NetComm NP207 Bedienungsanleitung

200Mbps Powerline Adapters with AC Pass-through - NP207

NetCommWireless

200Mbps Powerline Adapters

with AC Pass-through

QUICK START GUIDE

NetComm

Wireless

NP207

NetComm

Wireless

This quick start guide is designed to get you up and running quickly

with your new device. More advanced set up instructions can be found

in the user manual which can be downloaded from

www.netcommwireless.com

SETTING UP YOUR POWERLINE

ADAPTERS

1 2

Router

1. Using one of the supplied Ethernet cables connect one end into the

LAN Ethernet port of your modem/router.

2. Connect the other end of the same cable into one of the

Powerline adapters.

3. Connect the Powerline adapter to a power point near your

modem/router.

NOTE: For best performance plug your Powerline adapters directly into the wall.

Only connect to a powerboard as a last resort as this will reduce performance.

200Mbps Powerline Adapters with AC Pass-through - NP207

4. Connect one end of the other supplied Ethernet cable into the

Ethernet port of any device you want to connect to the Internet (PC,

set-top box, gaming console, PVR, blu-ray player etc).

5. Connect the other end of the cable into the second Powerline adapter.

6. Connect the Powerline adapter to a power point near your device.

NOTE: For best performance plug your Powerline adapters directly into the wall.

Only connect to a powerboard as a last resort as this will reduce performance.

TV PC

Powerboard

At this point, you can plug another electrical appliance into the Powerline

adapter’s AC pass-through socket if you wish to do so.

Both adapters will take a short time to nd each other. Once they have, all

three lights on both adapters should be on.

NOTE: For best performance connect other electrical devices to the AC Pass-

through socket of the Powerline adapter. If possible, also avoid plugging

other electrical devices into the socket next to the Powerline adapter to

ensure your network performs to its full potential.

NetComm

Wireless

LEDS

What can the LEDs tell me?

The Powerline LED changes colour depending on the speed of your

data transfer.

- Fastest

- Faster

- Fast

LED Off- The adapter is not paired or wall socket not

turned on.

NOTE: The devices work on the same electrical circuit with the same circuit

breaker. When they are on different circuit breakers they wont work and

the LED will be off.

- Lights up when a device is connected to the adapter via an

Ethernet cable

- Lights up when the adapter is connected to a power point

200Mbps Powerline Adapters with AC Pass-through - NP207

TROUBLE SHOOTING

My Powerline adapters will not connect to each other

1. Connect all adapters to powerpoints near each other in the same

room (or temporarily to a powerboard)

2. Press and hold down the black button on one of the adapters for

15 seconds, or until the LED’s ash. This will reset the password on

that device.

3. Press and hold the black button on the other device for 2 seconds.

This will put the adapter in pairing mode. When the adapter is in

pairing mode, the LED will ash.

4. Finally hold the black button on the rst device for 2 seconds to

complete the pairing process. When pairing is complete, the LED

on both adapters will be lit. Both adapters now share the same

password and will be able to communicate with each other.

NetComm

Wireless

To connect additional adapters

1. Connect adapter 1 and adapter 2 to powerpoints near each other in

the same room (or temporarily to a powerboard)

Powerboard

1 2

Additional

adapter

(unpaired)

Already Paired

adapter

200Mbps Powerline Adapters with AC Pass-through - NP207

2. Press and hold the black button on adapter 1 for 15 seconds, or

until the LEDs ash to reset the password

Additional

adapter

(unpaired)

(press for 15 seconds)

3. Press and hold the black button on adapter 2 for 2 seconds to put

the adapter into pairing mode. The LED

will ash

Already

paired

adapter

(press for 2 seconds)

NetComm

Wireless

4. Hold the black button on adapter 1 for 2 seconds to complete

the pairing process. When pairing is complete, the LED on both

Adapters will be lit and all adapters will share the same password.

Repeat for any further additions

Additional

adapter

(unpaired)

(press for 2 seconds)

Congratulations now you have paired an extra Powerline adapter

YML-NP207-V1
