Electra Elite®Wireless

The PSII Wireless User Guide

NECK-008 Guide Cover Final 5/3/01 9:28 AM Page 3

To recharge a PSII (with the battery

pack inside) place phone here.

To recharge a spare battery pack,

place it here.

CAUTION: The caution label

always faces front.

NOTE: When both the PSII and

the spare battery are in the

charger, the spare battery charges

first, followed by the PSII. Red

indicates charging in process,

green indicates charging is

complete.

Battery lamp indicates the charging

status of the spare battery.

PS lamp indicates the charging status of

the battery inside the PSII.

AC power adapter is supplied with

the PSII charger.

Charging the Battery

NECK-008 Guide Cover Final 5/3/01 9:28 AM Page 4

PAGES 2 & 3

Displays and Keys

The PSII Display

PAGES 4 & 5

Basic Operation

PSII Features

PAGES 6 & 7

Entering Names In The

Directory

Directory Dialing

Speed Dial Numbers

Last Number Redial

PAGES 8 & 9

Call Forwarding

Transferring a Call

Calling Party Number

Place a Call On Hold

Set Call Park

Retrieve a Parked Call

Initiate a Conference call

Adjust Call Volume

PAGES 10 & 11

PSII Functions

Program/Erase Softkeys

Softkey Chart

Table of Contents

PAGES 12 & 13

Program/Erase Message Keys

Access Message Keys

Program/Erase VM Speed Dial

Speaker Ring

Keypad Lock

Automatic Answer

Headset Ring

PAGES 14 & 15

Number Display

Key Click

Key Light

LED Flash

Station/Line Ring

Service Alarm

Confirmation Tone

PAGES 16 & 17

Answer Tone

Modem Dial

Call Forwarding Busy

Call Forwarding Doesn’t Answer

Call Forwarding All

Power On Message

PAGES 18 & 19

Password

Protect Directory

Default Set

Reset All

INSIDE BACK COVER

Accessories

NECK-008 Inside Final 5/3/01 9:35 AM Page 1

Displays and Keys

Feature Keys

Control specific

features of phone.

FNC/CLEAR

(Function Key)

Press to activate

numerous telephone

functions. Press to

clear entry.

END/PWR

(End Power On/Off

Key) Push once to

end a call. Press for

more than two

seconds to turn

power on and off.

L1 Button

Press to originate or

answer a call.

L2 Button

Not available for

Electra Elite.

Microphone

Fixed, Snub-Nose

Antenna

No need to pull out

or adjust.

LED Ring

Indicator

Red light indicates

incoming call.

LCD Display

Headset Jack

Scroll Keys

Press while in the

standby mode

to access additional

feature levels. Press

and hold for more

than two seconds

during a call to

increase or lower

volume receiver.

Battery

Compartment

(in back)

Programming

Interface

(on bottom)

NECK-008 Inside Final 5/3/01 9:35 AM Page 2

To view digit overflowing the display

to the left or right.

Off-hook, indicating the PSII is off-

hook.

Signal strength, indicating strength or

weakness of signal being received. The

antenna picture display illuminates as

the phone powers up, indicating that

the phone can make a call.

Envelope indicates user has at least one

new voice mail message.

Keylock status illuminates when

Keylock is on.

Illuminated ANS indicates that Auto

Answer is active.

Battery indicates charge level. The line

indicates weak charge. Battery without

line indicates strong charge.

Illuminated V indicates that incoming

call vibration notification is active.

Illuminated S indicates that incoming

ring volume is silent.

The PSII Display

NECK-008 Inside Final 5/3/01 9:35 AM Page 3

TOTURN THE PHONE ON/OFF

➤Press the END/PWR key and hold for more than two seconds to turn on.

*The PSII will display the start-up greeting: Please Wait

* indicates communication is available.

*NO SERVICE indicates your PSII is out of the service area. No service

indication may also indicate the number of visitors limit has been exceeded

when roaming.

➤Press the END/PWR key and hold for more than two seconds to turn off.

TOORIGINATE A CALL

➤Enter the telephone number.

➤Press L1.

➤Press L1. If number display is on, the PSII will momentarily display the

extension number of the selected line.

➤Enter the telephone number.

TORECEIVE A CALL

➤During ringing, press L1.

➤Begin speaking into the microphone.

TOADJUST RING VOLUME

➤Press FNC/CLEAR.

➤Press F2 to turn off, F3 to turn up or F1 to turn down.

➤Press selection repeatedly until desired setting or SILENCE appears in the

display.

➤Press L1 to enter new volume.

*If volume is turned off, the silent ring icon (S) will appear in the display.

TOSELECT INCOMING CALL VIBRATION NOTIFICATION

➤Press FNC/CLEAR.

➤Enter 06.

➤Press F1 to turn on or F3 to turn off.

➤Press L1 to enter vibration setting.

*The incoming call vibration notification indicator (V) will appear in the

display.

Basic Operation

NECK-008 Inside Final 5/3/01 9:35 AM Page 4

Elite Wireless supports 11 preset keys, 10 programmable softkeys and 6

programmable message softkeys. All can be accessed by pressing the F1, F2 or F3

feature keys then pressing the up and down scroll keys as needed to move between

levels. Preset features include:

DIR Directory

SPD Speed Dialing

LNR Last Number Redial

CFW Call Forwarding

TRF Call Transfer

CPN Calling Party Number

HLD Hold

VOL Call Volume Control

or Scroll Display

PAUSE Inserts pause in dialing sequence

S1 – S9 Programmable softkeys

M1 – M6 Programmable message keys

VM Voicemail

TM Text Messaging

NOTE: Text Messaging is not supported on Electra Elite.

F1 F2 F3

Level 0 Pause

Level 1 DIR SPD LNR

Level 2 CPN CFW

Level 3 HLD TRF VOL

Level 4 S1 S2 S3

Level 5 S4 S5 S6

Level 6 S7 S8 S9

Level 7 M1 M2 M3

Level 8 M4 M5 M6

Level 9 TM VM

Features

NECK-008 Inside Final 5/3/01 9:35 AM Page 5

TOENTER NAMES IN THE DIRECTORY

➤Press FNC/CLEAR.

➤Enter 03.

➤Press F1.

➤Key in the name using the following chart:

➤When the name is complete, Press L1.

➤Enter the number.

*If a pause is required (after trunk access 9 for an outside line) press F2 to

insert a pause.

➤Press L1 to enter directory.

➤Press L1 again to confirm.

➤Press END/PWR to exit.

Times 12345 12345

Key Upper Lower

1.,1 .,1

2ABC2 abc2

3DEF3 def3

4GHI4 ghi4

5JKL5 jkl5

6MNO6 mno6

7PQRS7pqrs7

8TUV8 tuv8

9WXYZ9wxyz9

0SP–0 SP–0

**( *(

##) #)

PAUSE Change to lower case Change to upper case

FNC/Clear Delete entry Delete entry

NECK-008 Inside Final 5/3/01 9:35 AM Page 6

TOUSE DIRECTORY DIALING

➤While in standby mode, press F1.

➤To search the directory in alphabetical order, press SCROLL DOWN.

*You may push SCROLL UP to scan in reverse order.

➤To search the directory by name, key in the first few letters of the person’s last

name then push the down key until the desired selection appears.

➤Once you’ve found the name, press L1 to dial the number.

➤To make another selection, press END/PWR then repeat above steps.

TOENTER SPEED DIAL NUMBERS

➤Press FNC/CLEAR.

➤Enter 04.

➤Press F1.

➤Enter your speed dial number 01 through 20.

➤Press L1 to enter.

➤Key in the name using the chart on page 6.

➤Press L1 to enter name.

➤Key in the digits for that number.

➤Press L1 to enter digits.

➤Press L1 again to confirm.

➤Press END/PWR to exit.

NOTE: Do not remove the battery until at least one minute has elapsed since entering Directory or Speed Dial numbers.

TOUSE SPEED DIAL NUMBERS

➤While in stand-by mode, press F2.

➤Key in the speed dial number 01 through 20.

➤Press L1 to dial the number or press one of the SCROLL keys to scroll

through the list of speed dial entries.

TOACCESS LAST NUMBER REDIAL

➤While the phone is in standby mode, press F3.

➤The PSII will display the last number dialed.

➤If that is the number you wish to dial, press L1.

➤If that is not the number you wish to dial, press SCROLL DOWN to scroll

through the last five numbers dialed.

NOTE: The PSII retains the last five numbers you have called.

NECK-008 Inside Final 5/3/01 9:35 AM Page 7

TOUSE CALL FORWARDING

NOTE: Before using this feature, call forward access codes need to be established. Refer to Functions to set access codes.

➤While the phone is in standby mode, press SCROLL DOWN.

*If access codes are not established, display will show CFW Empty.

CALL FORWARD BUSY

➤Press F2 to select call forwarding.

➤Press F1 to set the extension to forward busy calls.

➤Press L1.

➤Dial the destination number to forward the calls or press SCROLL DOWN

key for Call Forward D/A.

CALL FORWARD D/A

➤Press F2 to select call forwarding.

➤Press SCROLL DOWN.

➤Press F1 to set the extension to forward calls which are not answered.

➤Press L1.

➤Dial the destination number to forward the calls or press SCROLL DOWN

key for Call Forward All.

CALL FORWARD ALL

➤Press F2 to select call forwarding.

➤Press SCROLL DOWN twice.

➤Press F1 to set the extension to forward all calls.

➤Press L1.

➤Dial the destination number to forward the calls or press SCROLL DOWN

key for Call Forward N/R.

CALL FORWARD N/R

NOTE 1: Call forward N/R is not supported on Electra Elite. Press SCROLL DOWN key for Call

Forward Busy.

NOTE 2: One default access code is provided for Call Forward Busy / Call Forward No Answer. Check

with your system administrator for additional access codes.

TOTRANSFER A CALL

➤With a call in progress, press F2.

*You will hear a special dial tone.

➤Key in the telephone number you wish to transfer the call to.

➤Press END/PWR to complete the transfer. Your PSII will return to the

standby mode.

NECK-008 Inside Final 5/3/01 9:35 AM Page 8

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere NEC Schnurloses Telefon Handbücher

NEC

NEC SL1000 Bedienungsanleitung

NEC

NEC DS1000 Bedienungsanleitung

NEC

NEC Dterm Cordless II Bedienungsanleitung

NEC

NEC DTR-1R-2 Bedienungsanleitung

NEC

NEC Dterm PSIII Bedienungsanleitung

NEC

NEC Dterm Cordless Lite II Bedienungsanleitung

NEC

NEC G277 Bedienungsanleitung

NEC

NEC DSX CORDLESS LITE II Bedienungsanleitung

NEC

NEC NCS Bedienungsanleitung

NEC

NEC MDview 232 Bedienungsanleitung

NEC

NEC DTL-12BT-1 - DT330 - Plus BCH Bedienungs- und Montageanleitung

NEC

NEC G566 Bedienungs- und Wartungshandbuch

NEC

NEC DTR-IR-2 Bedienungsanleitung

NEC

NEC Dterm Analog Cordless Bedienungsanleitung

NEC

NEC DTL-12BT-1 series Bedienungsanleitung

NEC

NEC DTH-4R-1 Bedienungsanleitung

NEC

NEC Xen Topaz Gebrauchsanweisung

NEC

NEC IP3NA-12TXHBT Bedienungsanleitung

NEC

NEC Aspire Bedienungsanleitung

NEC

NEC 910i Bedienungsanleitung

NEC

NEC DS1000/2000 Bedienungsanleitung

NEC

NEC Dterm Cordless II DTR-4R BK Bedienungsanleitung

NEC

NEC DTL-8LD-1 Bedienungsanleitung

NEC

NEC Dterm I Series Bedienungsanleitung

Beliebte Schnurloses Telefon Handbücher anderer Marken

3Com

3Com NBX Bedienungsanleitung

Panasonic

Panasonic KX-TGK210HK Bedienungsanleitung

Panasonic

Panasonic KX-TCA181EX Bedienungsanleitung

BT FREESTYLE 3200 Bedienungsanleitung

AT&T

AT&T CL84102 Bedienungsanleitung

BREZZICNI

BREZZICNI CL-3622 Bedienungsanleitung

Panasonic

Panasonic KX-TG1831NZ Bedienungsanleitung

Panasonic

Panasonic KX-TG7301E Bedienungsanleitung

Furuno

Furuno FM-4721 Bedienungsanleitung

Sanyo

Sanyo CLT-J70 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 201 Bedienungsanleitung

GE 26992 Bedienungsanleitung

AT&T

AT&T E1812B Bedienungsanleitung

Sanyo

Sanyo CLT-670 Bedienungsanleitung

GE 15432970 Bedienungsanleitung

Curtis

Curtis TC595 Bedienungsanleitung

Gigaset

Gigaset Gigaset 3000 Micro Bedienungsanleitung

Poly

Poly VVX D230 Einrichtungshandbuch
