR's copyright notice must be included.

It is the policy of NCR Corporation (NCR) to improve products as new technology, components, software, and firmware become

available. NCR, therefore, reserves the right to change specifications without prior notice.

All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances,

photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR

office for information that is applicable and current.

To maintain the quality of our publications, we need your comments on the accuracy, clarity, organization, and value of this book.

Please use the link below to send your comments.

EMail: FD230036@ncr.com

By NCR Corporation

Global Headquarters

864 Spring St. NW

Atlanta, GA 30308

United States

Revision Record

Issue Date Remarks

AMar 2019 First issue.

BMar 2020 • Updated K580/K583/K584 Kit Contents.

• Modified the following sections:

•Installation Procedures on page9.

•Installing Power Pole Cover Assembly on page20.

•Installing Skirt Panels on page11.

•Installing Corner Bagwell on page13.

• Added the following sections:

•Changing Corner Bagwell Orientation on page29.

•Removing Fences on page33.

•Removing Corner Bagwell on page36.

•Removing Power Strip from the Corner Bagwell on page37.

•Routing Cables to Power Pole on page18.

Large Basket Corner Module

The Large Basket Corner Module (Corner Bagwell) is a component of the Large Basket

(Basket) Module, which consists of the following kits:

• Large Basket Angled Module (V-Bagwell)—an angled bagging area that is designed

to address large customer transactions.

• Large Basket Corner Module (Corner Bagwell)—a bagging area that provides

customers an area where they can place their items after scanning.

The NCRFastLane SelfServ™ Checkout (7358) R6L Plus with a Bagging Area (Bagwell)

Module or Large Basket (Basket) Module can be configured for either Left-hand (LH)

orientation or Right-hand (RH) orientation, which refers to the direction customers

scan and bag items.

•Left-hand (LH) orientation—Customers scan from left to right.

•Right-hand (RH) orientation—Customers scan from right to left.

Note: The orientation of the unit is determined by the position of the Lower Core

(Cabinet) Module in relation to the Bagging Area (Bagwell) Module or Large Basket

(Basket) Module.

Example: The Left-hand (LH) unit has the Cabinet positioned on the left side of the

Bagwell or Basket.

Prerequisite

The following kits should be ordered together to complete the Large Basket (Basket)

Module:

• 7358-K580/K583/K584 Large Basket Corner Module (Corner Bagwell)

• 7358-K589/K590/K591 Large Basket Angled Module (V-Bagwell)

2 Large Basket Corner Module

Kit Contents

Depending on the color variant of the Corner Bagwell, refer to the following sections for

information about kit contents:

•7358-K580 Corner Bagwell Module (NCRDark White) on the facing page.

•7358-K583 Corner Bagwell Module (Walmart Light Blue) on page5.

•7358-K584 Corner Bagwell Module (Walmart Medium Gray) on page7

Shipping Dimension and Weight

This section shows the approximate dimension and weight for the Corner Bagwell.

Note: These values are for reference only.

Shipping Dimension Shipping Weight

Height Length Width Pounds (lbs) Kilograms (kgs)

965.2 mm (38 in) 1219.2 mm (48 in) 1016 mm (40 in) 200 lbs 90.7 kgs

Large Basket Corner Module 3

7358-K580 Corner Bagwell Module (NCRDark White)

4 Large Basket Corner Module

Part Numbers Description

497-0527589 Kit - Large Basket Corner Module (NCR Dark White)

006-8627719 Split Lock Washer, Zinc-Plated Steel,½ in Screw Size (4 pcs)

006-8611505 Bushing, Nylon

006-8627720 Washer, Zinc-Plated Steel, ½ in Screw Size (8 pcs)

006-8612443 Flexible Leveling Foot - 2 in Dia. (5/16 in Hex x 3.25 in Length)

(2 pcs)

795-0279431 Assembly - Power Pole Cover (NCR Dark White)

007-7022121 Screw MA Flat Poz M4 8L (4 pcs)

006-8604541 Screw, ¼-20 x ½, Pan Head, Phillips (4 pcs)

009-0006593 Screws M4 x 10 (13 pcs)

009-0006593 Screws M4 x 10 (14 pcs)

006-8625423 Bolt - Hex Head, ½-13 x 4.50 in, With Nylon Patch (4 pcs)

497-0421485 Power Strip, Iec 4-Pos, Plastic Case

795-0284831 Walmart, Goods Shelf, Rectangle Module (NCR Dark White)

497-0524419 Goods Shelf, Rectangle, Skirt Assy

795-0269931 Bagwell Cable Access Cover (NCR Dark White)

497-0524421 Skirt Front and Back (2 pcs)

795-0275231 Corner Fence (NCR Dark White)

497-0524422 Side Skirt (2 pcs)

795-0275331 Rectangle Side Fence (NCR Dark White)

795-0274731 Square, Side Input Shelf (NCR Dark White)

795-0275031 Goods Shelf, Rectangle, Door Panel Assy (NCR Dark White)

497-0527183 Rectangle, Top Tray Assembly

795-0275431 Rectangle End Fence (NCR Dark White)

795-0281601 Hole Cover Label - (NCR Dark White)

006-8611539 Nut- Hex, 1/2-13, .427-.448 Thick (4 pcs)

* 497-0423108 Instructions - Kit (Reference Sheet)

* Items marked with an asterisk are not called out on the image.

Large Basket Corner Module 5

7358-K583 Corner Bagwell Module (Walmart Light Blue)

6 Large Basket Corner Module

Part Number Description

497-0527590 Kit - Large Basket Corner Module (Walmart Light Blue)

006-8627719 Split Lock Washer, Zinc-Plated Steel,½ in Screw Size (4 pcs)

006-8627720 Washer, Zinc-Plated Steel, ½ in Screw Size (8 pcs)

006-8612443 Flexible Leveling Foot - 2 in Dia. (5/16 in Hex x 3.25 in Length) (2

pcs)

* 795-0281612 Hole Cover Label - (Walmart Light Blue)

795-0275412 Rectangle End Fence (Walmart Light Blue)

006-8604541 Screw, ¼-20 x ½, Pan Head, Phillips (4 pcs)

795-0275012 Goods Shelf, Rectangle, Door Panel Assy (Walmart Light Blue)

006-8625423 Bolt - Hex Head, ½-13 x 4.5 in, With Nylon Patch (4 pcs)

795-0275212 Corner Fence (Walmart Light Blue)

795-0284812 Walmart, Goods Shelf, Rectangle Module (Walmart Light Blue)

795-0274712 Square, Side Input Shelf (Walmart Light Blue)

795-0275312 Rectangle Side Fence (Walmart Light Blue)

795-0269912 Bagwell Cable Access Cover (Walmart Light Blue)

007-7022121 Screw MA Flat Poz M4 8L (4 pcs)

009-0006593 Screws M4 x 10 (13 pcs)

009-0006593 Screws M4 x 10 (14 pcs)

006-8611505 Bushing, Nylon

497-0421485 Power Strip, Iec 4-Pos, Plastic Case

497-0524419 Goods Shelf, Rectangle, Skirt Assy

497-0524421 Skirt Front And Back (2 pcs)

497-0524422 Side Skirt (2 pcs)

497-0527183 Rectangle, Top Tray Assembly

795-0279412 Assembly - Power Pole Cover (Walmart Light Blue)

006-8611539 Nut- Hex, ½-13, 0.427 - 0.448 Thick (4 pcs)

* 497-0423108 Instructions - Kit (Reference Sheet)

* Items marked with an asterisk are not called out on the image.

Large Basket Corner Module 7

7358-K584 Corner Bagwell Module (Walmart Medium Gray)
