NEC Pmn Bedienungsanleitung

MultiSync LCD400

MultiSync LCD2000

User’s Manual

Declaration of the Importer

We hereby certify that the color monitors

MultiSync LCD400 (LA-1421JMW)

MultiSync LCD2000 (LA-2031JMW)

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Europe Ltd. Ismaning Office

Steinheilstraße 4-6

D-85737 Ismaning, Germany

Safety Instruction

Caution:

When operating the LA-1421JMW/LA-2031JMW with a 220-240V AC

power source in Europe except UK, use the power cord provided with

the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the LA-1421JMW/LA-2031JMW with a 220-240V AC

Power source in Australia, use the power cord provided with the

monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of

International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,

OptiClear, CROMACLEAR and Advanced Digital Control System are trademarks of NEC Home

Electronics, Ltd.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home

Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,

Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

For the Customer to use in U.S.A or Canada.

Canadian Department of Communications Compliance

Statement

DOC: This Class B digital apparatus meets all requirements of the

Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du

Règlement sur le matériel brouiller du Canada.

C-UL: Bears the C-UL Mark and is in compliance with Canadian

Safety Regulations according to C.S.A. C22.2 #950.

Ce produit porte la marque ‘C-UL’ et se conforme aux règlements de

sûrele Canadiens selon CAN/CSA C22.2 No. 950.

FCC Information

1. Use the attached specified cables with the LA-1421JMW and

LA-2031JMW color monitors so as not to interfere with radio and

television reception.

(1) Please use the Shielded power cable or equivalent to ensure

FCC compliance.

(2) MultiSync LCD400: Shielded video signal cable.

(3) MultiSync LCD2000: Shielded 15-pin VGA to BNC cable.

Use of other cables and adapters may cause interference with

radio and television reception.

2. This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency

energy, and, if not installed and used in accordance with the

instruction, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or

more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and

receiver.

-Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

-Consult your dealer or an experienced radio/TV

technician for help.

If necessary, the user should contact the dealer or an

experienced radio/television technician for additional

suggestion. The user may find the following booklet, prepared

by the Federal Communications Commission, helpful: “How

to Identify and Resolve Radio-TV Interference Problems.”

This booklet is available from the U.S. Government Printing

Office, Washington, D.C., 20402, Stock No.

004-000-00345-4.

English

Introduction to the NEC MultiSync LCD400/LCD2000

Congratulations on your purchase of the NEC MultiSync LCD400/

LCD2000 true colour monitor!

Analog Advantage

Capable of displaying unlimited colours in a continuous spectrum,

providing a truer representation of colour. The monitor’s high contrast

LCD enhances colour vibrancy and improves focus with no geometric

distortion.

Wider Compatibility

Because the MultiSync LCD monitor is analog through and through, it

does not require special analog to digital display or interface cards but

can accept RGB input directly.

Reduced Footprint

Provides the ideal solution for environments requiring superior image

quality but with size and weight limitations. The monitor’s small

footprint and low weight allow it to be moved or transported easily from

one location to another.

Colour Control system

Allows you to adjust the colours on your screen and customize the

colour accuracy of your monitor to a variety of standards.

OSM (On-Screen Manager) Controls

Allows you to quickly and easily adjust all elements of your screen

image via simple to use on-sreen menus.

Introduction to the NEC MultiSync LCD400/LCD2000 E - 1

ErgoDesign Features

Enhance human ergonomics to improve the working environment,

protect the health of the user and save money. Examples include OSM

controls for quick and easy image adjustments, tilt/swivel base for

preferred angle of vision small footprint and compliance with MPRII

guidelines for lower emissions.

Plug and Play (MultiSync LCD400 only)

The Microsoft solution with the Windows 95 operating system

facilitates setup and installation by allowing the monitor to send its

capabilities (such as screen size and resolutions supported) directly to

your computer, automatically optimizing display performance.

IPM (Intelligent PowerManager) System

Provides innovative power-saving methodes that allow the monitor to

shift to a lower power consumption level when on but not in use, saving

two-thirds of your monitor energy cost, reducing emissions and

lowering the air conditioning cost of the workplace.

Multiple frequency Technology

Automatically adjusts monitor to the display card’s scanning frequency,

thus displaying the resolution required.

FullScan Capability

Allows you to use the entire screen area in most resolutions,

significantly expanding image size.

E - 2 Introduction to the NEC MultiSync LCD400/LCD2000

Contents of Package

Your new MultiSync LCD monitor box should contain the following:

–NEC MultiSync LCD400 (Model LA-142lJMW)/

NEC MultiSync LCD2000 (Model LA-203lJMW).

–AC power cable.

–Video signal cable – 15 pin mini D-SUB to 15 pin mini D-SUB

(LCD400)/

Video signal cable – 15 pin mini D-SUB to BNC (LCD2000).

–User’s manual.

Remember to save the original box and packing materials to transport or

ship this monitor.

Contents of Package E - 3
