NetComm V90 VoIP Phone
Quick Start Guide
Draft Release 0.1
Overview NetComm V90 SIP VoIP Phone User Guide
2 NetComm Ltd.
Table of Contents
Overview............................................................................................................ 3
V90 VoIP Phone Specification ..................................................................................4
Shipping Contents................................................................................................5
Installation and Basic Configuration........................................................................... 7
Hardware Installation ...........................................................................................7
Accessing the Web Configuration Menu ......................................................................7
Obtaining the VoIP Phone IP Address ......................................................................7
Entering V90 IP Address into a Browser ...................................................................8
Configuring the VoIP Phone .................................................................................9
More Configurations .............................................................................................11
Setting the LCD Default display.............................................................................. 11
Setting the Authentication ID and Password............................................................... 11
Selecting Network Tones and Ring Tone ................................................................... 11
Network Configuration ........................................................................................ 12
LAN Port Configuration........................................................................................ 12
PC Port Configuration ......................................................................................... 12
Identifying the Time Server .................................................................................. 13
Changing the Time Zone ...................................................................................... 13
Performing an Online Upgrade............................................................................... 13
Reset Configuration Settings ................................................................................. 14
System Reboot.................................................................................................. 14
VoIP Phone Operation...........................................................................................15
Making and Answering Calls .................................................................................. 15
Making a Basic Call ......................................................................................... 15
Making a Hands-Free Call.................................................................................. 15
Dialing from the Phonebook............................................................................... 15
Dialing from the Speed Dial............................................................................... 16
Dialing from the Call History.............................................................................. 16
Answering an Incoming Call ............................................................................... 16
Using other Call Features*.................................................................................... 17
Putting a Call on Hold...................................................................................... 17
Transferring a Call.......................................................................................... 17
Using Voicemail ............................................................................................. 17
Call Waiting.................................................................................................. 17
Using the Flash Button ..................................................................................... 18
Other Phone Operations ...................................................................................... 18
Checking Call History....................................................................................... 18
Accessing Phonebook....................................................................................... 18
Adding contacts to Speed Dial memory ................................................................. 19
Adjusting the Ring Volume ................................................................................ 19
Resetting Phone Configuration ........................................................................... 19
LCD Indicators .................................................................................................. 20
Date and Time............................................................................................... 20
Unanswered Calls ........................................................................................... 20
Menu Display................................................................................................. 20
Call Display .................................................................................................. 20
Keypad Encoding Scheme.................................................................................. 20
NetComm V90 SIP VoIP Phone User Guide Overview
1
Overview
V90 VoIP Phone is fully compatible open SIP industry standard. It is designed as a
third-party enterprise grade VoIP device, which makes it easy to integrate into
an existing SIP network.
Figure 1 V90 VoIP Phone
The feature-rich VoIP Phone is designed to work seamlessly with
most of the existing SIP VoIP systems.
NetComm Ltd. 3
Overview NetComm V90 SIP VoIP Phone User Guide
4 NetComm Ltd.
V90 VoIP Phone Specification
Advanced System Features
•Power of Ethernet (802.3af) Support
•Setup Wizard for different types of network environment and IP phone accounts
•Auto Configuration Support via TFTP and HTTP (Plug-n-Play operation - requires no
user setup when network access is available.)
•Smart Firmware Management Support via TFTP and HTTP (No need for manual
firmware upgrade)
•Centralized management software for easy management for mass V90 deployment
•Primary and Backup SIP server support for primary proxy server failover and network
redundancy
•Programmable QoS Marking (both 802.1q VLAN and ToS/DiffServ)
•Compatibility in multi- vendor open architecture VoIP networks
•Retrieving time via NTP Servers and SIP message
•NAT/ Firewall Traversal Support with Border Session Controller or Stun Server
•Screen Saver for displaying logo/banner
Key Features
•SIP 2.0 standardization deployed throughout
•Advanced audio processing – jitter buffer with packet delay and packet loss
concealment
•Voice packetization & flexible voice compression
•Programmable voice packet payload size
•Dynamic & automatic negotiation of codec selection
•In-band and Out-band DTMF transport
•G.168 Echo Cancellation
•Two Ethernet ports supporting router and bridge mode
•Call Redial, Flash, Mute
•Caller ID / Caller ID Call Waiting
•Visual Message Waiting Indicator (VMWI)
•Call hold/Forward/Transfer (attended/unattended call transfer)
•Phone Book Memory Dialing
•Speed Memory Dialing
•Hands Free Dialing
•Hotline Dialing
•Call history for incoming, outgoing and missed calls
•Programmable Generic Function Key Definitions (automatic adding
prefixes/customized LCD menu)
•Dialing Plan (Digit Map)
•Soft Login/Logout key for SIP registration
•128x64 dot matrix LCD with/without black light
•Full Duplex Speakerphone
NetComm V90 SIP VoIP Phone User Guide Overview
NetComm Ltd. 5
•Programmable Phone Commands (via dialing keypad) for additional functions
(Optional)
•Auto Provisioning Support
•Firmware upgrading, loading configuration, phone status reports and etc via
Centralized Management tool
•Local Music on Hold
Standards Supported
•SIP V2.0 Standard (RFC 3261)
•SDP (RFC 2327)
•Digest authentication and MD5 encryption (SIP)
•ITU-T G.711 Alaw/Ulaw, G.729A, G.729AB, G.723.1 and GSM Voice Codec
•RTP (Real Time Data Transmission) RFC1889
•RTCP (Real Time Transport Control Protocol) RFC 3550
•Proprietary Firewall-Pass-Through Technology
•Simple Traversal of UDP over NAT (STUN)
•Web-base Management
•PPP over Ethernet (PPPoE)
•PPP Authentication Protocol (PAP)
•Internet Control Message Protocol (ICMP)
•TFTP Client
•Hyper Text Transfer Protocol (HTTP)
•Dynamic Host Configuration Protocol (DHCP)
•Domain Name System (DNS)
•Out-band DTMF Relay: RFC 2833 and SIP Info
•SIP proxy address in DHCP (RFC 3361)
•RFC 3265 and RFC 3842 for Message Waiting Indication
Hardware Interface
•Ethernet PC & LAN Port (2 x RJ-45, 10/100BaseT)
•DC Jack
Shipping Contents
Table 1 below shows what comes packed with the V90 VoIP Phone.
Table 1 Items Shipped with the V90
Item Description
Warranty Registration Phone warranty card
Ethernet Cable Straight-through cable
Power Supply V90 can be powered by either LAN port (PoE
enabled network or via a 12VDC/500mA output
Overview NetComm V90 SIP VoIP Phone User Guide
6 NetComm Ltd.
external power supply
NetComm Ltd. 7
2
Installation and Basic
Configuration
Hardware Installation
1. Connect the handset and telephone cord to the base of the VoIP Phone.
2. Use the enclosed Ethernet cable to connect the LAN port to a hub or switch,
or to a DSL Router or Cable Modem.
3. Connect the power supply using the enclosed AC power supply (Note:
external power supply is not required if V90 connects to a PoE enabled
network via it LAN port).
4. For the first time installation, the phone will scan the network for available
services which are DHCP, PPPoE, and Fixed IP. Select the preferred service
and enter the required information if needed. No user input is required for
DHCP service. User ID and Password are required for PPPoE. IP address,
Netmask, and Gateway IP Address are required for Fixed IP mode.
Accessing the Web Configuration Menu
The steps for accessing the V90 Web Configuration Menu are:
¾Obtain the V90 IP address.
¾Enter the IP address into a browser.
¾Log in to the V90 web configuration page.
Obtaining the VoIP Phone IP Address
To retrieve the IP address from the VoIP Phone:
¾When the phone is in the on-hook state, press Menu.
Installation and Configuration NetComm V90 SIP VoIP Phone User Guide
8 NetComm Ltd.
¾Press 3(System Tools).
¾Press 1(Phone Status).
¾Press 1(LAN Port).
The phone displays:
IP: xxx.xxx.xxx.xxx
where xxx is any valid IP address between 0 and 255.
Entering V90 IP Address into a Browser
•Logging into the VoIP Phone
Connect a laptop or desktop computer to the same subnet as the SIP
Phone when accessing V90 Web Configuration Page. The SIP Phone Web
Configuration Menu can be accessed from any Web browser using the
following URL:
http://<phone-IP-address>
where <phone-IP-address> is the IP address of the phone.
For administrator mode, the default User Name is “admin”; the default
Password is “admin”.
Enter the User Name and Password into the Log In screen.
Click OK to log in to the VoIP Phone.
NetComm V90 SIP VoIP Phone User Guide Installation and Configuration
Configuring the VoIP Phone
Figure 2 Call Settings Screen - SIP
•Following is minimal configurations required to get V90 registered in your
service providers’ SIP proxy server. However, depending on your network
setup, more advanced information may be need. Please consult your
network administrator if necessary.
SIP Phone number
Display name (Optional, This name will be used for Call ID Name
Delivery, so that the other part can see your name before answering.)
SIP Proxy (IP Address or Fully Qualified Domain Name)
SIP Registrar (IP Address or Fully Qualified Domain Name)
Home Domain (IP Address or Fully Qualified Domain Name)
NetComm Ltd. 9
Installation and Configuration NetComm V90 SIP VoIP Phone User Guide
10 NetComm Ltd.
Enable Authentication (Enable this option if authentication is required
by your VoIP service provider)
oAuthentication ID
oPassword
•Selecting the Advanced Settings for additional VoIP settings for more
advance operation
•Selecting the Media Settings for packet length, jitter, Codec, and network
tones settings.
•Selecting Save Changes to store the current settings.
