Net Optics 10/100BaseT Slim Tap Bedienungsanleitung
Installation Guide for
10/100BaseT Tap
Doc. PUBTPCUU Rev.2, 06/06
10/100BaseT Tap
Contents
Introduction.1
Key.Features.2
Unpacking.and.Inspection.3
About.This.Guide.3
Product.Diagrams.4
LED.Indicators.4
Cabling.Guidelines.5
Connecting.to.the.Network.5
Connecting.to.the.Monitoring.Device. 6
Specications.7
Limitations.on.Warranty.and.Liability. 8
10/100BaseT Tap
PLEASE READ THESE LEGAL NOTICES CAREFULLY.
By.using.a.Net.Optics.Tap.you.agree.to.the.terms.and.conditions.of.usage.set.forth.by.Net.Optics,.Inc
No.licenses,.express. or. implied,. are. granted.with.respect. to. any. of. the.technology.described. in. this.
manual.Net.Optics.retains.all.intellectual.property.rights.associated.with.the.technology.described.in.
this.manual.This.manual.is.intended.to.assist.with.installing.Net.Optics.products.into.your.network
Trademarks and Copyrights
©.2009.by.Net.Optics,.Inc.Zero.DelayTM.and.Net.Optics®.is.a.registered.trademark.of.Net.Optics,.Inc.
Additional.company.and.product.names.may.be.trademarks.or.registered.trademarks.of.the.individual.
companies.and.are.respectfully.acknowledged
Additional Information
Net.Optics,.Inc.reserves.the.right.to.make.changes.in.specications.and.other.information.contained.
in.this.document.without.prior.notice.Every.effort.has.been.made.to.ensure.that.the.information.in.this.
document.is.accurate
10/100BaseT Tap
1
Introduction
Net.Optics.10/100BaseT.Taps.supply.mission-critical.networks.with.superior.
network.visibility.and.security.access.The.breakthrough.design.of.the.Net.
Optics.10/100BaseT.Tap.ensures.zero.impact.on.network.trafc.while.main-
taining.uninterrupted.access.for.monitoring.and.security.devices.These.are.the.
world’s.rst.and.only.10/100BaseT.Taps.offering.“zero.delay”.technology
Highly.sensitive.network.locations.can.improve.monitoring.performance.via.
the.innovative.features.of.Net.Optics.Taps.If.power.is.lost.to.other.10/100.
Taps,.the.connected.devices.may.introduce.delays.as.they.detect.the.power.
loss.and.try.to.re-establish.their.link.
Net.Optics’.pioneering.design.ensures.that.any.loss.of.power.to.the.Tap.is.
transparent.to.the.network,.and.does.not.affect.the.ow.of.trafc.through.the.
Tap.–.eliminating.packet.delay.and.loss.as.potential.security.issues.
Simply Plug It In
Full-duplex.monitoring.is.a.snap.with.a.custom.monitoring.cable.that.sends.each.
side.of.the.signal.to.a.separate.NIC.on.the.monitoring.device.All.network.and.
monitoring.cables.are.included.with.the.10/100BaseT.Tap.for.plug-and-play.
deployment
Security and Visibility
Without.an.IP.address,.monitoring.devices.are.isolated.from.the.network,.
dramatically.reducing.their.exposure.to.attacks.However,.the.monitoring.
device.connected.to.the.Tap.still.sees.all.full-duplex.trafc.as.if.it.were.in-line,.
including.Layer.1.and.Layer.2.errors
Reliability
For.extra.uptime.protection,.Net.Optics.10/100BaseT.Taps.offer.redundant.
power.connections.Should.the.primary.power.source.fail,.the.Tap.
automatically.switches.to.the.backup.power.source.Power.LEDs.on.the.
front.of.the.Tap.indicate.the.current.power.source.–.even.if.power.is.lost.and.
reapplied,.there.is.always.zero.delay.to.network.trafc
10/100BaseT Tap
2
Key Features
Passive, Secure Technology
•. Provides.passive.access.at.10.or.100.Mbps.without.data.stream.interference.
or.introducing.a.point.of.failure
•. Unique.Zero.Delay.technology.ensures.no.packet.delay.or.loss.if.power.is.
lost.to.the.Tap
•. Compatible.with.Power.over.Ethernet.(PoE).applications
•. Passes.all.full-duplex.trafc.(including.errors).from.all.layers.for.compre-
hensive.troubleshooting
•. No.IP.address.is.needed.for.the.Tap.or.monitoring.device,.enhancing.moni-
toring.security
•. Redundant.power.ensures.monitoring.uptime
•. Fully.IEEE.8023.compliant
•. Fully.RoHS.compliant
Ease of Use
•. Front-mounted.connectors.support.easy.installation.and.operation
•. LED.indicators.show.redundant.power.status
•. Silk-screened.application.diagram.illustrates.all.connections.for.easy.
deployment
•. Optional.19-inch.rack.frames.hold.up.to.3.or.12.Taps
•. Available.with.-48VDC.power
•. Compatible.with.all.major.manufacturers’.monitoring.devices,.including.
protocol.analyzers,.probes,.and.intrusion.detection/prevention.systems
Support
•. Net.Optics.offers.free.technical.support.throughout.the.lifetime.of.your.
purchase.Our.technical.support.team.is.available.from.8.am.to.5.pm.Pacic.
Time,.Monday.through.Friday.at.+1.(408).737-7777.and.via.email.at.ts-
support@netopticscom.FAQs.are.also.available.on.Net.Optics.website.at.
wwwnetopticscom
10/100BaseT Tap
3
About This Guide
This.guide.explains.how.to.install.the.10/100BaseT.Tap.Please.read.the.Guide.
before.attempting.to.install.the.10/100BaseT.Tap
This.guide.covers.the.following.models:.Model.TP-CU
Unpacking and Inspection
Carefully.unpack.the.10/100BaseT.Tap.and.check.for.damaged.or.missing.
parts.The.Tap.ships.with.the.following:
•. 10/100BaseT.Tap.
•. 2.power.supplies
•. 2.power.cords
•. 2.network.cables
•. 2.monitor.cables
•. Installation.Guide
You.may.have.also.ordered..a.panel.for.rack.mounting.and.an.extended.war-
ranty.Carefully.check.the.packing.slip.against.parts.received.If.any.part.is.
missing.or.damaged,.contact.Net.Optics'.Customer.Service.immediately
10/100BaseT Tap
4
Product Diagrams
Figure 1: Front Panel
Figure 2: Rear Panel AC Power Model
Figure 3: Rear Panel DC Power Model
LED Indicators
•. PWR 1/ PWR 2:.Main.and.Redundant.Power.If.the.Tap.is.deployed.with.
both.power.supplies,.both.LEDs.illuminate.white.when.the.Tap.is.connected.
to.power.An.off.power.LED.indicates.that.the.corresponding.power.supply.
is.not.functioning.or.not.connected
www.netoptics.com
Network Monitor
1
2
10/100 Ethernet Tap10/100 Ethernet Tap
A AB B
Power LEDsMonitor A & BNetwork A & B
1 2
12V DC
1.5 Amp max. +
OUTPUT PIN ASSIGNMENT
- +
- +
- +
- +
10/100BaseT Tap
5
Cabling Guidelines
•. If.connecting.to.Switches.or.Hubs,.use.CAT5.RJ45.cross-over.cabling
•. If.connecting.to.Routers.or.NICs,.use.CAT5.RJ45.straight-through..
cabling
Connecting to the Network
.
1..Connect.Network.Port.A.to.the.appropriate.switch,.server.or.router.using.a.
CAT5e.cable.
2..Connect.Network.Port.B.to.the.appropriate.switch,.server.or.router.using.a.
CAT5e.cable.
Figure 5: Connecting to the Network
3. Verify.that.the.Tap.Network.Ports.are.cabled.in-line.between.two.devices
www.netoptics.com
Network Monitor
1
2
10/100 Ethernet Tap10/100 Ethernet Tap
A AB B
To network switch or router
To network switch or router
10/100BaseT Tap
6
Connecting to the Monitoring Device
1. Supply.power.to.the.Tap.using.the.two.redundant.power.supplies.included.
with.the.unit.Verify.that.the.Power.LED.illuminates
2. Connect.Monitor.Port.A.to.the.appropriate.port.on.the.monitoring.device.
using.a.CAT5e.straight-through.cable
3. Connect.Monitor.Port.B.to.the.appropriate.port.on.the.monitoring.device.
using.a.CAT5e.straight-through.cable
Note: _______________________________________________________________
The second power supply is available to support the ow of trafc to the
monitoring device in the event that the rst power supply becomes
unavailable.
______________________________________________________________________
Figure 6: Connecting to the Monitoring Device
www.netoptics.com
Network Monitor
1
2
10/100 Ethernet Tap10/100 Ethernet Tap
A AB B
To monitor NIC
To monitor NIC
