Self Installation Guide
IN-360
Mail'n Ship Station
CONTENTS
IN-360 Mail'n Ship Station
LAN Cable or Modem and Phone Cord Welcome Kit Integrated Scale
Feed Deck with Moistener Postage Meter Ink Cartridge and
Postage Meter Tapes
Power Cord
Optional
1
or
Catch Tray
Optional External Scale
STEP 1 INSTALL THE FEED DECK
Feed Deck
Place the Feed Deck to the left of the Mail'n Ship Station.
2
A B
Remove the two pieces of shipping tape
on each side and remove the foam block.
Lift up and lockdown the slots of the
Mail'n Ship Station base over the tabs of
the feed deck.
STEP 2 INSTALL THE POSTAGE METER
Open the Mail'n Ship Station
Cover
Open the top cover by lifting at the open
slot
Remove the PSD (Postage
Meter) from the packaging Insert the Postage Meter into
the Mail'n Ship Station
1. Open the Postage Meter Cover in the left
side
2. Slide the Postage Meter securely into
the slot, positioning the postage meter
so the contacts are facing the rear of the
base and the locator runner (ridge) is
towards the bottom.
3. Close the Postage Meter Cover
3
A B C
INSTALL THE INK CARTRIDGE AND THE SCALE
Remove the Ink Cartridge from
the packaging.
Remove the caps and film strips from
the bottom of the Ink Cartridge
Insert the Ink Cartridge into
the Mail'n Ship Station.
1. Slide the Ink Cartridge into the slot
located on the right, positioning the
cartridge with the contacts facing the
rear of the system.
2. With your thumb "click" the ink cartridge
towards the back of the system to the
locked position
3. Close the top cover
Place the scale on top of the
machine and slide forward to
lock.
STEP 3
4
A B C
Attach the
cable and
close the
panel door.
STEP 4 CONFIGURATION AND ACTIVATION
Set-up the connection to the server, contact the server and activate the Mail'n Ship Station.
In order to load funds, download rates and support your Mail'n Ship Station, you must set up a connection between the Mail'n Ship Station and the
server .This can be done in two different ways:
1. LAN (Standard)
The Mail'n Ship Station communicates with the server over a high-speed internet connection or LAN (Local Area Network).
»This standard method allows for fast, seamless postage rate updates and funds download; and software updates to be performed
remotely and automatically.
»Utilizing LAN connectivity eliminates connection errors when connecting to the server.
»If you choose this method, proceed to Step 4A (pg 6) – Connecting The LAN Cable.
2. Modem (Optional)
If you do not have a high speed internet connection available, the Mail'n Ship Station can communicate with the server using a dial-up
modem connected to an analog telephone line or fax line.
»This method can only be used for postage rate updates and funds download.
»If you choose this method, skip to Step 4B (pg 8) – Connecting The Modem.
5
Connect to Internet / LAN jack
or router.
1. Select a location for the Mail'n
Ship Station near an Internet /
LAN jack or router.
2. Plug one end of the LAN cable
into the Internet jack.
Connect the other end of the
LAN cable into the Internet
jack or router on the left side
of the Mail'n Ship Station.
Connect the power.
Using the Power Cord, plug the female
connector into the right bottom back
corner of the Mail'n Ship Station. Take
the male end and plug it into the
power outlet.
Note : Switch your Mail'n Ship Station
on.
CONNECTING THE LAN CABLE
STEP 4A
6
A B C
1. LAN
Installation process
OK
MENU
STEP 4A (CONTINUED)CONNECTING THE LAN CABLE
OK
Installation process
Welcome, please press
"Ok" to begin the
installation process
OK
MENU
Suite
Installation process
Please plug in your USB modem
or cable and press next
OK
MENU
Press the “OK” button..
If the system is already plugged in, and
it is in sleep mode, press the
Sleep/Wake button.
Press the “OK” button.
Select “Next” by pressing the
“OK” button.
7
F
D E
STEP 4B
Select a location for the Mail'n
Ship Station near an analog
telephone jack.
The following are usually analog phone
lines:
»Fax lines
»Lines used by modems or credit
card readers
»Most residential phone lines
Connect the modem.
1. Plug one end of the telephone
cable into the analog phone outlet.
2. Take the other end of the phone
cord and connect it to the USB
modem.
3. Plug the USB modem into the USB
port located on the left side of the
Mail'n Ship Station.
CONNECTING THE MODEM (OPTIONAL ACCESSORY)
Connect the power.
Using the Power Cord, plug the female
connector into the right bottom back
corner of the Mail'n Ship Station. Take
the male end and plug it into the
power outlet.
8
A B C
Installation process
OK
MENU
OKBack
Installation process
Press next to select your
Connection Type
OK
MENU
Next
Installation process
1. Modem
OK
MENU
Press the “OK” button.
If the system is already plugged in, and
it is in sleep mode, press the
Sleep/Wake button.
Select “Next” by pressing the
“OK” button. Press "OK".
CONNECTING THE MODEM (OPTIONAL ACCESSORY)
STEP 4B (CONTINUED)
9
D E F
Welcome, please press
"Ok" to begin the
installation process
