MODEL No.

N-3480

N-4880

FS-5170

Instruction Manual

Colour Television

Important Safeguards

To operate your television at peak performance, please read this Instruction Manual

carefully and retain it for future reference.

• Place this unit on a flat, level surface and in a dry area free from dust and moisture.

•Adequate ventilation must be provided to prevent heat building up inside the unit.

Do not build this set into a bookcase or other enclosure in which it would be poorly

ventilated.

• Do not place liquids including flower vases and vessels filled with chemicals or

water, etc. on top of the unit. Keep the inside of the unit free from foreign objects

such as hairpin. If hazardous objects fall inside of the unit, unplug it immediately and

call a qualified technician for removal.

• Do not remove the back cover of the TV set.Accidental contact with high voltage

components could result in electric shock.

• Never place the set near heat sources (e.g. radiator)

• When you don't use the set for an extended period during vacation or other occa-

sions, always make sure of switching off the MAIN POWER(ON/OFF) SWITCH of

the TV set.

• You should disconnect your set from the mains and the aerial system during thun-

derstorms.

• Unplug the television from the wall outlet before cleaning. Do not use liquid clean-

ers of aerosol cleaners. Use only a lightly dampened soft cloth.

• Do not place this television equipment on an unstable cart, stand, or table. The tele-

vision equipment may fall, causing serious injury to a child or adult, and serious

damage to the equipment. Use only with a cart or stand recommended by the man-

ufacturer, or sold with the television equipment.Wall or shelf mounting should follow

the manufacturer’s instructions, and should use a mounting kit approved by the

manufacturer.

• When replacement parts are required, be sure the service technician has used

replacement parts specified by the manufacturer that have the same characteristics

as the original parts. Unauthorized substitutions may result in fire, electric shock, or

other hazards.

• Upon completion of any service or repairs to the set, ask the service (as specified

by the manufacturer) to determine that the set is in safe operating condition.

• If anything goes wrong, don’t try and fix it yourself, get a qualified service agent to

look at it.

IDENTITY OF FEATURES ON CTV AND REMOTE CONTROL

LOCAL CONTROL

REMOTE CONTROL

MAIN

ON/OFF

BUTTON

VIDEO

INPUT EAR

PHONE

STAND-BY

INDICATOR REMOTE

SENSOR

VOLUME

DOWN/UP

BUTTONS

CHANNEL

DOWN/UP

BUTTONS

TV/VIDEO

/MENU

BUTTON

VIDEO AUDIO

CH VOL

ON/OFF MENU

STAND-BY

TV/VIDEO

AUDIO

INPUT

FRONT

OPERATE

SLEEP

VOL

CH-CALL


SKIP

TV/VIDEO

MOVE

DELETE

MODE

VOL

TELETEXT mode

1 OPERATE

2 NUMBER 0-9

3 INDEX

4 MIX

5 PAGE UP

6 SUBPAGE

7 MENU

8 PAGE DOWN

9 HOLD

10 MUTE

11 REVEAL

12 SIZE

13 CANCEL

14 Green Key

15 Red Key

16 TV/TEXT

17 Yellow Key

18 Cyan Key

TV mode

1 OPERATE

2 NUMBER 0-9

3 PICTURE

4 TV/VIDEO

5 CH (CURSOR)UP

6 VOLUME UP (CURSOR RIGHT)

7 MENU

8 CH(CURSOR) DOWN

9 VOLUME DOWN(CURSOR LEFT)

10 MUTE

11 RECALL

12 SLEEP

13 Not Used

14 MOVE(Edit mode only)

15 SKIP(Edit mode only)

16 TV/TEXT

17 DELETE(Edit mode only)

18 MODE(Picture System Change)

VIDEO AUDIO

VIDEO

OUTPUT AUDIO

OUTPUT

BACK

CONTENTS

* Identity of features on Local and Remote Control 1

* Installation 3

After moving the set 3

Inserting Batteries into the Remote Control Unit 3

Aerial connection 3

Mains connection 4

Switching the set on and off 4

Tuning the TV Channels 5

Edit 6

Manual Channel Setting 7

* Daily use 8

Selecting a Programme Number 8

Volume and Picture control 8

Timer 9

Sleep 9

Recall 9

Child Lock 9

Mode 10

OSD HALF-TONE function 10

Local control key Mode 10

*Connecting External Equipment 11

*Teletext 11

*Specifications 13

*Troubleshooting 14

INSTALLATION

AFTER MOVING THE SET

If the used set is moved or placed in a different direction, the MAIN

ON/OFF button must be switched off for at least 15 minutes in order

to take out a colour strain on the screen.

INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT

Press down the battery compartment grip and slide the cover. Insert

the batteries supplied(two 1.5V, type AA).

Make sure that the polarity matches with the (+) and (-) marks inside

the battery compartment.

Used batteries should be disposed of properly.

AERIAL CONNECTION

For better picture and sound quality, an effective aerial installation is most

important.

If you are located in a relatively strong signal area, you will be able to use

the indoor aerial.

When using an outdoor aerial, it is usually connected to the set by means

of 75 ohm coaxial cable.

MAINS CONNECTION

Plug the mains cable into the power socket with 240V ~, 50Hz.

SWITCHING THE SET ON AND OFF

Switching On

Switch the set on with the MAIN ON/OFF button on the front of the

television. The STAND-BY INDICATOR will turn on.

And then, press : - CH UP or DOWN buttons on the front of the set -

or ON/OFF button or the CH UP/DOWN buttons or one of the NUM-

BER buttons 0..9 on the remote control unit.

The STAND-BY INDICATOR will turn off and a picture will appear on

the screen.

Switching Off

Press ON/OFF button on the remote control unit to return the set to its

stand-by mode.

The STAND-BY INDICATOR will illuminate.

If you don't use the set for extended period of time, turn it off with the

MAIN ON/OFF button on the front of the receiver.

TUNING THE TV CHANNELS

Press the MENU button to call up the MENU.

The MENU consists of 4 sub-menus:

PICTURE, TIMER, LANGUAGE, INSTALL menu.

INSTALL menu disappeared on theAV mode.

LANGUAGE SELECTION [figure 1]

Select the LANGUAGE menu at the MAIN MENU by placing the

cursor on the LANGUAGE with UP/DOWN buttons(CHV/W) and

press the RIGHT button(VOLB).

You can choose the language you require with the UP/DOWN but-

tons.

Press the MENU button to return to the MEIN MENU.

AUTOMATIC CHANNEL MEMORY [figure 2,3]

Select the INSTALL menu at the MEIN MENU.

Place the cursor at Auto setup menu.

Press the RIGHT button(VOLB). The channel will search from the

VHF-L, then VHF-H and UHF.

Please wait until the EDIT menu appears.

If you want to cancel automatic channel memory, press the MENU

button.


Timer

Language

Install English

Français

Deutsch

Select Return

[Figure 1]

Install

Auto setup

Manual tune

Fine tune

Edit

Position

Return Start

[Figure 2]

Auto setup

Please wait !

VHF-L Pr 01

[Figure 3]

EDIT

The EDIT menu shows you the programme position assignment.

You can change this programme position assignment according to

your personal preferences.

SKIPPING CHANNELS [figure 4]

You can select SKIP “YES” or “NO” with the SKIP button(Red Key).

Position the cursor to a Programme to skip “YES” or “NO” with the

UP/DOWN buttons(CHV/W).

A programme marked with SKIP “YES” is skipped when changing

channel using the Programme UP/DOWN.(on normal operation)

DELETE PROGRAMME POSITION DATA

Position the cursor on programme to delete with the UP/DOWN but-

tons(CHV/W).

Press the DELETE button(Yellow Key). While this is being carried

out “Please wait!” appears and the “deleted” programme is moved to

programme No. 99 and the programmes below the deleted pro-

gramme No. will be shifted to the lower programme No one by one.

The programme moved to No. 99 will be set as SKIP “YES”.

CHANGING THE ORDER OF THE CHANNELS

The cursor to a Programme to move and press the MOVE button.

The cursor to programme No. to move and press the MOVE button.

A programme will be moved.

ENTER A STATION NAME

Locate a cursor to below Name with LEFT/RIGHT buttons

(VOLC/B).

Using the UP/DOWN buttons(CHV/W), select the desired letter,

number or blank. Press the right button to select the next position.

Press the MENU button to complete this procedure.

Select Skip

Position Move

Return Delete

[Figure 4]

Edit

Pr Name Picture Sound Skip

01 F--- PAL BG No

02 ---- SECAM DK No

03 ---- PAL I No

04 ---- PAL I No

05 ---- SECAM BG Yes

Press the NUMBER buttons 0..9 or UP/DOWN buttons(CHV/W) to

select the programme number you want.

The screen will change according to the selected programme number.

You can also call up Manual tune at the Install menu.

SEARCHING A CHANNEL (figure 5)

Move the cursor to Manual tune with the UP/DOWN buttons(CH

V/W

)

and then press the LEFT/RIGHT buttons(VOL

C/B

The tuning screen will appear and the cursor will move from left to right

or from right to left. The channel, will be searched from the band area

of the current programme. If you continuously press the LEFT or

RIGHT button the over 5 seconds, the current band area is shifted to

the next band area.(VHF-L VHF-H UHF)

After searching a station, the tuning screen will disappear.

To stop searching, press the MENU button.

FINE TUNING (figure 6)

If you are unable to get a good picture or sound because of a poor

broadcasting signal, it is possible to adjust the fine tuning.

Move the cursor to Fine tune and press the LEFT/RIGHT buttons

(VOLC/B) to activate fine tuning.

It operates only when the LEFT/RIGHT buttons(VOLC/B) are being

pressed. The changes are memorized automatically.

SELECT SOUND SYSTEM

If you hear strange sound or noise sound, then call up the Edit menu

at the Install menu.

Move the a cursor to below SOUND the LEFT/RIGHT buttons

(VOLC/B).

Select the sound system BG, DK, I with the UP/DOWN buttons(CH

V/W

then sound will be changed automatically .

MANUAL CHANNEL SETTING

Install

Auto setup

Manual tune

Fine tune

Edit

[Figure 5]

Manual tune UHF Pr 01

Install

Auto setup

Manual tune

Fine tune

Edit

[Figure 6]

Fine tune 61.25MHz

VOLUME CONTROL

Adjust the volume with the VOLUME DOWN/UP buttons on the front

of the set, or with the LEFT/RIGHT buttons(VOLC/B) on the remote

control unit.

MUTE

Pressing the MUTE( ) button once turns the sound off.

At the same time, the mute sign( ) is displayed on the screen.

The sound returns if the button is pressed once more or the volume is

adjusted with the VOLUME DOWN/UP buttons, or with the

LEFT/RIGHT buttons(VOLC/B).

NORMAL PICTURE SELECTION (figure 7)

When you press the PICTURE button repeatedly you can call up three

picture settings:

for NORMAL 1 (hard picture), NORMAL 2 (soft picture), FAVOURITE

(adjustable picture).

PICTURE CONTROL (figure 8)

Press the MENU button to call up the MENU.

Press the RIGHT button to call up the PICTURE MENU.

You can select each function with the UP/DOWN buttons(CHV/W).

Use the LEFT/RIGHT buttons(VOLC/B) to adjust each function:

Brightness - Contrast - Colour - Sharpness - Tint(NTSC only) -

BlueBack.

*Yon can set BlueBack function Yes/No by using the LEFT/RIGHT

buttons(VOLC/B) or CHV/W.

If you set BLUEBACK function “Yes”, you can see in blue screen

when the TV receives no signal.

InAV mode, the screen is always displayed with the bluescreen when

there is no signal.

The last set value is automatically stored in FAVOURITE mode.

Note that if you set the Brightness values too low, the On-screen-dis-

play becomes dark.

DAILY USE

SELECTING A PROGRAMME NUMBER

The set has a total of 100 programme numbers, 00..99.

The NUMBER buttons 0..9 are used for direct programme selection.

In order to select two-digit programmes, press the second numbered

button within two seconds.

Switch through the programme number one by one with the

UP/DOWN buttons(CHV/W).

VOLUME AND PICTURE CONTROL

Favourite

clock --:--

[Figure 7]


Brightness

Contrast

Colour

Sharpness

Tint

BlueBack

Position

Return Adjust

[Figure 8]

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere NEC Fernseher Handbücher

NEC

NEC DTE-25G5THS Bedienungsanleitung

NEC

NEC PXT-32XD3 Bedienungsanleitung

NEC

NEC DTA-14V4THS Bedienungsanleitung

NEC

NEC DTE-29U1TH Bedienungsanleitung

NEC

NEC E463 Bedienungsanleitung

NEC

NEC FS-59V81S Bedienungsanleitung

NEC

NEC PF32W01 Bedienungsanleitung

NEC

NEC E553 Stücklistenhandbuch

NEC

NEC DSC-3261HA Bedienungsanleitung

NEC

NEC PV46-AVT Bedienungsanleitung

NEC

NEC PX-42VR5W Bedienungsanleitung

NEC

NEC NLT-19HDB3 Bedienungsanleitung

NEC

NEC DSC-3261HA Bedienungsanleitung

NEC

NEC N-3481 Bedienungsanleitung

NEC

NEC E585 Bedienungsanleitung

NEC

NEC FP-68T30 Bedienungsanleitung

NEC

NEC AccuSync PV40-AVT Bedienungsanleitung

NEC

NEC PV32-AVT Bedienungsanleitung

NEC

NEC NLT-40HDEM2 Bedienungsanleitung

NEC

NEC PF51T31 Bedienungsanleitung

NEC

NEC FS-8002 Bedienungsanleitung

NEC

NEC FS-59T90 Bedienungsanleitung

NEC

NEC NLT-15C Bedienungsanleitung

NEC

NEC NLT-32HDB3 Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
