NEC MH4000 Bedienungsanleitung

``````````````()

■■■■■■■

Server MH4000

User’s Guide

Trademarks

Adaptec is a registered trademark of Adaptec Corporation

DigiBoard is a trademark of DigiBoard Corporation

INTEL is a registered trademark of Intel Corporation

Mylex is a registered trademark of Mylex Corporation

MS-DOS is a registered trademark of Microsoft Corporation

Pentium is a registered trademark of Intel Corporation

PS/2 is a trademark of International Business Machines Corporation

Other product and company names are registered trademarks and trademarks of their respective holders.

Printed in the United States of America.

PN: 101846-01 7/97

Safety Notices



Caution: To reduce the risk of electric shock which could cause personal injury, follow all safety

notices. The symbols shown are used in your documentation and on your equipment to indicate safety

hazards.



Warning: Lithium batteries can be dangerous. Improper handling of lithium batteries may result in

an explosion. Dispose of lithium batteries as required by local ordinance or as normal waste if no

local ordinance exists.



Warning: The detachable power supply cords are intended to serve as disconnect devices.



Warning: This equipment uses 3-wire, grounded power cords. To prevent electrical hazards, do not

remove or defeat the ground prong on the power cords. Replace a power cord if it gets damaged.

Contact your dealer for an exact replacement.

In the U.S.A. and Canada, the power cord must be a UL-listed detachable power cord (in Canada,

CSA-certified), type ST or SJT, 16 AWG, 3-conductor, provided with a molded-on NEMA type

5-15 P plug cap at one end and a molded-on cord connector body at the other end. The cord length

must not exceed 9 feet (2.7 meters).

Outside the U.S.A. and Canada, the plug must be rated for 250 VAC, 10 amp minimum, and must

display an international agency approval marking. The cord must be suitable for use in the end-user

country. Consult your dealer or the local electrical authorities if you are unsure of the type of power

cord to use in your country. The voltage change occurs via a switch in the power supply.



Warning: Under no circumstances should the user attempt to disassemble the power supply. The

power supply has no user-replaceable parts. Inside the power supply are hazardous voltages that can

cause serious personal injury. A defective power supply must be returned to your dealer.

Safety Notices for Users Outside of the U.S.A. and Canada



PELV (Protected Extra-Low Voltage) Integrity: To ensure the extra-low voltage integrity of the

equipment, connect only equipment with mains-protected electrically-compatible circuits to the

external ports.



Remote Earths: To prevent electrical shock, connect all local (individual office) computers and

computer support equipment to the same electrical circuit of the building wiring. If you are unsure,

check the building wiring to avoid remote earth conditions.



Earth Bonding: For safe operation, only connect the equipment to a building supply that is in

accordance with current wiring regulations in your country. In the U.K., those regulations are the

IEE.

Care and Handling

Use the following guidelines to properly handle and

care for your system.

Protect the system from extremely low or high

temperatures. Let the system warm (or cool) to room

temperature before using it.

Keep the system away from magnetic forces.

Keep the system dry. Do not wash the system with a wet cloth or

pour fluid into it.

Protect the system from being bumped or dropped.

Check the system for condensation. If condensation exists, allow

it to evaporate before powering on the system.

Keep the system away from dust, sand, and dirt.

raham

Bill GrahamContents

Chapter 1 Introduction

Chapter 2 Features

Chapter 3 Setup

Chapter 4 Configuring Your System

Chapter 5 Upgrades and Options

Chapter 6 Problem Solving

Appendix A Cabling

Appendix B Memory Configurations

Appendix C Option Boards

Appendix D Devices

Appendix E Network Operating Systems

Glossary

Equipment Log

Bill Graham

Chapter 1

Introduction

Contents

Organization ........................................................................ 1

Notational Conventions ......................................................... 3

Bill Graham

1-1

Introduction

This guide tells you how to configure and upgrade your

server. Its goal is to familiarize you with your server

and the tasks necessary for system configuration and

upgrading.

Organization

Chapter 1

Introduction Introduces you to the purpose and

structure of this guide.

Chapter 2

Features Gives you an overview of the server and

describes major system components.

Chapter 3

Setup Tells you how to select a site, unpack the

system, get familiar with the system, make cable

connections, and power on the system.

Chapter 4

Configuring Your System Tells you how to configure

the system and provides instructions for running the

System Configuration Utility (SCU), the BIOS Setup

Utility and the SCSISelect Utility. This chapter also

tells you how to configure function select switches and

system board jumpers in order to set specific operating

parameters.

Chapter 5

Upgrades and Options Provides you with

instructions for upgrading your system with optional

processor, memory, options cards, and peripheral

devices.

Chapter 6

Problem Solving Contains helpful information for

solving problems that might occur with your system.
