NEC Express5800 140He Bedienungsanleitung



User’s Guide

Express5800 140He

000

Proprietary Notice and Liability Disclaimer

The information disclosed in this document, including all designs and related materials, is the

valuable property of NEC Computers and/or its licensors. NEC Computers and/or its licensors,

as appropriate, reserve all patent, copyright and other proprietary rights to this document,

including all design, manufacturing, reproduction, use, and sales rights thereto, except to the

extent said rights are expressly granted to others.

The NEC Computers product(s) discussed in this document are warranted in accordance with

the terms of the Warranty Statement accompanying each product. However, actual

performance of each product is dependent upon factors such as system configuration, customer

data, and operator control. Since implementation by customers of each product may vary, the

suitability of specific product configurations and applications must be determined by the

customer and is not warranted by NEC Computers.

To allow for design and specification improvements, the informationinthis document issubject

to change at any time, without notice. Reproduction of this document or portions thereof with-

out prior written approval of NEC Computers is prohibited.

Trademarks

NEC ESMPRO and NEC EXPRESSBUILDER are trademarks of NEC Corporation.

Microsoft, Windows, Windows Server, and MS-DOS are registered trademarks or trademarks of

Microsoft Corporation in the United States and other countries.

Intel and Pentium are registered trademarks of Intel Corporation.

Xeon is a trademark of Intel Corporation.

Novell and NetWare are registered trademarks of Novell, Inc. of the United States.

Datalight is a registered trademark of Datalight, Inc.

ROM-DOS is a registered trademark of Datalight, Inc.

AT is a registered trademark of International Business Machines Corporation in the United States and

other countries.

Adaptec and its logo is a registered trademark of Adaptec, Inc. of United States.

SCSISelect is a trademark of Adaptec, Inc. of the United States.

Adobe, Adobe logo, and Acrobat are trademarks of Adobe Systems Incorporated.

DLT and DLTtape are trademarks of Quantum Corporation of the United States.

All other product, brand, or trade names used in this publication are the trademarks or registered

trademarks of their respective trademark owners.

AVOCENT and DVC (Dambrackas Video Compression) are registered trademarks or trademarks of

AVOCENT in the United States and other countries.

rev 3.0 January 2006

NEC Computers S.A.S.

10 rue Godefroy

Immeuble OPTIMA

92821 PUTEAUX

FRANCE

This page is intentionally left blank.

Keep this User’s Guide at hand for quick reference at anytime necessary.

SAFETY INDICATIONS

Follow the instructions in this User’s Guide for your safety to use the server.

The server contains components with possible danger, hazards that may cause by ignoring warnings, and preventive

actions against such hazards.

Server components with possible danger are indicated with a warning label placed on or around them as well as

described in this User’s Guide.

In the User’s Guide or warning labels, "WARNING" or "CAUTION" is used to indicate a degree of danger. These terms

are defined as follows:

WARNING Indicates the presence of a hazard that may result in death or serious personal injury.

CAUTION Indicates the presence of a hazard that may cause minor personal injury, including

burns, or property damage.

Precautions and notices against hazards are presented with one of the following three symbols. The individual symbols

are defined as follows:

This symbol indicates the presence of a hazard.

An image in the symbol illustrates the hazard type. (Attention)

This symbol indicates prohibited actions. An image in the symbol illustrates a particular prohibited

action. (Prohibited Action)

This symbol indicates mandatory actions. An image in the symbol illustrates a mandatory action to

avoid a particular hazard. (Mandatory Action)

(Example) Symbol to draw attention

Term indicating a degree of danger

CAUTION

High temperature.

Immediately after the server is powered off, its internal components such as hard disks are

very hot. Leave the server until its internal components fully cool down before

installing/removing any component.

Symbol indicating a prohibited

action (may not always be

indicated)

Description of the danger

SYMBOLS USED IN THIS USER'S GUIDE AND WARNING LABELS

Attentions

Indicates that improper use may cause an electric shock.

Indicates that improper use may cause personal injury.

Indicates that improper use may cause fingers to be caught.

Indicates that improper use may cause the clip of a hand.

Indicates that improper use may cause fumes or fire.

Indicates a general notice or warning that cannot be specifically identified.

Indicates that improper use may cause loss of eyesight due to laser beam.

Prohibited Actions

Indicates a general prohibited action that cannot be specifically identified.

Do not disassemble, repair, or modify the server. Otherwise, an electric shock or fire may be caused.

Mandatory Action

Unplug the power cord of the server. Otherwise, an electric shock or fire may be caused.

Indicates a mandatory action that cannot be specifically identified. Make sure to follow the

instruction.

SAFETY INDICATIONS BY COLOUR OF THE PARTS

Only green area is available for hot swap or hot plug operation. To avoid electric shock, disconnect allAC power cords

before accessing to other parts especially blue area inside the system.

NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

CE Statement

Warning: This is a Class A product. In domestic environment this product may cause radio interference in which case

the user may be required to take adequate measures (EN55022).

CLASS 1

LASER PRODUCT

This system is classified as a CLASS 1 LASER PRODUCT. This

label is located on the internal optical disk drive installed in your

system.

Momentary voltage drop prevention:

This product may be affected by a momentary voltage drop caused by lightning. To prevent a momentary voltage drop,

an AC uninterruptible power supply (UPS) unit should be used.

Notes:

(1) No part of this manual may be reproduced in any form without the prior written permission of NEC Computers.

(2) The contents of this User's Guide may be revised without prior notice.

(3) The contents of this User’s Guide shall not be copied or altered without the prior written permission of NEC

Computers.

(4) All efforts have been made to ensure the accuracy of all information in this User’s Guide. If you notice any part

unclear, incorrect, or omitted in this User’s Guide, contact the service representative where you purchased this

product.

(5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or consequential

damages arising from the use of this User’s Guide regardless of Item (4).

PREFACE

Welcome to the Express5800/140He server.

The Express5800 server holds powerful performance and employs the latest technology to implement a computer for

the next generation. With its potential capabilities, the server may be used as a workstation PC that configures a

client-server system and provides high-speed processing and superior reliability.

Read this User’s Guide thoroughly to fully understand handling of the server and appreciate its functions to the

maximum extent.

ABOUT THIS USER'S GUIDE

This User’s Guide is a guide for proper setup and use of the server.

This User’s Guide also covers useful procedures for dealing with difficulties and problems that may arise during setup

or operation of the server. Keep this manual for future use.

The following describes how to proceed with this User’s Guide.

How to Use This User's Guide

To aid you in finding information quickly, this User’s Guide contains the following information:

Chapter 1 Notes on Using Your Server

includes information that needs attention when using the server. Make sure to read this chapter before setting

up and using the server.

Chapter 2 General Description

includes information necessary to use the server, such as names and functions of its components, handling of

the floppy disk and CD-ROM drives. It also includes requirements and advisory information for transfer and

disposal of the server.

Chapter 3 Setting Up Your Server

tells you how to select a site, unpack the system, make cable connections, and power on your system.

Chapter 4 Configuring Your Server

tells you how to configure the system and provides instructions for running the BIOS Setup Utility and the

MegaRAID Configuration Utility, which is used to configure SCSI devices in your system. This chapter also

provides information on I/O board jumper settings.

Chapter 5 Installing the Operating System with Express Setup

describes how to install the operating system.

Chapter 6 Installing and Using Utilities

describes how to install the utilities for the server. It also includes a description on using the attached

"EXPRESSBUILDER" CD-ROM.

Chapter 7 Maintenance

provides you with all the information necessary to maintain successful operation of the server. This chapter also

includes a description on relocating and storing the server.

Chapter 8 Troubleshooting

contains helpful information for solving problems that might occur with your system.

Chapter 9 Upgrading Your Server

provides you with instructions for upgrading your system with an additional processor, optional memory, optional

add-in cards, hard disk drives, peripheral devices, and power supply.

Appendix A Specification

provides specifications for your server.

Appendix B Other Precautions

provides supplementary notes on using the server.
