NEC Express 5800/320Fd Handbuch

ReadMe First: Unpacking

Express5800/320FdSystem Cabinets

NEC Corporation of America

456-01741-000

Notice

The information contained in this document is subject to change without notice.

UNLESS EXPRESSLY SET FORTH IN A WRITTEN AGREEMENT SIGNED BY

AN AUTHORIZED REPRESENTATIVE OF NEC, NEC MAKES NO WARRANTY

OR REPRESENTATION OF ANY KIND WITH RESPECT TO THE INFORMATION

CONTAINED HEREIN, INCLUDING WARRANTY OF MERCHANTABILITY AND

FITNESS FOR A PURPOSE. NEC assumes no responsibility or obligation of any

kind for any errors contained herein or in connection with the furnishing,

performance, or use of this document.

Software described in NEC (a) is the property of NEC and/or its licensees, (b) is

furnished only under license, and (c) may be copied or used only as expressly

permitted under the terms of the license.

NEC documentation describes all supported features of the user interfaces and the

application programming interfaces (API) developed by NEC and/or its licensees.

Any undocumented features of these interfaces are intended solely for use by NEC

personnel and are subject to change without warning.

This document is protected by copyright. All rights are reserved. No part of this

document may be copied, reproduced, or translated, either mechanically or

electronically, without the prior written consent of NEC Corporation of America.

The NEC Corporation of America logo, Express5800/320Fd, and the

Express5800/320Fdlogo, are trademarks of NEC Corporation of America.

ActiveService Network is a trademark of Stratus Technologies Bermuda, Ltd. All

other trademarks and trade names are the property of their respective owners.

Manual Name: Read Me First: Unpacking Express5800/320FdSystem Cabinets

Part Number: 465-01741-000

Revision Number: 0

Publication Date: July 2008

NEC Corporation of America

10850 Gold Center Drive, Suite 200

Rancho Cordova, CA 95670

-iii-

Contents

Introduction 1

Packaged Cabinet 1

Before Unpacking the Cabinet 3

Moving the Cabinet to the Installation Site 6

Unpacking and Checking the Cabinet 7

Tools Needed to Unpack the Cabinet 8

Removing the Packing Materials 8

Removing the Cabinet from the Pallet 15

Checking the Cabinet and Systems 17

Verifying the Express5800/320Fd Serial Number 18

Stabilizing the Systems 19

Disposing of Shipping Materials 20

What Happens Next? 20

System Documentation 20

-iv-

-1-

Introduction

Read Me First: Unpacking Express5800/320FdCabinets

describes how to move cabinets that contain these systems to an

installation site and how to unpack them.

Warnings, cautions, and notes in this document convey the

following special information:

WARNING

A warning indicates a situation where failure

to take or avoid a specified action could cause

bodily harm or loss of life.

CAUTION

A caution indicates a situation where failure to

take or avoid a specified action could damage a

hardware device, program, system, or data.

NOTE

A note provides important information concerning

the operation of your system.

Packaged Cabinet

Figure 1 shows a shipping container for a 38U cabinet that

contains one or more systems and optional components. (“U,” for

unit, equals 1.75 inches (in.), or 4.45 centimeters (cm).)

-2-

Figure 1. Cabinet Packaged for Shipping

The cardboard shipping container is secured to a shipping pallet

by exterior shipping straps. (Inside the shipping container, interior

shipping straps secure the cabinet to the pallet.) A ramp for rolling

the cabinet off the pallet is attached to one side of the shipping

container, at the rear of the cabinet. Labels on the cardboard cap

indicate the front and rear of the cabinet.

hsys032

Ramp

Pallet

Tie-down

straps

-3-

Before Unpacking the Cabinet

1. Check the packing list to verify that you have received the

correct shipment.

2. Verify that the Tip-N-Tell and Shockwatch handling indicators

on the outside of the shipping container have not been

activated.

CAUTION

If you received the wrong shipment or a handling

indicator has been activated, do not proceed

with the unpacking. Contact the vendor from

which you purchased your system and the

shipping carrier immediately.

3. Verify that the area through which you must move the cabinet

has adequate clearance, as the following figures indicate:

•Figure 2 shows the dimensions of a packaged 38U

cabinet.

•Figure 3 shows the dimensions of a packaged 24U

cabinet.

•Figure 4 shows the clearances required at the installation

site.

Include the height of the pallet jack when you calculate the

overall cabinet height.

-4-

Figure 2. Dimensions of a Packaged 38U Cabinet

80 in.

(2m)

41 in.

(104.14 cm)

53 in.

(134.62 cm)

5 in.

(12.7 cm)

38U Cabinet

hsys033

-5-

Figure 3. Dimensions of a Packaged 24U Cabinet

Figure 4. Clearances Required at the Installation Site

56.5 in.

(1.435m)

41 in.

(104.14 cm)

53 in.

(134.62 cm)

5 in.

(12.7 cm)

24U Cabinet

hsys034

Cabinet

on Pallet

Pallet Ramp

Unload From

This End

42 in.

(107 cm)

42 in.

(107 cm)

150 in.

(381 cm)

42 in.

(107 cm)

-6-

If the corridor and door dimensions are large enough to

accommodate the unpacked cabinet still tied to its pallet, use a

pallet jack to move it from the delivery site to the installation site,

as described in “Moving the Cabinet to the Installation Site” on

page 6.

If the corridor and door dimensions are too small to accommodate

the unpacked cabinet still tied to its pallet, unpack the cabinet and

unload it from the pallet before you move it to the installation site.

In this case, use the pallet jack to move the unpacked cabinet as

close to the installation site as possible. Then, unpack the cabinet,

remove it from its pallet, and roll it carefully on its casters to the

installation site.

Moving the Cabinet to the Installation Site

WARNING

To avoid personal injury or damage to the

systems or cabinet, two persons are required

to move, unpack, and install a cabinet that

contains Express5800/320Fdsystems.

Because of the size and weight of the systems

in cabinets, consider using professional

movers to deliver and move the packaged

units to the installation site.

CAUTION

To prevent or minimize condensation on the

systems’ internal and external surfaces, avoid

exposing the systems to extreme temperature or

humidity changes when moving them to the

installation site. If the systems have been

exposed to extreme temperature or humidity

conditions during transit, or if condensation is
